Timkan Technologies
Realtime
Precision
Everywhere
 Company
 Technology & Products
 Applications & References
Symeo Presentation
Symeo GmbH – Radio Based Positioning
and Distance Measurement Solutions
High frequency radio based position
and distance measurement sensors
Products
Complete sensor solutions for seamless
position tracking, data communication,
and load detection
Solutions
Customer specific OEM product
development
Engineering
Symeo Presentation
Key Markets
Metals
Industry
Public
Transport
Timkan
Technologies
Container
Terminals
Mining/
Bulk
Cranes
Warehouses

Typical use cases: distance, position and collision avoidance of devices like
- cranes, - transport vehicles, - machine components, - products

Radio signals as source of sensor information mean:
no optics, no moving parts, no wear and tear, extremely robust against harsh
and adverse conditions (weather, dust, dirt, temperatures, vibration)
 maintenance-free operation
 uninterrupted processes
 new optimization opportunities
 significant cost savings
Symeo Presentation
End Users, Integrators
and OEM Customers
Symeo Presentation
Timkan
Technologies
Innovation in Sensor Technology
for Distance (d) and Position
Measurement
Timkan
Technologies
d
d
electromechanic
d
d
laser
ultrasonic
radio (Symeo LPR )
Planned and unplanned service cost in industrial environment
high (wear & tear)
high (lens cleaning)
high (head cleaning)
0
Influence of dust, heavy weather, vibration
high
high
high
0
Accuracy in long distance measurement (5 m or more)
good

better
good
better
For many industrial applications, the Symeo high precision radio distance
measurement is the best solution (cost and reliability)
Symeo Presentation
Technology & Products
 Company
 Technology & Products
 Applications & References
Symeo Presentation
LPR-1DXi
Components
Timkan
Technologies
LPR -1DXi with
integrated antenna
measured
distance

LPR-1DXi
- Accuracy:
- Measurement range:
- Measurement frequency:
- on-board relays:
± 0.5 m (option: up to ± 5 cm)
120m (option: 500 m)
5.8 GHz
dry contacts for distance control
Symeo Presentation
Distance Measurement &
Avoidance of Collision

Contact-less measurement via radio
waves

Unaffected by contamination, weather
and vibration

Usable indoors and outdoors

No precise alignment necessary

Easy to configure

Redundant system set-up for highsecurity applications

No additional operating or maintenance
costs
Symeo Presentation
Timkan
Technologies
LPR-1DXi
LPR-1D (type 1DX, 1DP, 1DP/2)
Components
Timkan
Technologies
optional antenna diversity measurement for long
distances/enhanced accuracy
measured
distance
HF-antenna cable

LPR-1D
- Accuracy:
- Measurement range:
- Measurement frequency:
- Optional on-board relays:
- User data transmission option
- Multiple data interfaces:
- Different antenna options:
Sector:
160° horizontal
30° vertical
Directive:
9° horizontal
9° vertical
up to +/- 5 cm
up to 1800 m
5.8 GHz
dry contacts for distance control
RS232, Ethernet TCP/IP, Profibus
Omnidirectional:
360° horizontal
9° or 30° vertical
Symeo Presentation
antenna
LPR -1D
Distance Measurement &
Avoidance of Collision
Timkan
Technologies
LPR-1DP
LPR-1DP/2
LPR-1DP/2
LPR-1DP/2
Virtual stop area
Virtual stop area
Captured data
(e.g. from load cell)
Captured data
(e.g. from load cell)
Dynamic acquisition of coordinates of an object with
two axes of movement, e.g. a crane trolley.
Sensor combination to avoid collision and provide
dynamic distances to fix point

By means of the LPR radio communication, all distances and captured IO data are available on
all three system units

Definition of ´no go´ areas (relays on crane / trolley) and active switching of external devices
(e.g. switching of warning lights; relays on wall unit) are standard features
Symeo Presentation
LPR-1DHP
Components
Timkan
Technologies
4°
optional antenna diversity measurement for long
distances/increased accuracy
measured
distance
integrated antenna
link cable

LPR-1DHP
- Accuracy:
- Measurement range:
- Measurement frequency:
- Multiple data interfaces:
- Integrated antenna:
up to +/- 1 cm
up to 500 m
61 GHz
RS232, Ethernet TCP/IP, Profibus
4° horizontal and vertical
opening angle
Symeo Presentation
LPR-1DHP
LPR-1DHP: ±1 cm Precise
Radio Distance Measurement
Timkan
Technologies
Advantage of LPR-1DHP :

