Draw the 3D Model using the SolidWorks basic sketching techniques.
Draw the Model of the Carbon Fiber Gasket shown in Figure 1-14, 1-18 and 1-19 . The Full model of the gasket is
1-19. Assume the thickness of the Gasket to be 0.25in. Assume suitable dimensions if necessary. (All Dimensions
are in inches)
Figure 1-19 Full Model of the Carbon Fiber Gasket
