Typical dimensions
of footing
BIM For Civil Engineering
1
The building
2
Length (L)
Footing plan
Breadth (B)
Breadth (B)
For Week 6
Typical dimension
Footing in the central area
Dimension
Breadth (B) and Length (L), m
Thickness (T), m
Value
1.2-1.8
0.3-0.5
Footing at the building perimeter
Dimmension
Breadth (B) and Length (L), m
Thickness (T), m
Value
1.0-1.5
0.3-0.5
3
Footing examples
4
Footing examples
5
