RPG Video Series
Contents
EXER0101 – “Hello World”, Your First RPG Program. ............................................................................................. 2
EXER0102 – Adding Two Numbers .......................................................................................................................... 4
EXER0201 – This program and print file produces a list of customers in arrive sequence. .................................... 5
EXER0301 – This program accepts a character variable and displays it. ................................................................ 7
EXER0302 – This program allows a user to maintain a customer master file......................................................... 9
EXER0401 – Customer Listing using arrays and Data Structures .......................................................................... 13
EXER0402 - Redo CRUD application with data structures for file I/O ................................................................... 16
EXER0501 – This program allows a user to maintain a customer master file....................................................... 21
EXER0502 – Customer Master Listing with Control-Break Logic .......................................................................... 27
EXER0601 & EXER0602– Customer Master Updates using Service Program ....................................................... 29
EXER0701 – No Documentation ............................................................................................................................ 36
EXER0801 – This program demonstrates using RPG Built-In Functions................................................................ 37
EXER0902 – Subfile program for Order Entry and Maintenance application ....................................................... 42
EXER1001 – This program accepts two parameters and displays a list of items ................................................. 51
EXER1002 & EXER1003 – Displays a list of open orders, allows an order to be deleted, changed or viewed. .... 59
RPGVideo_AttendeeWorkbook.docx
1 of 79
EXER0101 – “Hello World”, Your First RPG Program.
The program demonstrates the following concepts:
•
•
•
•
•
•
•
•
•
Entering RPG program source
Declaring a program as free format
Declaring a character variable in RPG
Assigning a value to a variable
Displaying data with the DSPLY operation code
Ending an RPG program
Saving source code
Creating an RPG program
Running an RPG program
You Will Need a Library to Work In
A library is a cross between a “schema” that you might find in database software, and a “folder” that you
might use on a PC. It is used to store database tables like a schema, but is also used to store source code,
programs, and many other things.
On other platforms, the things you store in a folder are often referred to as “files”, but on IBM i the term “file”
is only used for data files. Instead, we use the term “object” to refer to the various things that can be placed in
a library. Program, file, and other things are “object types.”
You should check with your system administrator to find out if you already have a library that you can use to
create programs while you are learning. If you don’t already have one, you can create one from the IBM i
command line with the following command (replace EXAMPLE with the name of your library):
CRTLIB LIB(EXAMPLE)
In your library you will need a file for storing RPG source code. If you don’t already have one, you can create
one from the command line with the following command (replace EXAMPLE with the name of your library):
CRTSRCPF FILE(EXAMPLE/QRPGLESRC) RCDLEN(112)
The name QRPGLESRC is the traditional name of a source file for storing RPG source code. A source file is not
limited to only one program’s source, it can contain as many as you like. Each program’s source is called a
“source member”. Libraries, objects, files and members will be discussed further in the next video.
Program Source for EXER0101
**FREE
// *************************************************************
// Written - Scott Klement
*
// *************************************************************
dcl-s Hello char(12);
dcl-s keypress char(1);
Hello = 'Hello World';
DSPLY Hello '' keypress;
*INLR = *ON;
RETURN;
RPGVideo_AttendeeWorkbook.docx
2 of 79
Tell RDi Where to Put Your Program
New program objects are put into your “current library.” To set the current library in RDi, follow these steps:
•
•
•
•
In RDi’s “Remote Systems” view, expand your IBM i connection
Expand “Objects”
Right-click “Library List”
Use the “Change Current Library” option to set it to your library
Compile Your Program
• Make sure your source member is selected by clicking on the tab
• Click Compile, then the Compile option from the drop-down
• Choose CRTBNDRPG
Run Your Program
• Use the EDTLIBL command to add your library to the library list
• Type: CALL EXER0101
RPGVideo_AttendeeWorkbook.docx
3 of 79
EXER0102 – Adding Two Numbers
The program demonstrates the following concepts:
•
•
•
•
•
Declaring Integers
Using the DSPLY opcode for input
Adding numbers
Concatenating character data
Upper and lowercase work the same
Since you’ve already done one example, this one should be easy! Enter the source code into RDi, compile it,
and run it.
Program Source for EXER0102
**free
// *************************************************************
// Written - Scott Klement
*
// *************************************************************
dcl-s var1 int(10);
dcl-s var2 int(10);
dcl-s result int(10);
dcl-s keypress char(1);
dsply ('Enter the first number') '' var1;
dsply ('Enter the second number') '' var2;
result = var1+var2;
dsply ('Result is ' + %char(result)) '' keypress;
dsply ('Enter a number') '' var1;
*inlr = *on;
RETURN;
RPGVideo_AttendeeWorkbook.docx
4 of 79
EXER0201 – This program and print file produces a list of customers in arrive sequence.
The program demonstrates the following concepts:
•
•
•
•
•
One of the uses of the Ctl-Opt Keyword
Opening Print files and data files.
A simple example of the Dcl-S keyword
The READ keyword for sequentially reading a database file
The use of the DOW keyword to loop through a DB2 table
The print file EXER0201P used to produce the Customer listing
Printer Output from EXER0201
Program Source for EXER0201
RPGVideo_AttendeeWorkbook.docx
5 of 79
// * Control Options Section
Ctl-opt Option(*Nodebugio);
// *************************************************************
// Creates a listing of CloudServices247 Inc customers
*
// EXER0201 - COMMON RPG Video Series
*
// Written Jim Buck 12-01-16
*
// *************************************************************
Dcl-F CSCSTP Disk(*Ext) Usage(*input);
Dcl-F EXER0201P Printer(*ext) Usage(*Output) Oflind(EndOfPage);
// * Declarations Section
Dcl-s EndOfPage Ind Inz(*on);
// * Main Section
Read CSCSTP;
// Read the First Record
Dow NOT %EOF;
RPTMESSAGE = *Blanks;
// Check the Balance Due field and assign value to message field
Select;
When BALDUE < 0;
RPTMESSAGE = 'BALDUE is less than Zero';
When BALDUE > 0 and BALDUE < 500;
RPTMESSAGE = 'BALDUE is > 0 and < 500';
When BALDUE > 500 and BALDUE < 1000;
RPTMESSAGE = 'BALDUE is > 500 and < 1000';
When BALDUE > 1000;
RPTMESSAGE = 'BALDUE is > 1000';
Other;
RPTMESSAGE = 'Other BALDUE Values!';
ENDSL;
// Check for the End of Page
If Endofpage;
Write Heading; // Write Heading on report
Endofpage = *Off;
Endif;
Write Detail; // Write a detail line on the report
READ CSCSTP;
EndDo;
// Turn on last record indicator and return to caller
*INLR = *ON;
Return;
RPGVideo_AttendeeWorkbook.docx
6 of 79
EXER0301 – This program accepts a character variable and displays it.
The program demonstrates the following concepts:
•
•
•
•
•
•
Displaying an input screen and then display the information on a second screen
The use of the DOW keyword to loop until the user wants to exit the screen
Introduction to INDARA keyword & INNDS data structure
Use of F3 and F12 function keys (CA keys)
Use of keywords COLOR and EDTWRD
A simple example of the Dcl-S keyword
The Display file EXER0301D used to produce the Customer Update Application
Display Customer data from EXER0301 using the EXER0301D Display file
RPGVideo_AttendeeWorkbook.docx
7 of 79
Program Source for EXER0301
// *************************************************************
// This program accepts a name and then after the user presses *
// the Enter key. The program displays the value entered on the*
// previous screen
*
// Written - Jim Buck - 02-25-2017
*
// *************************************************************
Dcl-f Exer0301D WORKSTN INDDS(Indicators);
// Indicator Data Structure
Dcl-ds Indicators Len(99);
Exit
ind Pos(3) inz(*off);
Cancel
ind Pos(12);
End-ds;
// Stand Alone Variables
Dcl-s PgmName char(9) inz('Exer0301');
// *******************************************************
// Loop until user presses the Exit (F3) Key
// *******************************************************
DOW NOT Exit;
Reset Name;
EXFMT InputSrcn; // Display the Enter Name Screen
// Figure out what happened in the screen
SELECT;
WHEN Exit;
LEAVE;
// Leave loop and Exit the program
WHEN Cancel;
ITER;
// Loop again
ENDSL;
EXFMT DspScrn; // Display Name Entered
ENDDO;
*INLR = *ON;
RETURN;
// ************************************************************
RPGVideo_AttendeeWorkbook.docx
8 of 79
EXER0302 – This program allows a user to maintain a customer master file.
The program demonstrates the following concepts:
•
•
•
•
•
•
The use of the DOU keyword to loop until the user wants to exit the screen
The CHAIN, WRITE, DELETE and UPDATE keywords to manipulate a database file
One of the uses of the Ctl-Opt Keyword
Opening Display files and data files.
An expanded example of the Dcl-ds keyword
Additional use of DDS keywords – CHECK, DSPATR, EDTWRD and EDTCDE
The Display file EXER0302D used to produce the Customer Update Application
Display Customer data from EXER0302 using the EXER0302D Display file
RPGVideo_AttendeeWorkbook.docx
9 of 79
Program Source for EXER0302
// *************************************************************
// This program allows users to interactively maintain Cloud- *
// Services Customer Mstr file by adding, changing, and dele- *
// ing records. For adds, the next customer number is assigned*
// by the system. Customer's whose balance is greater than
*
// zero cannot be deleted.
*
// Written - Jim Buck - 02-25-2017
*
// *************************************************************
Dcl-f CSCSTP
DISK(*ext) keyed Usage(*Update:*Delete:*Output);
Dcl-f Exer0302D WORKSTN INDDS(Indicators);
// Indicator Data Structure
Dcl-ds Indicators Len(99);
Exit
ind Pos(3) inz(*off);
FkeyPressed ind Pos(10) Inz(*off);
Cancel
ind Pos(12);
BalDueError ind Pos(30);
RecNotFound ind Pos(90);
UpdateError ind Pos(91);
ProtectField ind Pos(92) inz;
End-ds;
// Stand Alone Variables
Dcl-s PgmName char(9) inz('Exer0302');
Dcl-s Errormsg char(20);
// *******************************************************
// Loop until user presses the Exit (F3) Key
// *******************************************************
DOU Exit;
CustIn = 0;
Exsr ClearFields;
EXFMT InputScrn; // Display the Enter Custnbr Screen
// Figure out what happened in the screen
SELECT;
WHEN Exit;
LEAVE;
// Leave loop and Exit the program
WHEN Cancel;
ITER;
// Loop again
WHEN Action = 'A';
EXSR AddRecord;
WHEN Action = 'C';
EXSR ChangeRecord;
WHEN Action = 'D';
EXSR DeleteRecord;
Other;
ITER;
ENDSL;
ENDDO;
*INLR = *ON;
RETURN;
RPGVideo_AttendeeWorkbook.docx
10 of 79
// *******************************************************
// * Add A Record
// *******************************************************
BEGSR AddRecord;
Mode = 'Add';
EXSR AssignNextNbr; // Assign the next Customer Number
EXFMT DispScrn;
IF NOT FkeyPressed;
CustNo = CustIn;
WRITE(E) CustRec;
// Write a new record
UpdateError = %ERROR;
ENDIF;
ENDSR;
// ******************************************************
// * Get Next Customer Number - Not used to be used in production
// ******************************************************
BEGSR AssignNextNbr;
SETGT 999999 CSCSTP;
// Determine last customer number
READP CSCSTP;
// Read the previous record
CustIn = CustNo + 1;
// Increment for new customer
EXSR ClearFields;
// Clear out the fields
ENDSR;
// ******************************************************
// * Change a Record
// ******************************************************
BEGSR ChangeRecord;
Mode = 'Change';
IF NOT FkeyPressed;
CHAIN CustIn CSCSTP;
RecNotFound = NOT %FOUND;
SELECT;
WHEN FkeyPressed;
LEAVESR;
WHEN RecNotFound;
ErrorMsg = 'Record Not Found';
LEAVESR;
WHEN NOT RecNotFound;
EXFMT DispScrn;
CustNo = CustIn;
UPDATE(E) CustRec; // Update the record
UpdateError = %ERROR;
ENDSL;
ENDIF;
ENDSR;
RPGVideo_AttendeeWorkbook.docx
11 of 79
// ***********************************************************
// * Delete a Record if they don't have a Balance
// ***********************************************************
BEGSR DeleteRecord;
Mode = 'Delete';
IF NOT FkeyPressed;
CHAIN CustIn CSCSTP;
RecNotFound = NOT %FOUND;
BalDueError = (BalDue > 0); // Balance is greater than zero; can't delete
SELECT;
WHEN FkeyPressed;
LEAVESR;
WHEN RecNotFound;
ErrorMsg = 'Record Not Found';
LEAVESR;
WHEN BalDueError;
ErrorMsg = 'Balance Due > Zero';
LEAVESR;
WHEN NOT BalDueError;
ProtectField = *on;
// Turn on to protect the fields from change
EXFMT DispScrn;
ProtectField = *off;
DELETE(E) CustRec;
UpdateError = %ERROR;
ENDSL;
ENDIF;
ENDSR;
// ************************************************************
// * Clear out the fields
// ************************************************************
BEGSR ClearFields;
RESET Custrec;
ErrorMsg = *Blank;
RESET BalDueError;
RESET RecNotFound;
RESET UpdateError;
ENDSR;
// ************************************************************
RPGVideo_AttendeeWorkbook.docx
12 of 79
EXER0401 – Customer Listing using arrays and Data Structures
This program splits a phone number area code, looks up the full state name from an array, and prints the
report with a defined printer file.
