TIA Portal V14 SP1 Technical Slides

advertisement
TIA Portal V14 SP1
Technical slides
Unrestricted © Siemens AG 2017
TIA Portal
Highlights of TIA Portal V14 SP1
1. Hardware configuration
Details
2. STEP 7 - Innovations
Support for new hardware components
- CPU1511T(F) / CPU1515T(F)
- Power Supply 60W 24/48/60V DC HF
6. TIA Portal options
Freely editable comments for array and UDT
New functions for the operability
TIA updater: Fast mass update
New instructions
Openness: Ex/Import HW +IO via AutomationML
Single block comparison
ProDiag: Criteria analysis for S7-Graph
User comments visible directly in the code
Safety: Consistent Hardware- and Software Upload
Option handling with S7-1500F
F-IO-Status function block
New technology object for SIMATIC Ident
5. System functions
3. WinCC - Innovations
Windows 10 support
Integration of SINUMERIK Operate in Runtime Advanced
OPC UA DA client for WinCC Runtime Professional
4. Startdrive - Innovations
Password API
User-defined filters for cross-references
WinCC WebUX- Auto Login for WinCC RT Professional
Unrestricted © Siemens AG 2017
Page 2
March 2017
Optimized and extended
commissioning wizard
Online/offline comparison of parameter
values
Library handling
Hardware configuration
S7-1500 CPU Portfolio has been enlarged by T-CPU
Compact
CPU
Standard
CPU
1511C-1
PN
1512C-1
PN
1511F-1
PN
1513F-1
PN
1
1
1
1
1
1
1
1
1
1
Program/
Data memory
175 KB
1 MB
250 KB
1 MB
150/225 KB
1 MB
300/450 KB
1.5 MB
500/750 KB
3 MB
1/1.5 MB
5 MB
Bit-Performance
60 ns
48 ns
60 ns
40 ns
30 ns
Width
85mm
110mm
35mm
35mm
5
10
5
10
5
10
800
800
800
CPU-types
Interfaces
Positioning axis
typical 2)
maximum 3)
Motion Control
Ressources 4)
1) 20 MB additional memory for ODK application
4) Ressources for Motion Control technology objects (examples):
5) Additional Number of Cam´s: 1511T: 20; 1515T: 60; 1517T: 128
Unrestricted © Siemens AG 2017
Page 3
March 2017
1515F-2
PN
New ODKCPU
Technology
CPU
1516F-3
PN/DP
1518F-4
PN/DP
1
1
2
1
1
1
3
1
1
2/3 MB
8 MB
4/6 MB
20 MB
225/225 KB
1 MB
750/750 KB
3 MB
3/3 MB
8 MB
4/6 MB
20 MB1)
10 ns
2 ns
1 ns
60 ns
30 ns
2 ns
1 ns
70mm
70mm
175mm
175mm
35mm
70mm
175mm
175mm
5
10
7
30
7
30
70
128
128
128
5
10
7
30
70
128
128
128
800
2400
2400
10240
10240
800 5)
2400 5)
10240 5)
10240
2
1
2
1
2
1
1511TF-1 1515TF-2 1517TF-3
PN
PN
PN
1518F-4
PN/DP
ODK
1517F-3
PN/DP
2) at 4ms Servo/IPO cycle time and 35% CPU load due to Motion Control
2
1
2
1
1
2
1
3
3) no further TO´s applicable
Speed setpoint: 40; Positioning: 80; Gearing: 160; Output cam: 20; Output camtrack: 160; Measuring input: 40
1
PROFINET IO with IRT
2
PROFINET IO with RT
3
PROFINET basic services
PROFIBUS
Hardware configuration
Configuration of the System Power Supply PS 60W 24/48/60V DC HF
Highlights with PS 60W 24/48/60V DC HF
 Infeed of 60W into the backplane bus, integrated power balancing in
the TIA Portal, connection to 24/48/60 V DC
 Energy buffering for data backup (up to 20 MB) in the CPU
 Can be used with standard- and fail-safe CPUs
 105mm width (can be plugged only on the left, next to the CPU)
 I&M 0 … 3 („electronic rating plate“ with article number, version, etc.)
Customer benefits:
 Easy handling of huge data amounts, which has to be kept retentive,
e.g. in order to save settings or parameterization data during power
off on the CPU.
 Migration of S7-400 applications in factory automation is possible
Unrestricted © Siemens AG 2017
Page 4
March 2017
Hardware configuration
Configuration of the System Power Supply PS 60W 24/48/60V DC HF
Precondition for Configuration
 Configuration in STEP 7 V14 SP1
 CPU firmware: V2.1,
power supply for the CPU is done via the backplane bus
 Can be used with the following S7-1500 CPUs:
 CPU 1511(F/T) up to CPU 1516(F) with
article number: 6ES751x-xyy01-0AB0 (starting with FS01)
 CPU 1511C and CPU 1512C (starting with FS01)
 CPU 1517(F) and CPU 1518(F) starting with FS03
FS: Hardware functional state
Unrestricted © Siemens AG 2017
Page 5
March 2017
Hardware configuration
Configuration of the System Power Supply PS 60W 24/48/60V DC HF
 Increased quantity structure for retentive data
 Identical handling of retentive data like before
Unrestricted © Siemens AG 2017
Page 6
March 2017
Hardware configuration
Configure all IO channels of a module in a grid
Configure all I/O channels
of a module in a grid:
 All of the channels of the
ET200MP DI&DQ HF
can be configured in one
grid.
 Improved overview and
helpful functions like
