Scheme of work Week 1 - Revision Week 2- Force (meaning of force) Week 3 - Force (Gravitational force) Week 4 - Force ( Friction) Week 5 - Force(Gravitational force and weightlessness) Week 6 - Force (The earth in space) Week 7 - Midterm break Week 8 - Force (Space travel) Week 9 - Force ( satellite) Week 10 - 13: Revision and examination. FORCE MEANING OF FORCE Force is any action that moves an object or alters its uniform motion in a given direction. Force is the product of mass of the objects and its acceleration. In science, force is a pull or push. Force is measured in Newton ( the symbol is N) Mathematical Expression of Force Force ά mass x acceleration F= ma, where F= force, m= mass and a= acceleration Example 1: Calculate the amount of force required to move a body of mass 10kg with an acceleration of 3m/s2 SOLUTION Given : mass = 10kg , 2 acceleration = 3 m/s F= ? Recall that, F = ma F= 10 x 3 F = 30N. Example 2: The force which is required to move an object of mass 500g moving with an acceleration of 4m/s2 is . SOLUTION Given that, F = ?, m = 500g, a = 4 m/s2 . Convert 500g to kg before solving. 1Kg = 1000g mass = 500/1000 Mass = 1/2kg Recall that, F = ma F=½x4 F = 2N. EFFECTS OF FORCE Force has the following effects on a body. 1. It changes the shape of a body. 2. It makes a body at rest move 3. It makes a moving object stop 4. It causes an object to change its direction 5. It causes a body to change its speed. TYPES OF FORCES There are two types of force. These are 1. Contact force 2. Non-contact force (or force field) 1. CONTACT FORCE These are force whose sources are in contact with the body to which they are applied. Examples are pull, push, tension forces ( in strings and wires) and frictional force (between surfaces). It can be direct (push, pull & friction) or indirect ( tension). 2. NON- CONTACT FORCE (OR FORCE FIELDS) This is a force whose source does not require contact with the object to which it is applied. It occurs between two bodies or objects that are separated by Space. Examples are Magnetic force, Gravitational force & Electric force 1. MAGNETIC FORCE This is a force that exists around magnet . Objects like iron, pin and nail are attracted by the magnetic force if brought within the magnetic field. 2 GRAVITATIONAL FORCE. This is the force with which the earth pulls all objects towards its centre. It is also called force of gravity. 3. ELECTRIC FORCE This is a force that exists between two electric charges. Unlike charges attract each other. While like charges repels each other. DIFFERENCES BETWEEN GRAVITATIONAL FORCE AND MAGNETIC FORCE Gravitational Magnetic Force Force 1. It is a property 1. It is the pull of some exerted by the substance to earth on objects attract iron or steel objects towards itself. 2. The direction of 2. The direction of the force is the force is towards the always magnet. downward the 3. The strength 3. The strength of the force is of the force is weak strong 4. It cannot pass 4. It can easily through pass through substances like substances like wood, metal or wood or glass. glass. 5. It gives objects its weight 6. It enables fruits to fall from trees 5. It cannot give weight to objects 6. It cannot fall fruits from trees. USES OF FORCE 1. It is needed to make objects move 2. It prevents car wheels from slipping on a tarred road when moving on it. 3. It makes it possible for the car to stop or slow down when the brakes are applied 4. Friction between the sole of our feet and the ground makes it possible for us to walk without slipping. 5. Magnetic force is used by watch repairers to pick tiny iron materials like pin and screws 6. Magnetic force is applied to separate iron dust from solid nonmagnetic substances like sulphur and sand. TOPICAL QUESTIONS ON FORCE 1. Which of the following is an example of direct contact force? A. Gravitational B. Magnetic C. Tension D. Friction 2. The quantity of matter in a body is called its A. Force B. Space C. Mass D. Volume 3. These are field forces EXCEPT ----------force. A. Electric B. Frictional C. Gravitational D. Magnetic 4. The amount of force needed to lift an object depend on the object's A. Energy B. Size C. Mass D. Force 5. The S.I unit of force is A. N B. Nm C. Mn D. Kg 6. In science, a push or pull is a A. Fall B. Rise C. Game D. Force 7. Which of the following is a direct contact force? A. Push B. Pull