The program demonstrates the following concepts:
•
•
•
•
•
•
Declares Files (Dcl-F), Stand-alone variables (Dcl-S), and Data Structures (Dcl-DS)
Shows *N usage within Data Structures
Shows initializing variables
Shows overview of a printer file
Shows Read, DoW, %EOF, If, and Write keywords.
Shows %Subst, %EditC, and %Dec keywords.
The Printer file PROG401P used to produce the report for the Area Code Listing.
Records
Real Time Display
Properties of each field
RPGVideo_AttendeeWorkbook.docx
13 of 79
// * Control Options Section
Ctl-opt Option(*Nodebugio);
// *************************************************************
// Splits Phone Number Area Code and Prints on Report
*
// Array
*
// PROG401 - COMMON RPG Video Series
*
// Written Jim Buck 03-15-17
*
// Revised Kody Robinson
*
// *************************************************************
Dcl-F CSCSTP Disk(*Ext) Usage(*input);
Dcl-F Prog401P Printer(*ext) Usage(*Output) Oflind(EndOfPage);
// * Declarations Section
Dcl-S AreaCode Packed(3:0);
Dcl-S EndOfPage Ind Inz(*on);
Dcl-S Position Packed(5:0);
Dcl-S Statename Char(14);
Dcl-Ds Abbreviations;
*n
Char(30)
INZ('ALAKAZARCACOCTDEFLGAHIIDILINIA');
*n
Char(30)
INZ('KSKYLAMEMDMAMIMNMSMOMTNENVNHNJ');
*n
Char(30)
INZ('NMNYNCNDOHOKORPARISCSDTNTXUTVT');
*n
Char(10)
INZ('VAWAWVWIWY');
ABBREV
Char(2)
Pos(1) DIM(50);
End-Ds;
//
Dcl-Ds NAMES;
*n
Char(14)
INZ('Alabama');
*n
Char(14)
INZ('Alaska');
*n
Char(14)
INZ('Arizona');
*n
Char(14)
INZ('Arkansas');
*n
Char(14)
INZ('California');
*n
Char(14)
INZ('Colorado');
*n
Char(14)
INZ('Connecticut');
*n
Char(14)
INZ('Delaware');
*n
Char(14)
INZ('Florida');
*n
Char(14)
INZ('Georgia');
*n
Char(14)
INZ('Hawaii');
*n
Char(14)
INZ('Idaho');
*n
Char(14)
INZ('Illinois');
*n
Char(14)
INZ('Indiana');
*n
Char(14)
INZ('Iowa');
*n
Char(14)
INZ('Kansas');
*n
Char(14)
INZ('Kentucky');
*n
Char(14)
INZ('Louisiana');
*n
Char(14)
INZ('Maine');
*n
Char(14)
INZ('Maryland');
*n
Char(14)
INZ('Massachusetts');
*n
Char(14)
INZ('Michigan');
*n
Char(14)
INZ('Minnesota');
*n
Char(14)
INZ('Mississippi');
*n
Char(14)
INZ('Missouri');
*n
Char(14)
INZ('Montana');
*n
Char(14)
INZ('Nebraska');
*n
Char(14)
INZ('Nevada');
RPGVideo_AttendeeWorkbook.docx
14 of 79
*n
Char(14)
INZ('New Hampshire');
*n
Char(14)
INZ('New Jersey');
*n
Char(14)
INZ('New Mexico');
*n
Char(14)
INZ('New York');
*n
Char(14)
INZ('North Carolina');
*n
Char(14)
INZ('North Dakota');
*n
Char(14)
INZ('Ohio');
*n
Char(14)
INZ('Oklahoma');
*n
Char(14)
INZ('Oregon');
*n
Char(14)
INZ('Pennsylvania');
*n
Char(14)
INZ('Rhode Island');
*n
Char(14)
INZ('South Carolina');
*n
Char(14)
INZ('South Dakota');
*n
Char(14)
INZ('Tennessee');
*n
Char(14)
INZ('Texas');
*n
Char(14)
INZ('Utah');
*n
Char(14)
INZ('Vermont');
*n
Char(14)
INZ('Virginia');
*n
Char(14)
INZ('Washington');
*n
Char(14)
INZ('West Virginia');
*n
Char(14)
INZ('Wisconsin');
*n
Char(14)
INZ('Wyoming');
STATE
Char(14)
Pos(1) DIM(50);
End-Ds;
//
//*******************************************************************//
//
MainLineLogic
//
//*******************************************************************//
// Reset Fields
AreaCode = *Zeros;
// Read First Record
Read CSCSTP;
// Loop until End-Of-File
Dow NOT %EOF;
// Get area code from phone number file (first three numbers)
AreaCode = %Dec(%Subst(%EditC(CPHONE:'X'):1:3):3:0);
// Get State Name
Position = %Lookup(CSTATE:Abbrev);
If Position > 0;
Statename = State(Position);
EndIf;
// Check for the End of Page
If Endofpage;
Write Heading; // Write Heading on report
Endofpage = *Off;
Endif;
Write Detail; // Write a detail line on the report
READ CSCSTP;
EndDo;
// Turn on last record indicator and return to caller
*INLR = *ON;
Return;
RPGVideo_AttendeeWorkbook.docx
15 of 79
EXER0402 - Redo CRUD application with data structures for file I/O
This program allows users to interactively maintain the master file by adding, changing, and deleting the
records within it.
The program demonstrates the following concepts:
•
•
•
•
Declares Files (Dcl-F), Stand-alone variables (Dcl-S), and Data Structures (Dcl-DS)
o Indicator Data Structure
o Data Structure as Input/Output
o WORKSTN INDDS – pass in DS for indicators
DoU, Select(s), Subroutines, When,
Embedded functions
The Screen PROG402FM is broken down into two screens, or “records.” The first, INPUTSCRN, lets you enter
a customer number (CUSTIN) and then the action code (ACTION). Selecting add will let you input from
scratch on the next screen. Change, will populate the information currently in the database and then update
it. Delete will delete.
RPGVideo_AttendeeWorkbook.docx
16 of 79
// * Control Options Section
Ctl-opt Option(*Nodebugio);
// *************************************************************
// This program allows users to interactively maintain Cloud- *
// Services Customer Mstr file by adding, changing, and dele- *
// ing records. For adds, the next customer number is assigned*
// by the system. Customer's whose balance is greater than
*
// zero cannot be deleted.
*
// Written - Kody Robinson - 03/21/17
*
// *************************************************************
Dcl-f CSCSTP
DISK(*ext) keyed Usage(*Update:*Delete:*Output);
Dcl-f Prog402FM WORKSTN INDDS(Indicators);
// Data Structure for I/O
Dcl-Ds CusData qualified;
Dcl-SubF CusDataIn
likerec(CustRec:*input);
Dcl-SubF CusDataOut
likerec(CustRec:*output)
overlay(In);
End-Ds;
// Indicator Data Structure
Dcl-ds Indicators Len(99);
Exit
ind Pos(3) inz(*off);
RPGVideo_AttendeeWorkbook.docx
17 of 79
FkeyPressed ind Pos(10) Inz(*off);
Cancel
ind Pos(12);
BalDueError ind Pos(30);
RecNotFound ind Pos(90);
UpdateError ind Pos(91);
ProtectField ind Pos(92) inz;
End-ds;
// Stand Alone Variables
Dcl-s PgmName char(9) inz('Exer0302');
Dcl-s Errormsg char(20);
// *******************************************************
// Loop until user presses the Exit (F3) Key
// *******************************************************
DOU Exit;
CustIn = 0;
Exsr ClearFields;
EXFMT InputScrn; // Display the Enter Custnbr Screen
// Figure out what happened in the screen
SELECT;
WHEN Exit;
LEAVE;
// Leave loop and Exit the program
WHEN Cancel;
ITER;
// Loop again
WHEN Action = 'A';
EXSR AddRecord;
WHEN Action = 'C';
EXSR ChangeRecord;
WHEN Action = 'D';
EXSR DeleteRecord;
Other;
ITER;
ENDSL;
ENDDO;
*INLR = *ON;
RETURN;
// *******************************************************
// * Add A Record
// *******************************************************
BEGSR AddRecord;
Mode = 'Add';
EXSR AssignNextNbr; // Assign the next Customer Number
EXFMT DispScrn;
IF NOT FkeyPressed;
CustNo = CustIn;
WRITE(E) CustRec CusDataOut;
// Write a new record
UpdateError = %ERROR;
ENDIF;
ENDSR;
// ******************************************************
// * Get Next Customer Number - Not used to be used in production
// ******************************************************
BEGSR AssignNextNbr;
SETGT 999999 CSCSTP;
// Determine last customer number
READP CSCSTP;
// Read the previous record
RPGVideo_AttendeeWorkbook.docx
18 of 79
CustIn = CustNo + 1;
EXSR ClearFields;
ENDSR;
// Increment for new customer
// Clear out the fields
// ******************************************************
// * Change a Record
// ******************************************************
BEGSR ChangeRecord;
Mode = 'Change';
IF NOT FkeyPressed;
CHAIN CustIn CustRec CusDataIn;
RecNotFound = NOT %FOUND;
SELECT;
WHEN FkeyPressed;
LEAVESR;
WHEN RecNotFound;
ErrorMsg = 'Record Not Found';
LEAVESR;
WHEN NOT RecNotFound;
EXFMT DispScrn;
CustNo = CustIn;
UPDATE(E) CustRec CusDataOut; // Update the record
UpdateError = %ERROR;
ENDSL;
ENDIF;
ENDSR;
// ***********************************************************
// * Delete a Record if they don't have a Balance
// ***********************************************************
BEGSR DeleteRecord;
Mode = 'Delete';
IF NOT FkeyPressed;
CHAIN CustIn CustRec CusDataIn;
RecNotFound = NOT %FOUND;
// Balance is greater than zero; can't delete
BalDueError = (BalDue > 0);
SELECT;
WHEN FkeyPressed;
LEAVESR;
WHEN RecNotFound;
ErrorMsg = 'Record Not Found';
LEAVESR;
WHEN BalDueError;
ErrorMsg = 'Balance Due > Zero';
LEAVESR;
// Turn on to protect the fields from change
WHEN NOT BalDueError;
ProtectField = *on;
EXFMT DispScrn;
ProtectField = *off;
DELETE(E) CustRec CusDataOut;
UpdateError = %ERROR;
ENDSL;
ENDIF;
ENDSR;
RPGVideo_AttendeeWorkbook.docx
19 of 79
// ************************************************************
// * Clear out the fields
// ************************************************************
BEGSR ClearFields;
RESET Custrec;
ErrorMsg = *Blank;
RESET BalDueError;
RESET RecNotFound;
RESET UpdateError;
ENDSR;
// *********************************************************
RPGVideo_AttendeeWorkbook.docx
20 of 79
EXER0501 – This program allows a user to maintain a customer master file.
These programs demonstrates the following concepts:
Define and use Control Break Logic (not using the cycle)
Declare and use Iteration
Declare and use DOW, DOU and FOR Operations
Declare and use Subprocedures
Declaring local variables
Parameters & Return values
Passing Parameters by Value
Calling Programs
Prototypes procedure interfaces
The Display file EXER0501D used to produce the Customer Update Applicatio
Create – a database record
Read –
a database record
Update – a database record
Delete – a database record
RPGVideo_AttendeeWorkbook.docx
21 of 79
// * Control Options Section
Ctl-opt Option(*Nodebugio) DFTACTGRP(*no);
// *************************************************************
// This program allows users to interactively maintain Cloud- *
// Services Customer Mstr file by adding, changing, and dele- *
// ing records. For adds, the next customer number is assigned*
// by the system. Customer's whose balance is greater than
*
// zero cannot be deleted.