Best accuracy for automated and semi-automated processes

Cost savings for installation and maintenance-free operation compared to conventional sensors

Not affected by material on the ground / debris on crane rails

Multiple functionality:
Anti skew - Position detection - Anti collision
Symeo Presentation
DR-1DHP
Passive Radar Components
corner
reflector
DR-1DHP

measured
distance
wide variety of
passive surfaces
DR-1DHP
- Accuracy:
- Measurement range:
- Measurement frequency:
- Multiple data interfaces:
- Integrated antenna:
up to +/- 1 cm
up to 70 m on cooperative targets
61 GHz
RS232, Ethernet TCP/IP, Profibus, relays
4° horizontal and vertical opening angle
Symeo Presentation
LPR-2D:
General Positioning Principle

Position of target is determined
by at least 3 distance
measurements to fixed
reference points at known
positions

LPR determines distances by
measuring the round-trip-timeof-flight (RTOF) of the radar
signal between target and
reference point (no optical or
cable network necessary)
Symeo Presentation
Timkan
Technologies
Highly Reliable Position Tracking for
Transport Vehicles and Cranes: LPR2D
Timkan
Technologies

Determination of position and heading angle (with 2 antenna set-up)

Contact-less measurement via radio waves

Unlimited system range

Unaffected by contamination, weather and vibration for indoors and outdoors operation

Simple installation, retrofit during continued operations possible

Suitable for all vehicle and crane types

Maintenance-free
Symeo Presentation
LPR-2D Components
Timkan
Technologies
LPR-2DB transponder
measured
distance
HF-antenna cable
antenna
alternative
receiver
LPR-2DB

LPR-2DB
- Accuracy:
- Measurement range:
- Measurement area:
- Measurement frequency:
- Multiple data interfaces:
- Orientation of moving object:
up to +/- 5 cm
up to 400 m
unlimited
5.8 GHz
RS232, Ethernet TCP/IP, Profibus
measured, if 2 antennas are
attached to LPR-2D
Symeo Presentation
SPU type,
with
integrated
antennae
Combination of D-GPS and LPR in
1 unit
Timkan
Technologies

Satellite navigation with a corrective differential signal allows the determination of
positions in unobstructed outdoor areas with up to +/- 1 m accuracy

LPR transponders serve as position reference in areas where DGPS is not reliable or
not available at all, with an even higher precision (few cm), indoor and outdoor
Symeo Presentation
2D Collision Avoidance
Timkan
Technologies

Freely moving objects like cranes or vehicles measure their position with LPR or GPS and
send/receive location and heading information by radio

Fixed objects can be protected also

No central control unit; Extension without updating any database of existing objects
Symeo Presentation
Combined LPR-2D/DGPS Receiver
LPR-2D
transponders

Timkan
Technologies
GPS satellites
LPR-2DB/D-GPS
- Accuracy:
- Measurement range:
- Measurement area:
- Orientation of moving object:
- Data interface:
LPR: up to ± 5 cm, D-GPS: up to ± 0.5 m
LPR: up to 400 m; D-GPS: outdoor
unlimited
measured, if 2 antennas each (LPR/GPS)
are attached to the unit
cable/wifi (TCP/IP) or Zigbee radio
Symeo Presentation
Monitoring Software
Symeo MAP and VISU

Monitoring and realtime
visualization of LPR or GPS
receivers (position,
orientation, status, signal
strength)

Display of raw
measurement results from
each transponder
Timkan
Technologies
Tracked movements of fork lift
during loading, transport and
discharge
Symeo Presentation

Component monitoring

Tracking of movements
and movement history

Visual replay of historic
data
Auxiliaries
2/3-dimensional
1-dimensional
Product Portfolio - Radio Based
Distance & Position Sensors
integrated
antenna
DR-1DHP
distance &
data
distance
distance &
data
LPR-1DX
LPR-1DP
LPR-1DP/2
1800 m
± 5 cm
5.8 GHz
LPR-1DXi
max. range:
max. accuracy:
frequency:
500 m
± 5 cm
5.8 GHz
Software tools
MAP
VISU
LPR-2DB
or
300 m
SPU
± 20 cm
5.8 GHz
LPR-1DHP
distance
500 m
± 1 cm
61 GHz
position (x,y) &
data
max. range:
max. accuracy:
frequency:
Timkan
Technologies
position (x,y)
& data
position (x,y)
& data
LPR-2DB/D-GPS
400 m / n.a.
or SPU
± 20 cm / 0.6m
5.8 & 1.5 GHz
Symeo Data Collector (SDC)
Sensors
Options:
- Digital I/O
- Analog inputs
- Data processing
- TCP/IP and serial
interfaces
Symeo Presentation
Ultrasonic
Inductive
50 m
± 1 cm
61 GHz
STU
n.a.
±3m
1.5 GHz
Antennae
LPR antennae:
- Directive
- Sector
- Omnidirectional
GPS antennae
Inertia
GPRS, zigbee, wifi
LPR – Customer Benefits
Timkan
Technologies

