IBR Modeling Fundamentals
Songzhe Zhu
WECC MVS Workshop
September 17, 2020
ISO Public
Outline
• Modeling guideline for all IBRs connecting to
transmission and subtransmission
– Power Flow Representation
– Dynamic Models
– Active power – frequency control
– Reactive power – voltage control
– Fault ride-through
• Solar PV
• BESS and Hybrid
ISO Public
Page 2
Basics of modeling IBR connecting to
transmission and sub-transmission
ISO Public
Page 3
Power Flow Representation
• transmission and sub-transmission connected IBR
1
Interconnection
Transmission
Line
2
Substation
Transformer
3
Equivalent
Collector
System
4
Equivalent
Pad-mounted
Transformer
5
EQ
Point of
Interconnection
Equivalent
Generator
Plant-level
Reactive
Compensation
(if applicable)
Typical Single-Generator Equivalent Power Flow Representation
ISO Public
Collector System & IBR Equivalencing
• Equivalent impedance of the collector system shall be
represented
– Inverters respond to the terminal voltage
– Voltage at POI and terminals are quite different
• Multi-generator representation may be needed
– Multiple main GSUs, with separate collectors behind them
– Significantly diverse impedances behind different feeders
– Inverters by different manufacturers are installed behind the
feeders and these inverters have different control and protection
settings
ISO Public
Page 5
Multi-Generator Representation
1
Interconnection
Transmission
Line
2
Substation
Transformer
3
Equivalent
Collector
System
4
Equivalent
Pad-mounted
Transformer
5
G1
Equivalent
Generator 1
Point of
Interconnection
6
7
8
G2
Equivalent
Generator 2
G3
Equivalent
Generator 3
9
Illustrative Multi-Generator Equivalent Power Flow Representation
* Although not illustrated by this example, all var devices should be modeled explicitly.
ISO Public
Page 6
Positive Sequence Dynamic Models
• Generic models approved by WECC
• Very flexible to model different control setups
• Models are supported and benchmarked among different
software platforms
• Easy access to model documents and user guides
• Generally applicable for systems with a short circuit ratio
of 3 and higher at the point of interconnection
ISO Public
Page 7
Generic Dynamic Models
Enhanced model approved or under
development
Description
Model Name Applicability Notes
Converter
REGC_A
REGC_B
REGC_C
All IBR: current source model
All IBR: voltage source model
All IBR: REGC_B plus PLL and inner
current control loops
REEC_A
REEC_C
REEC_D
Type 3 and 4 WTG, solar PV
Battery energy storage
Enhanced model for all types of IBR
REPC_A
REPC_B
REPC_C
For controlling single device
For controlling multiple devices
Enhanced model for controlling single
device
LHVRT
LHFRT
Voltage ride-through
Frequency ride-through
Electrical control
Plant controller
Ride-through protection
* Models specific to WTGs are discussed in wind plant modeling session.
ISO Public
Page 8
Generic Model Structure
REPC
Q/V reference
P reference
REEC
iq command
ip command
ISO Public
REGC
Network
Interface
Page 9
Scaling for the Equivalent Generator Size
• Pmax and MVA base in the power flow model and
dynamic models are aggregated values
• Power flow model –
– MVA base is the sum of the individual MVA rating of the inverters
– Pmax is the maximum active power output from the equivalent
generator in accordance with the generation interconnection
study and interconnection agreement
• often lower than the sum of the individual rated MW of the
inverters due to the practice of oversizing inverters
• Dynamic models –
– Model parameters are expressed in per unit of the MVA base for
the model
– Typically MVA base matches the MVA base in the power flow
model
ISO Public
Page 10
Active Power – Frequency Control Options
• Power flow model: base load flag (BL)
– BL = 0: Pgen can be dispatched downward and upward
– BL = 1: Pgen can be dispatched downward only
– BL = 2: Pgen is fixed
• Dynamic model: REPC
– frqflag= 0/1: frequency response no/yes
– ddn & dup: downward & upward regulation gain
– fdbd1 (+) & fdbd2 (-): over- and under-frequency deadband for
frequency response (pu)
ISO Public
Page 11
Active Power – Frequency Control Options (Cont’d)
• With earlier version of the models (prior to Aug 2020)
– base load flag is not used in the dynamic simulation
– block frequency response through frqflag/ddn/dup
Functionality
BL
frqflag
ddn
dup
No response
2
0
-
-
Down regulation only
1
1
>0
0
Up and down regulation
0
1
>0
>0
• With model enhancement
– Base load flag is used to block frequency response in reec and repc
models except for repc_b.