auto fill, copy & paste for
diagnostics & IO
parameters
Unrestricted © Siemens AG 2017
Page 7
March 2017
Hardware configuration
Direct renaming of device names in the network and topology view
Direct renaming of device
names in the network and
topology view
 Time savings thanks to
direct renaming in the
network and topology
view without opening the
device properties
 Renaming via F2
shortcut, shortcut menu
or by double-clicking on
the device label
Unrestricted © Siemens AG 2017
Page 8
March 2017
Hardware configuration
Optimized (multi-)selection via shift key for network and device editor
Optimized selection for
network and device editor
 Quick (multi-)selection of
several devices and
modules with only two
mouse clicks
1st click
 Support of device and
network editor in all
views
Shift key
+ 2nd click
Unrestricted © Siemens AG 2017
Page 9
March 2017
Hardware configuration
Overview of IO tags of the complete IO station
Overview of all IO tags of
a complete IO station
 Additional display for the
IO tags of the complete
IO station that are used
 Display structured
according to modules for
easy assignment of the
IO tags to the hardware
Unrestricted © Siemens AG 2017
Page 10
March 2017
Hardware configuration
Easy removal of unused GSD files
Easy removal of unused
GSD files in the project
1
 Cleaning up of
references to unused
GSD files in the project
 Easy removing of
unused GSDs from
project with 3 clicks
3
2
Unrestricted © Siemens AG 2017
Page 11
March 2017
Hardware configuration
Improved zoom and overview navigation for the device and network editor
Improved zoom and
overview navigation for
the device and network
editor
 The zoom function via
toolbar controls now
obtains the selected
object in the visible area
 The overview navigation
shows the complete
configuration and
automatically optimizes
the display to the
available area
Unrestricted © Siemens AG 2017
Page 12
March 2017
Hardware configuration
Easy-to-find "PROFINET I/O system" properties
Easy-to-find "PROFINET
I/O system" properties
 Properties now also
become visible by
selecting the subnetwork
 All of the parameters of
the subnetwork and
PROFINET I/O systems
in the overview
Unrestricted © Siemens AG 2017
Page 13
March 2017
HWCN editors
Wizard extension for UDP multicast with Open User Communication (OUC)
S7-1500
Wizard extension for UDP
multicast with Open User
Communication (OUC):
 Easy UDP Multicast
configuration for programmed
or configured connections with
S7-1500 incl. CM/CP
 Extension for CPU internal
interfaces of S7-1500 V2.1 or
higher
Unrestricted © Siemens AG 2017
Page 14
March 2017
S7-1200
S7-300/400/WinAC
TIA Portal
Highlights of TIA Portal V14 SP1
1. Hardware configuration
2. STEP 7 - Innovations
Details
Freely editable comments for array and UDT
Support for new hardware components
- CPU1511T(F) / CPU1515T(F)
- Power Supply 60W 24/48/60V DC HF
6. TIA Portal options
New functions for the operability
TIA updater: Fast mass update
New instructions
Openness: Ex/Import HW +IO via AutomationML
Single block comparison
ProDiag: Criteria analysis for S7-Graph
User comments visible directly in the code
Safety: Consistent Hardware- and Software Upload
Option handling with S7-1500F
F-IO-Status function block
New technology object for SIMATIC Ident
5. System functions
3. WinCC - Innovations
Windows 10 support
Integration of SINUMERIK Operate in Runtime Advanced
OPC UA DA client for WinCC Runtime Professional
4. Startdrive - Innovations
Password API
User-defined filters for cross-references
WinCC WebUX- Auto Login for WinCC RT Professional
Unrestricted © Siemens AG 2017
Page 15
March 2017
Optimized and extended
commissioning wizard
Online/offline comparison of parameter
values
Library handling
STEP 7 - Language innovations
Freely editable comments for arrays and UDTs
S7-1500
S7-1200
S7-300/400/WinAC
Function
New
 UDT and array comments can be changed instancespecifically
 Inheritance of defined comments by default
 Multilingual support
Customer benefits
1. Display on the application
2. Use for message text
3. Further benefits
 Individual use of the
same UDTs
 Unambiguous description
of array elements
Unrestricted © Siemens AG 2017
Page 16
March 2017
STEP 7 - Language innovations
New instructions: Scatter* / Gather*
S7-1500
Converting data for
further processing
 SCATTER* converts elementary
data types to a bit array
New
 GATHER* converts a bit array to
an elementary data type
 Expanded instructions