No moving parts – no wear and tear, no complex mechanical interface

No optical parts – no cleaning of lenses

Measurement not affected by harsh operational conditions (rain, snow, dust,
dirt, extreme temperatures, vibrations)

No maintenance necessary => costs of ownership= 0

Availability >>99% is industry proven
Symeo Presentation
Metals Industry Solutions

radio based position
measurement for material
tracking and automation

anti-collisions sensors
Timkan
Technologies
Slab/coil/billet
production
Bulk
material
Yard with finished
products
Furnaces /
cont. casting
Scrap metal
Coke oven

for cranes, transfer cars, transport vehicles, stacker/reclaimer and others
Symeo Presentation
Bulk Material Handling
Stockpile Measurement

Extremely dusty environment

System integrator provides
surface scanning

LPR is used for 1D position
acquisition of the scanner

Result is 3D dynamically
updated stockpile volume
model
Timkan
Technologies
LPR-1DP
Symeo Presentation
Brunsbuettel Port
Wheel Loader Tracking

Copper concentrate (granular) is
delivered by vessel and stored in
dedicated compartments of the
large storage hall

For copper production, certain
different materials have to be
delivered to the same in-feed
hopper by big wheel loaders

Wrong material can spoil the
blend – only real-time tracking
can detect drivers errors early
enough to warn them before
picking up or unloading wrong
materials

LPR-2D is used to track the
wheel loader movement in the
extremely dusty environment
LPR-2D
Symeo Presentation
Stacker/ Reclaimer
Position and Collision Avoidance

Stacker has drive units left
and right of stockpile;
LPR determines position of
each leg independently, also
avoiding crane skewing

Reclaimer position captured
along the drive rail

Position data also used to
avoid collision between the
machines
Reclaimer
LPR-1DP
Stacker
Symeo Presentation
Timkan
Technologies
Anti-collision for Coal Unloading

Timkan
Technologies
LPR to measure relative distance between gantry
cranes and digger
LPR-1DX

Simple, low cost solution

Maintenance-free, not affected by coal dust
COAL
Symeo Presentation
Coke Oven Battery Automation:
Reliable and Cost-effective
Positioning
Quenching car
Timkan
Technologies
Charging car
Coke batteries
Pusher car



LPR-1DHP
Accurate positioning of coke oven
equipment moving on rails
measured distance
Not affected by dust and dirt accumulating
on the sensors
Easy installation and retrofit on existing
cars on uneven rails
unit at the beginning of the battery
Symeo Presentation
unit on car
LPR-Based Oven Identification
and Machine Positioning System

Contact less, real-time
determination of distances and
positions for pusher and quenching
cars

LPR-1DHP distance measurement is
particularly well suited for the very
harsh coke battery environment, in
which other systems such as
mechanical encoders or lasers have
limited reliability and create service
cost

LPR-1DHP
Distance reading is available on both
active units of a measurement pair
Symeo Presentation
Timkan
Technologies
Iron Ore Transfer Car
Timkan
Technologies
Transfer car
Loading chute
LPR-1DHP
Automation of transfer car:

Positioning of ore car under chute

Positioning of ore car inside plant

Inmune to dust and temperature

Accuracy and range:
 LPR-1DP: 1800 m, up to +/- 5cm
 LPR-1DHP: 500 m, up to +/- 1cm
Symeo Presentation
Ladle Car Positioning


No active unit on the ladle car

no power req´d;

measurement immune to
very high temperatures
Position accuracy up to +/- 1 cm
DR-1DHP
metal
reflector
extreme heat
Symeo Presentation
Scrap Yard Crane - LPR Used to
Avoid Skewing and Collision

Scrap falling on the crane rails often
created crane damages and
downtimes

LPR measures position and skewing
to provide stop signal if scrap blocks
drive units of the crane
Timkan
Technologies
LPR-1DP
Symeo Presentation
ThyssenKrupp, Sepetiba Bay, Brazil;
Crane and Vehicle Tracking
Timkan
Technologies
Application:
 Position detection of vehicles and
cranes handling slabs and coils
 on site and during transportation
from plant to harbor
 system running on:
26 slab carriers (GPS)
4 overhead cranes (LPR-1D)
3 forklift trucks (DGPS/LPR-2D)
1 reach stacker (DGPS/LPR-2D)
Symeo Presentation
LPR-1DP
LPR-2D/D-GPS
Bilstein
Combined Crane and Forklift Tracking