Functionality
BL
frqflag
ddn
dup
No response
2
-
-
-
Down regulation only
1
1
>0
-
Up and down regulation
0
1
>0
>0
ISO Public
Page 12
Active Power – Frequency Control Key Parameters
• Other control parameters in REPC for frequency
response
– Kpg: proportional gain
– Kpi: integral gain
– Tlag: lag time constant
Non-step
deadband
ISO Public
Page 13
Reactive Capacity Requirement
• Interconnection requirement for IBR reactive capacity
has evolved, e.g.
– No requirement
– 0.95 power factor at POI
– FERC Order No. 827: 0.95 power factor (dynamic var)
at high side of the substation transformer
• The modeling recommendation in this presentation
focuses on IBR complying with FERC Order No. 827
ISO Public
Page 14
Model IBR Reactive Capability
• Inverter P-Q capability
– Manufacturer provides P-Q capability curves under different ambient
temperatures and DC voltages
– Use the P-Q capability curves to verify if there is sufficient capability to
meet the interconnection requirement
• Generator reactive capability in the power flow model
– Model the required reactive capability
– Qmax and Qmin of the equivalent generator are reactive capability at
Pmax, limited by the minimum amount to meet the interconnection
requirement
• Generator reactive capability in the dynamic models
– The physical capability is modeled, not limited by the PF requirement
ISO Public
Page 15
Reactive Power – Voltage Control in Power Flow
Assuming the only dynamic var sources are inverters –
• If inverters regulating voltage at point of measuring (POM)
– Voltage regulation bus is the high-side bus of the GSU
– The Generator is set to cont_mode = 2 with pf = 0.95, i.e. the power
flow solution will try to hold voltage at the regulated bus constant within
Q limits specified by pf
• If inverters regulating terminal voltage
– The Generator is set to cont_mode = -2 with pf ≤ 0.95, i.e. the
power flow solution will try to hold terminal voltage constant
within Q limits specified by pf
• Voltage regulation of LTC transformers
• Controlled shunts – SVD
ISO Public
Page 16
Power Flow Modeling Limitation on Reactive Power /
Voltage Control Coordination
• Reactive power – voltage control is coordinated by the
power plant controller (PPC)
• Inverter reactive output is controlled along a voltage
droop curve
• Most power flow software do not currently model PPC
and can’t do voltage droop control
– PPC power flow model is under development. WECC MVS has
published the model specification.
• Discuss more on PPC control in the hybrid plant
modeling session.
ISO Public
Page 17
Reactive Power – Voltage Control in Dynamic Models
• Different voltage control options are modeled by the
combination of pfflag, vflag and qflag in reec model and
refflag in repc model
Functionality
PfFlag
Vflag
Qflag
RefFlag
Constant local PF control
1
N/A
0
N/A
Constant local Q control
0
N/A
0
N/A
Local V control
0
0
1
N/A
0/1
1
1
N/A
Plant level Q control
0
N/A
0
0
Plant level V control
0
N/A
0
1
0
1
1
0
0
1
1
1
0
N/A
0
2
0
1
1
2
Local coordinated V/Q control
Plant level Q control + local coordinated
V/Q control
Plant level V control + local coordinated
V/Q control
Plant level PF control*
Plant level V control + local coordinated
V/Q control*
* repc_b only
ISO Public
Page 18
Plant Level Reactive Power – Voltage Control Options
• Voltage Control: RefFlg=1
– Select the regulating bus (Vreg)
– Set the monitored branch
– Set VcmpFlg=1 if using line
drop compensation (Rc and Xc)
– Set VcmpFlg=0 if using reactive
droop (Kc)
• Constant Q Control:
RefFlg=0
– Select the monitored branch
ISO Public
Page 19
Multiple Device Plant Control: REPC_B
Multiple Device
Control
Plant PF Control
ISO Public
Page 20
Plant Level Reactive Power – Voltage Control Key
Parameters
• Key parameters
–
–
–
–
–
–
Control deadband (dbd)
Input (emax/emin) and output (qmax/qmin) limits
Control gains (kp/ki)
Intentional phase lead (Tft)
Communication lag (Tfv)
Voltage threshold to freeze plant voltage integral control (vfrz)
ISO Public
Page 21
Inverter Level Reactive Power – Voltage Control
Options
If no plant controller –
PF Control
Constant Q Control
Local V Control
Local Coordinated Q/V Control
ISO Public
Page 22
Inverter Level Reactive Power – Voltage Control
Options (Cont.)
