IEEE Transactions on Power Delivery, Vol. 13, No. 1, January 1998
241
SSSC - Static Synchronous Series Compensator:
Theory, Modeling, and Applications
Kalyan K. Sen, Member, IEEE
Westinghouse Electric Corporation
13 10 Beulah Road
Pittsburgh, PA 15235, USA
-
Abstract This paper describes the theory and the modeling
technique of a Flexilile Alternating Current Transmission
Systems (FACTS) device, namely, Static Synchronous Series
Compensator (SSSC) using an Electromagnetic Transient
Program (EMTP) simullation package. The SSSC, a solid-state
voltage source inverter coupled with a transformer, is
connected in series with a transmission Line. A0 SSSC injects
an almost sinusoidal voltage, of variable magnitude, in series
with a transmission line. This injected voltage is almost in
quadrature with the line current, thereby emulating an
inductive or a capacitive reactance in series with the
transmission line. This emulated variable reactance, inserted
by the injected voltage source, influences the electric power
flow in the transmissioni line.
Keywords - AC transinission, FACTS, power flow controller,
power converter, inverter, thyristor, GTO, etc.
I. INTRODUCTION
Electric power flow h o u g h an altemating current transmission
line is a function of the line impedance, the magnitudes of the
sending-end and receiving-end voltages, and the phase angle
between these voltages. The power flow can be decreased by
inserting an additional inductive reactance in series with the
transmission line, therehy increasing the effective reactance of the
transmission line between its two ends. Also, the power flow can
be increased by inserting an additional capacitive reactance in
series with the transmission line, thereby decreasing the effective
reactance of the transmission line between its two ends.
Traditionally, in order to control the power flow of the
transmission line, the effective line reactance is controlled by using
fixed or thyristor-controlled series capacitors or inductors.
Recently, a new power flow controller entitled Transmission Line
Dynamic Impedance Compensation System [13, which uses solidstate switching converters has been proposed. With the use of the
impedance compensaticm controller, a Static Synchronous Series
Compensator (SSSC), which is a solid-state voltage source
inverter, injects an almost sinusoidal voltage, of variable
magnitude, in series with a transmission line. This injected voltage
is almost in quadrature with the line current. A small part of the
injected voltage which is in phase with the line current provides the
losses in the inverter. Most of the injected voltage which is in
quadrature with the line current emulates an inductive or a
capacitive reactance in series with the transmission line. This
emulated variable real3ance, inserted by the injected voltage
source, influences the electric power flow in the transmission line.
PE-862-MD-0-04-1907 A paper recommended and approved by
the IEEE Transmission ;and Distribution Committee of the IEEE Power
Engineering Society for publication in the IEEE Transactions on Power
Delivery. Manuscript sutimitted December 27, 1996; made available for
printing April 17, 1997.
An impedance compensation controller can compensate for the
transmission line resistance if an SSSC is operated with an energy
storage system [2]. An impedance compensation controller, when
used with an SSSC and no energy storage system, is essentially a
reactance compensation controller. The reactance compensation
controller is used to operate the inverter in such a way that the
injected altemating voltage in series with the transmission line is
proportional to the line current with the emulated reactance being
the constant of propoftionality. When an SSSC injects an
alternating voltage leading the line current, it emulates an inductive
reactance in series with the transmission line causing the power
flow as well as the line current to decrease as the level of
compensation increases and the SSSC is considered to be operating
in an inductive mode. When an SSSC injects an altemating voltage
lagging the line current, it emulates a capacitive reactance in series
with the transmission line causing the power flow as well as the
line current to increase as the level of compensation increases and
the SSSC is considered to be operating in a capacitive mode.
FACTS devices consist of a solid-state voltage source inverter
with several Gate Turn Off (GTO) thyristor switch-based valves
and a DC link capacitor, a magnetic circuit, and a controller. The
number of valves and the various configurations of the magnetic
circuit depend on the desired quality of AC waveforms generated
by the FACTS devices. The objective in this paper is to describe
the fundamentals of an SSSC and to implement the operation of an
SSSC using an Electromagnetic Transients Program (EMTP)
simulation package. The inverter configuration described in this
paper is one of many different possible configurations that can be
used to build a voltage source inverter. The digital simulation
includes the injection of a 24-pulse harmonic neutralized voltage
source of variable magnitude in series with a 3-phase transmission
line connecting a 3-phase voltage source at each end. The
simulation results show the basic functions of an SSSC in terms of
controlling the power flow in the transmission line.
