Lecture 1
ADU
3
One thing you learn in science is that
there is no perfect answer, no perfect
measure.
A. O. Beckman
Topic 1: Mechanism and
Kinematics
MEC 411
Introduction and Basic Concepts
3
Lecture 1
MEC 411
4
ADU
Chapter Objectives
Up on completion of this chapter, the student
will be able to
 Explain the need for kinematic analysis of
mechanism.
 Define the basic components that comprise
a mechanism.
 Draw the kinematic diagram from a view of
a complex mechanism.
 Compute the number of degrees of
freedom of a mechanism.
 Identify a four bar mechanism and classify
it according to its possible motion.
 Identify a slider crank mechanism.
4
Lecture 1
MEC 411
5
ADU
1.1 ANALYSIS AND SYSTHESIS
 Analysis: the techniques that allow the
designer to critically examine an already
existing or proposed design in order to
judge its suitability for task.
 Synthesis (or Design): the process of
prescribing the sizes, shapes, material
compositions, and arrangements of parts
so that the resulting machine will perform
the prescribed task.
5
Lecture 1
MEC 411
6
ADU
1.2 DESIGN PROCESS
6
Lecture 1
 There are several systems of units used in
engineering. The most common in the
United States are:
◼ The U.S. foot-pound-second (fps) system,
◼ The U.S. inch-pound-second (ips) system,
and
◼ The System International (SI)
MEC 411
7
ADU
1.4 UNITS
7
Lecture 1
MEC 411
8
ADU
1.4 UNITS
8
Lecture 1
MEC 411
9
ADU
1.5 THE SCIENCE OF MECHANICS
 Statics: deals with analysis of stationary
systems, that is, those in which time is
not a factor.
 Dynamics: deals with systems that change
with time.
 Kinematics: the study of motion, quite
apart from the forces which produce that
motion. More particularly kinematics is
the study of position, displacement ,
rotation, speed, velocity, and acceleration.
 Kinetics: the study of force on system in
motion.
9
Lecture 1
MEC 411
10
ADU
1.5 THE SCIENCE OF MECHANICS
10
Lecture 1
MEC 411
11
ADU
1.5 THE SCIENCE OF MECHANICS
Definitions:
 Kinematic Link or Element: It is each part of a
machine, which moves relative to some other
part. A link may consist of several parts,
which are rigidly fastened together (resistant
body), so that they do not move relative to
one another. Types of links are: Rigid,
Flexible, and Fluid.
 Kinematic Pair: The two links or elements of a
machine, when in contact with each other, are
said to form a pair. If the relative motion
between them is completely or successfully
constrained (i.e. in a definite direction), the
pair is known as kinematic pair. Types of
Kinematic Pairs are: Sliding, Turning, rolling,
screw, and spherical.
11
Lecture 1
MEC 411
12
ADU
1.5 THE SCIENCE OF MECHANICS
Definitions (cont.):
 Kinematic Chain: is defined as a combination
of kinematic pairs, joined in such a way that
each link forms a part of two pairs and the
relative motion between the links or elements
is completely or successfully constrained.
 Kinematic Chains should satisfy the following
two conditions:
1. L=2P-4, where L is the number of links, P is
the number of pairs which constitute a
kinematic chain.
2. h/2+J= 3/2 L – 2, where J is the number of
binary joints and h is the number of higher
pairs which constitute a kinematic chain.
12
Lecture 1
MEC 411
13
ADU
1.5 THE SCIENCE OF MECHANICS
Definitions (Cont.):
 Mechanism: an assemblage of resistant bodies,
connected by movable joints, to form a closed
kinematic chain with one link fixed and having
the purpose of transforming motion with low
forces and little power transmitted.
 Machine: a combination of resistant bodies
connected by joints so arranged (designed) to
transmit significant forces and power (work)
accompanied by certain determinate motion.
 Structure: also a combination of resistant
bodies connected by joints, but its purpose is
not to do work or to transform motion. A
structure is intended to bear load (be rigid).
13
Lecture 1
MEC 411
14
ADU
1.5 THE SCIENCE OF MECHANICS
14
Lecture 1
ADU
15
One thing you learn in science is that
there is no perfect answer, no perfect
measure.
A. O. Beckman
Topic 2: Mechanism and
Kinematics
MEC 411
Kinematics Fundamentals
15
Lecture 1
MEC 411
16
ADU
2.1 DEGREE OF FREEDOM (DOF) OR MOBILITY
 A mechanical system’s mobility (M) can be
classified according to the number of
degrees of freedom (DOF) that it
possesses.
 The system’s DOF is equal to the number of
independent parameters (measurements)
that are needed uniquely to define its
position in space and at any instant of time.
 The system of the pencil in the plane has
three DOF.
 The pencil in this example represents a
rigid body, or link, which for the purposes
of kinematics analysis we will assume to be
incapable of deformation.