If coordinated with plant controller –
Plant level Q or V Control
Plant level Q or V Control and Local Coordinated Q/V Control
ISO Public
Page 23
Inverter Level Reactive Power – Voltage Control
during Voltage Dip
• Voltage dip: Vt < Vdip or Vt > Vup
• During voltage dip, local Q control and local V control
freeze
• K-factor control: proportional gain Kqv
ISO Public
Page 24
Coordinate Plant Level and Inverter Level Controls
• Key factors to achieve desired control performance –
– Choose control option: plant level control or plant level control
and local coordinated control
– At what voltage levels, freeze plant level Q/V control (vfrz) and
local Q/V control (vdip), taking into account plant controller
regulates POM bus voltage while the inverter controller regulates
terminal bus voltage
– At what voltage levels, k-factor control shall be activated
– Control gains and time constant associated with each control
mode
– P/Q priority
ISO Public
Page 25
Inverter Current Limit
iq control
Ip and Iq control
come together
ip control
ISO Public
Page 26
Invert Current Limit (Cont.)
• Define the maximum
inverter current imax
• REEC_A: voltagedependent current limits for
ip and iq separately (VDL1
and VDL2)
• Total current
𝑖𝑖𝑝𝑝2 + 𝑖𝑖𝑞𝑞2 is
limited by imax
• During low voltage, ipcmd or
iqcmd may be reduced until
the voltage recovers
depending on P/Q priority
ISO Public
Page 27
P-Q Priority
ISO Public
Page 28
Example of Different Control Strategies
Kvi = 40 & plant control
Vdip=0.9, Kqv = 2.0
Vt at fault is below 0.25.
Iqcmd rises quickly to 1.3.
Vt at fault is below 0.25.
Iqcmd rises quickly to
1.07.
After fault, initial Vt is 1.2.
After fault, initial Vt is
1.196.
Slower plant control keeps
voltage at 1.2 for about
0.13 sec.
Plant control freezes for
voltage outside [0.9,1.1].
Iqcmd reduces
immediately post fault.
Control Setup 1: slow plant control and no voltage dip and kqv control
Control Setup 2: enable voltage dip and kqv control
ISO Public
Frequency Ride-through
• Lhfrt model parameters should reflect the actual frequency
protective relay settings
• The settings should be PRC-024 compliant
• Frequency calculation in positive sequence stability programs are
not accurate during and immediately following the fault
• Work-around of false frequency tripping for a close-by simulated
fault –
– Use lhfrt in “alarm only” mode and analyze each individual alarms
– Disable frequency tripping under low voltage condition (dypar[0].v_f_inh
in javaini.p)
– Do not set instantaneous tripping and always include some delay for
frequency tripping
ISO Public
Page 30
Voltage Ride-through
• Lhvrt model parameters should match the actual voltage
protective relay settings
• The settings should be PRC-024 compliant
– PRC-024 requirement is set with voltage at the high side of the
substation transformer (POM)
– The actual protection is set with terminal voltage
– The voltage setpoints should take into account the difference between
inverter terminals and POM
ISO Public
Page 31
Modeling solar PV plants connecting to
transmission and sub-transmission
ISO Public
Page 32
Model Solar PV Momentary Cessation
• Model structure: REGC, REEC_D, REPC
• Modeling elements
– Current reduction during cessation [REEC_D].VDLq and VDLp
• set current limits to 0 for both ip and iq when the voltage is below Vmc-lv or
above Vmc-hv
– Disable low voltage power logic [REGC].lvplsw = 0
– Ramp control [REGC].rrpwr, iqrmax and iqrmin
– P/Q priority during recovery [REEC_D].pqflag
– Voltage dip logic [REEC_D].vblkl = Vmc-lv, vblkh = Vmc-hv
– Current recovery delay [REEC_D].Tblk_delay
ISO Public
Page 33
Comparison of REEC_D with REEC_A for Modeling
Momentary Cessation
• REED_D has the full capability of modeling momentary
cessation, while REEC_A does not.
