Section 3B
MEMB 243 Mechanics of Materials
Semester 2 2014/2015
Quiz 2
Question 1
Link BD is made of brass (E = 105 Gpa) and has a cross-sectional area of 240mm2 . Link CE is made of
aluminium (E = 72 Gpa) and has a cross-sectional area of 300 mm2 . Knowing that they support the rigid
member ABC, determine the maximum force P that can be applied vertically at point A if the deflection of
A is not to exceed 0.35 mm.
Question 2
The device is used to measure a change in temperature. Bars AB and CD are made of A-36 steel and 2014T6 aluminium alloy respectively. When the temperature is at 40°C, ACE is in the horizontal position.
Determine the vertical displacement of the pointer at E when the temperature rise to 80°C.