16
Lecture 1
MEC 411
17
ADU
2.1 DEGREE OF FREEDOM (DOF) OR MOBILITY
17
Lecture 1
18
ADU
2.1 DEGREE OF FREEDOM (DOF) OR MOBILITY
3 DOF of Rigid body in
MEC 411
6 DOF of rigid body in Space
Plane
18
Lecture 1
ADU
2.2 TYPES OF MOTION
19
 Pure translation
MEC 411
Rectilinear Motion
Curvilinear Motion
19
Lecture 1
ADU
2.2 TYPES OF MOTION
20
 Pure rotation
Reference line
MEC 411
Reference line
20
Lecture 1
ADU
2.2 TYPES OF MOTION
21
 Complex Motion : Rotation + Translation
MEC 411
q
21
Lecture 1
MEC 411
22
ADU
2.3 LINKS, JONTS AND KINEMATIC CHAINS
 Linkages are the basic building blocks of all
mechanisms. A linkage consist of links (or
bars), generally considered rigid, which are
connected by joints, such as pins (or
revolute), or prismatic joints to form open or
closed chains (or loops).
 Such kinematic chains, with at least one link
fixed, become:
◼ (1) mechanisms if at least two other links
retain mobility, or
◼ (2) structures if no mobility remains.
22
Lecture 1
MEC 411
23
ADU
2.3 LINKS, JONTS AND KINEMATIC CHAINS
23
Lecture 1
MEC 411
24
ADU
Kinematics Mechanisms.avi - YouTube
 Kinematics:
https://www.youtube.com/watch?v=8JtcEja
qc4Y&list=PLB059985630300733
(By Kinematics with MicroStation)
https://www.youtube.com/watch?v=4Y8Pg
UlR0bQ&list=PLpe3qgeJLpB2psRDpvi1dprhT
PW5p0Tt_&index=3 (By Magic Marks)
 Automobile Engineering:
https://www.youtube.com/watch?v=c3Calfd
YZYw&list=PLpe3qgeJLpB2wAoaRSY9_yAeOt
7u0LTNd (By Magic Marks)
24
Lecture 1
ADU
2.3 LINKS, JONTS AND KINEMATIC CHAINS
https://youtu.be/4Y8PgUlR0bQ?list=PLpe3qgeJLpB2psRDpvi1dprhTPW5p0Tt_&t=53
MEC 411
25
 A link is a rigid body that possesses at least
two nodes that are points for attachment to
other links.
25
Lecture 1
ADU
2.3 LINKS, JONTS AND KINEMATIC CHAINS
 Link of different order:
26
◼ Binary link : has 2 nodes
◼ Ternary link : has 3 nodes
MEC 411
◼ Quaternary link : has 4 nodes
26
Lecture 1
MEC 411
27
ADU
2.3 LINKS, JONTS AND KINEMATIC CHAINS
 A joint is a connection between two or
more links (at their nodes), which allows
some motion, or potential motion,
between the connected links.
 Joints (also called kinematic pairs) can be
classified in several ways:
1. By the type of contact between the elements,
line, point or surface.
2. By the number of degrees of freedom allowed
at the joint.
3. By the type of physical closure of the joint:
either force or form closed.
4. By the number of links joined (order of the
joint).
https://www.youtube.com/watch?v=TYq_0v66ucM&index=2&list=PLB059985
630300733
27
Lecture 1
28
Lecture 1
MEC 411
28
ADU
ADU
2.3 LINKS, JONTS AND KINEMATIC CHAINS
The kinematic pairs can be:
 Higher pair (point or line contact): are
the joints with point or line contact
between the pair elements.
MEC 411
29
 Lower pair (surface contact): are the
joints with surface contact between
the pair elements.
29
Lecture 1
ADU
2.3 JOINT PAIRS: THE SIX LOWER PAIRS
 Lower Pair:
MEC 411
30
Name (symbol)
DOF Contains
Revolute (R)
1
R
Prismatic (P)
1
P
Screw or Helical (H)
1
R+P
Cylindrical (C)
2
R+P
Spherical (S)
3
R+R+R
Planar or Flat (F)
3
R+P+P
Planar Mechanism
3-D Mechanism
DOF: Degree of Freedom
30
Lecture 1
ADU
2.3 JOINT PAIRS: THE SIX LOWER PAIRS
 Revolute (R): Rotating full pin joint
MEC 411
31
Dq
31
Lecture 1
ADU
2.3 JOINT PAIRS: THE SIX LOWER PAIRS
 Prismatic (P): Translating full slider joint
MEC 411
32
DX
32
Lecture 1
ADU
2.3 JOINT PAIRS: THE SIX LOWER PAIRS
MEC 411
33
 Helical (H):
33
Lecture 1
ADU
2.3 JOINT PAIRS: THE SIX LOWER PAIRS
MEC 411
34
 Cylindrical (C):
34
Lecture 1
ADU
2.3 JOINT PAIRS: THE SIX LOWER PAIRS
MEC 411
35
 Spherical (S):
35
Lecture 1
ADU
2.4 JOINT PAIRS: THE SIX LOWER PAIRS
MEC 411
36
 Flat (F) :
36
Lecture 1
ADU
2.3 JOINT PAIRS: HIGHER PAIRS AND HALF JOINT
 Roll-slide (Half or RP) joint
Dq
MEC 411
37
DX
Linkage against Plane (Force close)
37
Lecture 1
ADU
2.3 JOINT PAIRS: HIGHER PAIRS AND HALF JOINT
 Higher Pair: 2 DOF
38
DX
MEC 411
Dq
Pin in Slot (Form Close)
38
Lecture 1
ADU
2.3 PLANAR MOTION
MEC 411
39
 Lower pair or Full joint : 1 DOF joint
 Higher pair, half joint : > 1 DOF, roll-slider
 Joint order = number of link joined - 1
First
order
pin
joint
First o
rder pin
join
t
S
econd ordorder
er pin jopin
int joint
Second
39
Lecture 1
MEC 411
40
ADU
2.3 PLANAR MOTION
 KINEMATIC CHAIN: An assemblage of links
and joints, interconnected in a way to
provide a controlled output motion in
response to a supplied input motion.