C. Tension D. Tendon 8.The weight of an object is measured in A. Kilobytes B. Kilometers C. Kilowatt D. Newton 9.Gravitational, magnetic and electric forces are generally called A. Contract forces B. Contact forces C. Noncontract forces D. Non-contact forces 10.A force applied directly to an object which may involve pushing or pulling is called A. Gravitational B. Frictional C. Contact D. Magnetic WEEK 3 CALCULATION OF GRAVITATIONAL FORCE Gravitational force: is the force with which the earth pulls all objects towards its centre. It is also called force of gravity. The instrument used for measuring gravitational force is called spring balance. When a ball of mass, m, kilograms(kg) is thrown upward above the ground level to a height, h, metres(m). Gravitational force on the ball is given as: F =mxg F = mg---------- (1) Where m is the mass of the ball in kg, g is the acceleration due to gravity in m/s2 (meter per second square). Note: On the earth surface the universal value of acceleration due to gravity(g) is 9.8 m/s2 or 10 m/s2 . The System International(S.I) unit of force is Newton( the symbol is N) named after Sir Isaac Newton who first discovered the facts about gravity. Work done is defined as the product of force and the distance covered by the object. Work done = force x distance W.D = F x h …………. (2) Recall that, f = mg from equation (1) W.D = m x g x h W.D = mgh…………… (3). This is used for calculation of work done against gravity. The S.I unit of work done is Joules (the symbol is J). Note that 1000J = 1KJ. Example 1: Calculate the gravitational force required to pull down a mango tree of mass 10kg falling with an acceleration 0f 5 m/s2 . SOLUTION Given that: F = ?, m= 5kg, a = 5 m/s2 Recall that F = mg from equation (1) F = 10 x 5 F = 50N. Example 2: Calculate the work done if a box is pulled by a person with a force of 30N through a distance of 7m. Then, SOLUTION Given that, W.D = ?, F = 30N, h = 7m Recall that W. D = F x h from equation (2) W.D = 30 x 7 = 210J Example 3: If a load of mass 12kg is raised up to a height of 40m. What is the work done in the process?(Take g=10 m/s2 ). SOLUTION Given that, W.D=?, m=12kg, g=10 m/s2 , h=40m Recall that W.D = mgh from equation (3) W.D = 12 x 10 x 40 W.D = 4800J or 4.8KJ ASSIGNMENT 1. A mass of 300g is acted upon by a force which produces an acceleration of 5m/s2. Calculate the force. 2. What is the work done by a man who lifts a block of 30kg through a height of 3 meters? (g=10m/s2). 3. How many work is done when a force of 200N is applied by a car over a distance of 6m ? 4. Suppose you lift an object of mass 2kg from the ground to height of 2m, what is the work done in lifting the object? ( Take g = 10 metres per second square). 5. Calculate the gravitational force on an object of mass 80kg which produces an acceleration of 22 meters per second square. WEEK 4 FRICTION This can be defined as any force that tries to stop a body from moving or that opposes motion. NOTE: Friction is greater when the surfaces of the body in contact are rough than when they are smooth. Friction slows down motion and acts in the opposite direction to the way they are moving. ADVANTAGES OF FRICTION 1. It enables us to stand, walk and run without falling. 2. It makes sharpening of tools like cutlass, knives etc possible. 3. It is a useful force when we tie shoe lace. 4. It is a useful force when we strike a match or sit on a chair. 5. Build up of friction between the bolts and nuts help them to stay tightened 6. It makes the use of belt possible in machines. 7. It makes a moving vehicle come to a stop whenever it brakes are applied. DISADVANTAGES OF FRICTION 1. It causes wear and tear on the moving parts of machines. 2. It causes unpleasant sound(noise) 3. It increases the cost of maintenance 4. It causes heat in any engine which can lead to breakdown of the machine. 5.It reduces motion. 6.It reduces the efficiency of machines. 7.It increases the energy required to operate machine. HOW TO REDUCE FRICTION Friction can be reduced in the following ways: 1.Use of lubricants e.g. greases and oils. 2.Polishing or Smoothening the surfaces in contact. 3.Ball-bearing or rollers reduces friction. 