*
// Written - Jim Buck - 03/22/2017
*
// *************************************************************
Dcl-f CSCSTP DISK(*ext) keyed Usage(*Update:*Delete:*Output);
Dcl-f DisplayScreen WORKSTN Qualified Alias ExtFile(*extdesc)
ExtDesc('EXER0501D') indds(indicators);
// Copy in the Prototypes
/copy BCRPG/QRPGLESRC,EXER0501CP
// Indicator Data Structure
Dcl-ds Indicators Len(99);
Exit
ind Pos(3) inz(*off);
FkeyPressed ind Pos(10) Inz(*off);
Cancel
ind Pos(12);
BalDueError ind Pos(30);
RecNotFound ind Pos(90);
UpdateError ind Pos(91);
ProtectField ind Pos(92) inz;
End-ds;
// Data Structure for Screen I/O
Dcl-Ds InputScreenDS likerec(DisplayScreen.InputScrn:*all);
Dcl-Ds CustDataInDS likerec(DisplayScreen.DispScrn:*All);
// Data Structures for Database I/O
Dcl-Ds CSCSTPDataIODS Ext ExtName('CSCSTP':*All) Qualified
End-DS;
// Stand Alone Variables
Dcl-s PgmName char(9) inz('Exer0501');
Dcl-s CustInWrk Packed(6:0);
// *******************************************************
// Loop until user presses the Exit (F3) Key
// *******************************************************
DOU Exit;
ClearFields();
// Display the Enter Custnbr Screen
EXFMT DisplayScreen.InputScrn InputScreenDS;
CustInWrk = InputScreenDS.CustNo;
// Reset screen indicators
RESET BalDueError;
RESET RecNotFound;
RESET UpdateError;
// Figure out what happened in the screen
SELECT;
WHEN Exit;
LEAVE;
// Leave loop and Exit the program
WHEN Cancel;
ITER;
// Loop again
WHEN InputScreenDS.Action = 'A';
RPGVideo_AttendeeWorkbook.docx
22 of 79
AddRecord();
WHEN InputScreenDS.Action = 'C';
ChangeRecord();
WHEN InputScreenDS.Action = 'D';
DeleteRecord();
Other;
ITER;
ENDSL;
ENDDO;
*INLR = *ON;
RETURN;
// *******************************************************
// * Add A Record
// *******************************************************
Dcl-Proc AddRecord;
AssignNextNbr(); // Assign the next Customer Number
CustDataInDS.Mode = 'Add';
CustDataInDS.CustNo = CustInWrk;
EXFMT DisplayScreen.DispScrn CustDataInDS;
IF NOT FkeyPressed;
EVAL-CORR CSCSTPDataIODS = CustDataInDS;
UpdateError =
WriteCSCSTP_Data(CSCSTPDataIODS:CustInWrk);
ENDIF;
End-Proc;
// ******************************************************
// * Get Next Customer Number - Not used to be used in production
// ******************************************************
Dcl-Proc AssignNextNbr;
SETGT 999999 CSCSTP;
// Determine last customer number
READP CSCSTP;
// Read the previous record
CustInWrk = CustNo + 1; // Increment for new customer
ClearFields();
// Clear out the fields
End-Proc;
// ******************************************************
// * Change a Record
// ******************************************************
Dcl-Proc ChangeRecord;
CustDataInDS.Mode = 'Change';
IF NOT FkeyPressed;
RecNotFound =
GetCSCSTP_Data(CSCSTPDataIODS:CustInWrk);
SELECT;
WHEN FkeyPressed;
Return;
WHEN RecNotFound;
// ErrorMsg = 'Record Not Found';
Return;
WHEN NOT RecNotFound;
EVAL-CORR CustDataInDS = CSCSTPDataIODS;
EXFMT DisplayScreen.DispScrn CustDataInDS;
IF NOT FkeyPressed;
Eval-corr CSCSTPDataIODS = CustDataInDS;
UpdateError =
UpdateCSCSTP_Data(CSCSTPDataIODS:CustInWrk);
RPGVideo_AttendeeWorkbook.docx
23 of 79
Endif;
ENDSL;
ENDIF;
End-Proc;
// ***********************************************************
// * Delete a Record if they don't have a Balance
// ***********************************************************
Dcl-Proc DeleteRecord;
CustDataInDS.Mode = 'Delete';
IF NOT FkeyPressed;
RecNotFound = GetCSCSTP_Data(CSCSTPDataIODS:CustInWrk);
Eval-corr CustDataInDS = CSCSTPDataIODS;
// Balance is greater than zero; can't delete
BalDueError = (CustDataInDS.BalDue > 0);
SELECT;
WHEN FkeyPressed;
Return;
WHEN RecNotFound;
// ErrorMsg = 'Record Not Found';
Return;
WHEN BalDueError;
// ErrorMsg = 'Balance Due > Zero';
Return;
WHEN NOT BalDueError;
// Turn on to protect the fields from change
ProtectField = *on;
EXFMT DisplayScreen.DispScrn CustDataInDS;
ProtectField = *off;
IF NOT FkeyPressed;
Eval-corr CSCSTPDataIODS = CustDataInDS;
UpdateError = DeleteCSCSTP_Data(CSCSTPDataIODS:CustInWrk);
EndIf;
ENDSL;
ENDIF;
End-Proc;
// ************************************************************
// * Retrieves DB2 Data For CSCSTP
// ************************************************************
Dcl-Proc GetCSCSTP_Data;
Dcl-Pi *N IND;
CSCSTPDataDS LIKEDS(CSCSTPDataIODS);
CustNbrWrk Packed(6:0);
End-Pi ;
Dcl-s RecNotFound Ind;
CHAIN(E) CustNbrWrk CustRec CSCSTPDataDS;
RecNotFound = NOT %FOUND;
return RecNotFound;
End-Proc;
// ************************************************************
// * Deletes DB2 Data For CSCSTP
// ************************************************************
Dcl-Proc DeleteCSCSTP_Data;
Dcl-Pi *N IND;
RPGVideo_AttendeeWorkbook.docx
24 of 79
CSCSTPDataDS LIKEDS(CSCSTPDataIODS);
CustNbrWrk Packed(6:0);
End-Pi ;
Dcl-s DeleteError Ind;
DELETE(E) CustNbrWrk CustRec;
DeleteError = %ERROR;
return DeleteError;
End-Proc;
// ************************************************************
// * Updates DB2 Data For CSCSTP
// ************************************************************
Dcl-Proc UpDateCSCSTP_Data;
Dcl-Pi *N IND;
CSCSTPDataDS LIKEDS(CSCSTPDataIODS);
CustNbrWrk Packed(6:0);
End-Pi ;
Dcl-s UpDateError Ind;
UPDATE(E) CustRec CSCSTPDataDS;
UpDateError = %ERROR;
return UpDateError;
End-Proc ;
// ************************************************************
// * Adds New DB2 Data For CSCSTP
// ************************************************************
Dcl-Proc WriteCSCSTP_Data;
Dcl-Pi *N IND;
CSCSTPDataDS LIKEDS(CSCSTPDataIODS);
CustNbrWrk Packed(6:0);
End-Pi ;
Dcl-s WriteError Ind;
WRITE(E) CustRec CSCSTPDataDS;
WriteError = %ERROR;
return WriteError;
End-Proc;
// ************************************************************
// * Clear out the fields
// ************************************************************
Dcl-Proc ClearFields;
RESET Custrec;
CLEAR CustDataInDS;
CLEAR InputScreenDS;
CLEAR CSCSTPDataIODS;
CustDataInDs.PgmName = PgmName;
InputScreenDS.PgmName = PgmName;
End-Proc;
RPGVideo_AttendeeWorkbook.docx
25 of 79
// ************************************************************
// Prototypes used for CSCSTP CRUD Application
*
// Written: Jim Buck 03-20-2017
*
// ************************************************************
DCL-PR DeleteCSCSTP_Data IND;
CSCSTPDataDS LIKEDS(CSCSTPDataIODS);
CustNbrWrk Packed(6:0);
END-PR ;
DCL-PR GetCSCSTP_Data IND;
CSCSTPDataDS LIKEDS(CSCSTPDataIODS);
CustNbrWrk Packed(6:0);
END-PR ;
DCL-PR UpDateCSCSTP_Data IND;
CSCSTPDataDS LIKEDS(CSCSTPDataIODS);
CustNbrWrk Packed(6:0);
END-PR ;
DCL-PR WriteCSCSTP_Data IND;
CSCSTPDataDS LIKEDS(CSCSTPDataIODS);
CustNbrWrk Packed(6:0);
END-PR ;
RPGVideo_AttendeeWorkbook.docx
26 of 79
EXER0502 – Customer Master Listing with Control-Break Logic
// * Control Options Section
Ctl-opt Option(*Nodebugio);
// *************************************************************
// Creates a listing of CloudServices247 Inc customers
*
// EXER0502 - COMMON RPG Video Series
*
// Written Jim Buck - 03-10-17
*
// *************************************************************
Dcl-F EXER0502L Disk(*Ext) Usage(*input) Keyed;
Dcl-F EXER0502P Printer(*ext) Usage(*Output) Oflind(EndOfPage);
// * Declarations Section
Dcl-s ZipTotDue Zoned(8:2);
// Used in Report Breakline
Dcl-s RrtTotBal Zoned(10:2); // Used in Report Total Line
Dcl-s EndOfPage Ind Inz(*on);
Dcl-s HoldZipCode Char(9);
// Used for Break Processing
// Convert the alpha zipcode to numeric
Dcl-ds CZip;
PrtZipCode Zoned(9:0) Pos(1);
End-Ds;
// * Main Section
Read CustRec;
// Read the First Record
HoldZipCode = CZip; // used to compare current Zip code to last
Dow NOT %EOF;
RPTMESSAGE = *Blanks;
// Check the Balance Due field and assign value to message field
Select;
When BALDUE < 0;
RPTMESSAGE = 'BALDUE is less than Zero';
When BALDUE >= 0 and BALDUE <= 500;
RPTMESSAGE = 'BALDUE is >= 0 and <= 500';
When BALDUE > 500 and BALDUE < 1000;
RPTMESSAGE = 'BALDUE is > 500 and < 1000';
RPGVideo_AttendeeWorkbook.docx
27 of 79
When BALDUE >= 1000;
RPTMESSAGE = 'BALDUE is >= 1000';
Other;
RPTMESSAGE = 'Other BALDUE Values!';
ENDSL;
// If the zip-code has changed handle the break processing
If HoldZipCode <> CZip;
Exsr ZipCodeBreak;
ZipTotDue += BalDue;
Else;
ZipTotDue += BalDue;
ENDIF;
// Count the records
RecCount += 1;
// Check for the End of Page
ExSr CheckOverFlow;
Write Detail;
// Write a detail line on the report
READ CustRec;
EndDo;
// Handle the total line
ExSr ReportTotals;
// Turn on last record indicator and return to caller
*INLR = *ON;
Return;
// *************************************************************
// Handle Zipcode Report Break
*
// *************************************************************
BegSr ZipCodeBreak;
RptTotBal += ZipTotDue; // Accumulate the report totals
Write Brkline;
ZipTotDue = *Zero;
// Clear Zip Total
HoldZipCode = CZip;
// Move to the hold area Zip
EndSr;
// *************************************************************
// Handle End of Report Total Lines
*
// *************************************************************
BegSr ReportTotals;
ExSr ZipcodeBreak;
Write RptTotal;
EndSr;
// *************************************************************
// Checks and Handles Report Overflow
*
// *************************************************************
BegSr CheckOverFlow;
If Endofpage;
Write Heading; // Write Heading on report
Endofpage = *Off;
Endif;
EndSr;
// *************************************************************
RPGVideo_AttendeeWorkbook.docx
28 of 79
EXER0601 & EXER0602– Customer Master Updates using Service Program
EXER0602 – “Service Program Example”
The program demonstrates the following concepts:
•
•
•
•
•
Improving Code To Make it More Reusable
Creating Binder Language Source
Creating a Service Program
Creating a Binding Directory
Binding a Program To a Service Program
EXER0601 is the same code as exer0501, except
that the code used to update the database is
moved into a module.
EXER0602 compiles the module into a service
program.
Start With the EXER0601 Example
This example builds on the customer maintenance example that was presented earlier in this video. To get
started you should:
•
•
•
•
•
•
•
•
•
•
•
•
•
Copy display file EXER0601D to EXER0602D and compile it
Copy EXER0601 to EXER0602, and find/replace “EXER0601” in the code with “EXER0602”
Copy EXER0601CP to EXER0602CP
Copy EXER0601M to EXER0602M
Rename the procedures to use the CUST prefix
Remove unnecessary parameters
Add the CONST keyword where appropriate
Make the database logic stateless
Compile Everything Into Modules
Create Binder Language Source
Compile EXER0602M as a Service Program
Create a Binding Directory
Create EXER0602 and bind it to EXER0602M by reference
The program sources below are the modified copies for your reference, so you can see a working version if you
get stuck.
Program Source for EXER0602:
// * Control Options Section
Ctl-opt Option(*Nodebugio: *Srcstmt);
// *************************************************************
// This program allows users to interactively maintain Cloud- *
// Services Customer Mstr file by adding, changing, and dele- *
// ing records. For adds, the next customer number is assigned*
// by the system. Customer's whose balance is greater than
*
// zero cannot be deleted.