TI. THEORY
Fig. 1 shows a single line diagram of a simple transmission line
with an inductive reactance, X,,connecting a sending-end voltage
source,
,and a receiving-end voltage source, ,respectively.
vr
vs
"L
Fig. 1 An Elementary Power Transmission System
The real and reactive power (P and Q) flow at the receiving-end
voltage source are given by the expressions
-
p = -VsVr sin(6, - 6 , )
VL
=-
sin6
XL
XL
and
e=-VsVr
0
(1
-
XL
VL
c o s ( 6 s - 6 r ) ) =(1
XL
0885-8977/98/$10.00 0 1997 IEEE
Authorized licensed use limited to: Universidad de Sevilla. Downloaded on December 15,2021 at 15:20:59 UTC from IEEE Xplore. Restrictions apply.
242
where V, and Vr are the magnitudes and 6
phase angles of the voltage sources
, and
6
are the
vs and vr,respectively. For
simplicity,the voltage magnitudes are chosen such that V, = Vr =V
and the difference between the phase angles is 6 = 6 - 6 .
An SSSC, limited by its voltage and current ratings, is capable
of emulating a compensating reactance, Xq, (both inductive and
capacitive) in series with the transmission line inductive reactance,
X,. Therefore, the expressions for power flow given in equation (1)
become
V2
p =4
V2
sin 6 =
sin 6
(2a)
XLU- Xq / X L )
%ff
and
V2
(1 - cos 6 ) =
V2
(1 - COS 6 )
(2b)
XL(1- X q I X L )
where Xef is the effective reactance of the transmission line
between its two ends, including the emulated variable reactance
inserted by the injected voltage source of the SSSC. The
compensating reactance, Xq, is defined to be negative when the
SSSC is operated in an inductive mode and positive when the
SSSC is operated in a capacitive mode.
Fig. 2 shows an example of a simple power transmission
system with an SSSC operated both in inductive and in capacitive
modes and the related- phasor diagrams. The line current decreases
to 1-100%, when the inductive reactance
from fo%
compensation, -Xq/XL, increases from
- 0% to 100%. The line
current increases from 70% to 133%, when the capacitive
reactance compensation, XdXL, increases from 0% to 33%.
Q4 =-
%ff
transmission line with an XLIR ratio of 3.7 and no reactance
compensation of any kind, i.e., Xq=O, delivering power from
voltage source Vs to voltage source Fr through a transmission
line. In order to increase the power flow, Pq and Qq, through the
transmission line, an SSSC must emulate a capacitive reactance in
series with the transmission line. The trajectory of line current
from 70% with no reactance compensation to 750% with 50%
capacitive reactance compensation, (XJ& = 0.5), is shown in Fig.
4. As the capacitive reactance compensation further increases, the
line current and the power flow increase as indicated by the dashed
line. The trajectory of line current from 70% with no reactance
-
compensation to 1-100% with 100% inductive reactance
compensation, (Xq/XL= -1.O$, is also shown in Fig. 4. As the
inductive reactance compensation further increases, the line current
and the power flow decrease towards a minimum value. The
implementation of the reactance emulation technique using an
SSSC is described in the next section.
0
-
II e?j90
-
-
inductive
region
capacitive
region
vqt
Xq= V3
I
1 /capacitive
1
inductive
1- X q l X L
\
xs
-1
01
1
XL
Fig. 3 Effect of CompensatingReactance on Power Flow and Effective
~
Reactance
v, = v,
Fig. 2 A Static Synchronous Series Compensator Operated in Inductive
and Capacitive Modes and the Related Phasor Diagrams
From equations ( 1 ) and (2), the expressions for the normalized
power flow in the transmission line and the normalized effective
reactance of the transmission line can be written as
P41P
=
Qq/Q=lI(l-X4/XL)
Xe8 /
xr,
3
1- Xq /
x,
(3)
(4)
The effects of the compensating reactance, Xq, on the normalized
power flow in the transmission line and the normalized effective
reactance of the transmission line are shown in Fig. 3. When the
emulated reactance is inductive, the power flow, Pq and Qq,
decrease and the effective reactance, X , increases as the reactance
compensation, -XJXL, increases. When the emulated reactance is
capacitive, the power flow, Pq and Qq, increase and the effective
reactance, Xeg, decreases as the reactance compensation, Xq/XL,
increases.