REEC_A
MC low voltage threshold
MC high voltage threshold
Voltage-dependent reactive
current limit*
Voltage-dependent reactive
current limit*
Active current recovery delay
Reactive current recovery
delay
REEC_D
vdip
vup
VDL1
4 pairs of (vq, iq)
VDL2
4 pairs of (vp,ip)
Thld2
vblkl
vblkh
VDLq
10 pairs of (vq, iq)
VDLp
10 pairs of (vp, ip)
Tblk_delay
Not modeled
Tblk_delay
ISO Public
Page 34
REEC_D Model Enhancement
ISO Public
Page 35
Converting REEC_B to REEC_D
Parameter Name
•
REEC_D is an expansion of
REEC_B. If the solar PV
inverters do not use
momentary cessation, the
previous REEC_B models
can be easily converted to
REEC_D by adding
parameters in this table.
Value
rc
0
Xc
0
Tr1
0
Kc
0
Vcmpflag
0
Ke
0
Iqfrz
0
Thld
0
VDLq
(-1.0, imax), (2, imax), (0,0) …
VDLp
(-1.0, imax), (2, imax), (0,0) …
vblkl
0
vblkh
2
Tblk_delay
0
iqfrz
0
thld
0
thld2
0
vref1
0
pflag
0
ISO Public
Page 36
Modeling BESS and hybrid power plants
connecting to transmission and subtransmission
ISO Public
Page 37
Definition of Hybrid Power Plant
• A generating resource that is comprised of multiple
generation technologies that are controlled by a single
entity and operated as a single resource behind a single
point of interconnection (POI).
• Single point control of multiple generators is the key that
requires additional modeling capability.
ISO Public
Page 38
Two Types of Configuration
DC-Coupled
AC-Coupled
ISO Public
Page 39
BESS Plant and DC-Coupled Hybrid Plant – Power
Flow Model
• DC-coupled hybrid plant is modeled the same way as a
BESS only plant
• Batteries and solar PV arrays on the DC side are
modeled in a single generator
• Pmin in the power flow model represents the maximum
charging power
– For stand-alone BESS, pmin < 0;
– For hybrid, pmin <0 if charging from the grid; pmin = 0
if DC-side charging only.
ISO Public
Page 40
BESS Plant and DC-Coupled Hybrid Plant – Dynamic
Model
• Use the second generation RES models: regc, reec_c or
reec_d, repc
• Reec_c includes simulation of the state of charge
Common simulation set-up mistake:
PGEN < 0 and SOCini = 1.0; PGEN > 0 and SOCini = 0
• Reec_d does not have the state of charge logic any
more.
ISO Public
Page 41
AC-Coupled Hybrid Plant
• Different technologies are modeled by separate
generators
• Single point control needs to be implemented in both the
power flow model and the dynamic model
– Power Plant Controller (PPC) power flow model is
being developed
– Repc_b has been enhanced for better hybrid
frequency response control
ISO Public
Modeling Requirement for AC-Coupled Plant
• Frequency / active power control
– The total MW injection at the point of interconnection is limited
by the contractual maximum
– Different components have different frequency response
• Voltage / reactive power control
– Plant reactive output limit is typically 0.95 power factor at the
high side of substation transformer
– Power plant controller coordinates operation of the inverters,
transformer tap changers, SVDs, and other var devices to
maintain the regulated bus voltage within a deadband from the
voltage schedule
ISO Public
Proposed PPC Power Flow Model
• A PPC model is defined by:
– Individual devices such as generators, SVDs, and
other controllable reactive devices*
– A regulated bus
– QV characteristics at the regulated bus
– Plant real power limits
*Transformers that control tap will not be part of the
PPC
ISO Public
Page 44
PPC QV Characteristics
• The power flow solution represents an operating point such that the
Mvar being injected at the Regulated Bus from the devices in the
PPC will follow a QV characteristic with a deadband.
