Reverse Design a Part
R. Repucci NVTHS
1-19-2022
1) Choose a part from the box.
2) Measure the entire object using a caliper or scale (ruler).
3) Create a multi-view sketch in your engineering notebook.
4) Create a 3-D model of your part based upon your sketch and measurements.
5) Create a 2-D drawing of your model with dimensions.
6) Submit your 2-D drawing to teacher in the classroom or share.
Due Date: Friday, February 4th.