Fig. 4 shows a single line diagram of a power transmission
system with an SSSC emulating a reactance in series with the
transmission line and the related phasor diagrams. Consider a
Fig. 4 Reactance Compensation of a Lossy Transmission Line
III. A STATIC SYNCHRONOUS SERIES COMPENSATOR
Fig. 5 shows an SSSC connected in series with a simple
transmission line between BUS 1 and BUS 2. The transmission
line has an inductive reactance, X,, and a voltage source,
,at the
vs
sending-end and an inductive reactance, Xr, and a voltage source,
Vr , at the receiving-end, respectively. The SSSC consists of a 24-
Authorized licensed use limited to: Universidad de Sevilla. Downloaded on December 15,2021 at 15:20:59 UTC from IEEE Xplore. Restrictions apply.
243
pulse harmonic neutralized voltage source inverter, VSZ2, a
magnetic circuit, MC2, a coupling transformer, T2, a mechanical
switch, MS2, two electronic switches, ES2 and ES22, current and
voltage sensors, and a controller. The power circuit which consists
of a voltage source inverter and a magnetic circuit and the
controller are described below.
SSSC
Fig. 5 A Static Synchroiious Series Compensator Model in EMTP
A. Poier circuit
inverters are phase shifted by -7.5", +7.5", and +22.5", respectively
in the positive direction, irrespective of their sequence. When the
time shifted pole voltage sets from two 6-pulse inverters (AlBlCl
and DlElFl), shown in Fig. 7, with a phase displacement of 30'
between them are fed to two Y-windings and the output voltages
(after properly phase shifted) are combined by connecting the
corresponding phases in series, a 12-pulse harmonic neutralized
waveform is obtained. Similarly, when the time shifted pole
voltage sets from the remaining two 6-pulse inverters (A2B2C2 and
D2E2F2), shown in Fig. 7, with a phase displacement of 30"
between them are fed to two Y-windings and the output voltages
(after properly phase shifted) are combined by connecting the
corresponding phases in series, a second 12-pulse harmonic
neutralized waveform is obtained whose harmonic components (n =
12k f 1 for k = 1, 2, 3, etc.) have the same magnitudes as the
corresponding harmonic components of the first 12-pulse harmonic
neutralized waveform. However, the harmonic components (n =
12k f 1 for k = 1, 3, 5, etc.) are in opposite phases while the
harmonic components (n = 12k & 1 for k = 2, 4, 6, etc.) are in
phases with the corresponding harmonic components of the first
12-pulse harmonic neutralized waveform. Therefore, if all the
outputs from each 6-pulse inverter are combined, as shown in Fig.
7, by connecting the corresponding phases in series, a 24-pulse
harmonic neutralized waveform is obtained. The resulting output
voltage exhibits a fundamental component of amplitude (2/n)v,
where vm is the DC link capacitor voltage and any odd harmonic
component (n) whose normalized amplitude to the fundamental
component is (lln) where n = 24k f 1 for k = 1,2,3, etc.
I
I.
InwrterA1BlC1,
+22.5'
lnverterAZBZC2,
Z
+7 5'
-.
$&.<I
.Fig. 6 A 24-Pulse Hannonic Neutralized Inverter Configuration
Fig. 6 shows a 24-pdse harmonic neutralized voltage source
inverter configuration. The pole voltages from four 6-pulse
inverters (AlBlCl, AZB2C2, D l E l F l , and D2E2F2) are
combined by a magnetic circuit whose output is connected to a 3phase load. The poles A l , B1, C1, A2,B2, C2, D1, E l , F1, D2,
voltage
E2, and F2 are operated in such a way that the pole
fundamental phasors in a group, for example
Vm,l, and
-
Va,l of A l B l C l inverttx,
inverter,
-
-
FDl,l, VE1,l, and
VAT
-
VB2, ,and
%A
I\
I 2-Pulse Inverter I2
vAl,l,
Vcs
of A2B2C2
vm,lof D l E l F l inverter, and VD2, ,
vF,,
V,,,,
and
of lD2E2F2 inverter, are 120" apart. The
displacement angle betwc:en two consecutive 6-pulse inverters in a
multipulse inverter configuration is 2d6m (= 15") where m (= 4) is
the total number of 6-pulse inverters used. The fundamental
voltage phasor set of the A l B l C l inverter is time shifted by an
angle of +22.5". The fundamental voltage phasor set of the
A2B2C2 inverter is time shifted by an angle of +7.5". The
fundamental voltage phiisor set of the D l E l F l inverter is time
shifted by an angle of -7.5'. The fundamental voltage phasor set of
the D2E2F2 inverter is time shifted by an angle of -22.5". The
configuration of the magnetic circuit is such that all the time shifted
pole voltages (fundamental and harmonic components) of the
AlBlCl inverter are phase shifted by an angle of -22.5' in the
positive direction, irrespcctive of their sequence. Similarly, all the
time shifted pole voltages of the A2B2C2, D l E l F l , and D2E2F2
Fig. 7 A Magnetic Circuit for a 24-Pulse Harmonic Neutralized Inverter
B. Controller
Fig. 8 shows the control block diagram of an SSSC. An
instantaneous 3-phase set of line voltages, v,, at BUS 1 is used to
calculate the reference angle, 0,
which is phaselocked to the phase a
of the line voltage, via. An instantaneous 3-phase set of measured
Authorized licensed use limited to: Universidad de Sevilla. Downloaded on December 15,2021 at 15:20:59 UTC from IEEE Xplore. Restrictions apply.