*
// Written - Jim Buck - 03/22/2017
*
// Changed to use a service program by Scott Klement
*
// *************************************************************
//
RPGVideo_AttendeeWorkbook.docx
29 of 79
//
//
//
//
//
//
To compile this:
- first compile EXER0602D (display file)
- second create service EXER0602M
- compile this with: CRTRPGMOD
- finally: CRTPGM PGM(EXER0602) BNDSRVPGM(EXER0602M)
Dcl-f DisplayScreen WORKSTN Qualified Alias ExtFile(*extdesc)
ExtDesc('EXER0602D') indds(indicators);
//
Copy in the Prototypes
/copy COMMONVID/QRPGLESRC,EXER0602CP
// Indicator Data Structure
Dcl-ds Indicators Len(99);
Exit
ind Pos(3) inz(*off);
FkeyPressed ind Pos(10) Inz(*off);
Cancel
ind Pos(12);
BalDueError ind Pos(30);
RecNotFound ind Pos(90);
UpdateError ind Pos(91);
ProtectField ind Pos(92) inz;
End-ds;
// Data Structure for Screen I/O
Dcl-Ds InputScreenDS likerec(DisplayScreen.InputScrn:*all);
Dcl-Ds CustDataInDS likerec(DisplayScreen.DispScrn:*All);
// Data Structures for Database I/O
Dcl-Ds CSCSTPDataInDS Ext ExtName('CSCSTP':*Input) Qualified
End-DS;
Dcl-Ds CSCSTPDataOutDS Ext ExtName('CSCSTP':*Output) Qualified
End-DS;
// Stand Alone Variables
Dcl-s PgmName char(9) inz('Exer0602');
Dcl-s CustInWrk Packed(6:0);
// *******************************************************
// Loop until user presses the Exit (F3) Key
// *******************************************************
DOU Exit;
ClearFields();
// Display the Enter Custnbr Screen
EXFMT DisplayScreen.InputScrn InputScreenDS;
CustInWrk = InputScreenDS.CustNo;
// Reset screen indicators
RESET BalDueError;
RESET RecNotFound;
RESET UpdateError;
// Figure out what happened in the screen
SELECT;
WHEN Exit;
LEAVE;
// Leave loop and Exit the program
WHEN Cancel;
ITER;
// Loop again
WHEN InputScreenDS.Action = 'A';
AddRecord();
RPGVideo_AttendeeWorkbook.docx
30 of 79
WHEN InputScreenDS.Action = 'C';
ChangeRecord();
WHEN InputScreenDS.Action = 'D';
DeleteRecord();
Other;
ITER;
ENDSL;
ENDDO;
*INLR = *ON;
RETURN;
// *******************************************************
// * Add A Record
// *******************************************************
Dcl-Proc AddRecord;
AssignNextNbr(); // Assign the next Customer Number
CustDataInDS.Mode = 'Add';
CustDataInDS.CustNo = CustInWrk;
EXFMT DisplayScreen.DispScrn CustDataInDS;
IF NOT FkeyPressed;
EVAL-CORR CSCSTPDataOutDS = CustDataInDS;
UpdateError =
CUST_write(CSCSTPDataOutDS);
ENDIF;
End-Proc;
// ******************************************************
// * Get Next Customer Number - Not used to be used in production
// ******************************************************
Dcl-Proc AssignNextNbr;
CustInWrk = CUST_getHighest() + 1;
ClearFields();
// Clear out the fields
End-Proc;
// ******************************************************
// * Change a Record
// ******************************************************
Dcl-Proc ChangeRecord;
CustDataInDS.Mode = 'Change';
IF NOT FkeyPressed;
RecNotFound =
CUST_get(CSCSTPDataInDS:CustInWrk);
SELECT;
WHEN FkeyPressed;
Return;
WHEN RecNotFound;
// ErrorMsg = 'Record Not Found';
Return;
WHEN NOT RecNotFound;
EVAL-CORR CustDataInDS = CSCSTPDataInDS;
EXFMT DisplayScreen.DispScrn CustDataInDS;
IF NOT FkeyPressed;
Eval-corr CSCSTPDataOutDS = CustDataInDS;
UpdateError =
CUST_update(CSCSTPDataOutDS:CustInWrk);
Endif;
ENDSL;
ENDIF;
RPGVideo_AttendeeWorkbook.docx
31 of 79
End-Proc;
// ***********************************************************
// * Delete a Record if they don't have a Balance
// ***********************************************************
Dcl-Proc DeleteRecord;
CustDataInDS.Mode = 'Delete';
IF NOT FkeyPressed;
RecNotFound = CUST_get(CSCSTPDataInDS:CustInWrk);
Eval-corr CustDataInDS = CSCSTPDataInDS;
BalDueError = (CustDataInDS.BalDue > 0);
SELECT;
WHEN FkeyPressed;
Return;
WHEN RecNotFound;
// ErrorMsg = 'Record Not Found';
Return;
WHEN BalDueError;
// ErrorMsg = 'Balance Due > Zero';
Return;
WHEN NOT BalDueError;
ProtectField = *on;
// Turn on to protect the fields from change
EXFMT DisplayScreen.DispScrn CustDataInDS;
ProtectField = *off;
IF NOT FkeyPressed;
UpdateError = CUST_delete(CustInWrk);
EndIf;
ENDSL;
ENDIF;
End-Proc;
// ************************************************************
// * Clear out the fields
// ************************************************************
Dcl-Proc ClearFields;
CLEAR CustDataInDS;
CLEAR InputScreenDS;
CLEAR CSCSTPDataInDS;
CLEAR CSCSTPDataOutDS;
CustDataInDs.PgmName = PgmName;
InputScreenDS.PgmName = PgmName;
End-Proc;
Program Source for EXER0601CP:
DCL-PR CUST_delete IND;
CustNbrWrk Packed(6:0) const;
END-PR ;
DCL-PR CUST_get IND;
CSCSTPDataDS LIKEDS(CSCSTPDataInDS);
CustNbrWrk Packed(6:0) const;
END-PR ;
DCL-PR CUST_update IND;
RPGVideo_AttendeeWorkbook.docx
32 of 79
CSCSTPDataDS LIKEDS(CSCSTPDataOutDS) const;
CustNbrWrk Packed(6:0) const;
END-PR ;
DCL-PR CUST_write IND;
CSCSTPDataDS LIKEDS(CSCSTPDataOutDS) const;
END-PR ;
Dcl-PR CUST_getHighest like(CSCSTPDataInDS.CustNo);
END-PR;
Program Source for EXER0601M:
ctl-opt NOMAIN option(*nodebugio: *srcstmt);
// *************************************************************
// This module handles the database logic for the CSCSTP
- *
// maintenance program.
*
// Written - Jim Buck - 03/22/2017
*
// Changed into a service program by Scott Klement
*
// *************************************************************
//
// To compile this:
// - First compile the module with: CRTRPGMOD
// - Make a service program with: CRTSRVPGM SRVPGM(EXER0602M)
Dcl-f CSCSTP
DISK(*ext) keyed Usage(*Update:*Delete:*Output);
// Copy in the Prototypes
/copy COMMONVID/QRPGLESRC,EXER0602CP
// Data Structures for Database I/O
Dcl-Ds CSCSTPDataInDS Ext ExtName('CSCSTP':*Input) Qualified
End-DS;
Dcl-Ds CSCSTPDataOutDS Ext ExtName('CSCSTP':*Output) Qualified
End-DS;
// ************************************************************
// * Retrieves DB2 Data For CSCSTP
// ************************************************************
Dcl-Proc CUST_get EXPORT;
Dcl-Pi *N IND;
CSCSTPDataDS LIKEDS(CSCSTPDataInDS);
CustNbrWrk Packed(6:0) const;
End-Pi ;
Dcl-s RecNotFound Ind;
CHAIN(n) CustNbrWrk CustRec CSCSTPDataDS;
RecNotFound = NOT %FOUND;
return RecNotFound;
End-Proc ;
// ************************************************************
RPGVideo_AttendeeWorkbook.docx
33 of 79
// * Updates DB2 Data For CSCSTP
// ************************************************************
Dcl-Proc CUST_delete EXPORT;
Dcl-Pi *N IND;
CustNbrWrk Packed(6:0) const;
End-Pi ;
Dcl-s DeleteError Ind;
DELETE(E) CustNbrWrk CustRec;
DeleteError = %ERROR;
return DeleteError;
End-Proc ;
// ************************************************************
// * Updates DB2 Data For CSCSTP
// ************************************************************
Dcl-Proc CUST_update EXPORT;
Dcl-Pi *N IND;
CSCSTPDataDS LIKEDS(CSCSTPDataOutDS) const;
CustNbrWrk Packed(6:0) const;
End-Pi ;
Dcl-s UpDateError Ind;
chain(e) CustNbrWrk CSCSTP;
if %error or not %found;
UpdateError = *ON;
else;
UPDATE(E) CustRec CSCSTPDataDS;
UpdateError = %ERROR;
endif;
return UpdateError;
End-Proc ;
// ************************************************************
// * Adds New DB2 Data For CSCSTP
// ************************************************************
Dcl-Proc CUST_write EXPORT;
Dcl-Pi *N IND;
CSCSTPDataDS LIKEDS(CSCSTPDataOutDS) const;
End-Pi ;
Dcl-s WriteError Ind;
WRITE(E) CustRec CSCSTPDataDS;
WriteError = %ERROR;
return WriteError;
End-Proc ;
Dcl-Proc CUST_getHighest EXPORT;
RPGVideo_AttendeeWorkbook.docx
34 of 79
Dcl-PI *N like(CSCSTPDataInDS.CustNo);
END-PI;
clear CSCSTPDataInDS;
SETGT 999999 CSCSTP;
// Determine last customer number
READP(N) CSCSTP CSCSTPDataInDS; // Read the previous record
return CSCSTPDataInDS.CustNo;
End-Proc;
Binder Language Source (source file QSRVSRC, member EXER0602M):
STRPGMEXP PGMLVL(*CURRENT)
export symbol(CUST_delete)
export symbol(CUST_get)
export symbol(CUST_update)
export symbol(CUST_write)
export symbol(CUST_getHighest)
ENDPGMEXP
Compile Your Source As Modules, Then Create the Service Program, Binding Directory and Program
CRTDSPF FILE(EXER0602D) SRCFILE(QDDSSRC)
CRTRPGMOD MODULE(EXER0602M) SRCFILE(QRPGLESRC)
CRTRPGMOD MODULE(EXER0602) SRCFILE(QRPGLESRC)
CRTSRVPGM SRVPGM(EXER0602M) SRCFILE(QSRVSRC)
CRTBNDDIR BNDDIR(COMMONVID/MYBNDDIR)
ADDBNDDIRE BNDDIR(MYBNDDIR) OBJ((EXER0602M *SRVPGM))
CRTPGM PGM(EXER0602) BNDDIR(MYBNDDIR)
RPGVideo_AttendeeWorkbook.docx
35 of 79
EXER0701 – No Documentation
RPGVideo_AttendeeWorkbook.docx
36 of 79
EXER0801 – This program demonstrates using RPG Built-In Functions.
The program is a simple example of reading some records from a file, processing information from the records,
and reporting in a simple form of output to a printer device file which is output to a spooled file.
Upon reading a record, it passes field values from the record to subprocedures which return values used for
output.
There are subprocedures to:
1. Convert the input value to the proper case for a person's name. For simplicity for this exercise, the first
letter in each separate word of the name would be uppercased, and the remainder of each word
would be lowercased. The name values stored in the sample CSCSTP data file appear to be all
uppercase to begin with.
2. Check if a date value is within a certain number of days of the current date when the program is run.
To see if it is a "recent" date. However, since the sample CSCSTP dat file was created some years ago,
the un-altered versoin of the file has all old dates going back a few years. To allow for this and still get
some "positive hits", the input parameter supplying the number of days for the range is set to 5 years.
Output is kept simple by using program-described file output, assigning a constructed string value to a data
structure and then writing the data structure to QGPL/QPRINT, a system supplied printer device file.
There is only the one source EXER0801 of type RPGLE to compile and run.
To compile and run it, your job library list should contain QGPL (for the QPRINT file) and the library with the
CSCSTP data file.
The following command parameters avoid spoecifying library names by relying on their being a current library
assigned to the library list, into which the program is compiled, and then found for running. (Use CHGCURLIB
to set if needed.)
Compile command:
CRTBNDRPG PGM(EXER0801)
This uses all the other command defaults, including the source file QRPGLESRC
To run the pgm: (Therre are no program parameters to set)
call exer0801
To view the output to the spooled file:
WRKSPLF
This shows columns for the first and last names which have been set to the proper name case, and declares
'RECENT' when the date range check met the range parameter (5 years), and finally also lists out the date value
which was being tested. (The date value is in MMDDYYYY format.)
RPGVideo_AttendeeWorkbook.docx
37 of 79
Note: The source program contains DSPLY statements which are commented out to disable them. These can
be un-commented to help trace values when running.
RPGLE Program source for EXER0801:
// * Control Options Section
Ctl-opt Option(*Nodebugio: *Srcstmt);
CTL-Opt actgrp(*caller);
// *************************************************************
// Session 8 Exercise - RPG Built In Functions
// *************************************************************
//
// To compile this:
// - Add the library with the CSCSTP data file to your library list
// - CRTBNDRPG PGM(EXER0801)
//
// To Run:
// - Call EXER0801
//
Upon completion, it should have created a spooled file in
//
your output queue.
// - WRKSPLF
// In a loop, read a record from the data file, using data from the
// record to test our procedures against.
// Limit the loop to the first 50 records, for the purposes of our test.
// Output the list to a spool file using the QGPL/QPRINT device file
dcl-f cscstp usage(*input);
dcl-f qprint PRINTER(80);
RPGVideo_AttendeeWorkbook.docx
38 of 79
dcl-ds prtline len(80) end-ds;
dcl-s count int(10) inz(0);
dcl-s recent char(6);
read custrec;
dow ( (not %eof(cscstp)) and (count <50));
count += 1;
//dsply ( cfname + ', ' + clname);
//dsply ( NameCase(cfname) + ', ' + NameCase(clname));
//dsply ('Date: ' + %char( orddat) );
//dsply ('Near: ' + CheckDateRecent(orddat: 1500) );
// Special Note: Due to the sample data in the data file having
// old dates from a few years ago, and nothing very recent, I am using
// a date range value of 5 years, in order to get some hits occuring.
if
CheckDateRecent(orddat: 5 * 365);
recent = 'RECENT';
else;
recent = *blank;
endif;
// Write a line out to the printer device file.
prtline = NameCase(cfname) + ', ' + NameCase(clname)
+ ' ' + recent + ' ' + %char( orddat);
write qprint prtline;
read custrec;
ENDDO;
*inlr = *on;
// *************************************************************
// Procedure NameCase:
//
Convert the input value ot the proper case for a name and return it.
//
//
There are many considerations for the proper case presentation of a
//
person's name, but that is beyond the scope of this exercise.
//
//
For simplicity for this exercise, the procedure will determine
//
the blank-separated parts of the name string, and convert the
//
first character of each part to uppercase, and the remaining
//
characters of the part to lowercase.
