HVAC Project and System Summary
for the Sample Residence
Project Description
1 floors • approx. 3,000 square feet
Winter Design conditions 28°F outside / 70°F inside
Summer Design conditions 94°F outside / 75°F inside
e
Building Description
pl
R-0 Slab floor
R-19 above grade walls (spray foam)
R-21 encapsulated attic (spray foam)
Infiltration Semi-Tight
ERV for ventilation
Windows & Glazed doors Low-E - U-value 0.32 SHGC 0.30 – no internal shade/insect screens
Glazing shaded per elevations
Ducts located in the encapsulated attic
Round Metal trunks (R-6) and flexible branches (R-6)
am
Calculated loads
Entire House
Recommended Equipment
Heating Btuh
46,362
Cooling Btuh
39,083
S
Summary: A 4-ton heat pump is a good choice for this project. Two stage or variable capacity
compressors will provide better low temperature operation in the winter and are
recommended. The software indicates the ideal equipment would be able to satisfy demand to
24°F in heat pump mode. This should be verified with actual equipment under consideration.