244
line currents, i, is first decomposed into its real or direct component,
Id, and reactive or quadrature component, I,, and then the amplitude,
I, and the relative angle, e,, of the line current with respect to the
phase-lock-loop angle, 0,are calculated. The phase angle, a,,of the
line current is calculated by adding the relative angle, O,, of the line
current and the phase-lock-loop angle, 0.The calculated amplitude,
I, of the l$e current multiplied by the compensating refctance
demand, X, , is the insertion voltage amplitude demand, V, . The
phase angle, O,, of this insertion voltage demand is either OJ+900if
the demanding compensating reactance is inductive or OJ-900if the
demanding compensating reactance is capacitive. The DC link
capacitor voltage is dynamically regulated in relationship with the
insertion voitage amplitude demand. The insertion voltage ampQtude
demand, V, , and the DC link capacitor voltage demand, V, , are
related by the inverter DC-to-fundamental AC amplitude g$n factor,
(Kim = 2h). The DC link capacitor voltage demand, VDc, and the
measured DC voltage, vm,are compared and the error is passed
through an error amplifier which produces an angle, p. The phase
angle, 02,
of the inverter voltage is calculated by adding the angle, p,
of the DC voltage regulator and the phase angle, O,, of th: insertion
voltage demand. The compensating reactance demand, Xq , is either
negative ifthe SSSC is emulating an inductive reactance or positive if
it is emulating a capacitive reactance. In another application, the
insertion voltage amplitude demand, Vq* may directly be specified
and the SSSC will inject the desired voltage almost in quadrature
with the line current.
power flow always increases if the emulated reactance is
capacitive.
Fig. 9 Performance of a Static Synchronous Series Compensator with a 24Pulse HarmonicNeutralized Inverter Operating in Inductive and Capacitive
Modes
Fig. 10 shows the expanded view of the two sections of Fig. 9.
The inverter voltage show the presence of 24-pulse harmonic
components.
1 - V,AtX,P
lOU\
P"
Controller
0
-1 -
i
V I
1-
L__________________________________________------~
Fig. 8 Control Block Diagram of a Static SynchronousSeries Compensator
IV.RESULTS
Fig. 9 shows the digital simulation results when an SSSC
emulates a reactance in series with the transmission line. At the
beginning of the operation, the mechanical switch, MS2, and the
electronic switch, ES22, are open and the electronic switch, ES2, is
closed. The inverter, VSI2, injects no voltage. The DC link capacitor
voltage, vDc, is zero. At 50 ms, an inductive reactance compensation
of 0.15 per unit is requested. The inverter output 24-pulse voltage,
ea, of phase a leads the line current, i,, by almost 90". At 175 ms,
the inductive reactance demand is increased to 0.3 per unit. As the
inductive reactance demand increases, the line current, i, and the
power flow, P, and Q,, in the transmission line decrease. At 300 ms,
a capacitive reactance compensation of 0.1 per unit is requested. The
inverter voltage, ek, lags the line current, i,, by almost 90". At 450
ms, the capacitive reactance demand is increased to 0.15 per unit. As
the capacitive reactance demand increases, the line current, i,, and the
power flow, P, and Qq, in the transmission line increase. In reality,
the SSSC would encounter power losses in the valves and in the
magnetic circuit. Therefore, there will always be a small part of real
current component, I , , flowing into the inverter and the inverter
voltage will be ahnost 90" out of phase with the line current. The
instantaneous DC link capacitor voltage is proportional to the
amplitude of the inverter voltage.
Therefore, when an SSSC emulates a reactance in series with
the transmission line, the power flow in the transmission line
always decreases if the emulated reactance is inductive. Also, the
Fig 10 Waveforms from a Static Synchronous Series Compensator with a
24-Pulse Harmonic Neutralized Inverter Operatmg in Inductive and
Capacitive Modes
V. USEFULNESS OF THE MODEL
The EMTP SSSC model and accompanying descriptions are
powerful tools that provide the fundamentals of how a voltage
source inverter is used in a FACTS application, such as a series
compensator. The model is self-contained and includes all the
necessary components - a voltage source inverter with a DC link
capacitor, a magnetic circuit, and a realizable controller. The
control system in the model has been implemented using a per unit
system. Therefore, it is easy to integrate the model in a power
system network of any voltage and current level. The model can be
quite beneficial for utility system planners to use in an integrated
fashion with their existing EMTP network model. The model can
be used to highlight the SSSC's capability to inject an AC voltage
in series with a transmission line in order to control the power flow
of the line. One can study the faults in the line and also the effects
of voltage and current unbalances on an SSSC. The model can also
be used to showcase the performance of the SSSC technology over
its conventional series compensator counterpart.
VI. CONCLUSION
An SSSC has been modeled using an EMIT' simulation
package. The SSSC which is a voltage source inverter injects an
almost sinusoidal voltage in series with the transmission line. This
injected voltage is almost in quadrature with the line current,
Authorized licensed use limited to: Universidad de Sevilla. Downloaded on December 15,2021 at 15:20:59 UTC from IEEE Xplore. Restrictions apply.
245
thereby emulating an inductive reactance or a capacitive reactance
in series with the transmission line. The power flow in the
transmission line always decreases when the injected voltage by the
SSSC emulates an inductive reactance in series with the
transmission lime and the power flow in the transmission line
always increases when the injected voltage by the SSSC emulates a
capacitive reactance in series with the transmission line. The
transition from one mode of operation to the other mode takes place
in a sub-cycle time. The operation of the model is verified by
connecting the model in series with a simple transmission line
which can easily be replaced by the utility’s existing more complex
power system network.
W. ACKNOWLEDGMENT
I would like to acknclwledge my colleagues at Westinghouse
Electric Corporation and Dr. A. J. F. Keri of American Electric
Power for their comments in preparing this document. I would also
like to show my special gratitude to Dr.L. Gyugyi for his valuable
suggestions in many technical discussions.
VIE. APPENDIX
99icpu
= ic / Ibasei
99ids
=
iapu
99iqs
= -(iapu t 2.0 * icpu) / SQRT(3)
99id
= ids * COSPLL t iqs * SINPLL
99iq
= -ids
SINPLL t iqs * COSPLL
99iampl
= SQRT(id * id t iq * iq)
99thetaa = ATAN( iq / (id t 1.lE-10) )
99thetab =thetaa + PI*((id .LT. 0 . 0 ) .AND. (iq .GE. 0 . 0 ) )
99thetir =thetab - PI*((id .LT. 0 . 0 ) .AND. (iq .LT. 0 . 0 ) )
C Series inverter current computation
99i2a
= INV02A
99i2b
= INV02B
= INV02C
99i2c
99i2apu
= i2a / Ibasei
99i2bpu = i2b / Ibasei
99i2cpu = i2c / Ibasei
C Setting the SSSC reactance demand
99Xqcml
= 0.15 * (TIMEX .GE. 0.05)
99Xqcm2
= 0.15 * (TIMEX .GE. 0.175)
99Xqcm3
= 0.4 * (TIMEX .GE. 0.30)
99Xqcm4
= 0.05 * (TIMEX .GE. 0.45)
99Xqcmd
= -Xqcml - Xqcm2 t Xqcm3 t Xqcm4
lXqref
+Xqcmd
1.0
1.0
0.0020
C Inverter angle calculation
99Vqcmd
= Xqref * iampl
99VDCcmd = ABS(Vqcmd / Kinv)
99VDCsgn = SIGN(Vqcmd)
99VDCerr = (VDCcmd - vDCpu) * ES2
99VDCint = VDCini + VDCerr * DELTAT
WCini +VDCint
99beta
= VDCsgn * (KpseV * VDCerr + KiseV * VDCint)
99thetai = theta + thetir
99thetav = thetai - W C s g n * PI / 2
99tha2
= thetav t PI / 2 + beta
C This addition of PI/2 is because the gating signals are
C sine reference and the Phase-Lock-Loop signals are
C cosine reference.
