Assignment 9
• TASK: Create the three-dimensional assembly model and technical
assembly drawing of the Pulley Assembly. Parts’ dimensions are given
on the next page.
• Files to be delivered:
• Individual files of all parts used in the assembly (*.SLDPRT)
• Assembly file (*.SLDASM)
• Assembly technical drawing file (*.SLDDRW)
• Submission format: All files will be in ONE SİNGLE archive file! (file with *.zip
or *.rar extension)
• File name: "A9_Surname_NameInitials_StudentNo.rar"
• Evaluation Criteria:
• Rules of 2D assembly drawing,
• BOM and numbering,
• Ability to fit the views into the frame in the given template
(enlargement or reduction scaling if necessary, to use the paper area
efficiently),
• Proper alignment of views within the frame and their placement in
accordance with the described rules.
▪ The assembly drawing must be in a single file and consists of:
1. An isometric view and a section view of the assembly model .
2. Adequate views and dimensioning of each of the parts.
3. Balloon numbering and bill of materials.
5. Shaft
5
4
3
4. Cylinder
6
2
1
3. Ring (2 pieces)
30
Front View
(through hole)
Fillets R3
2. Bearing body (2 pieces)
1. Table
