METU - DEPARTMENT OF MECHANICAL ENGINEERING
ME105 COMPUTER AIDED ENGINEERING GRAPHICS
HOMEWORK 8
Please upload your solutions to "Homework 8" link on ODTUClass under your section.
You can find the "due date" of this homework under "Homework 8" link.
Homework "due date" will not be extended and resubmission of homework files (file change, update, etc.) will not be
allowed after the "due date".
Only files which are uploaded to the "Homework 8" link before the "due date" will be graded. Homework files which
are sent via email will not be accepted and will not be graded.
QUESTION (15 points)
Isometric view of an object is given. Construct the solid model and prepare a technical drawing showing the following
views on Siemens NX 11.
Use view scale 1:1, paper size A4 and do not use a Template.
a) Top, front, right side views
b) Auxiliary view of the inclined surface
c) Isometric view of the object without dashed lines
Filename: IDnumber-HW8 (Example: 1234567-HW8)