– For example, Qdb is 0 or equal to the var losses on the gen-tie;
qmax and qmin represents 0.95 lag/lead power factor at the
regulated bus
ISO Public
Page 45
Real Power Monitoring
• The PPC model monitors the real power injection at the
monitored bus and generate warning messages if the
injection is outside the plant real power limits.
ISO Public
Page 46
An Example of PPC Model
1
Interconnection
Transmission
Line
2
Substation
Transformer
3
Equivalent
Collector
System
4
Equivalent
Pad-mounted
Transformer
5
PV
Point of
Interconnection
T1
SVD
“SD”
100 MW
7
6
8
BT
T2
230kV
Equivalent
Generator for
Solar PV
Equivalent
Generator for
Battery
100 MW
34.5kV
PPC: Solar-BESS
Devices
Device Type
Bus 5 "PV"
Generator
Bus 8 "BT"
Generator
Bus 3 "SD"
SVD
Reactive Power Control
Regulated Bus
Bus 2
Qmax (Mvar)
34
Qmin (Mvar)
-34
Real Power Monitor
Monitored MW
At Bus 1 from Bus 2
Pmax
100
Pmin
-100
690V
QV Curve at Bus 2
ISO Public
Page 47
Dynamic Model for AC-Coupled Hybrid
• Use regc, reec and repc_b modules.
Module
Grid interface
BESS
Electrical
Component
controls
Non-BESS Component
Plant controller
Aux control
Voltage/frequency protection
PSLF modules
regc_*
reec_c or reec_d
PSSE modules
REGC*
REECC1 or
REECD1
Use appropriate modules for the
gen type
repc_b
PLNTBU1
REAX4BU1 or
REAX3BU1
lhvrt/lhfrt
VRGTPA/FRQTP
A
ISO Public
Page 48
More on REPC_B
• Invocation notes
– In PSLF implementation, REPC_B is invoked from one of generators in the plant.
It is important to have REPC_B invoked from an online generator.
– The regulated bus and the monitored branch must be specified for REPC_B.
• Reactive control
– Qmax and qmin are plant level reactive limits; on the system MVA base in PSLF
implementation
• Frequency control
– Set frqflag to enable plant level frequency response
– Use base load flag to enable or block individual component response
Component
Solar PV - Frequency response, down
only regulation
BESS - Frequency response, up and
down
Plant controller
BaseLoad flag
1
0
Module
reec_d
reec_c or reec_d
Repc_b with
Frqflag=1, dup > 0, ddn > 0
ISO Public
Page 49
Reference
• WECC MVS, Solar PV Plant Modeling and Validation Guideline
https://www.wecc.org/Reliability/Solar%20PV%20Plant%20Modeling%20and%
20Validation%20Guidline.pdf
• Pouyan Pourbeik, Memo RES Modeling Updates 083120_Rev17
https://www.wecc.org/Administrative/Memo_RES_Modeling_Updates_083120_
Rev17_Clean.pdf
• WECC MVS, Converting REEC_B to REEC_A/D
https://www.wecc.org/Reliability/WECC%20White%20Paper%20on%20Convert
ing%20REEC%20rev202008.pdf
• WEC MVS, Hybrid Plant Modeling Enhancement
https://www.wecc.org/_layouts/15/WopiFrame.aspx?sourcedoc=/Administrative/
WECC%20White%20Paper%20on%20modeling%20hybrid%20solarbattery.pdf
ISO Public
Page 50
Download
