80-40m Dipole
Approx. 26m
22.72m
L1
L1
1.55m
50Ω coax
Wavelength  λ=
Speed of Light C 
Frequency
299.792
= λm= f
MHz
The antenna can be used without a balun, but to avoid
common mode current problems, I would suggest a 1:1 balun.
Total span is approx. 26m. On 40m it is a full-size dipole with good performance,
on 80m it is a loaded dipole. VSWR @ 50Ω is < 2:1 on all bands.
L1
Ø = 40mm, Length = 114mm,
1mm Cul (wire), Inductance = 120µH
