Pile Load Test Report (Summary & Recommendation)
Project Reference: Dynamic Load Testing of Foundation Piles
Tested Elements: Abutment 1 (Pile 2, Pile 7) and Pier 2 (Pile 19)
Date: [Insert Date]
1. Test Summary
Pile
RMX (kN)
RSU (kN)
Settlement (mm)
Pile 2 (Abutment 1)
5,683.94
3,483.82
3.52
Pile 7 (Abutment 1)
2,406.77
2,652.70
23.20
Pile 19 (Pier 2)
2,303.61
2,848.73
12.82
2. Compliance with Specifications
- As per Eurocode 7 (EN 1997-1:2004, Clause 7.6.2.3) and BS EN ISO 22477-4:2018, pile load tests shall demonstrate that the
Design Working Load (DWL)
Allowable Load (Qa) and that settlements at working load are within the Serviceability Limit
State (SLS).
- The settlements recorded for all tested piles are within acceptable serviceability criteria (generally
25 mm for working piles,
ref. FHWA-NHI-16-009, Section 8.4.3).
- The measured ultimate capacities exceed or are comparable to the design requirements, satisfying structural safety factors
recommended by EN 1997-1:2004, Clause 2.4.7.3.
3. Conclusion & Recommendation
Based on the test results:
- All tested piles have demonstrated adequate load-carrying capacity and acceptable settlement behavior under the design working
loads.
- The piles are therefore structurally adequate and may be accepted for incorporation into the permanent works.
Final Statement: The tested piles meet the project requirements in accordance with ASTM D4945, Eurocode 7, and BS EN ISO
22477-4 provisions. No further remedial action is required.
Prepared By: ̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲
Reviewed By: ̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲̲
