Quiz-2 Question

advertisement
24/10/2022
MMU-203 Statics (Quiz-2)
The homogeneous plate has a mass of 90 kg. The magnitude of the tension in the cable is 800 N.
Replace the weight and cable forces by an equivalent force-couple system at hinge A.