SCATTER_BLK and
GATHER_BLK for "array of data
type"
Example use case
 Breaking down, processing and
status words
* from FW V2.1 (S7-1500), V4.2 (S7-1200)
Unrestricted © Siemens AG 2017
Page 17
March 2017
New
S7-1200
S7-300/400/WinAC
STEP 7 - Language innovations
New instructions: Polyline
Input is mapped to
output via characteristic line
 Characteristic line is defined as
a polyline
 Up to 50 points
 Linear interpolation between
points
Use cases
 Adaption of measured values
 Linearization of actuators
with nonlinear characteristic
(e.g. compensation of valve
characteristics)
Unrestricted © Siemens AG 2017
Page 18
March 2017
x1
S7-1500
7
6
5
4
Output=3.5
3
2
1
0
0
1
2
3
4
5
6
Input=5.5
New
7
S7-1200
S7-300/400/WinAC
STEP 7 - Language innovations
New instruction: GetSMCinfo
S7-1500
S7-1200
S7-300/400/WinAC
FW
2.0
"Service life" display of the SIMATIC memory card
 Generation of a diagnostic entry when a user-defined service life
is exceeded (in a percentage of the guaranteed read/write cycles)
 Visual indicator on the CPU via the maintenance LED
 Information in the user program can be evaluated via the
"GetSMCinfo" block:
New
 Card size and memory that is already assigned
RS ER MT
80%
 Number of write and delete processes carried out for the
card
Field of application
 When recipes and archives are intensively used, information on
the "service life" of the card can be evaluated and the SMC card
can be swapped in advance if need be.
Unrestricted © Siemens AG 2017
Page 19
March 2017
New
STEP 7 - Language innovations
Symbolic programming  UDT1 := UDT2
S7-1500
Use case
S7-1200
S7-300/400/WinAC
Programming example
New
 Various types of valves can be stored
or manipulated in an array
Customer benefits
 Easy back-up of various types of
data
 Type safety because different UDTs
can be assigned
 Compared to Serialize/Deserialize
clearly better runtime behavior
Unrestricted © Siemens AG 2017
Page 20
March 2017
Requirements
 The various types of UDT must have the same structure of the
individual elements.
 The symbolic names may differ.
:=
STEP 7 - Language innovations
S7-Graph: Extension function block 1/2
S7-1500
Basic principle
OB, FB, FC
S7-1200
„My S7-Graph FB“,
My S7-Graph DB
 With introduction of the expansion function
block for S7-Graph all static variables can be
accessed generically via the InOut interface.
 The created extension function block can be
called as multi- or single instance.
Customer benefits
 Indexed access to the whole sequence
 Access to internal parameters like
- number of active steps (SAX)
- number of disturbed steps (SERRX)
- number of valid transitions (TVX)
- and so on….
Unrestricted © Siemens AG 2017
Page 21
March 2017
New
Call „My S7-Graph FB“
My S7-Graph DB
Extension
function block
S7-300/400/WinAC
STEP 7 - Language innovations
S7-Graph: Extension function block 2/2
S7-1500
Workflow
1) Create S7-Graph block (from V4.0)
3
2a
a) Define InOut parameters to access S7Graph variables
b) Sample program for indexed access to
steps and transitions
c) Sample program for access of internal
parameters
2b
3) Define extension function block as multi
instanz within the static-section of
S7-Graph block
4) Define the extension block name
within the properties of the
S7-Graph block.
Unrestricted © Siemens AG 2017
Page 22
March 2017
* SCL only
2c
4
S7-300/400/WinAC
2
1
2) Create Extension function block*
S7-1200
STEP 7 - Technology
SIMATIC Ident: new technology object (TO)
S7-1500
Basic principle
 The technology object for SIMATIC
Ident is the link between the HW
design and the SW programming
 The user allocates every device with
a unique name which is also used for
programming.
 Parametrization of hardware by the
technology object
 Diagnostic by displaying messages
that are produced within the
application software.
Unrestricted © Siemens AG 2017
Page 23
March 2017
S7-1200
S7-300/400/WinAC
STEP 7 - Technology
SIMATIC Ident: Adressing scheme using TO
S7-1500
Easiest configuration
1. Design hardware and network. Assign
RFID devices with their own name.
2. Call the TO window and select a RFID
device.
3. Adjust all parameter for the selected
RFID device/reader.
4. Select a RFID device in your
application software. Only configured
devices are shown in the drop dwon
menu.
1. Design the hardware
Unrestricted © Siemens AG 2017
Page 24
March 2017
S7-1200
S7-300/400/WinAC
2. Call TO
3. Adjust parameter
4. Select device in
function block of the
application
