TUTORIAL 1: EEU 104 (2023/2024)
Refer to Figure 1.
a. Find currents Is, I2 and I6.
b. Find voltage V1 and V5
1.
Figure 1
2. For network in Figure 2:
i.
ii.
iii.
Determine RT
Find Is, I1 and I2
Find voltage V4
Figure 2
3.
Considering the network in Figure 3.
Figure 3
i.
ii.
Redraw the network after combining the series/parallel elements.
Calculate the indicated currents and voltages, I5, V7, I6 and Is
4. Write the mesh equations for the network in Fig 4 and solve for the loop currents by using
clockwise mesh currents.
Figure 4
5. By using nodal analysis, calculate the currents I1, I2, I3 , I4 and V0 in the circuit in Fig. 5.
Figure 5
6.
Obtain v1 and v2 in the circuit using nodal analysis.
Figure 6