99theta2 = tha2 t TWOPI
(tha2 .LT. 0 . 0 ) - TWOPI * (tha2
.GE. TWOPI)
C Inverter Pole Voltages
99an2A1
= theta2 t 22.5 * CDR
99ang2A1 = an2Al t TWOPI * (an2Al .LT. 0 . 0 ) - TWOPI *
(an2Al .GE. TWOPI)
99a12A1
= (ang2Al .GE. 0 ) .AND. ((ang2Al - PI) .LT. 0 )
99be2A1
= ( (ang2Al - PI) .GE. 0 ) .AND. ( (ang2Al - TWOPI)
.LT. 0 )
99v2A1
= vDC / 2 * a12A1 - vDC / 2 * be2Al
99an2B1
= theta2 t (-120.0 + 22.5) * CDR
99ang2B1 = an2Bl + TWOPI * (an2B1 .LT. 0 . 0 ) - TWOPI *
(an2B1 .GE. TWOPI)
99a12B1
= (ang2B1 .GE. 0 ) .AND. ((ang2B1 - PI) .LT. 0 )
99be2B1
= ((ang2B1 - PI) .GE. 0 ) .AND. ((ang2B1 - TWOPI)
.LT. 0 )
99v2B1
= vDC / 2 * a12B1 - vDC / 2 * be2Bl
99an2C1
= theta2 + (-240.0 t 22.5) * CDR
99ana2C1 = anPC1 t TWOPI * (anPC1 .LT. 0.0) - TWOPI *
(an2h .GE. TWOPI)
99a12C1
= (ang2C1 .GE. 0 ) .AND. ((ang2C1 - PI) .LT. 0 )
99be2C1
= ((ang2C1 - PI) .GE. 0 ) .AND. ((ang2C1 - TWOPI)
.LT. 0 )
99v2C1
= vDC / 2 * a12C1 - vDC / 2 * beZCl
99an2A2
= theta2 + 7.5 * CDR
99ang2A2 = an2A2 t TWOPI * (an2A2 .LT. 0 . 0 ) - TWOPI *
(an2A2 .GE. TWOPI)
99a12A2
= (ang2A2 .GE. 0 ) .AND. ((ang2A2 - PI) .LT. 0 )
99be2A2
= ((ang2A2 - PI) .GE. 0 ) .AND. ((ang2A2 - TWOPI)
.LT. 0 )
99v2A2
= vDC / 2 * a12A2 - vDC / 2 * be2A2
99an2B2
= theta2 t (-120.0 + 7.5) * CDR
99ang2B2 = an2B2 + TWOPI * (an2B2 .LT. 0 . 0 ) - TWOPI *
(an2B2 .GE. TWOPI)
= (ang2B2 .GE. 0 ) .AND. ((ang2B2 - PI) .LT. 0 )
99a12B2
99be2B2
= ((ang2B2 - PI) .GE. 0 ) .AND. ((ang2B2 - TWOPI)
.LT. 0 )
99v2B2
= vDC / 2 * a12B2 - vDC / 2 * be2B2
99an2C2
= theta2 t (-240.0 + 7.5) * CDR
99ang2C2 = an2C2 t TWOPI * (an2C2 .LT. 0 . 0 ) - TWOPI *
(an2C2 .GE. TWOPI)
= (ang2C2 .GE. 0 ) .AND. ((ang2C2 - PI) .LT. 0 )
99a12C2
99be2C2
= ((ang2C2 - PI) .GE. 0 ) .AND. ((ang2C2 - TWOPI)
.LT. 0 )
99v2C2
= vDC / 2 * a12C2 - vDC / 2 * be2C2
99an2D1
= theta2 + (-30.0 + 22.5) * CDR
99ang2D1 = an2D1 t TWOPI * (an2D1 .LT. 0 . 0 ) - TWOPI *
(an2D1 .GE. TWOPI)
99a12D1
= (ang2D1 .GE. 0 ) .AND. ((ang2D1 - PI) .LT. 0 )
99be2D1
= ((ang2D1 - PI) .GE. 0 ) .AND. ((ang2D1 - TWOPI)
.LT. 0 )
QQv2D1
= vDC / 2 * a12D1 - vDC / 2 * b e 2 D l
99an2E1
= theta2 + (-150.0 t 22.5) * CDR
99ana2E1 = an2El + TWOPI * (an2El .LT. 0 . 0 ) - TWOPI *
( a 4 1 .GE. TWOPI)
99a12E1
= (ang2El .GE. 0 ) .AND. ((ang2El - PI) .LT. 0)
99be2E1
= ((ang2El - PI) .GE. 0 ) .AND. ((ang2El - TWOPI)
.LT. 0 )
99v2E1
= vDC / 2 * a12E1 - vDC / 2 * be2El
~
BEGIN NEW DATA CASE
C FILE NAME = 24PSSSC.IIAT (24-Pulse harmonic neutralized
C SSSC). This SSSC Power Flow Controller was implemented
C by K. K. Sen at Westjnghouse, STC, Pittsburgh, PA 15235.