STEP 7 - Trace
New options for graphical representation
Online
Options
5
Offline
1. Preview window for the illustration
and choice of the current zoom area
2. Choice of the time format for the xaxis
3. Display format for the number
representation switch-selectable
4. Switchover between steps and linear
interpolated signal (REAL)
5. Ongoing automatic measuring
repetition
4
2
Customer benefit
 Better Usability
Unrestricted © Siemens AG 2017
Page 25
March 2017
1
3
STEP 7 - Language innovations
Collection of useful function expansions
SCL: Surrounding a code that is used
 Selected code lines can be encompassed
with control structures using the "Surround
with" function.
New
SCL: Insert and overwrite modes
 You can switch between
insert and overwrite mode
using the Ins key.
Unrestricted © Siemens AG 2017
Page 26
March 2017
Insert mode
New
"Ins key"
Overwrite mode
STEP 7 – Editor innovations
Collection of useful function expansions
Individual block comparison
 The detailed comparison of individual
blocks can be started directly from the
project navigation.
 Offline/offline but also online/offline
New
Display of the tag comment
 In LAD/FBD, the tag comment can be
displayed directly on the application.
 Hierarchical comments can also be
displayed
Unrestricted © Siemens AG 2017
Page 27
March 2017
New
STEP 7 - Editor innovations
Collection of useful function expansions
Tag comment in the watch table
 The defined tag comment can also be
displayed in the watch table.
Inserting a comment line in the watch table
 A comment line can be inserted using the
new icon.
"Open block/PLC data type..." via F7
 The F7 function can also be started within
editors using Focus.
Unrestricted © Siemens AG 2017
Page 28
March 2017
New
New
STEP 7 - Editor innovations
Collection of useful function expansions
"Deep export" of external sources
 The export of objects as an external source
takes the UDTs defined in the interface,
multi-instances and all called blocks into
consideration.
Upgrade of the project version to the latest
version
 In the Instructions task card, the project can
upgraded to the latest version to be able to
use all of the new instructions.
Update of the instructions used in a
controller
 All of the instructions used for a controller
can be updated to the latest version in the
Instructions task card.
Unrestricted © Siemens AG 2017
Page 29
March 2017
New
New
New
STEP 7 - Editor innovations
Collection of useful function expansions
Settings for library types
 Under Settings/General/Library settings, the
type cancellation of objects can be
suppressed.
Protection for unintentional cancellation
of a typified object.
New
Terminate connection to type
Corporate
settings
Settings for user-defined help
 Under Settings/General, the user can select
whether the user-defined help is to be
opened in the selected editing language.
Unrestricted © Siemens AG 2017
Page 30
March 2017
New
STEP 7 - Editor innovations
Collection of useful function expansions
Export of PLC tags used
 The export of tag tables can be limited to
the tags used in the project.
Ne
w
Monitoring of blocks
 When monitoring blocks it will be shown
whether online values are updated.
Unrestricted © Siemens AG 2017
Page 31
March 2017
New
New
TIA Portal
Highlights of TIA Portal V14 SP1
1. Hardware configuration
2. STEP 7 - Innovations
Support for new hardware components
- CPU1511T(F) / CPU1515T(F)
- Power Supply 60W 24/48/60V DC HF
6. TIA Portal options
Freely editable comments for array and UDT
New functions for the operability
TIA updater: Fast mass update
New instructions
Openness: Ex/Import HW +IO via AutomationML
Single block comparison
ProDiag: Criteria analysis for S7-Graph
User comments visible directly in the code
Safety: Consistent Hardware- and Software Upload
Option handling with S7-1500F
F-IO-Status function block
New technology object for SIMATIC Ident
3. WinCC - Innovations
5. System functions
Details
Windows 10 support
Integration of SINUMERIK Operate in Runtime Advanced
OPC UA DA client for WinCC Runtime Professional
4. Startdrive - Innovations
Password API
User-defined filters for cross-references
WinCC WebUX- Auto Login for WinCC RT Professional
Unrestricted © Siemens AG 2017
Page 32
March 2017
Optimized and extended
commissioning wizard
Online/offline comparison of parameter
values
Library handling
WinCC for Basic Panels
Collection of useful function expansions
Functional improvements for Basic Panel






Assignment of IP address is not limited to S7-1200 and S7-1500 anymore
USB Rescue Stick to reset Panel if connection is not possible
Siemens barcode scanners are now officially released with HMI Panels
Download Chinese/Japanese/Korean fonts to Basic Panel
(use of browser in these countries) via ProSave
Picture and text in parallel on a button
Unicode csv export of recipes on Basic Panels
USB Reset to Factory with USB stick
 Creation of the USB stick
 download of software
 Unzip onto USB stick
 Copy of Image from TIA folder into folder of USB stick
 Start Basic Panel with inserted USB stick
 Follow instructions
 Restart the device
 Available via download or from hotline
 Preconditions:
 USB is FAT32 formatted
 Image is TIA V14 or higher
Unrestricted © Siemens AG 2017
Page 33
March 2017
WinCC for Comfort / Mobile Panel
Collection of useful function expansions
Functional improvements for Comfort / Mobile Panel
 Uninstall WinCE applications for Comfort Panels (via ProSave)
 Siemens barcode scanners are now officially released with HMI
Panels
 Support of new network cameras
 Unlimited usage of scripts (no system limit anymore)
 Additional system functions in zone editor for Mobile
 System function for restart of Comfort Panels
 New supported printers:
 Brother HL-5100DN (black laser)
 Brother HL-L8250CDN (color laser )
Connectivity – Tested products
 Support of Siemens barcode scanners
 Optical handheld reading devices MV320/MV325/MV340
 Update of tested network cameras
 AXIS M1013, AXIS M1011
 D-Link DCS-942L, D-LINK 4701E
Unrestricted © Siemens AG 2017
Page 34
March 2017
https://support.industry.siemens.com/cs/ww/en/view/62383298
https://support.industry.siemens.com/cs/ww/en/view/19188460
WinCC for Mobile Panels 2nd Generation and Runtime Advanced
Collection of useful function expansions
System functions for Mobile Panels 2nd Generation
 Evaluation of the connection point
 ShowPopUpScreen
 ShowSlideInScreen
 ShowLogonDialog
 Log on user, log off user
 VB script
General enhancements for Runtime Advanced



