Course
ENGINEERING
ENGINEERING SCIENCE
N4
(15070434)
PROGRAMME:
CHEMICAL
ENGINEERING
LECTURER:
R SINGH
Berea Technology College
CHAPTER
HYDRAULICS
Berea Technology College
TOPIC
LESSON 39
HYDRAULIC PUMPS
Berea Technology College
OUTLINE
1. Learning outcomes
2. Introduction
3. Content
a) Concept
b) Examples
4. Activity
5. Additional Resources
Berea Technology College
LEARNING OUTCOMES
Students should be able to:
1. Analytically solve practical problems to determine
 the volume of liquid delivered per stroke
The pressure in the liquid, plunger diameter and force on plunger
The power required and efficiency with input power in the case of
single, double and three cylinder single acting pumps
Berea Technology College
INTRODUCTION
1. HYDRAULIC PUMPS
-
hydraulic pumps are used to transmit liquid
vertically, horizontally or against pressure
2. WORKING PRINCIPLE
Berea Technology College
-
If the plunger moves upwards, valve A is
opened and liquid is sucked from reservoir,
while valve B is closed
-
When the plunger is moving down, valve A is
closed and valve B is opened and liquid is
delivered at pressure
CONCEPT
3. WORK DONE AGAINST PRESSURE
𝑺𝒕𝒂𝒕𝒊𝒄𝒉𝒆𝒂𝒅 = 𝑺𝒖𝒄𝒕𝒊𝒐𝒏𝒉𝒆𝒂𝒅 + 𝑫𝒆𝒍𝒊𝒗𝒆𝒓𝒚𝒉𝒆𝒂𝒅
WD = F x s
WD = mgh
WD = (Vρ) xgh
WD = Ph x V
WD – work done (J)
F – force (N)
m- mass(kg)
h- height (m)
V – volume 𝒎𝟑
Ph – pressure (Pa)
S – distance (m)
4. VOLUME DELIVERED
V = A x sl x n
5. Water
𝑽𝒅 = 𝑨𝑷 𝐱 𝐬𝐥 𝐱 𝐧 × 𝑪 × 𝑵 × ʯ
1000 l = 𝟏𝒎𝟑
𝑽𝒅 - volume delivered (𝒎𝟑 )
ρ = 1000 kg/𝒎𝟑
𝑨𝑷 -
area (𝒎𝟐
)
𝒔𝒍 - stroke length (m)
𝒏 – number of strokes
𝑪 – number of cylinders
𝑵 – rotational frequency
ʯ - efficiency
𝝅𝒅𝟐
𝑨𝑷 =
𝟒
1l = 1kg
EXAMPLES
1 The plunger of a three-cylinder pump has a diameter of 1.1 water delivered in 𝑙/𝑠
90 mm and a stroke length of 590 mm. The crankshaft
𝑽𝑷 = 𝑨𝑷 𝐱 𝐬𝐥 𝐱 𝐧 × 𝑪 × 𝑵 × ʯ
speed is 240 r/min.
𝜋(0,09)2
4
Calculate the quantity of water delivered in litres per
second if the slip is 1,8%.
=
Given
= 0,044𝑚3 x 1000
= 44 𝑙/𝑠
D = 90 mm ÷ 1000
Sl = 590 mm ÷ 1000 = 0,59 m
= 0,09 m
N = 240 r/min ÷ 60 = 4r/s
ʯ = 100 – 1,8
= 98,2%/100% = 0,982
C=3
x 0,59 x 1x 3 x 4 x 0,982
2 The plunger of a three-cylinder single-acting
pump has a diameter of 280 mm and a stroke
length of 390 mm. The crankshaft speed is
333,33 r/min.
Calculate the volume of water delivered per hour if
the slip is 4,8%.
Given
d = 280 mm ÷ 1000
Sl = 390 mm ÷ 1000 = 0,39 m
= 0,28 m
N = 333,33 r/min × 60 = 20000 r/h
ʯ = 100 – 4,8
= 95,2% /100% = 0,952
C=3
1.1 water delivered /ℎ𝑟
𝑽𝑷 = 𝑨𝑷 𝐱 𝐬𝐥 𝐱 𝐧 × 𝑪 × 𝑵 × ʯ
𝜋(0,28)2
4
=
x 0,39 x1 X 3 x 20000x 0,952
=1371,699 𝑚3 /hr x 1000
=1371699 𝑙/ℎ𝑟
ACTIVITY
1. The crankshaft of a single-acting 3-cylinder water pump has plungers each having a diameter of 200 mm and a stroke
length of 600 mm runs at
1 800 r/min.
Calculate the following:
1.1
1.2
The volume of water delivered in kℓ/h if there is a slip of 5%
The input power to drive the pump if the efficiency is 90% and the static head is 32 m
HINT: Use the density for water as 1 000 kg/m3
ADDITIONAL RESOURCES
ENGINEERING SCIENCE N4 MJJ VAN RENSBURG
PAGE 125
Activity 5.1
Qn 2
PAGE 122
EXAMPLE 5.3
