IEC 61537 TEST SUMMARY
TEST RESULTS: FOE-100 CL-900
LOADING TEST
The table shows maximum allowed safe working load, safety factor is 1.7. End span is reduced to 3/4 of intermediate span.
Description
Support Spacing (m)
SWL (Kg/m)
SWL deflection intermediate span (mm)
FOE-100 CL-900
3
230
15
IMPACT TEST
The criteria for passing the test is that the samples show no signs of disintegration and/or deformation that impairs safety.
Product
Material thickness
rung/wall (mm)
Temperature
(°C)
Approximate energy
(J)
Result
5/4
-20
20
Passed
FOE-100 CL-150
ELECTRICAL PROPERTIES TEST
Cable tray system components and cable ladder system components shall be deemed electrically non-conductive if having
surface resistivity values of 100 MΩ or greater. Compliance is checked according to IEC 61537:2006, 11.2.1-11.2.6.
FRP System
Tested surface resistivity (MΩ)
FOE Cable Ladder
7180
Test results
Passed
FIRE HAZARD TESTS
Contribution to Fire:
System components which might be exposed to abnormal heat due to an electical fault shall have limited ignitability.
Compliance is checked by the test according to IEC 60695-2-11:2000 with a glow-wire temperature of 650ºC.
Observations: No visible flame observed and no substantial glowing. No ignition of wrapping tissue paper.
Test results: Passed
Spread of Fire:
Non-flame propagating systems components shall either not ignite or, if ignited, shall have a limited spread of fire.
Compliance is checked by;
(1) Test according to IEC 60695-2-11 with a glow-wire temperature of 650ºC for 30s.
Observations: No visible flame observed and no substantial glowing. No ignition of wrapping tissue paper.
Test results: Passed
(2) Flame test using the burner specified in IEC 60695-11-2 (exposure of the flame for 60s ± 2s)
Observations: No ignition observed. No ignition of wrapping tissue paper. No evidence of burning.
Test results: Passed
ØI-RD-TD-EN-0195 Rev. 3
Øglænd System AS
E-mail: oglaend@oglaend-system.com
Phone: +47 51 78 81 00
www.oglaend-system.com
Date: 21/02/22
Page 1/1
