ĐẶC TÍNH KỸ THUẬT CƠ BẢN TÀU
KHẢO SÁT ĐỊA VẬT LÝ VÀ VẬN CHUYỂN NHÂN SỰ
General information
Vessel Type
: Survey/ Supply vessel
Classification /
Notation
: DUAL CLASS, VR ✠ABS or BV/DNV/LR ✠A1E,
✠SURVEY/SUPPLY VESSEL, SPS, ✠AMS, UWILD
Working area
: Worldwide
Dimensions
Length overall
: about 60m
Beam
: about 14m
Depth
: about 5 m
Draught
: about 3.6m
Deck space
: about 260 m2
Performance
Maximum Speed
: 12knts
Economic Speed
: 8knts
Survey Speed
: 3-5knts
Duration
: 40 days
Accommodation
Accommodation
: Total about 60 berths
Hospital
: 1 x 2 berths
Gym/ Video
: 1 x Gym/ Video
Working Spaces
: 1 x Equipment Rack (about 16m)
1 x Instrument Room, Processing and Reporting Office, Meeting
Room (about 60m2)
1 x Laboratory (about 20m2)
1 x Workshop (about 35m2);
1 x Geophysical Store (about 10m2)
Others
: 2 x Mess rooms; 1 x Changing room; 1 x Laundry and Drying room;
1 x Dry Store room; 1 x Frozen room; 1 x Cold room; 1 x Galley
Machinery
Propulsion
: 02 main engines with total capacity around 2.500kW
Propellers
: 2 x CPP (independent & synchronize)
1 x Bow Thruster
Electrical Power
Generator
: 2 x 550 eKW Diesel Generator
Emergency Generator
: 1 x Emergency Diesel Generator
Harbor Generator
: 1 x 300 eKW Diesel Generator
Capacities
Fresh Water System
Water maker
: FW tanks (Approx.600m3); 1 x Discharging pump
: 02 (4-5m3/ea/day)
Fuel Oil System
: FO tanks (Approx. 600m3); 1 x Discharging pump
Deck Machinery
Stern A-Frame
: 01 x Stern A-Frame (Portable), SWL @ 15 tones, 6mW x 8mH,
outreach: 6m
Aux Crane
: 1 x 2T Provision Crane, SWL @12m Radius. Electro-hydraulic
cylinder luffing/knuckle jib crane
Launch boom
: 2 x 2.5T, SWL @ 12m for Sparker & Gun deployment
Capstan
: 2 sets (5 tons)
Search light
: 4 sets
Navigation and Communication
Radar
: 2 x Marine Radar (01 S- band/ 01 X-band), ARPA Plot functions,
and combined electronic chart)
GPS
: 2 x DGPS/GPS
AIS
: Area 3/ MF/HF AIS System
Echo sounder
: 1 x Echo Sounder with recording capacity
Speed log
: 1 x Speed log
Gyro Compass
Wind speed
(Anemometer)
: 2 x Gyro Compass
: 1 set
Radio
: 2 x GMDSS Radio
VHF
: 6 x VHF
1 x VHF portable
Navtex receiver
: 1 x Navtext
Autopilot
: 2 x Autopilot
Simplified voyage
: Yes
data recorder (SVDR)
Other equipment
: 1 x SSB with DSC; 1 x PA system; 1 x Electronic Chart; 1 x SSAS
system
Inmarsat
: 1 x VSAT or Starling system with Local Network
Safety Equipment
Rescue System
: 1 x Fast rescue boat (rigid designed) 10 persons with davit system
according to SOLAS requirements. Inboard Diesel Engine with jet
propulsion (Engine 150 BHP);
H2S System
: 1 set (4-6 points)
Other Requirements
Moon pool (optional)
: about 1200mm x 1800mm for deployment of survey gears (USBL,
MBES)
Deck strength
: 7.5 T/m2
Air Cascade System
: Yes
Sewage treatment
plant
: 1 set
Oil water separator
: 1 set
Oil dispersant system
: 1 set
Bridge
: 2 control table (forward / aft), GMDSS table, Chart table, Toilet
room, Working table with chair