//
It will only treat the standard characters A-Z, a-z. It will not try
//
to treat other characters or accented characters.
dcl-proc NameCase;
dcl-pi *n char(15);
p1 char(15) value;
END-PI;
dcl-c LOWER 'abcdefghijklmnopqrstuvwxyz';
RPGVideo_AttendeeWorkbook.docx
39 of 79
dcl-c UPPER 'ABCDEFGHIJKLMNOPQRSTUVWXYZ';
dcl-s i int(10) inz(1);
dcl-s c char(1);
// Loop thru the characters of the value to find the parts
// separated by blanks.
dow (i <= %len(p1));
c = %subst(p1:i:1);
if ( *blank = c);
i += 1;
else;
// Convert first letter of a part to uppercase
%subst(p1:i:1) = %xlate(LOWER:UPPER: c);
i+= 1;
// Convert remaining characters of a part to lowercase
dow i <= %len(p1);
c = %subst(p1:i:1);
if ( *blank = c);
i += 1;
leave;
else;
%subst(p1:i:1) = %xlate(UPPER:LOWER: c);
i+= 1;
endif;
enddo;
endif;
enddo;
return p1;
END-PROC;
// *************************************************************
// Procedure CheckDateRecent:
//
Test the input value to test if the date it represents is
//
within a certain number of days of the current date,
//
returning an indicator result.
dcl-proc CheckDateRecent;
dcl-pi *n ind;
pnum packed(8:0);
dayRange int(10) value;
END-PI;
dcl-s pdate date(*iso);
dcl-s delta int(10);
//dsply (%char(pnum));
// Convert the input packed value (expected to be in a *USA format)
// to a DATE data type
pdate = %DATE( pnum: *usa);
RPGVideo_AttendeeWorkbook.docx
40 of 79
// Calculate the difference in number of days between the current date
// and the input value
delta = %DIFF( %date: pdate: *days);
//dsply (%char(delta));
return ( %ABS(delta)
END-PROC;
RPGVideo_AttendeeWorkbook.docx
<= dayRange);
41 of 79
EXER0902 – Subfile program for Order Entry and Maintenance application
and displays a list of open orders. It calls a CRUD EXER0903 to view, change, delete or enter a new order.
Users can do the following tasks using the program:
-
See a list of open orders by paging up and down
Filter the list by entering customer numbers and order dates
View order details for an order by taking option V
Change or add products for an order by using option C
Delete existing order by using option D
Create a new order by pressing function key 6
All detail (product) related operations are performed by EXER0903 which receives a parameter identifying
the action.
The program needs a way to access open only orders without reading entire order file, so it uses a logical file
CSORDPL01 that selects orders with statuses eligible for maintenance.
The program demonstrates the following concepts:
-
Using logical file to select records
Loading subfile using Load All technique
Reading user input from subfile using READC opcode
Validating user input and responding to errors
Calling another program with a parameter
Logical File CSORDPL01 selecting only open orders
RPGVideo_AttendeeWorkbook.docx
42 of 79
Screen displaying orders open for maintenance
Display file source EXER0902D
A*%%TS SD 20170304 100830 MVALDMAN
REL-V7R1M0 5770-WDS
A*****************************************************************
A*$
A*$ SYSTEM NAME:
ORDER MAINTENANCE - ORDER LIST
A*$ FILE NAME:
EXER0902D
A*$ TYPE OF FILE:
DSPF
A*$
A*$ AUTHOR:
MAX VALDMAN
A*$
A*$ DESCRIPTION:
A*$
A*$ FILE REVISION LOG:
A*$ ----------------A*$
A*$
DATE
PROGRAMMER
PROJECT# DESCRIPTION OF REVISION
A*$ -------- -------------- -------- ----------------------------A*$
A*****************************************************************
A*%%EC
A
DSPSIZ(24 80 *DS3)
A
PRINT(*LIBL/QSYSPRT)
A
INDARA
A*---------------------------------------------------------------A*
A
R SCR01
SFL
A*%%TS SD 20170303 145942 MVALDMAN
REL-V7R1M0 5770-WDS
A
OPTS
1A B 7 3
RPGVideo_AttendeeWorkbook.docx
43 of 79
A
A
A
A
A
A
A
A
A
A
A
A
A*%%TS
A
A
A
A 98
A 98
A
A
A 30
A 31
A 32
A 99
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
ORD#S
ODATES
ORDTOTS
PAYMNTS
TWGTS
TZIPS
ORDSTSS
7 8
7 15EDTCDE(Y)
7 26EDTCDE(4 $)
7 38EDTCDE(4 $)
7 50EDTCDE(4)
7 57
7 63
8 10'Customer'
COLOR(TRQ)
CUSNAMES
26
O 8 19COLOR(TRQ)
CUSTNOS
6 0O 8 47COLOR(TRQ)
R SCR02
SFLCTL(SCR01)
SD 20170304 100830 MVALDMAN
REL-V7R1M0 5770-WDS
CA03(03 'Exit')
CF05(05 'Refresh')
CF06(06 'New prospect')
ALARM
MSGALARM
OVERLAY
SFLCSRRRN(&SFLRRN)
SFLDSP
SFLDSPCTL
SFLCLR
SFLEND(*MORE)
SFLSIZ(0045)
SFLPAG(0007)
SFLDSP
4S 0H
SFLRCDNBR
SFLRRN
5S 0H
1 2'Oper ID:'
1 11USER
1 32'Order Maintenance'
DSPATR(HI)
DSPATR(UL)
1 62'SCR02'
1 72DATE
EDTCDE(Y)
2 2'EXER0902'
2 34'Order Summary'
DSPATR(HI)
2 72TIME
4 3'Filter by:'
COLOR(BLU)
4 14'Customer-'
CUSTNOF
6Y 0B 4 24EDTCDE(Z)
CHANGE(71)
4 32'Order Date From-'
ODATEF
6Y 0B 4 49EDTCDE(Y)
CHANGE(71)
4 60'Orders Shown:'
ORDNUMD
4Y 0O 4 74EDTCDE(Z)
5 2'Options: D=Delete, C=Change, V=View'
DSPATR(HI)
6 2'Opt'
COLOR(YLW)
6 8'Ord #'
COLOR(YLW)
6 15'Ord Date'
RPGVideo_AttendeeWorkbook.docx
5S 0O
6Y 0O
7Y 2O
7Y 2O
3Y 0O
3S 0O
10A O
44 of 79
A
COLOR(YLW)
A
6 26'Ord Tot'
A
COLOR(YLW)
A
6 38'Pay Incl'
A
COLOR(YLW)
A
6 50'Wgt'
A
COLOR(YLW)
A
6 56'Zone'
A
COLOR(YLW)
A
6 63'Status'
A
COLOR(YLW)
A
R SCR03
A*%%TS SD 20170303 140708 MVALDMAN
REL-V7R1M0 5770-WDS
A
23 3'F03=Exit
F05=Refresh
A
rder'
A
COLOR(BLU)
A
MSGLINE
70A O 24 3DSPATR(BL)
A*%%RS+<record-sequences>
A*%%RS+ <sequence name="SCREEN1">
A*%%RS+ <record-write record-format="SCR02" />
A*%%RS+ </sequence>
A*%%RS </record-sequences>
RPGVideo_AttendeeWorkbook.docx
F06=New O-
45 of 79
Display file EXER0902D open in RDi Screen Designer
Program Source for EXER0902
ctl-opt datfmt(*iso) datedit(*ymd) timfmt(*iso)
truncnbr(*yes) option(*srcstmt : *nodebugio) ;
// **************************************************************
// Displays list of open orders to maintain/option to enter new*
// EXER0902 - COMMON RPG Video Series
*
// Written 02-28-17
*
// **************************************************************
//?==================
Files
=================================
dcl-f exer0902d workstn sfile(scr01:rrn1) indds(f_keys);
dcl-f csordpl01 keyed;
dcl-f cscstp keyed;
//?==================
Variables
=================================
dcl-s rrn1 packed(4); // rrn subfile 1
dcl-s q1 packed(5);
dcl-s pMode char(1);
dcl-s OdateF8 packed(8:0) ;
dcl-s pOpt char(1) ;
dcl-s pOrd# packed(5:0) ;
dcl-ds ProgramStatus PSDS;
SourceLine# char(8) pos(21); // Source List line #
ExceptType char(3) pos(40); // Exception type
RPGVideo_AttendeeWorkbook.docx
46 of 79
ExceptNumber char(4) pos(43); // Exception Number
ExceptData char(80) pos(91); // Exception Data
ExceptID char(4) pos(171); // Exception ID
Date char(8) pos(191); // Date in *date fmt
JobName char(10) pos(244); // Job Name
UserID char(10) pos(254); // User
JobNumber zoned(6) pos(264); // Job Number
end-ds;
// ?Display Function Keys indicators
dcl-ds F_Keys;
ExitRequest ind pos(3);
RefreshRequest ind pos(5);
NewOrder ind pos(6);
SflDisplay ind pos(30);
CntrlDisplay ind pos(31);
SflClear ind pos(32);
filterChanged ind pos(71);
Alarm ind pos(98);
SflEnd ind pos(99);
end-ds;
*
Prototype for procedure to see, maintain delete
dcl-pr orderMaintenance extpgm('EXER0903');
*n packed(5:0); // order number
*n char(1) ;
// option
end-pr;
//?==================
loadSfl() ;
//
C-Specs
=================================
Load subfile with open orders
Dou ExitRequest;
//
?Display screen
Write scr03;
Exfmt scr02;
ResetScreen() ;
//
?Support Function Keys
Select;
When ExitRequest ;
Leave;
When RefreshRequest;
ValidateInput();
// validate search on refresh request
If msgLine <> *Blanks ;
Iter;
Endif;
loadSfl() ;
Iter;
When NewOrder;
pOrd# = 0 ;
pOpt = 'A' ;
orderMaintenance(pOrd#:pOpt) ; // Screen to enter new order
Iter ;
Other ;
RPGVideo_AttendeeWorkbook.docx
47 of 79
checkOptions() ;
// Enter, read subfile
ValidateInput() ;
// See if filters changed
If msgLine <> *Blanks ;
Iter;
Endif;
If filterChanged ;
// if filter fields changed
LoadSfl() ;
// reload subfile
Endif ;
Iter;
Endsl;
Enddo;
*INlr = *ON;
//------------------------------------------------------------------Dcl-proc LoadSfl;
//
?Initialize subfile
rrn1 = 0 ;
SflDisplay = *off;
CntrlDisplay = *off;
SflClear = *on;
Write scr02;
SflClear = *off;
optS = ' ' ;
//
?Load subfile
Setll *Loval OrdrRec ;
Dou %eof(csordpl01) ;
Read OrdrRec ;
If %eof(csordpl01) ;
Leave ;
Endif ;
//
Read Order File
If CustNoF <> 0 and CustNoF <> Cust# ;
Iter ;
// Skip customers if use filter
Endif;
If Odate < OdateF8 ; // can use without check for zero
Iter ;
// because any valid date will qualify
Endif;
Ord#S = OrdNbr ;
// Load fields
OdateS = %dec(%date(Odate:*ISO):*MDY) ;
OrdTotS = OrdTot ;
PaymntS = Paymnt ;
TwgtS = Twgt ;
Select ;
When Osts = ' ' ;
OrdStsS = 'OPEN' ;
When Osts = 'BO' ;
OrdStsS = 'BACKORDER' ;
Other ;
OrdStsS = 'UNKNOWN' ;
Endsl;
CustNoS = Cust# ;
Chain Cust# CustRec ;
RPGVideo_AttendeeWorkbook.docx
48 of 79
If %found ;
CusNameS = %trimr(cFname) + ' ' + %trimr(cLname) ;
Else ;
CusNameS = 'Customer not found!!' ;
Endif;
rrn1 += 1 ;
Write scr01;
//
Write subfile record
If rrn1 = 9999 ;
Leave ;
Endif;
//
Stop if reach subfile limit
Enddo ;
OrdNumD = RRN1 ;
//
?Get ready to display, if there is something
CntrlDisplay = *on;
SflEnd = *on;
If rrn1 > 0;
SflDisplay = *on;
Else;
SflDisplay = *off ;
msgLine = 'No records to display' ;
Endif;
SflDsp = 1 ;
End-proc ;
//------------------------------------------------------------------------Dcl-proc checkOptions ;
If SflDisplay = *off ;
Return ;
Endif ;
//
//
If we didn't have anything to display
there is nothing to read in SFL
Dou %eof(exer0902d) ;
Readc scr01 ;
// Read changed records
If %eof(exer0902d) ;
Leave ;
Endif ;
If OptS = ' ' ;
// Option could be changed, but blank
Iter ;
Endif ;
If OptS = 'C' or OptS = 'V' or OptS = 'D' ;
// valid options only
orderMaintenance(Ord#S:OptS) ; // bring up order for appropriate
Endif ;
// action
OptS = ' ' ;
// clear option
Update scr01 ;
SflDsp = RRN1 ;
// display subfile at the last action
Enddo ;
End-proc ;
//-----------------------------------------------------------------------Dcl-proc validateInput ;
If CustNoF <> 0 ;
// need only one customer
Chain CustNoF CustRec ;
RPGVideo_AttendeeWorkbook.docx
49 of 79
If not %found(cscstp) ;
msgLine = 'Filter by Invalid Customer Number' ;
Return ;
Endif;
Endif;
If OdateF <> 0 ;
Monitor ;
// orders from entered date forward
OdateF8 = %dec(%date(OdateF:*MDY):*ISO) ;
On-Error ;
msgLine = 'Invalid From Date' ;
OdateF8 = 0 ;
Endmon;
Else ;
OdateF8 = 0 ;
Endif ;
End-proc;
//-----------------------------------------------------------------------Dcl-proc ResetScreen;
//
?Reset screen indicators
msgLine = *Blanks ;
Alarm = *off;
End-proc ;
RPGVideo_AttendeeWorkbook.docx
50 of 79
EXER1001 – This program accepts two parameters and displays a list of items
The program is based upon program EXER0901 but has been modified to use a dynamic embedded SQL
statement to retrieve the order details.
The program demonstrates the following concepts:
-
Setting SQL Options (TAG01)
Checking the parameter for validity (TAG02)
Building a dynamic SQL statement (TAG03)
Preparing the SQL Statement (TAG04)
Declaring a cursor (TAG05)
Opening the cursor (TAG06)
Fetching a row from the file (TAG07)
Closing the Cursor (TAG08)
The parameters passed to the program are both alphanumeric. The first parameter passed is a 5-character
order number. The second parameter is a single character that ranges from 1 to 7. The second parameter will
control the order in which the records are displayed on the screen.
