ECE103 – 1L: INDUSTRIAL ELECTRONICS LABORATORY FOR EE
Laboratory Activity #7
Basic Logic Functions
Name: ______________________
Date Performed: __________
Section: A18
Instructor: Ronel V. Vidal, PECE
I.
Objectives:
1. To design a PLC program in order to solve a given PLC problem
2. To construct the electrical ladder diagram
3. To construct and simulate the PLC ladder diagram using the Picosoft software
4. To sketch the I/O wiring diagram of the PLC with the solution to the problem
II.
Problem:
Design the electrical ladder diagram and PLC ladder diagram to control the four lamps
shown below. The four lamps will turn ON one at a time with an interval of 0.5 seconds.
Momentary push button switch 1 is used to start the sequence, while momentary push
button switch 2 stops the sequence at any time.
Illustration:
Switch 2
Switch 1
1 s ON
1 s ON
1 s ON
1 s ON
Lamp 1
Lamp 2
Lamp 3
Lamp 4
Inputs:
S1 : Switch on system (N.O.)
S2 : Switch off system (N.C.)
Outputs:
L1 : Lamp 1
L2 : Lamp 2
L3 : Lamp 3
L4 : Lamp 4
Parameters:
T1: On delay Timer 1 (1 sec)
T2: On delay Time 2 (1 sec)
T3: On delay Timer 3 (1 sec)
T4: On delay Timer 4 (1 sec)
III.
Electrical Ladder Diagram:
IV.
I/O Wiring Diagram:
PLC Ladder Diagram:
+24 Vdc –
Picosoft Simulation:
