National University of Sciences and Technology
School of Electrical Engineering and Computer Science
Department of Electrical Engineering
End Semester Project: Spring 2024
ME 109: Engineering Drawing
BEE15 D
Instructions
1. Design a 3D model of your preference that consists of at least 10 distinct components. This assignment
requires you to design a detailed model that showcases your mastery of AutoCAD's 3D drawing tools.
2. Please ensure that your project is uploaded to the Learning Management System (LMS) by 13:00 on
May 15th, 2024.
3. Late submissions will not be accepted.
4. To evaluate your End Semester Project, we will use the point distribution table provided below. This
table outlines the criteria we will use to grade your submission based on the accuracy, complexity, and
precision of your 3D model.
Activity
Timely Submission
Project Report
Viva
No. of Parts
Detailing and presentation of
project and report
Point Distribution
[03 Points]
[03 Points]
[03 Points]
[03 Points]
[03 Points]
Deliverables
 Project report – Should be formal and have 3 (Min) to 5 (Max) pages.
 Project file – Complete file of the object
End Semester Project
Author
ABC
Regn Number
123
Supervisor
XYZ
DEPARTMENT NAME
SCHOOL OF ELECTRICAL ENGINEERING AND COMPUTER SCIENCE
NATIONAL UNIVERSITY OF SCIENCES AND TECHNOLOGY
ISLAMABAD
May 15, 2024