4.Streamlining ( shape of an object). BALANCED FORCE This is the action of two equal and opposite forces acting on a body. It makes a body to remain in equilibrium i.e. no motion occur. UNBALANCED FORCE This is the action of two unequal and unidirectional forces acting on a body. It makes a body not to be in equilibrium by causing motion to occur. WEEK 5 GRAVITATION AND WEIGHTLESSNESS The pull or attraction of the earth towards its centre is called the earth’s gravitation. MEANING OF GRAVITATION This is a type of force that acts on a body across a distance, without any contact between the source and the body. MEANING OF CENTRE OF GRAVITY The centre of gravity of an object is the point where the object is perfectly balanced. Note : The amount of force with which gravity pulls an object depends on three things: i. The mass of the object. ii. The mass of the earth iii. The distance between the centre of the object and the earth. EFFECTS OF GRAVITATION ON OBJECTS 1.It gives objects weight 2.It keeps the earth and the other planets in their orbits around the sun. 3.It keeps the moon in its orbits around the earth 4.It keeps the moon in its path in the sky. 5.It is the work against gravity that make aeroplane to fly in the sky. 6.It brings about the formation of tides for convection. MEANING OF WEIGHTLESSNESS Weightlessness is defined as a state of not experiencing the effect of gravity. Astronauts in space do not feel the effects of gravity (gravitational pull). Weightlessness in objects is observed in places with very little or no force of gravity e.g. in space and moon. Note: The weight of an object in the moon is one sixth (1/6) of the weight of the object on earth and that is why astronauts seem lighter and need special boots and clothes to walk on the moon. Example 1: If an astronaut weighs 60N on earth, what will be his weight in the moon? SOLUTION Let M= the weight of the astronauts in the moon. Since, the weight of an astronaut on the moon is 1/6 of his weight on earth Therefore, M = 1/6 x 60N M= 10N. Example 2: If an astronaut weighs 160N in the moon, what will be his weight on the earth? SOLUTION Let E = the weight of the astronaut on earth. Since, the weight of the astronaut on the moon is 1/6 of his weight on earth Therefore, 160N = 1/6 x E Cross multiply E = 160N x 6 E= 960N. HINTS: 1. To determine the weight of an object in the moon, divide the value given by 6. 2. To determine the weight of an object on the earth, multiply the value given by 6. TOPICAL EVALUATION QUESTIONS 1. Gravity depends on these factors EXCEPT A. Mass of the object B. Mass of the earth C. Distance between object and the earth D. Distance between object and the moon. 2. The force with which the earth attracts objects towards its centre is called A. Gravity B. Force C. Mass D. Joules 3. The force of gravity attracts the objects going up to the A. Moon surface B. Satellite surface C. Earth's surface D. Sun surface 4. A calibrated spring balance can be used to measure A. Magnetic force B. Weight C. Gravitational force D. Electrical force 5. Centre of gravity simply means A. Centre at which the body balance its position to operate B. Centre at which the body remains at rest C. Point at which a body remains at rest D. Point where two or more bodies meet 6. The gravitational force on the moon is about 1/6 of that of the earth. Calculate the weight of a man on the moon who weighs 90kg on earth A. 15kg B. 75kg C. 84kg D. 540kg 7. Gravitational force is a force of A. Attraction B. Separation C. Opposition D. Movement 8. Astronauts in space have one major problem which is A. Weather B. Heaviness C. Communication D. Weightlessness 9. The further away an object is from the centre of the earth, the A. more its mass B. less its mass C. more its weight D. less its weight 10. The name of the scientist that proposed the principles of gravity which have become universally accepted is A. Nelson Mandela B. Sir Isaac Newton C. Muhammad Buhari D. Wale Adenuga 11. The main reason why the earth has a great gravitational pull on objects is A. The earth has a great mass B. The earth is spherical C. The earth is rotating D. The earth can move 12. Gravitational pull causes the following EXCEPT A. Makes objects to have weight B. Causes objects to fall back when thrown up C. Causes objects to float in air D. Causes objects to feel heavy 13. The attraction exerted by the earth which makes an object fall to the ground if not supported is known as A. Earth's movement B. Earth's attraction C. Earth's gravitational attraction D. Attraction of the