-
1 = Line Number
2 = Product Number
3 = Quantity Ordered
4 = Quantity on Hold
5 = Tracking Number
6 = Status
7 = Line Cost
After adding the Bootcamp Library to your library list type the following command:
CALL EXER1001 Parm(‘ 11012 ‘ ‘7‘) and press enter.
The following display will be shown:
Display file source EXER1001D
RPGVideo_AttendeeWorkbook.docx
51 of 79
A*%%TS SD 20170416 124612 MVALDMAN
REL-V7R1M0 5770-WDS
A*****************************************************************
A*$
A*$ SYSTEM NAME:
ORDER MAINTENANCE - SINGLE ORDER
A*$ FILE NAME:
EXER1001D
A*$ TYPE OF FILE:
DSPF
A*$
A*$ AUTHOR:
MAX VALDMAN
A*$
A*$ DESCRIPTION:
A*$
A*$ FILE REVISION LOG:
A*$ ----------------A*$
A*$
DATE
PROGRAMMER
PROJECT# DESCRIPTION OF REVISION
A*$ -------- -------------- -------- ----------------------------A*$
A*****************************************************************
A*%%EC
A
DSPSIZ(24 80 *DS3)
A
PRINT(*LIBL/QSYSPRT)
A
INDARA
A*---------------------------------------------------------------A*
A
R SCR01
SFL
A*%%TS SD 20170416 124612 MVALDMAN
REL-V7R1M0 5770-WDS
A
PRODNOS
6S 0O 7 6
A
DESCRPS
25A O 7 13
A
QTYORDS
4Y 0O 7 40EDTCDE(4)
A
LINECSTS
12Y 2O 7 46EDTCDE(4 $)
A
QTYHOLDS
4Y 0O 7 63EDTCDE(4)
A
TRACKS
7A O 7 69
A
STSS
2A O 7 78
A
R SCR02
SFLCTL(SCR01)
A*%%TS SD 20170416 124612 MVALDMAN
REL-V7R1M0 5770-WDS
A
SFLSIZ(0045)
A
SFLPAG(0014)
A
CA03(03 'Exit')
A
CF05(05 'Refresh')
A 98
ALARM
A 98
MSGALARM
A
OVERLAY
A
SFLCSRRRN(&SFLRRN)
A 30
SFLDSP
A 31
SFLDSPCTL
A 32
SFLCLR
A 99
SFLEND(*MORE)
A
SFLDSP
4S 0H
SFLRCDNBR
A
SFLRRN
5S 0H
A
1 2'Oper ID:'
A
1 11USER
A
1 34'Order Display'
A
DSPATR(HI)
A
DSPATR(UL)
A
1 62'SCR02'
A
1 72DATE
A
EDTCDE(Y)
A
2 2'EXER1001'
RPGVideo_AttendeeWorkbook.docx
52 of 79
A
2 72TIME
A
4 4'Customer:'
A
COLOR(BLU)
A
CUSTNOH
6Y 0O 4 14EDTCDE(4)
A
CNAME
20
O 4 22
A
4 65'Order #:'
A
COLOR(BLU)
A
ORD#H
5S 0O 4 74
A
6 10'Product'
A
COLOR(YLW)
A
6 39'Ord Q'
A
COLOR(YLW)
A
6 48'Line $'
A
COLOR(YLW)
A
6 62'Hld Q'
A
COLOR(YLW)
A
6 69'Track #'
A
COLOR(YLW)
A
6 78'Sts'
A
COLOR(YLW)
A
R SCR03
A*%%TS SD 20170416 124612 MVALDMAN
REL-V7R1M0 5770-WDS
A
23 3'F03=Exit F05=Refresh'
A
COLOR(BLU)
A
MSGLINE
70A O 24 3DSPATR(BL)
A*%%RS+<record-sequences>
A*%%RS+ <sequence name="SCREEN1">
A*%%RS+ <device type="display" width="80" height="24" />
A*%%RS+ <record-write record-format="SCR03" />
A*%%RS+ <record-write record-format="SCR01" />
A*%%RS+ <record-write record-format="SCR02" />
A*%%RS+ </sequence>
A*%%RS </record-sequences>
****
End Of Source Code ****
RPGVideo_AttendeeWorkbook.docx
53 of 79
Display file EXER1001D open in RDi Screen Designer
Program Source for EXER0901
ctl-opt datfmt(*iso) datedit(*ymd) timfmt(*iso) dftactgrp(*No)
truncnbr(*yes) option(*srcstmt : *nodebugio) ;
// **************************************************************
// Displays sigle order and sorts based on parameter
*
// EXER1001 - COMMON RPG Video Series
*
// Written 04-16-17
*
// **************************************************************
//?==================
Files
=================================
dcl-f exer1001d workstn sfile(scr01:rrn1) indds(f_keys);
dcl-f csordp usage(*input) keyed;
// dcl-f csordprp usage(*input) keyed;
dcl-f cscstp keyed;
dcl-f csinvp keyed;
//?==================
Variables
=================================
dcl-pr orderMaintenance extpgm('EXER1001'); // Declare program parameters
*n zoned(5:0); // pOrderNo
*n Char(1);
end-pr;
dcl-pi orderMaintenance;
pOrderNo zoned(5:0);
pSortOrder Char(1);
end-pi;
dcl-s rrn1 packed(4); // rrn subfile 1
dcl-s q1 packed(5);
dcl-s OdateF8 packed(8:0) ;
RPGVideo_AttendeeWorkbook.docx
54 of 79
dcl-s pOpt char(1) ;
dcl-s counter packed(4:0) ;
dcl-ds ProgramStatus PSDS;
SourceLine# char(8) pos(21); // Source List line #
ExceptType char(3) pos(40); // Exception type
ExceptNumber char(4) pos(43); // Exception Number
ExceptData char(80) pos(91); // Exception Data
ExceptID char(4) pos(171); // Exception ID
Date char(8) pos(191); // Date in *date fmt
JobName char(10) pos(244); // Job Name
UserID char(10) pos(254); // User
JobNumber zoned(6) pos(264); // Job Number
end-ds;
// ?Display Function Keys indicators
dcl-ds F_Keys;
ExitRequest ind pos(3);
RefreshRequest ind pos(5);
SflDisplay ind pos(30);
CntrlDisplay ind pos(31);
SflClear ind pos(32);
Alarm ind pos(98);
SflEnd ind pos(99);
end-ds;
//?==================
C-Specs
=================================
loadSfl() ;
Dou ExitRequest;
//
?Display screen
Write scr03;
Exfmt scr02;
ResetScreen() ;
//
?Support Function Keys
Select;
When ExitRequest ;
Leave;
When RefreshRequest ;
loadSfl() ;
Endsl;
Enddo;
*INlr = *ON;
//=======================================================================
Begsr *INZSR;
TAG01
// Commitment control is not being used
RPGVideo_AttendeeWorkbook.docx
55 of 79
TAG01
Exec SQL Set Option Commit = *None;
TAG02
TAG02
TAG02
TAG02
// Make sure that a valid Sort order was passed
If pSortOrder < '1' or pSortOrder > '7';
Eval pSortOrder = '1';
ENDIF;
ENDSR;
//---------------------------------------------------------------------------Dcl-proc LoadSfl;
TAG03
TAG03
TAG03
TAG03
TAG03
Dcl-S Select VarChar(512);
Dcl-S From VarChar(512);
Dcl-S Where VarChar(512);
Dcl-S OrderBy VarChar(512);
Dcl-S Statement VarChar(2048);
Dcl-DS RecordDS;
// Data Structure for Fetch
LnItmNo Zoned(3:0);
ProdNo Zoned(6:0);
QtyOrd Zoned(4:0);
QtyHold Zoned(4:0);
Track Char(7);
STS Char(2);
LineCst Zoned(12:2);
END-DS;
//
?Initialize subfile
rrn1 = 0 ;
SflDisplay = *off;
CntrlDisplay = *off;
SflClear = *on;
Write scr02;
SflClear = *off;
Ord#H = pOrderNo ;
Chain pOrderNo OrdrRec ;
If Not %found(csordp) ;
Clear Cust# ;
Endif;
Chain Cust# CustRec ;
If %found(cscstp) ;
CustNoH = Cust# ;
Cname = %trimr(cFname) + ' ' + %trimr(cLname) ;
Else ;
CustNoH = 0 ;
Clear Cname ;
Endif;
//
?Load subfile
// Setll Ord#H OrderRec ; //
// Dou %eof(csordprp) ;
// Reade Ord#H OrderRec ;
// If %eof(csordprp) ;
//
Leave ;
// Endif ;
RPGVideo_AttendeeWorkbook.docx
Read Order File
56 of 79
TAG03
TAG03
TAG03
TAG03
TAG03
TAG03
TAG03
// Build SQL Statement
Eval Select = 'Select LnItmNo, ' +
'ProdNo, ' +
'QtyOrd, ' +
'QtyHold, ' +
'Track, ' +
'STS, ' +
'LineCst ';
TAG03
TAG03
TAG03
TAG03
Eval From = ' From CSORDPRP';
Eval Where = ' Where ord# = ' + %Trim(%Char(Ord#H));
Eval OrderBy = ' Order by ' + pSortOrder;
Eval Statement = Select + From + Where + Orderby;
TAG04
TAG05
TAG06
Exec SQL Prepare Stmt From :Statement;
Exec SQL Declare C1 Cursor For Stmt;
Exec SQL Open C1;
If SQLSTT > '02000';
// The cursor could not be opened, Don't attempt to fetch
Else;
TAG07
TAG08
TAG08
DoU SQLstt > '02000';
Exec SQL Fetch from C1 into :RecordDS;
If SQLStt < '02000';
ProdNoS = ProdNo ;
// Load fields
Chain ProdNo InvRec ;
If %found ;
DescrpS = Descrp ;
Else ;
DescrpS = 'Product not found!!' ;
Endif;
QtyOrdS = QtyOrd ;
QtyHoldS = QtyHold ;
TrackS = Track ;
LineCstS = LineCst ;
StsS = Sts ;
rrn1 += 1 ;
Write scr01;
//
Write them to the subfile record
If rrn1 = 9999 ;
Leave ;
Endif;
Else;
Leave;
EndIf;
Enddo ;
//
Stop if reach subfile limit
// Close The Cursor
Exec SQL Close C1;
EndIf;
//
?Get ready to display, if there is something
CntrlDisplay = *on;
SflEnd = *on;
If rrn1 > 0;
RPGVideo_AttendeeWorkbook.docx
57 of 79
SflDisplay = *on;
Else;
SflDisplay = *off ;
msgLine = 'No records to display' ;
Endif;
SflDsp = 1 ;
End-proc ;
//---------------------------------------------------------------------------Dcl-proc ResetScreen;
//
?Reset screen indicators
msgLine = *Blanks ;
Alarm = *off;
End-proc ;
****
End Of Source Code ****
RPGVideo_AttendeeWorkbook.docx
58 of 79
EXER1002 & EXER1003 – Displays a list of open orders, allows an order to be
deleted, changed or viewed.
Program EXER1002 calls program EXER1003C. Program EXER1003C calls Program EXER1003. If the F06 key is
pressed, a new order may be entered. It is based upon exercise EXER0902 but it has been modified to use
commitment control.
The program demonstrates the following concepts:
-
Starting commitment control (TAG01)
Ending commitment Control (TAG02)
File Declaration keyword for commitment control (TAG03)
Using the Commit command (TAG04)
Using the Rollback command (TAG05)
Calling the Program
After adding the Bootcamp Library to the library list, type:
CALL EXER1002 and press the enter key.
Screen displaying a List of Open Orders
Press F06 to enter a new order or place a D, C or V in the option field and press the Enter key.
