Gland M20
ATEX+IECEx; Z0/1, Z21, Ex de, IIC/IIIC
Alu, coated
205.50[8.09]
73.00[2.87]
335.00[13.19]
208.50[8.21]
168.50[6.63]
FIT 1004
125.00[4.92]
103.00[4.06]
98.40[3.87]
17.90[0.70]
550.00[21.65]
40.90[1.61]
15.88[0.63]
58.00[2.28]
Cl.150 RF, Alloy C22, flange ASME B16.5
DN 40 1-1/2"
Alloy C22, not polished, extended temperature
First Angle Projection
XX.X [x.xx] = mm [inch]
Disclaimer:
Every reasonable effort has been made to ensure the accuracy
of the information contained in this document. Endress+Hauser does not give
any guarantee, express or implied, with respect to the accuracy,
the completeness or the technical or commercial usefulness of this document.
Endress+Hauser may modify or replace this document at any time.
10.03.2025 Endress+Hauser
Order Code :
8F3B40-BBDBAAAGAATHAACKA2+AC
Product Description :
Promass F 300, 8F3B40, DN40 1 1/2"