masses 14. -------------------- is a state of not experiencing the effect of gravity A. Force B. Push or pull C. Power D. Weightlessness 15. The weight of an object in the surface of the moon is A. One-tenth that on earth B. One-sixth that on earth C. The same with that on earth D. Twice that on earth ANSWER 1D 2 A 3C 4C 5C 6A 7A 8D 9D 10 B 11 A 12 C 13 C 14 D 15 B WEEK 6 THE EARTH IN SPACESOLAR SYSTEM, EARTH ROTATION AND ECLIPSE THE SOLAR SYSTEM The solar system consists of the sun, the eight official planets , at least three “ dwarf planets” more than 130 satellites of the planets, a large number of small bodies ( called the comets and asteroids) and the interplanetary medium. The solar system is divided into inner and outer parts. The inner solar system contains the Sun, Mercury, Venus, Earth and Mars while the outer part contains Jupiter, Saturn, Uranus, and Neptune. The two parts are demarcated by asteroid belt. ( Pluto is now classified as dwarf planet). The Eight Planets are: I. Mercury II. Venus III. Earth IV. Mars V. Jupiter VI. Saturn VII.Uranus VIII.Neptune ROTATION OF THE EARTH Rotation is the movement of the earth round its own axis. The earth rotates and completes one rotation on its axis every 24 hours. The rotation of the earth on its axis causes day and night. Therefore, one day and one night makes up the 24 hours. The Sun is a stationary body. This means that it does not move. The rotation of the earth makes it appear as if the sun is moving. THE MOON The moon is a natural satellite. A satellite is any object that revolves round a planet. Our planet ( Earth) has only one moon. Some planets have no moon at all, while others have more than one moon. PLANETS AND THEIR MOONS PLANET NUMBER OF MOONS NUMBER OF NATURAL SATELLITES MERCURY 0 0 VERNUS 0 0 EARTH 1 1 MARS 2 2 JUPITER 12 12 SATURN 10 10 URANUS 5 5 NEPTUNE 2 2 Earth’s moon is a slightly egg-shaped ball, and is composed mostly of rock and metal. It is the second brightest object after the sun. It does not produce any light of its own, but shines by reflecting the light from the sun. The moon is the ONLY place in space that humans have visited. ROTATION OF THE MOON The moon is a natural satellite of the earth and revolves round the earth once in about 27.3 days. However, for the moon to go from one phase to the next phase, it takes 29 days. This period is called the lunar months. Five phases occur during the rotation of the moon. They are as follows: I. New moon II. Quarter moon III.Half moon IV.Three quarter moon V. Full moon. REVOLUTION OF THE EARTH The revolution of the earth is the movement round the Sun. It takes 365 days (1 year) to complete one revolution round the Sun. The revolution of the earth causes seasons. There are two major seasons in a year namely summer and winter. What causes these seasons is due to the tilting of the Earth during rotation. When the earth rotates and comes to the east the northern axis tilts toward the sun causing summer while the southern axis tilts away from the sun causing winter. ECLIPSE An eclipse occurs when a heavenly body such as the moon get into the space between the earth and the Sun thereby blocking some part of the earth from receiving sunlight directly from the Sun. TYPES OF ECLIPSE There are two types of eclipse namely: 1.Eclipse of the sun 2.Eclipse of the moon 1. ECLIPSE OF THE SUN An eclipse of the sun is also called a solar eclipse. This occurs when the moon gets directly between the earth and the sun. At this period, the earth or parts of it will not see the sun for sometime during the day, until the moon moves out of that point. Another eclipse of the sun, which may occur, is the annular eclipse. This occurs when the moon is far away from the earth than usual, so that it casts a smaller shadow on earth that blocks out only the centre of the sun. So, only a partial shadow falls on the earth at this period. 