16.666-6600.00-3
40
10
1
TACS HYBRID
99CRD
= 180 / PI
99CDR
= 1 / CRD
99TWOPI
= 2.0 * PI
99Kll
= SIN(97.5 * CDR) / SIN(60 * CDR) / 4
99K12
= SIN(22.5 * CDR) / SIN(60 * CDR) / 4
99K21
= SIN(112.5
CDR) / SIN(60 * CDR) / 4
99K22
= SIN(7.5 * CDR) / SIN(60 * CDR) / 4
= 10
99KpseV
99KiseV
= 100
99Kinv
= 2 / PI
99KPLLp
= 100000.0
99KPLLi
= 250000.0
99MS2
= 0
99Cap
= 42.03-6
C Inverter base
99Vbasei = 112676.528
99Ibasei = 946.662704
C Inputs from the measuring switches
9OBUS0 1A
90BUSOlB
90BUSOlC
9o m
90VRB
9OVRC
91INV02A
91INVO2B
91INV02C
91BUS03A
91BUS03B
91BUS03C
C BUS1 voltage computation
99vla
= BUSOlA
= BUSOlB
99vlb
99vlc
= BUSOlC
99vlapu
= vla / Vbasisi
99vlbpu
= vlb / Vbasci
= vlc / Vbasei
99vlcpu
=
vlapu
99vlds
99Vlqs
= -(vlapu + 2 . 0 * vlcpu) / SQRT(3)
= vlds * COl3PLL t vlas * SINPLL
99vld
= -vlds * SIIJPLL t vlqs * COSPLL
99vlq
C Phase-Lock-Loop (locked to phase a voltage of BUS1)
99PLLerr = vlqs * COS(PLLi) - vlds * SIN(PLLi)
99PLLint = PLL‘ini t P:;Lerr * DELTAT
99PLLdot = KPLLi * PL:;int t KPLLp * PLLerr
PLLini tPLLint
99PLL
= PLLi + PLLdot * DELTAT
PLLi
tPLL
= PLL - TWOPC * TRUNC(PLL/TWOPI)
99theta
99COSPLL = COS(theta)
99SINPLL = SIN(theta)
C Receiving-end voltag,?computation
99vrapu = VRA / Vbascai
’
99vrbpu
=
VRB / Vbasei
99vrcpu
= VRC / Vbastsi
C Line current computation
99ia
= BUS03A
99ib
= BUS03B
99ic
= BUS03C
99iapu
= ia / Ibasei
= ib / Ibasei
99ibpu
I
Authorized licensed use limited to: Universidad de Sevilla. Downloaded on December 15,2021 at 15:20:59 UTC from IEEE Xplore. Restrictions apply.
246
99an2F1
= theta2 + (-270.0 + 22.5) * CDR
99ang2F1 = an2F1 + TWOPI * (an2F1 .LT. 0.0) - TWOPI *
(an2F1 .GE. TWOPI)
99a12F1
= (ang2F1 .GE. 0) .AND. ((ang2F1 - PI) .LT. 0)
99be2F1
= ((ang2F1 - PI) .GE. 0) .AND. ((ang2F1 - TWOPI)
.LT. 0)
99v2F1
= vDC / 2 * a12F1 - vDC / 2 * be2F1
= theta2 + (-30.0 + 7.5) * CDR
99an2D2
99ang2D2 = an2D2 + TWOPI * (an2D2 .LT. 0.0) - TWOPI *
(an2D2 .GE. TWOPI)
99a12D2
= (ang2D2 .GE. 0) .AND. ((ang2D2 - PI) .LT. 0)
99be2D2
= ((ang2D2 - PI) .GE. 0) .AND. ((ang2D2 - TWOPI)
.LT. 0)
99v2D2
= vDC / 2 * a12D2 - vDC / 2 * be2D2
99an2E2 = theta2 + (-150.0 + 7.5) * CDR
99ana2E2 = an2E2 + TWOPI * (an2E2 .LT. 0.0) - TWOPI *
(an2E2 .GE. TWOPI)
= (ang2E2 .GE. 0) .AND.