Combined crane and forklift tracking
with LPR-2D allows automatic update of
coil storage positions
LPR-2D
Symeo Presentation
Timkan
Technologies
Dillinger Huette:
Crane Position Measurement

Timkan
Technologies
Steel mill with several production halls and outdoor
storage yards

Strong requirement for continuous storage location of
steel slabs; staff intensive task

Extreme heat, dust, environmental conditions;
conventional sensors generated expensive maintenance
costs (rotary encoder and laser)

More than 40 indoor and outdoor cranes are equipped with LPR-2D

Crane length up to >1000 m!

Uninterrupted system operation since summer 2003 without preventive
maintenance
Symeo Presentation
LPR-2D
y
>1000m
Hoesch-Hohenlimburg
Hagen und Duisburg Sites
Timkan
Technologies

LPR is applied for highly reliable position measurement
at two sites of the ThyssenKrupp group company

By tracking the crane movement, each slab is assigned
the correct warehouse coordinates in the customer´s
Warehouse Management Software.
Outdoor slab yard
LPR-2D
LPR-2D with
antennas
mounted on
the crane
trolley
LPR
transponders
along the
crane rail
WMS realtime image of the slab
yard = crane driver view
Symeo Presentation
ThyssenKrupp, Mobile, USA
Tracking of Crane Movement
Timkan
Technologies
Application:
 Position detection of cranes
 indoor and outdoor
 LPR-1D system running on 30
cranes
LPR-1DP
Symeo Presentation
voest-alpine
LPR-2D For Plate Routing

All plate movements are tracked by acquiring the dynamic crane
positions in order to update product location information in the
Warehouse Management System

The position of two separate hoists is acquired by 2 independent
LPR-2D units
antenna
hoist 1
LPR-2D
antenna
hoist 2
Symeo Presentation
Timkan
Technologies
Salzgitter AG
Anti-Collision
Timkan
Technologies

LPR-1DX anticollision sensors, redundant set-up

Respective cranes have height and side offset

Uninterrupted measurement over up to 500 m
distance required for safety reasons
LPR-1DX
Symeo Presentation
Tianjin Tiantie Metallurgical Group
(China)
Symeo AntiColl
LPR-1DP/2

Symeo collision controller for situations with
more than 3 cranes

Collision avoidance by continuous measurement
of all crane´s and hoist´s position with active
movement control and optional 3D visualisation
for complex crane systems
Symeo Presentation
Timkan
Technologies
Dunaferr – Crane Tracking For
Coil Storage Position
Timkan
Technologies

By continuously acquiring the crane position, coil storage locations are updated upon every
movement

LPR-1DP/2 on both cranes ensures highly reliable and maintenance free position data
LPR-1DP/2
LPR-1DP/2
with antenna
Symeo Presentation
Vallourec & Mannesmann Tubes
Bundle Tracking

Tubes are bundled and tied together
with snythetic or steel ropes

Bundles are handled by multiple cranes
Crane movement and bundle
pickup/drop are tracked by LPR-2D

The WMS records all movements and
dynamically updates bundle positions
LPR-2D
transponder
LPR
transponder
one cell
aprox. 25 m
crane
bridge
crane
bridge
trolley
trolley
crane
bridge
trolley
LPR-1D
unit
2 omnidirectional
antennas
y
x
planar
antennas
schematic LPR design
WMS screen shot
Symeo Presentation
Slab transport tracking
transponder



Forklift trucks handle slabs on a remote
slab yard
All slab movements (from/to) and load
changes (pick/drop) are tracked by LPR
Connection to the WMS is via WiFi to
record all movements
LPR-2D
LPR-2D
lifting height
detection
(optional)
WMS
connection
Load change
detection
(optional)
Symeo Presentation
Summary
Timkan
Technologies
 Symeo LPR features the
most precise radio
distance and position
sensors in the market
 LPR is maintenance-free
under harsh industrial
conditions
 Very cost-effective with
short return on invest
(„months, not years“)
Symeo Presentation
Timkan Technologies
Timkan Technologies
200 Woodcliff Dr
Canonsburg PA 15317
Ph: (412) 206-9445
Fax. (412) 564‐2747
Cell: (412) 551-6682
www.timkantech.com sales@timkantech.com