2. ECLIPSE OF THE MOON The eclipse of the moon is also called Lunar Eclipse. This occurs when the earth moves between the sun and the moon. When this happens, the earth blocks the rays of light from reaching the moon, so that the shadow of the earth is cast on the moon for some time. There are two types of lunar eclipse, that is , the eclipse of the moon. (a) total lunar eclipse occurs when the earth’s shadow covers the entire moon. (b) A partial lunar eclipse occurs when the earth’s shadow falls on only a part of the moon. TOPICAL EVALUATION QUESTIONS 1. How many planets are there in the solar system? A. 6 B. 7 C. 8 D. 9 2. The Earth has A. Ten satellites B. Twenty artificial satellites C. One natural satellite D. Ten natural satellites 3. Which is the closest planet to the sun? A. Pluto B. Mercury C. Earth D. Saturn 4. The following are the components of the solar system EXCEPT A. Asteroid B. Comets C. Satellites D. Night 5. The earth takes---------- to complete one rotation around its axis per day. A. 1 hour B. 24 hours C. 27 hours D. 30 hours 6. The following form the inner solar system EXCEPT A. Mercury B. Venus C. Saturn D. Mars 7. The following form the outer solar system EXCEPT A. Neptune B. Venus C. Uranus D. Jupiter 8. The ONLY planet in the solar system with the temperature that can support life 9. Which of the following is a luminous body in the solar system? A. Earth B. Jupiter C. Saturn D. Sun 10. When the earth comes between the sun and the moon, ------------- occurs. A. Annular eclipse B. Eclipse of the moon C. Eclipse of the sun D. Partial eclipse 11. Which of the following is called a satellite of the earth? A. Asteroid B. Comet C. Moon D. Pluto 12. Seasons occur because of the A. Inclination of the earth as it rotates about its axis B. Revolution of the earth round the sun C. Rotation of the earth on its axis D. Rotation of the sun 13. The revolution of the earth causes A. Occurrence of seasons B. Day and night C. Rain and sun D. Dry and wet 14. Uranus is the ------- planet in the solar system. A. Third B. Sixth C. Second D. Seven 15. The moon revolves round the earth in ___ days. A 29 B 28 C 27.3 D 27 16. The largest planet in the universe is A. Jupiter B. Saturn C. Mercury D. Pluto 17. The planet which has disintegrated is A. Mercury B. Jupiter C. Pluto D. Saturn 18. When the moon is far from the earth such that no region of the moon falls on the earth, it results in A. Total eclipse B. Partial eclipse C. Annular eclipse D. Lunar eclipse 19. Solar system comprises of --- and ---A. Stars, moon B. Sun, planets C. Sun, metallic D. Sun, earth 20. The moon can be described as A. Comet B. Planet C. Satellite D. Star ANSWER 1C 2C 3B 4D 5B 6C 7B 8A 9D 10 B 11 C 12 B 13 A 14 D 15 C 16 A 17 C 18 C 19 B 20 C WEEK 8 SPACE TRAVEL LESSON OBJECTIVES At the end of the lesson, students should be able to: 1. explain space and space travel; 2. recall the first in space science; 3. enumerate two purposes of space travel; 4. outline four dangers of space travel. MEANING OF SPACE The place or region beyond the earth’s atmosphere is called space. MEANING OF SPACE TRAVEL Going into space (the moon, and other planets, or orbiting the earth) in a spaceship or space shuttle is called space travel. THE FIRST IN SPACE SCIENCE 1.Yuri Gagarin was the first person (male) to go to space on April 12, 1961. 2.Neil Armstrong was the first person to step on the moon on July 21, 1969. PURPOSE/ADVANTAGES OF SPACE TRAVEL 1.Advancing scientific research 2.Uniting different nations. 3.Ensuring the future survival of humanity 4.Developing strategic military advantages over other nations. 5.It helps in weather forecast and agriculture 6. It can be use to predict natural disasters using satellites 7. It helps in production of photographic equipment e.g. xray and gamma ray machines DANGERS OF SPACE TRAVEL 1.The major danger is that man cannot live permanently in the space. 2.Weightlessness 3.Explosion of rockets at the launch path or in flight. 4.Development of weak bones due to loss of calcium. 5.Failure of some necessary equipment in the spaceship to function well. 6. Space travel is risky. It may lead to loss of life e.g. The disappearance of the American Space Flight named Avenger with 11 crew members in 1980. 