Tutorial Letter 101/0/20223:
Assignment questions
Control Systems III – (Theory)
CSY3601
Year module
Department of Electrical Engineering
This tutorial letter contains assignment questions.
CSY3601 Assignment 1 2023
Assignment 1
Question 1: Modeling in the Time domain
Find the transfer function G(S)= Y(s)/R(s) for the following system represented in the state space:
0
1
0
0
𝑋̇ = [ 0
0
1 ]𝑥 + [ 0 ] 𝑟 ;
−3 −2 −5
10
𝑦 = [1
0 0] 𝑥
[15]
Question 2: Time Response.
361
Find ζ; ωn ; Ts ; Tp ; Tr and %OS whose transfer function is 𝐺(𝑠) = 𝑠2 +16𝑠+361
(20)
Total =35
2|Page