 CRANK: Link that makes a complete
revolution and is pivoted to ground.
 ROCKER: Link that has oscillatory (back and
forth) rotation and is pivoted to ground.
 COUPLER (or connecting rod): Link that has
complex motion and is not pivoted to
ground.
 GROUND: defined as any link or links that
are fixed (nonmoving) with respect to the
reference frame.
40
Lecture 1
41
ADU
2.5 DETERMINING DEGREE OF FREEDOM OR MOBILITY
 Degree of Freedom (DOF): Number or
inputs that need to be provided in order to
create a predictable output. Also: number
of independent coordinates required to
define its position.
 In Planar Mechanisms:
MEC 411
◼ 1 link in the plane has 3 DOF
41
Lecture 1
ADU
2.5 DETERMINING DEGREE OF FREEDOM OR MOBILITY
◼ 2 links in the plane have 6 DOF
Dq1
Dy2
Dx1
Dx2
Dq2
MEC 411
42
Dy1
42
Lecture 1
ADU
2.5 DETERMINING DEGREE OF FREEDOM OR MOBILITY
◼ 2 links connected by a full joint have 4 DOF
Dx
Dq1
Dq2
MEC 411
43
Dy
43
Lecture 1
ADU
2.5 DETERMINING DEGREE OF FREEDOM OR MOBILITY
◼ 2 links connected by a roll-slide (half) have
5 DOF
Dq2
44
Dx1
Dy
Dq1
MEC 411
Dx2
44
Lecture 1
ADU
2.5 DETERMINING DEGREE OF FREEDOM OR MOBILITY
https://youtu.be/6HPFzqA1p04?list=PLB059985630300733
 Gruebler’s equation
MEC 411
45
DOF or M = 3L – 2J – 3G
Where:
M=degree of freedom or mobility
L= number of links
J=number of joints (Count as 1 for full
0.5 for Half joint)
G=number of grounded links (always 1)
M = 3(L - 1) – 2J
45
Lecture 1
ADU
2.5 DETERMINING DEGREE OF FREEDOM OR MOBILITY
 Kutzbatch’s modification of Gruebler’s
equation
MEC 411
46
M = 3(L – 1)– 2J1 – J2
Where:
M= degree of freedom or mobility
L= number of links
J1= number of DOF (full) joints
J2= number of DOF (half) joints
Note:
J1=Full Joint = 1 & J2=Half Joint = 1
46
Lecture 1
47
ADU
2.5 DETERMINING DEGREE OF FREEDOM OR MOBILITY
MEC 411
M = 3(L - 1) – 2J
=3(8-1)-2x10=1
47
Lecture 1
M = 3(L - 1) – 2J
=3(6-1)-2x7.5=0
MEC 411
48
ADU
2.5 DETERMINING DEGREE OF FREEDOM OR MOBILITY
48
Lecture 1
 If the DOF is positive, it will be a mechanism, and
the links will have relative motion. If the DOF is
exactly zero, then it will be a structure, and no
motion is possible. If the DOF is negative, then it is
a preloaded structure, which means that no motion
is possible and some stresses may also be present
at the time of assembly.
MEC 411
49
ADU
2.6 MECHANISMS AND STRUCTURES
49
Lecture 1
ADU
Decoding Earth Moving Machines
MEC 411
https://youtu.be/b8c_9ZZX5_8?l
ist=PLB059985630300733
50
Lecture 1
https://youtu.be/0lui6cdRnCw?list=PLB0599856
30300733
MEC 411
51
ADU
1.12 EXAMPLES
51
Lecture 1
MEC 411
52
ADU
1.12 EXAMPLES
52
Lecture 1
MEC 411
53
ADU
1.12 EXAMPLES
53
Lecture 1
ADU
1.12 EXAMPLES
MEC 411
54
1. Number or links L = 4
2. Number of (full joint) 4 joints J=4
3. Number of ground link G=1
M = 3(4 - 1) – 2x4
M= 1
54
Lecture 1
ADU
1.12 EXAMPLES
MEC 411
55
1. Number or links L = 9
2. Number of full joints J=12
3. Number of ground link G=1
M = 3(9 - 1) – 2x12
M= 0
55
Lecture 1
Lecture 1
MEC 411
ADU
