Acceptance criteria for Ultrasonic Test
(UT)
(Refer: Mandatory appendix 12 (Page 435) of ASME BPVC Section VIII Div 1, 2017 Edition.)
(a) Indications characterized as cracks, lack of fusion, or incomplete penetration are unacceptable regardless of
length.
(b) Other imperfections are unacceptable if the indications exceed the reference level amplitude and have lengths
which exceed:



6 mm (1/4 in.) for T up to 19 mm (3/4 in.)
T/3 for T from 19 mm to 57 mm (3/4 in. to 21/4 in.)
19 mm (3/4 in.) for T over 57 mm (21/4 in.)
where T is the thickness of the weld excluding any allowable reinforcement. For a butt weld joining two members
having different thicknesses at the weld, T is the thinner of these two thicknesses. If a full penetration weld includes
a fillet weld, the thickness of the throat of the fillet shall be included in T.
Please watch the video (given below) for more clarity on acceptance
criteria for Ultrasonic test (UT);
*************************
Acceptance criteria for Radiography Test
(RT)
(Refer: UW-51: Sub Para b (Page 148 and 149) and Mandatory appendix 4 (Page 400 and Page 403) of
ASME BPVC Section VIII Div 1, 2017 Edition.)
Following terminologies have been used to explain the acceptance/rejection criteria for Radiography Test (RT);
Linear Indication: Any indication with length greater than three times the width. Linear indications are mainly
cracks, lack of penetration, lack of fusion and elongated slag inclusions.
Rounded Indication: Any indication with the length equal to or less than three times the width. A rounded
indication may be of circular, elliptical, conical, or irregular in shape and may have tails. While determining the size
of an indication, the tail shall also be included. Rounded indications may appear on radiograph from any
imperfection in the weld, such as porosity, slag, or tungsten.
Acceptance criteria for Linear Indication (UW – 51):
1. Any crack, lack of penetration and lack of fusion shall not be accepted
2. Any other elongated indication, shall be considered unacceptable, which has a length greater than;
 6 mm (1/4 in.) for T up to 19 mm (3/4 in.)
 T/3 for T greater than or equal to 19 mm (3/4 in.) and less than or equal to 57 mm (2-1/4 in.) i.e. 19 mm ≤
T ≤ 57 mm.
 19 mm (3/4 in.) for T greater than 57 mm (2-1/4 in.)
(Where, ‘T’ – Thickness of the weld metal excluding any allowable reinforcement).
3. Any group of indications (in line) with an aggregate length more than T (within a length of 12T) shall be
considered unacceptable except when the distance between the successive discontinuities exceeds 6L.
(where ‘L’ is the length of the longest imperfection in the group).
Acceptance criteria for Rounded Indication
(Mandatory appendix 4):
According to this appendix, those rounded indications which exceed the following dimensions shall be considered
relevant.




T/10 for T less than 3 mm (1/8 in.)
0.5 mm (1/64 in.) for T from 3 mm to 6 mm (1/8 in. to 1/4 in.), inclusive
1.0 mm (1/32 in.) for t greater than 6 mm to 50 mm (1/4 in. to 2 in.), inclusive
1.5 mm (1/16 in.) for T greater than 50 mm (2 in.)
Apart from the above conditions, Mandatory appendix 4 also contains some tables, charts and figures as a reference
for acceptance/rejection criteria.
Please watch the video (given below) for more clarity on acceptance
criteria for Radiogrphy test (RT);
Acceptance criteria for Visual Inspection
(Refer: UIG-97, Page – 345 of of ASME BPVC Section VIII Div 1, 2017 Edition.)
(a) The surface shall be free of any visible laminations, spalling, or cracks. Cracks in tubes shall not be repaired and
shall be considered cause for rejection.
(b) For tubes, scratches shall not exceed 1/32 in. (0.8 mm) in depth. For all other material, scratch depth shall not
exceed 1/8 in. (3 mm).
For acceptable limit of thickness reduction, Refer UW-35 (sub para b, page – 144) which states that:

The reduction in thickness shall not exceed 1mm (1/32 in.) or 10% of material nominal thickness
whichever is less, provided that the material of the adjoining surfaces below the design thickness at any
point.
For allowable limit of Weld Reinforcement, Refer UW-35 (sub para-d, Page – 144)
*************************
Acceptance criteria for Liquid Penetrant
Test
(Refer: Mandatory appendix 8 (Page 417) of ASME BPVC Section VIII Div 1, 2017 Edition.)
Following terminologies have been used to explain the acceptance/rejection criteria for Liquid Penetrant
Examination (PT).
Relevant Indications: Indications with major dimensions greater than 1.5 mm (1/16 in.) shall be considered
relevant.
Linear Indication: Any indication with length greater than three times the width.
Rounded Indication: Any indication with the length equal to or less than three times the width. A rounded
indication may be of circular or elliptical shape.
Acceptance Criteria for Liquid Penetrant Examination
(Mandatory appendix 8):
All surfaces to be examined shall be free of:
(a) Relevant linear indications shall be rejected.
(b) Relevant rounded indications greater than 5 mm (3/16 in.) shall be rejected.
(c) Four or more relevant rounded indications in a line separated by 1.5 mm (1/16 in.) or less (edge to edge).
*************************
Acceptance criteria for Magnetic Particle
Test (MT)
(Refer Mandatory appendix 6 (Page 412) of ASME BPVC Section VIII Div 1, 2017 Edition. Acceptance
criteria is same as that of Liquid Penetrant Examination)
Following terminologies have been used to explain the acceptance/rejection criteria for Magnetic Particle Test (PT).
Relevant Indications: Indications with major dimensions greater than 1.5 mm (1/16 in.) shall be considered
relevant.
Linear Indication: Any indication with length greater than three times the width.
Rounded Indication: Any indication with the length equal to or less than three times the width. A rounded
indication may be of circular or elliptical shape.
Acceptance Criteria for Magnetic Particle
Examination (Mandatory appendix 6):
All surfaces to be examined shall be free of:
(a) Relevant linear indications shall be rejected.
(b) Relevant rounded indications greater than 5 mm (3/16 in.) shall be rejected.
(c) Four or more relevant rounded indications in a line separated by 1.5 mm (1/16 in.) or less (edge to edge).