Camera view to display live video streams of current
network cameras over RTP/RTSP streaming protocols
and MJPEG, H264, MPEG4 codecs tested cameras
(AXIS M1013, AXIS M1011, D-Link DCS-942L, D-LINK
4701E, Siemens CCMS2025)
Extension of PDF view (Find and Copy)
License-free use of the Sm@rtServer on Runtime
Advanced (analogous to Comfort Panels)
Unrestricted © Siemens AG 2017
Page 35
March 2017
ID 9
ID 8
ID 7
WinCC Runtime Advanced
Integration of SINUMERIK Operate in Runtime Advanced
Integration of SINUMERIK Operate (GUI and data)
in Runtime Advanced

Access to SINUMERIK Operate user interface via new NC
Operate view in pictures of RT Advanced (also multitouch
operation)

Access to SINUMERIK NCU data by means of separate
SINUMERIK channel

Currently support of single-station solutions on SIMATIC IPC as
well as standard PC with Windows 7 Professional operating
system

Requires ES option SINUMERIK Integrate Create MyHMI/WinCC
as an enhancement for WinCC Advanced/Professional and RT
option SINUMERIK Integrate Run MyHMI/WinCC for operation
with WinCC Runtime Advanced

Requires SINUMERIK Operate/PCU or /PC as of version 4.8
SP1 or higher (customer-specific start of delivery scheduled for
May 2017)
Unrestricted © Siemens AG 2017
Page 36
March 2017
WinCC Runtime Professional
OPC UA DA Client
OPC UA DA Client
Unrestricted © Siemens AG 2017
Page 37
March 2017
WinCC Runtime Professional
Option WinCC/WebUX
Option WinCC/WebUX
Info about used licenses
Automatic Login ( “ViewOnly” for monitoring)
 Use Case: information display in manufacturing hall
Unrestricted © Siemens AG 2017
Page 38
March 2017
WinCC Runtime Professional
Collection of useful function expansions
Collection of useful function expansions
Modal Popups with ScreenWindow
 The screens, shown in screen window can be locked (no operation)
 UseCase: InputMask, Messageboxes, ...
 VBS Method: „SetOperationLock()“
Customizable Recipe Control
 Possibility to configure the following properties:
 Adapt the buttons (size and design)
 Elements of table (individual symbols, also dependent from tags)
 Scollbar (Style)
https://support.industry.siemens.com/cs/ww/en/view/76327375
Unrestricted © Siemens AG 2017
Page 39
March 2017
TIA Portal
Highlights of TIA Portal V14 SP1
1. Hardware configuration
2. STEP 7 - Innovations
Support for new hardware components
- CPU1511T(F) / CPU1515T(F)
- Power Supply 60W 24/48/60V DC HF
6. TIA Portal options
Freely editable comments for array and UDT
New functions for the operability
TIA updater: Fast mass update
New instructions
Openness: Ex/Import HW +IO via AutomationML
Single block comparison
ProDiag: Criteria analysis for S7-Graph
User comments visible directly in the code
Safety: Consistent Hardware- and Software Upload
Option handling with S7-1500F
F-IO-Status function block
New technology object for SIMATIC Ident
5. System functions
3. WinCC - Innovations
Windows 10 support
Integration of SINUMERIK Operate in Runtime Advanced
OPC UA DA client for WinCC Runtime Professional
Details
4. Startdrive - Innovations
Password API
User-defined filters for cross-references
WinCC WebUX- Auto Login for WinCC RT Professional
Unrestricted © Siemens AG 2017
Page 40
March 2017
Optimized and extended
commissioning wizard
Online/offline comparison of parameter
values
Library handling
SINAMICS Startdrive V14 SP1
Optimized and extended commissioning wizard
Integration of the previously two separated wizards
for standard commissioning and the use with a
SIMATIC Motion Control axis into one wizard
Unrestricted © Siemens AG 2017
Seite 41
March 2017
Integration of the selection of telegram, brake
resistance, filter at motor-side, temperature sensor
as well as Motor selection also by code number
SINAMICS Startdrive V14 SP1
Collection of useful function expansions
Online/offline comparison of parameter
values
 Track changes online / offline
Sensitive support for saving data
“RAM to ROM”

Message box displayed when disconnecting
from the drive (only if parameters have been
edited)
Unrestricted © Siemens AG 2017
Seite 42
March 2017
TIA Portal
Highlights of TIA Portal V14 SP1
1. Hardware configuration
2. STEP 7 - Innovations
Support for new hardware components
- CPU1511T(F) / CPU1515T(F)
- Power Supply 60W 24/48/60V DC HF
6. TIA Portal options
Freely editable comments for array and UDT
New functions for the operability
TIA updater: Fast mass update
New instructions
Openness: Ex/Import HW +IO via AutomationML
Single block comparison
ProDiag: Criteria analysis for S7-Graph
User comments visible directly in the code
Safety: Consistent Hardware- and Software Upload
Option handling with S7-1500F
F-IO-Status function block
New technology object for SIMATIC Ident
5. System functions
3. WinCC - Innovations
Details
Windows 10 support
Integration of SINUMERIK Operate in Runtime Advanced
OPC UA DA client for WinCC Runtime Professional
4. Startdrive - Innovations
Password API
User-defined filters for cross-references
WinCC WebUX- Auto Login for WinCC RT Professional
Unrestricted © Siemens AG 2017
Page 43
March 2017
Optimized and extended
commissioning wizard
Online/offline comparison of parameter
values
Library handling
System functions
Win10-Support for TIA Portal V14 SP1 incl. V13 SP2
Use case
Supported operating systems
End of ext.
support:
Windows 7
01/2020
Windows 10
10/2025
V13 SP2
V14 SP1
New
*
Customer benefits
 Long-term Microsoft Windows support with Windows 10
 One shared operating system platform for TIA Portal and
"Classic products"
project upgrade
V13  V14
New
 Project upgrade to a single-station computer :
Vxx  V13 SP2  V14 SP1
* planned Q2/2017
Unrestricted © Siemens AG 2017
Page 44
March 2017
* for STEP 7 / WinCC Basic also Windows 10 Home
System functions
Password API
Function
TIA Portal / STEP 7
New
Protected
program
blocks
Password prompt
via API
Integrated UI behavior:
Password prompt via dialog
Password API
Application examples
Central server management
with user authentication

Open interface for 3rd party tools to connect to
the TIA Portal

Definition or administration of passwords in
external tools

Automatic opening of know-how-protected
blocks without entering a password

Supported protective mechanisms:
- Know-how protection for PLC objects
- Write protection for PLC objects
- Copy protection for PLC objects
KHP-PW
User-specific hardware dongle
Customer benefits
ID card with
Smartcard chip
Unrestricted © Siemens AG 2017
Page 45
March 2017

Increased know-how protection because
passwords for the users are not visible/known