7. Wrong calculation of the angle, speed at the time of launching. TOPICAL EVALUATION QUESTIONS 1. The American Space Flight named Avenger suddenly disappears with how many crew members on board? A. 8 B. 9 C. 10 D. 11 2. Scientists that travel to space are called A. Archaeologist B. Astrologers C. Astronomers D. Astronauts 3. The sudden disappearance of the American Space Flight named Avenger occurred in what year A. 1908 B. 1890 C. 1809 D. 1980 4. The force needed by spaceship to keep it moving round the earth is known as------ force. A. Centrifugal B. Electrical C. Frictional D. Gravitational 5. Who was the first person to step on the moon? A. Neil Armstrong B. Jonathan Bassey C. Roberto Carlos D. Joseph Michael 6. The travel from the earth through space to other planets or earth's moon is called A. Journey B. Travelling C. Tourism D. Space travel 7. The first person to step on the moon did that in what year?I A. 1699 B. 1996 C. 1969 D.1973 8. A Russian cosmonaut who was the first man in space is by name? A. Neil Armstrong B. Yuri Gagarin C. Helen Sharman D. Valentine Tereshkova 9. Which of these is NOT a benefit of space travel? A. Weather forecast B. Alternative power source C. Land survey and navigation devices (GPS) D. Cordless tools for mass destruction 1 10. What's the full meaning of GPS? A. Gospel Preaching Students B. Global Positioning System C. God's Power Saves D. Government Public Schools 11. The Space outside the Sun, stars and planets is called A. Outer Space B. Galaxies C. Atmosphere D. Moon 12. What is the name of the special craft that could be used to travel to the Moon, planets or orbit the earth called A. Spaceship B. Sun C. Planets D. Craft ANSWER 1D 2D 3D 4D 5A 6D 7C 8B 9D 10 B 11 A 12 A WEEK 9 SPACE TRAVEL LESSON OBJECTIVES At the end of the lesson, students should be able to: 1. explain space and space travel; 2. recall the first in space science; 3. enumerate two purposes of space travel; 4. outline four dangers of space travel. MEANING OF SPACE The place or region beyond the earth’s atmosphere is called space. MEANING OF SPACE TRAVEL Going into space (the moon, and other planets, or orbiting the earth) in a spaceship or space shuttle is called space travel. THE FIRST IN SPACE SCIENCE 1.Yuri Gagarin was the first person (male) to go to space on April 12, 1961. 2.Neil Armstrong was the first person to step on the moon on July 21, 1969. PURPOSE/ADVANTAGES OF SPACE TRAVEL 1.Advancing scientific research 2.Uniting different nations. 3.Ensuring the future survival of humanity 4.Developing strategic military advantages over other nations. 5.It helps in weather forecast and agriculture 6. It can be use to predict natural disasters using satellites 7. It helps in production of photographic equipment e.g. xray and gamma ray machines DANGERS OF SPACE TRAVEL 1.The major danger is that man cannot live permanently in the space. 2.Weightlessness 3.Explosion of rockets at the launch path or in flight. 4.Development of weak bones due to loss of calcium. 5.Failure of some necessary equipment in the spaceship to function well. 6. Space travel is risky. It may lead to loss of life e.g. The disappearance of the American Space Flight named Avenger with 11 crew members in 1980. 7. Wrong calculation of the angle, speed at the time of launching. TOPICAL EVALUATION QUESTIONS 1. The American Space Flight named Avenger suddenly disappears with how many crew members on board? A. 8 B. 9 C. 10 D. 11 2. Scientists that travel to space are called A. Archaeologist B. Astrologers C. Astronomers D. Astronauts 3. The sudden disappearance of the American Space Flight named Avenger occurred in what year A. 1908 B. 1890 C. 1809 D. 1980 4. The force needed by spaceship to keep it moving round the earth is known as------ force. A. Centrifugal B. Electrical C. Frictional D. Gravitational 5. Who was the first person to step on the moon? A. Neil Armstrong B. Jonathan Bassey C. Roberto Carlos D. Joseph Michael 6. The travel from the earth through space to other planets or earth's moon is called A. Journey B. Travelling C. Tourism D. Space travel 7. The first person to step on the moon did that in what year?I A. 1699 B. 1996 C. 1969 D.1973 8. A Russian cosmonaut who was the first man in space is by name? A. Neil Armstrong B. Yuri Gagarin C. Helen Sharman D. Valentine Tereshkova 9. Which of these is NOT a benefit of space travel? A. Weather forecast B. Alternative power source C. Land survey and navigation devices (GPS) D. Cordless tools for mass destruction 1 10. What's the full meaning of GPS? A. Gospel Preaching Students B. Global Positioning System C. God's Power Saves D. Government Public Schools 11. The Space outside the Sun, stars and planets is called A. Outer Space B. Galaxies C. Atmosphere D. Moon 12. What is the name of the special craft that could be used to travel to the Moon, planets or orbit the earth called A. Spaceship B. Sun C. Planets D. Craft ANSWER 1D 2D 3D 4D 5A 6D 7C 8B 9D 10 B 11 A 12 A