RPGVideo_AttendeeWorkbook.docx
59 of 79
Screen displaying the New Order entry panel
Screen displayed when Deleting an order
Press the F07 key to delete the order
RPGVideo_AttendeeWorkbook.docx
60 of 79
Screen displayed when Changing an order
Screen displayed when Viewing an order
RPGVideo_AttendeeWorkbook.docx
61 of 79
Display file source EXER1002D
A*%%TS SD 20170304 100830 MVALDMAN
REL-V7R1M0 5770-WDS
A*****************************************************************
A*$
A*$ SYSTEM NAME:
ORDER MAINTENANCE - ORDER LIST
A*$ FILE NAME:
EXER1002D
A*$ TYPE OF FILE:
DSPF
A*$
A*$ AUTHOR:
MAX VALDMAN
A*$
A*$ DESCRIPTION:
A*$
A*$ FILE REVISION LOG:
A*$ ----------------A*$
A*$
DATE
PROGRAMMER
PROJECT# DESCRIPTION OF REVISION
A*$ -------- -------------- -------- ----------------------------A*$
A*****************************************************************
A*%%EC
A
DSPSIZ(24 80 *DS3)
A
PRINT(*LIBL/QSYSPRT)
A
INDARA
A*---------------------------------------------------------------A*
A
R SCR01
SFL
A*%%TS SD 20170303 145942 MVALDMAN
REL-V7R1M0 5770-WDS
A
OPTS
1A B 7 3
A
ORD#S
5S 0O 7 8
A
ODATES
6Y 0O 7 15EDTCDE(Y)
A
ORDTOTS
7Y 2O 7 26EDTCDE(4 $)
A
PAYMNTS
7Y 2O 7 38EDTCDE(4 $)
A
TWGTS
3Y 0O 7 50EDTCDE(4)
A
TZIPS
3S 0O 7 57
A
ORDSTSS
10A O 7 63
A
8 10'Customer'
A
COLOR(TRQ)
A
CUSNAMES
26
O 8 19COLOR(TRQ)
A
CUSTNOS
6 0O 8 47COLOR(TRQ)
A
R SCR02
SFLCTL(SCR01)
A*%%TS SD 20170304 100830 MVALDMAN
REL-V7R1M0 5770-WDS
A
CA03(03 'Exit')
A
CF05(05 'Refresh')
A
CF06(06 'New prospect')
A 98
ALARM
A 98
MSGALARM
A
OVERLAY
A
SFLCSRRRN(&SFLRRN)
A 30
SFLDSP
A 31
SFLDSPCTL
A 32
SFLCLR
A 99
SFLEND(*MORE)
A
SFLSIZ(0045)
RPGVideo_AttendeeWorkbook.docx
62 of 79
A
SFLPAG(0007)
A
SFLDSP
4S 0H
SFLRCDNBR
A
SFLRRN
5S 0H
A
1 2'Oper ID:'
A
1 11USER
A
1 32'Order Maintenance'
A
DSPATR(HI)
A
DSPATR(UL)
A
1 62'SCR02'
A
1 72DATE
A
EDTCDE(Y)
A
2 2'EXER1002'
A
2 34'Order Summary'
A
DSPATR(HI)
A
2 72TIME
A
4 3'Filter by:'
A
COLOR(BLU)
A
4 14'Customer-'
A
CUSTNOF
6Y 0B 4 24EDTCDE(Z)
A
CHANGE(71)
A
4 32'Order Date From-'
A
ODATEF
6Y 0B 4 49EDTCDE(Y)
A
CHANGE(71)
A
4 60'Orders Shown:'
A
ORDNUMD
4Y 0O 4 74EDTCDE(Z)
A
5 2'Options: D=Delete, C=Change, V=VieA
w'
A
DSPATR(HI)
A
6 2'Opt'
A
COLOR(YLW)
A
6 8'Ord #'
A
COLOR(YLW)
A
6 15'Ord Date'
A
COLOR(YLW)
A
6 26'Ord Tot'
A
COLOR(YLW)
A
6 38'Pay Incl'
A
COLOR(YLW)
A
6 50'Wgt'
A
COLOR(YLW)
A
6 56'Zone'
A
COLOR(YLW)
A
6 63'Status'
A
COLOR(YLW)
A
R SCR03
A*%%TS SD 20170303 140708 MVALDMAN
REL-V7R1M0 5770-WDS
A
23 3'F03=Exit
F05=Refresh
F06=New OA
rder'
A
COLOR(BLU)
A
MSGLINE
70A O 24 3DSPATR(BL)
A*%%RS+<record-sequences>
A*%%RS+ <sequence name="SCREEN1">
A*%%RS+ <record-write record-format="SCR02" />
RPGVideo_AttendeeWorkbook.docx
63 of 79
A*%%RS+ </sequence>
A*%%RS </record-sequences>
**** End of Source ****
Program Source for EXER1002
ctl-opt datfmt(*iso) datedit(*ymd) timfmt(*iso) dftactgrp(*No)
truncnbr(*yes) option(*srcstmt : *nodebugio) ;
// **************************************************************
// Displays list of open orders to maintain/option to enter new*
// EXER1002 - COMMON RPG Video Series
*
// Written 02-28-17
*
// **************************************************************
//?==================
Files
=================================
dcl-f exer1002d workstn sfile(scr01:rrn1) indds(f_keys);
dcl-f csordpl01 keyed;
dcl-f cscstp keyed;
//?==================
Variables
=================================
dcl-s rrn1 packed(4); // rrn subfile 1
dcl-s q1 packed(5);
dcl-s pMode char(1);
dcl-s OdateF8 packed(8:0) ;
dcl-s pOpt char(1) ;
dcl-s pOrd# packed(5:0) ;
dcl-ds ProgramStatus PSDS;
SourceLine# char(8) pos(21); // Source List line #
ExceptType char(3) pos(40); // Exception type
ExceptNumber char(4) pos(43); // Exception Number
ExceptData char(80) pos(91); // Exception Data
ExceptID char(4) pos(171); // Exception ID
Date char(8) pos(191); // Date in *date fmt
JobName char(10) pos(244); // Job Name
UserID char(10) pos(254); // User
JobNumber zoned(6) pos(264); // Job Number
end-ds;
// ?Display Function Keys indicators
dcl-ds F_Keys;
ExitRequest ind pos(3);
RefreshRequest ind pos(5);
NewOrder ind pos(6);
SflDisplay ind pos(30);
CntrlDisplay ind pos(31);
SflClear ind pos(32);
filterChanged ind pos(71);
Alarm ind pos(98);
SflEnd ind pos(99);
end-ds;
RPGVideo_AttendeeWorkbook.docx
64 of 79
*
Prototype for procedure to see, maintain delete
dcl-pr orderMaintenance extpgm('EXER1003C');
*n packed(5:0); // order number
*n char(1) ;
// option
end-pr;
//?==================
loadSfl() ;
//
C-Specs
=================================
Load subfile with open orders
Dou ExitRequest;
//
?Display screen
Write scr03;
Exfmt scr02;
ResetScreen() ;
//
?Support Function Keys
Select;
When ExitRequest ;
Leave;
When RefreshRequest;
ValidateInput();
// validate search on refresh request
If msgLine <> *Blanks ;
Iter;
Endif;
loadSfl() ;
Iter;
When NewOrder;
pOrd# = 0 ;
pOpt = 'A' ;
orderMaintenance(pOrd#:pOpt) ; // Screen to enter new order
Iter ;
Other ;
checkOptions() ;
// Enter, read subfile
ValidateInput() ;
// See if filters changed
If msgLine <> *Blanks ;
Iter;
Endif;
If filterChanged ;
// if filter fields changed
LoadSfl() ;
// reload subfile
Endif ;
Iter;
Endsl;
Enddo;
*INlr = *ON;
//---------------------------------------------------------------------------Dcl-proc LoadSfl;
RPGVideo_AttendeeWorkbook.docx
65 of 79
//
?Initialize subfile
rrn1 = 0 ;
SflDisplay = *off;
CntrlDisplay = *off;
SflClear = *on;
Write scr02;
SflClear = *off;
optS = ' ' ;
//
?Load subfile
Setll *Loval OrdrRec ;
Dou %eof(csordpl01) ;
Read OrdrRec ;
If %eof(csordpl01) ;
Leave ;
Endif ;
//
Read Order File
If CustNoF <> 0 and CustNoF <> Cust# ;
Iter ;
// Skip customers if use filter
Endif;
If Odate < OdateF8 ; // can use without check for zero
Iter ;
// because any valid date will qualify
Endif;
Ord#S = OrdNbr ;
// Load fields
OdateS = %dec(%date(Odate:*ISO):*MDY) ;
OrdTotS = OrdTot ;
PaymntS = Paymnt ;
TwgtS = Twgt ;
Select ;
When Osts = ' ' ;
OrdStsS = 'OPEN' ;
When Osts = 'BO' ;
OrdStsS = 'BACKORDER' ;
Other ;
OrdStsS = 'UNKNOWN' ;
Endsl;
CustNoS = Cust# ;
Chain Cust# CustRec ;
If %found ;
CusNameS = %trimr(cFname) + ' ' + %trimr(cLname) ;
Else ;
CusNameS = 'Customer not found!!' ;
Endif;
rrn1 += 1 ;
Write scr01;
//
Write subfile record
If rrn1 = 9999 ;
Leave ;
Endif;
//
Stop if reach subfile limit
RPGVideo_AttendeeWorkbook.docx
66 of 79
Enddo ;
OrdNumD = RRN1 ;
//
?Get ready to display, if there is something
CntrlDisplay = *on;
SflEnd = *on;
If rrn1 > 0;
SflDisplay = *on;
Else;
SflDisplay = *off ;
msgLine = 'No records to display' ;
Endif;
SflDsp = 1 ;
End-proc ;
//---------------------------------------------------------------------------Dcl-proc checkOptions ;
If SflDisplay = *off ;
Return ;
Endif ;
//
//
If we didn't have anything to display
there is nothing to read in SFL
Dou %eof(exer1002d) ;
Readc scr01 ;
// Read changed records
If %eof(exer1002d) ;
Leave ;
Endif ;
If OptS = ' ' ;
// Option could be changed, but blank
Iter ;
Endif ;
If OptS = 'C' or OptS = 'V' or OptS = 'D' ;
// valid options only
orderMaintenance(Ord#S:OptS) ; // bring up order for appropriate
Endif ;
// action
OptS = ' ' ;
// clear option
Update scr01 ;
SflDsp = RRN1 ;
// display subfile at the last action
Enddo ;
End-proc ;
//---------------------------------------------------------------------------Dcl-proc validateInput ;
If CustNoF <> 0 ;
// need only one customer
Chain CustNoF CustRec ;
If not %found(cscstp) ;
msgLine = 'Filter by Invalid Customer Number' ;
Return ;
Endif;
Endif;
If OdateF <> 0 ;
RPGVideo_AttendeeWorkbook.docx
67 of 79
Monitor ;
// orders from entered date forward
OdateF8 = %dec(%date(OdateF:*MDY):*ISO) ;
On-Error ;
msgLine = 'Invalid From Date' ;
OdateF8 = 0 ;
Endmon;
Else ;
OdateF8 = 0 ;
Endif ;
End-proc;
//---------------------------------------------------------------------------Dcl-proc ResetScreen;
//
?Reset screen indicators
msgLine = *Blanks ;
Alarm = *off;
End-proc ;
****
End Of Source
****
Program source EXER1003C
/*
TAG01
TAG02
This Program starts and ends commitment control
for the order maintenace program EXER1003 and is
called from program EXER1002.
Pgm
PARM(&ORDER &ACTION)
Dcl
Dcl
VAR(&ORDER) TYPE(*DEC) LEN(5 0)
VAR(&ACTION) TYPE(*CHAR) LEN(1)
STRCMTCTL
LCKLVL(*CHG) CMTSCOPE(*JOB)
Call
PGM(EXER1003) PARM(&ORDER &ACTION)
*/
EndCmtCtl
Endpgm
****
End Of Source
****
Display file source EXER1003D
A*%%TS SD 20170304 203348 MVALDMAN
REL-V7R1M0 5770-WDS
A*****************************************************************
A*$
A*$ SYSTEM NAME:
ORDER MAINTENANCE - SINGLE ORDER
A*$ FILE NAME:
EXER1003D
RPGVideo_AttendeeWorkbook.docx
68 of 79
A*$ TYPE OF FILE:
DSPF
A*$
A*$ AUTHOR:
MAX VALDMAN
A*$
A*$ DESCRIPTION:
A*$
A*$ FILE REVISION LOG:
A*$ ----------------A*$
A*$
DATE
PROGRAMMER
PROJECT# DESCRIPTION OF REVISION
A*$ -------- -------------- -------- ----------------------------A*$
A*****************************************************************
A*%%EC
A
DSPSIZ(24 80 *DS3)
A
PRINT(*LIBL/QSYSPRT)
A
INDARA
A*---------------------------------------------------------------A*
A
R SCR01
SFL
A*%%TS SD 20170304 203348 MVALDMAN
REL-V7R1M0 5770-WDS
A
LNITMNOH
3S 0H
A
QTYORDH
4S 0H
A
QTYHOLDH
4S 0H
A
TRACKH
7A H
A
OPTS
1A B 7 3
A 70
DSPATR(PR)
A
PRODNOS
6S 0O 7 6
A
DESCRPS
25A O 7 13
A
QTYORDS
4Y 0B 7 40EDTCDE(4)
A 70
DSPATR(PR)
A
LINECSTS
12Y 2O 7 46EDTCDE(4 $)
A
QTYHOLDS
4Y 0B 7 63EDTCDE(4)
A 70
DSPATR(PR)
A
TRACKS
7A B 7 69
A 70
DSPATR(PR)
A
STSS
2A O 7 78
A
R SCR02
SFLCTL(SCR01)
A*%%TS SD 20170304 192702 MVALDMAN
REL-V7R1M0 5770-WDS
A
SFLSIZ(0045)
A
SFLPAG(0014)
A
CA03(03 'Exit')
A
CF05(05 'Refresh')
A
CF06(06 'New Order')
A
CA12(03)
A
CF07(07 'Delete')
A 98
ALARM
A 98
MSGALARM
A
OVERLAY
A
SFLCSRRRN(&SFLRRN)
A 30
SFLDSP
A 31
SFLDSPCTL
A 32
SFLCLR
A 99
SFLEND(*MORE)
A
SFLDSP
4S 0H
SFLRCDNBR
A
SFLRRN
5S 0H
A
1 2'Oper ID:'
A
1 11USER
RPGVideo_AttendeeWorkbook.docx
69 of 79
A
1 32'Order Maintenance'
A
DSPATR(HI)
A
DSPATR(UL)
A
1 62'SCR02'
A
1 72DATE
A
EDTCDE(Y)
A
2 2'EXER1003'
A
2 32'Program Mode:'
A
DSPATR(HI)
A
MODE
6A O 2 46DSPATR(HI)
A
2 72TIME
A
4 2'New Line:'
A
COLOR(BLU)
A
4 12'Prod No-'
A
NPRODNO
6Y 0B 4 21EDTCDE(4)
A 72
DSPATR(PR)
A
4 30'Quantity-'
A
NQTYORD
4Y 0B 4 40EDTCDE(4)
A 72
DSPATR(PR)
A
4 47'Customer:'
A
COLOR(BLU)
A
CUSTNOH
6Y 0B 4 57EDTCDE(4)
A 71
DSPATR(PR)
A
4 65'Order #:'
A
COLOR(BLU)
A
ORD#H
5S 0O 4 74
A
5 2'Options: D=Delete'
A
DSPATR(HI)
A
6 2'Opt'
A
COLOR(YLW)
A
6 10'Product'
A
COLOR(YLW)