More convenient working with protective
mechanisms
System functions
Filter options for cross-references
Filter options
1
2
New
Example use case
 As a user, I would like to find all variable write
accesses in a block greater than 1.
Workflow
1. Select all of the variables and open the
cross-references ("F11" or inspector window)
2. Define filter
3. The filter results show only multiple
accesses
3
Customer benefits
 Specific information is quickly found
 Project-independent, can be saved and
exported
Unrestricted © Siemens AG 2017
Page 46
March 2017
System functions
Translation of libraries
Library
B1
B2
Library
ENG
GER
Export
ENG
GER
CHN
Translation of a library
ENG
GER
CHN
V 1.0.0
ENG
GER
V 1.0.1
V 0.3.2
ENG
GER
V 1.0.0
ENG
GER
V 0.3.2
ENG
GER
ENG
GER
ENG
CHN
Text 1
…
Text 2
…
…
…
B2
Translation
V 1.0.0
ENG
GER
V 0.5.9
ENG
GER
Unrestricted © Siemens AG 2017
Page 47
B1
Customer benefit
March 2017
ENG
GER
ITA
V 1.0.1
Import
ENG
GER
CHN
V 1.0.0
ENG
GER
V 0.5.9
ENG
GER
 Translation functions available for
project and
global libraries
 The import/export of texts can be
done for a complete library, for
several library elements, or an
individual library element.
 Consistent handling for copy
templates and types
System functions
Library functions – Type upgrade – With TIA Portal V14 SP1
1
4
2
3
Blue markings appear if the types in the
PLC_1 are instantiated.
Function
 Integration of deltaobjects for existing
types
Workflow
1.
2.
3.
4.
Unrestricted © Siemens AG 2017
Page 48
March 2017
The filter shows all of the types that can
be upgraded
The user selects the test environment
The system checks the prerequisites
The system performs the upgrade of the
selected types
Customer benefit

System supported integration of
changed objects into an existing
library
System functions
Project-Upgrade and Compatibility-Mode
V13 SP1/SP2
(usage also with V14 license )
<= V13-Project
V13 SP1-Project
Project Upgrade to V13 SP1
V14 SP1 Engineering Software
V14 Project
V14 SP1 Project
Project Upgrade to V14 SP1
All project versions can be accessed via side-by-side Installation of V13 SP2 and V14.
Unrestricted © Siemens AG 2017
Page 49
March 2017
System functions
Online-Compatibility
Online access after upgrade of project
 No Online/Offline difference
V14 Engineering Software
New
 No download or STOP necessary for:
Project Upgrade
 Go Online
 Monitoring blocks
 Control variables
V14 Project
V14 SP1 Project
 SW-Download in RUN (HW-Download always in STOP)
 PLC-Upgrade from V14 to V14 SP1
Customer benefits
 No machine interruption by project upgrade
 Program corrections can be downloaded in RUN
Online Upgrade via
download in RUN
 No lost of actual value
Unrestricted © Siemens AG 2017
Page 50
March 2017
V14
Upload in ES
Download in PLC
V14 SP1
Online & Diagnosis
Monitoring
System functions
Basic Integrity Check
Function
2
Optional check of
integrity information
1
Adding integrity
information
TIA-Portal
TIA-Portal
Project
File
Unrestricted © Siemens AG 2017
Page 51
March 2017
1

TIA-Portal features a base-protective
mechanism to detect changes in custom project
file (e.g. blocks, hardware configuration).

Causes for changes for example can be
tampering outside the TIA-Portal or defects in
the data storage medium.

The TIA-Portal automatically extends integrity
information to the project file during save
operation

The check can be performed individually when
opening a project or generally during project
open (Global Setting)
Save project
Customer benefits
2
Open project

