Submittal Data
SP 660
MPT SP are submersible borehole pumps, designed for pumping groundwater.
MPT SP are all stainless-steel pumps, and they are available in 3 material
grades. The pumps are suitable for boreholes in sizes ranging from 4" over 6"
and 8" to 10". The motor sizes for the pumpsare available in 0.37-250 kW.
Conditions of Service
Efficiency:
Liquid:
Temperature:
NPSH required:
Specific Gravity:
%
WATER
20 °C
m
1.000
Motor Data
Pump Data
Liquid temperature range:
-15 .. 45 °C
Rated voltage:
Mains frequency:
Enclosure class:
Product number:
On request
Thermal protection:
380-400-415 V
50 Hz
IP68
external
Submittal Data
MPT SP-660 MODEL
Performance curves are based on the kinematic viscosity = 1mm² /s and density ρ= 1000 kg /m³.
Submersible borehole pump, suitable for pumping clean water. Can be installed vertically. All steel
components are made in stainless steel, ( 304 , 316 ), on request that ensures high corrosive resistance.
Liquid:
Pumped liquid:
Liquid temperature range:
Max liquid t at
Selected liquid temperature:
Density:
Water
-15 .. 45 °C
0.5 m/sec: 45 °C
20 °C
998.2 kg/m³
Materials:
Pump:
Stainless steel
AISI (304 , 316)
Impeller:
Stainless steel
AISI (304 , 316)
Motor:
Stainless steel
AISI (304 , 316 , 904)