A
6 39'Ord Q'
A
COLOR(YLW)
A
6 48'Line $'
A
COLOR(YLW)
A
6 62'Hld Q'
A
COLOR(YLW)
A
6 69'Track #'
A
COLOR(YLW)
A
6 78'Sts'
A
COLOR(YLW)
A
R SCR03
A*%%TS SD 20170304 174106 MVALDMAN
REL-V7R1M0 5770-WDS
A
23 3'F03=Exit
F12=Cancel'
A
COLOR(BLU)
A 75
23 27'F07=Delete'
A
COLOR(BLU)
A
MSGLINE
70A O 24 3DSPATR(BL)
A*%%RS+<record-sequences>
A*%%RS+ <sequence name="SCREEN1">
A*%%RS+ <device type="display" width="80" height="24" />
A*%%RS+ <record-write record-format="SCR03" />
A*%%RS+ <record-write record-format="SCR01" />
A*%%RS+ <record-write record-format="SCR02" />
A*%%RS+ </sequence>
A*%%RS </record-sequences>
RPGVideo_AttendeeWorkbook.docx
70 of 79
****
End Of Source
****
Program source EXER1003
ctl-opt datfmt(*iso) datedit(*ymd) timfmt(*iso) DftActGrp(*No)
truncnbr(*yes) option(*srcstmt : *nodebugio) ;
// **************************************************************
// Displays order lines to maintain/option to enter new line
*
// and uses commitment control
*
// EXER1003 - COMMON RPG Video Series
*
// Written 03-04-17
*
// **************************************************************
//?==================
TAG03
TAG03
Files
=================================
dcl-f exer1003d workstn sfile(scr01:rrn1) indds(f_keys);
dcl-f csordp usage(*update: *output: *delete) keyed Commit;
dcl-f csordprp usage(*update: *output: *delete) keyed Commit;
dcl-f cscstp keyed;
dcl-f csinvp keyed;
//?==================
Variables
=================================
dcl-pr orderMaintenance extpgm('EXER1003'); // Declare program parameters
*n packed(5:0); // pOrderNo
*n char(1); // pAction
end-pr;
dcl-pi orderMaintenance;
pOrderNo packed(5:0);
pAction char(1);
end-pi;
dcl-s rrn1 packed(4); // rrn subfile 1
dcl-s q1 packed(5);
dcl-s pMode char(1);
dcl-s OdateF8 packed(8:0) ;
dcl-s pOpt char(1) ;
dcl-s pOrd# packed(5:0) ;
dcl-s needToReload ind ;
dcl-s counter packed(4:0) ;
dcl-ds ProgramStatus PSDS;
SourceLine# char(8) pos(21); // Source List line #
ExceptType char(3) pos(40); // Exception type
ExceptNumber char(4) pos(43); // Exception Number
ExceptData char(80) pos(91); // Exception Data
ExceptID char(4) pos(171); // Exception ID
Date char(8) pos(191); // Date in *date fmt
JobName char(10) pos(244); // Job Name
UserID char(10) pos(254); // User
RPGVideo_AttendeeWorkbook.docx
71 of 79
JobNumber zoned(6) pos(264); // Job Number
end-ds;
// ?Display Function Keys indicators
dcl-ds F_Keys;
ExitRequest ind pos(3);
CancelRequest ind pos(12);
DeleteRequest ind pos(7) ;
SflDisplay ind pos(30);
CntrlDisplay ind pos(31);
SflClear ind pos(32);
ProtectLine ind pos(70) ;
ProtectCustomer ind pos(71);
ProtectProductQty ind pos(72) ;
DeleteOrder ind pos(75) ;
Alarm ind pos(98);
SflEnd ind pos(99);
end-ds;
//?==================
C-Specs
=================================
detectMode() ;
loadSfl() ;
Dou ExitRequest;
//
?Display screen
Write scr03;
Exfmt scr02;
ResetScreen() ;
//
?Support Function Keys
Select;
When ExitRequest ;
Leave;
When DeleteRequest ;
If DeleteOrder ;
processDeleteRequest() ;
Leave ;
Endif;
Other ;
processAddChange() ;
If msgLine <> *Blanks ;
Iter;
Endif;
If needToReload ;
loadSfl() ;
Iter ;
Endif;
Iter;
Endsl;
RPGVideo_AttendeeWorkbook.docx
72 of 79
Enddo;
*INlr = *ON;
//---------------------------------------------------------------------------Dcl-proc detectMode;
//
//
Detect program mode, turn on/off appropriate
indicators, show program mode
Ord#H = pOrderNo ;
Select ;
When pAction = 'A' ;
Mode = 'ADD' ;
ProtectProductQty = *ON ;
ProtectLine = *ON ;
MsgLine = 'Enter Customer Number' ;
When pAction = 'C' ;
Mode = 'CHANGE' ;
ProtectCustomer = *ON ;
When pAction = 'V' ;
Mode = 'VIEW' ;
ProtectLine = *ON ;
ProtectCustomer = *ON ;
ProtectProductQty = *ON ;
When pAction = 'D' ;
Mode = 'DELETE' ;
ProtectLine = *ON ;
ProtectCustomer = *ON ;
ProtectProductQty = *ON ;
DeleteOrder = *ON ;
Other ;
Mode = *Blanks ;
Endsl;
End-proc;
//---------------------------------------------------------------------------Dcl-proc LoadSfl;
//
?Initialize subfile
rrn1 = 0 ;
SflDisplay = *off;
CntrlDisplay = *off;
SflClear = *on;
Write scr02;
SflClear = *off;
optS = ' ' ;
If pAction <> 'A' ;
Chain pOrderNo OrdrRec ;
If %found(csordp) ;
CustNoH = Cust# ;
RPGVideo_AttendeeWorkbook.docx
73 of 79
Else ;
CustNoH = 0 ;
Endif;
Endif;
//
?Load subfile
Setll Ord#H OrderRec ; //
Dou %eof(csordprp) ;
Reade Ord#H OrderRec ;
If %eof(csordprp) ;
Leave ;
Endif ;
Read Order File
If pAction = 'C' ;
If Sts = 'SH' ;
ProtectLine = *ON ;
// Can't change shipped line
Else ;
ProtectLine = *OFF ;
Endif;
Endif;
If pAction = 'D' ;
If Sts = 'SH' ;
// Can't delete when something
DeleteOrder = *Off ;
// is shipped
MsgLine = 'Order has shipped lines, cannot delete' ;
Endif ;
Endif;
ProdNoS = ProdNo ;
// Load fields
Chain ProdNo InvRec ;
If %found ;
DescrpS = Descrp ;
Else ;
DescrpS = 'Product not found!!' ;
Endif;
QtyOrdS = QtyOrd ;
QtyHoldS = QtyHold ;
TrackS = Track ;
LineCstS = LineCst ;
StsS = Sts ;
LnItmNoH = LnItmNo ;
// Load hidden fields too
QtyOrdH = QtyOrd ;
QtyHoldH = QtyHold ;
TrackH = Track ;
rrn1 += 1 ;
Write scr01;
//
Write them to the subfile record
If rrn1 = 9999 ;
Leave ;
Endif;
//
Stop if reach subfile limit
Enddo ;
RPGVideo_AttendeeWorkbook.docx
74 of 79
//
?Get ready to display, if there is something
CntrlDisplay = *on;
SflEnd = *on;
If rrn1 > 0;
SflDisplay = *on;
Else;
SflDisplay = *off ;
msgLine = 'No records to display' ;
Endif;
SflDsp = 1 ;
End-proc ;
//---------------------------------------------------------------------------Dcl-proc processAddChange ;
If pAction = 'A' ;
processAdd() ;
Return ;
Endif;
If pAction = 'C' ;
processChange() ;
Return ;
Endif;
End-proc ;
//---------------------------------------------------------------------------Dcl-proc processAdd ;
// This is a brand new order
needToReload = *OFF ;
//
//
//
TAG04
Make sure that work flow works - cuatomer # first
product number when customer is established
Validate all entires
If ProtectProductQty and CustNoH = 0 ;
MsgLine = 'MUST enter Customer # ' ;
Return ;
Endif;
If ProtectProductQty and InvalidCustomer(CustNoH) ;
MsgLine = 'Invalid Customer Number' ;
Return ;
Endif;
If ProtectProductQty = *ON ;
ProtectProductQty = *OFF ;
ProtectCustomer = *ON ;
Monitor;
writeOrderHeader() ;
Commit;
MsgLine = 'Continue entering products' ;
Return ;
On-Error;
MsgLine = 'Order Header Error';
RPGVideo_AttendeeWorkbook.docx
75 of 79
TAG05
ProtectProductQty = *On ;
ProtectCustomer = *Off ;
needToReload = *Off;
Rolbk;
Return;
EndMon;
Endif ;
If InvalidProduct(NprodNo) ;
MsgLine = 'Invalid Product entered' ;
Return ;
Endif;
If NqtyOrd = 0 ;
MsgLine = 'Must enter quantity' ;
Return ;
Endif;
//
//
TAG04
TAG05
If got here - need to write product detail
and reload subfile
Monitor;
WriteOrderDetail() ;
needToReload = *ON ;
Commit;
Return ;
On-Error;
Rolbk;
needToReload = *Off;
MsgLine = 'Could not add Item';
Return;
EndMon;
End-proc ;
//---------------------------------------------------------------------------Dcl-proc processChange ;
// Changing existing order
Monitor;
needToReload = *OFF ;
//
Validate entires on a new line
If NprodNo <> 0 and invalidProduct(NprodNo) ;
MsgLine = 'Invalid Product entered' ;
Return ;
Endif;
If NprodNo <> 0 and NqtyOrd = 0 ;
MsgLine = 'Must enter quantity' ;
Return ;
Endif;
If NprodNo <> 0 ;
WriteOrderDetail() ;
needToReload = *ON ;
Endif;
RPGVideo_AttendeeWorkbook.docx
76 of 79
//
TAG04
TAG05
Process changes to existing lines
For counter = 1 to lItems ;
Chain counter scr01 ;
If %found ;
If OptS = 'D' ; // delete line
Chain (pOrderNo:LnItmNoH) OrderRec ;
If %found ;
// no file name is intentional
Delete OrderRec ;
needToReload = *ON ;
Endif;
Iter ;
Endif;
If QtyOrdH <> QtyOrdS or // see if there was a change
QtyHoldH <> QtyHoldS or
TrackH <> TrackS ;
Chain (pOrderNo:LnItmNoH) OrderRec ;
If %found(csordprp) ;
QtyOrd = QtyOrdS ;
QtyHold = QtyHoldS ;
Track = TrackS ;
Update OrderRec ;
needToReload = *ON ;
Endif;
Endif;
Endif;
Endfor;
Commit;
On-Error;
Rolbk;
needToReload = *Off;
MsgLine = 'Problem changing the order';
EndMon;
End-proc ;
//---------------------------------------------------------------------------Dcl-proc writeOrderHeader ; // Create order header
Setgt *HIVAL OrdrRec ; //
Readp OrdrRec ;
Ord#H = Ordnbr + 1 ;
Clear *All OrdrRec ;
Ordnbr = Ord#H ;
Odate = %dec(%date:*ISO) ;
Cust# = CustNoH ;
Write OrdrRec ;
Get last used order number
End-proc ;
//---------------------------------------------------------------------------Dcl-proc writeOrderDetail ; // Write order detail
Clear *All OrderRec ;
RPGVideo_AttendeeWorkbook.docx
77 of 79
Chain Ord#H OrdrRec ;
If %found(csordp) ;
lItems += 1 ;
Update OrdrRec ;
Endif;
//
//
Increment number of lines
in order header
Ord# = Ord#H ;
ProdNo = NProdNo ;
QtyOrd = NQtyOrd ;
LnItmNo = lItems ;
LineCst = QtyOrd * SellPr ;
Write OrderRec ;
End-proc ;
//---------------------------------------------------------------------------Dcl-proc InvalidCustomer ;
// Validate customer number
Dcl-pi InvalidCustomer ind ;
checkCustNo packed(6:0) ;
End-pi;
dcl-s badCustNo ind ;
Chain checkCustNo CustRec ;
If not %found ;
badCustNo = *ON ;
Endif;
Return badCustNo ;
End-proc ;
//---------------------------------------------------------------------------Dcl-proc InvalidProduct ;
// Validate Product number
Dcl-pi InvalidProduct ind ;
checkProduct packed(6:0) ;
End-pi;
dcl-s badProduct ind ;
Chain checkProduct InvRec ;
If not %found ;
badProduct = *ON ;
Endif;
Return badProduct ;
End-proc ;
//---------------------------------------------------------------------------Dcl-proc processDeleteRequest ;
//
//
//
Always delete detail records before header records so
foreign key constraints can be more easily implemented
at a later date
// Begin monitoring for errors
RPGVideo_AttendeeWorkbook.docx
78 of 79
Monitor;
// Delete all order details
Setll pOrderNo OrderRec ;
Dou %eof(csordprp) ;
Reade pOrderNo OrderRec ;
If %eof(csordprp) ;
Leave ;
Endif;
Delete OrderRec ;
Enddo;
// Delete order header
Chain pOrderNo OrdrRec ;
If %found(csordp) ;
Delete OrdrRec ;
Endif;
TAG04
TAG05
// Commit Changes
Commit;
// Any Error in this procedure will issue a Rollback command
On-error;
Rolbk;
EndMon;
End-proc ;
//---------------------------------------------------------------------------Dcl-proc ResetScreen;
//
?Reset screen indicators
msgLine = *Blanks ;
Alarm = *off;
End-proc ;
****
End Of Source
****
RPGVideo_AttendeeWorkbook.docx
79 of 79