Improved detection of modifications on TIAPortal project files.
Note: If basic integrity check is activated operating speed is reduced
when opening projects and especially in multi-user scenarios
System functions
Collection of useful function expansions
Write protection for program blocks
 Password based write protection –
code visible but not editable
 Also for failsafe block
(F signature is not changed)
 Blocks still can be compiled
New
New properties and improved
usability in the alarm display
 Receive alarms can be activated
within inspector window
 With “freeze alarms” the view of the
alarm display can be frozen
Unrestricted © Siemens AG 2017
page 52
March 2017
New
New
TIA Portal
Highlights of TIA Portal V14 SP1
1. Hardware configuration
2. STEP 7 - Innovations
Support for new hardware components
- CPU1511T(F) / CPU1515T(F)
- Power Supply 60W 24/48/60V DC HF
6. TIA Portal options
Freely editable comments for array and UDT
New functions for the operability
TIA updater: Fast mass update
Details
New instructions
Openness: Ex/Import HW +IO via AutomationML
Single block comparison
ProDiag: Criteria analysis for S7-Graph
User comments visible directly in the code
Safety: Consistent Hardware- and Software Upload
Option handling with S7-1500F
F-IO-Status function block
New technology object for SIMATIC Ident
5. System functions
3. WinCC - Innovations
Windows 10 support
Integration of SINUMERIK Operate in Runtime Advanced
OPC UA DA client for WinCC Runtime Professional
4. Startdrive - Innovations
Password API
User-defined filters for cross-references
WinCC WebUX- Auto Login for WinCC RT Professional
Unrestricted © Siemens AG 2017
Page 53
March 2017
Optimized and extended
commissioning wizard
Online/offline comparison of parameter
values
Library handling
TIA Portal options
TIA Software Updater
TIA Software Updater
New
New
Function
 Multi-selection of support packages
 Automatic download and installation of
several support packages
Customer benefits
 Quick and easy adding of support
packages
Unrestricted © Siemens AG 2017
Page 54
March 2017
TIA Portal options
Openness: Standardized exchange between Electro-CAD and automation
TIA Portal V14 SP1
PLC_1
PLC_2
XML file
IOXML file
Device_1
AML file
HWCN + IO
Export/import
Export/import
Electrical CAD tools
 Article number
 Article description
 Network connections
 Configured firmware version
 Tag table
Customer benefits
 Replacement of hardware configuration and icons via XML files
 Bidirectional workflow CAD systems  TIA Portal
 Free tool support thanks to a standardized interface
 Further use case, e.g. TIA Selection Tool connection
Unrestricted © Siemens AG 2017
Page 55
March 2017
New
TIA Portal options
Openness: Automatic generation of projects, software and hardware
Customer benefits
Project generator
DLL
Project for Machine A
TIA openness
TIA Portal
Project for Machine B
Unrestricted © Siemens AG 2017
Page 56
March 2017
 Generation of the
complete automation
project with TIA Portal
openness (hardware &
software)
 Perfect customer workflow
from ordering to the
finished automated TIA
project.
TIA Portal options
ProDiag: Criteria analysis in the HMI PLC Code Viewer
Why?
Function
 Switchover of the view to the original
state when an error has occurred.
Customer benefits
 Focusing on the erroneous operands
Unrestricted © Siemens AG 2017
Page 57
March 2017
Original
problem
K
R
E
I
S
TIA Portal Optionen
STEP7 Safety: Consistent Upload of Safety projects
ET200SP 1
Customer benefits
Project 1
CPU 1
Service Techniker
CPU 2
 Avoidance of faults and
reduction of the service effort by
reduction of complex “offline”
administration
Project 2
ET200SP 2
Upload consistent
 Time and cost savings
 For S7-1500F and also
PLCSim Advanced
ET200SP 3
Project 3
CPU 3
Unrestricted © Siemens AG 2017
Page 58
March 2017
K
R
E
I
S
TIA Portal Optionen
STEP7 Safety: Configuration Control for F-I/O
Master-Project
Customer benefits
CPU 1
 F-modularization and fast
customization on customer wishes
without ES for serial production of
machines
Option 2
Option 1
 Supported for F-Periphery
dezentralized for F-PLC S7300/400/1200/1500 und centralized
for F-CPU S7-1500
CPU 1
CPU 1
 Controlling via F-Periphery-DBVariable „DISABLE“
 Analysis of the F-BG-deactivation
via „DISABLED“ F-DB-Variable
from Safety-System-Version V2.1
Unrestricted © Siemens AG 2017
Page 59
March 2017
3/31/2017
K
R
E
I
S
TIA Portal Optionen
STEP7 Safety: F-IO-Status function block
Customer benefits

Collective information of channel- or F-I/O
faults for each failsafe Runtime Group
„QSTATUS“ Bit (QBAD + Value_Status)

Separate collection of the RIOforFAValue-Status for all F-IO modules

Extensions for further F-I/O information
planned (PASS_OUT, ACK_REQ,
IPAR_OK, …)
New
Unrestricted © Siemens AG 2017
Page 60
March 2017
Thank you for your attention.
Subject to changes and errors. The information given in this document only contains general descriptions and/or performance features which may
not always specifically reflect those described, or which may undergo modification in the course of further development of the products. The requested
performance features are binding only when they are expressly agreed upon in the concluded contract.
All product designations, product names, etc. may contain trademarks or other rights of Siemens AG, its affiliated companies or third parties.
Their unauthorized use may infringe the rights of the respective owner.
siemens.com/tia-portal
Unrestricted © Siemens AG 2017
Page 61
March 2017
Download