((ang2E2 - PI) .LT. 0)
99a12E2
99be2E2
= ((ang2E2 - PI) .GE. 0) .AND. ((ang2E2 - TWOPI)
I."
.Ll. U )
99v2E2
= vDC / 2 * a12E2 - vDC / 2 * be2E2
99anZF2 = theta2 + (-270.0 + 7.5) * CDR
99ang2F2 = an2F2 + TWOPI * (an2F2 .LT. 0.0) - TWOPI *
(an2F2 .GE. TWOPI)
99a12F2
= (ang2F2 .GE. 0) .AND. ((ang2F2 - PI) .LT. 0)
99be2F2
= ((ana2F2 - PI) .GE. 0) .AND. ((ans2F2 - TWOPI)
.LT. 0)
99v2F2
= vDC / 2 * a12F2 - vDC / 2 * be2F2
C Magnetic Circuit
C Note: The signals vX, VY and VZ in Fig. 7 are renamed as
C e2a, e2b and e2c, respectively.
99v2Nll = (v2A1 + v2B1 + v2C1) / 3
99v2AlN = v2A1 - v2Nll
99v2BlN
= v2B1 - v2Nll
99v2ClN
= v2C1 - v2Nll
99v2N12
= (v2A2 + v2B2 + v2C2) / 3
99v2A2N = v2A2 - v2N12
99v2B2N = v2B2 - v2N3.2
99v2C2N
v2C2 - v2N12
99v2N21 = (v2D1 + v2E1 + v2F1) / 3
99v2DlN = v2D1 - v2N21
99v2ElN
= v2E1 - v2N21
99v2FlN
= v2F1 - v2N21
99v2N22
= (v2D2 + v2E2 + v2F2) / 3
99v2D2N
= v2D2 - v2N22
99v2E2N
v2E2 - v2N22
99v2F2N = v2F2 - v2N22
99e2al
= K11 * v2AlN + K12 * v2BlN
= K11 * v2BlN + K12 * v2ClN
99e2bl
99e2cl
= K11 * v2ClN + K12 * v2AlN
99e2a2
= K21 * v2A2N + K22 * v2B2N
99e2b2
= K21 * v2B2N + K22 * v2C2N
99e2c2
= K21 * v2C2N + K22 * v2A2N
99e2a3
= K21 * v2DlN + K22 * v2FlN
99e2b3
= K21 * v2ElN + K22 * v2DlN
99e2c3
= K21 * v2FlN + K22 * v2ElN
99e2a4
= K11 * v2D2N + K12 * v2F2N
99e2b4
= K11 * v2E2N + K12 * v2D2N
99e2c4
= K11 * v2F2N + K12 * v2E2N
99vX1
= e2al + e2a3
99vY1
= e2bl + e2b3
99vZ1
= e2cl + e2c3
C VSI2 output voltage
99e2a
= e2al + e2a2 + e2a3 + e2a4
= e2bl + e2b2 + e2b3 + e2b4
99e2b
99e2c
= e2cl + e2c2 + e2c3 + e2c4
99e2apu = e2a / Vbasei
99e2bpu = e2b / Vbasei
99e2cpu = e2c / Vbasei
C DC link capacitor voltage calculation
99Pin2
= e2a * 12a + e2b * i2b + e2c * 12c
99iDC2
= (Pin2 / (vDCpu + 1.OE-8) / Vbasei) * ES2
99DvDCpu = iDC2 / Cap / Vbasei
lvDCpu
+DvDCpu
1.0
0.0001 1.00
1.0
0.0
1.0
99vDC
= vDCpu * Vbasei
C Receiveing-end power calculation
99Pqpu
= (vrapu*iapu + vrbpu*ibpu + vrcpu*icpu) / 1.5
99Qqpu
= (vrapu*icpu - vrcpu*iapu) * SQRT(3) / 1.5
C Setting up the electronic switches
99ES22
= 0
99ES2
= .NOT. ES22
C TACS output
33vDCpu e2apu iapu Xqref Pqpu Qqpu
BLANK RECORD ENDING TACS
VSA
BUSOlA
1.0053 19.73
VSB
BUSOlBVSA
BUSOlA
VSC
BUSOlCVSA
BUSOlA
3.0159 59.19
BUS03AVRA
BUS03BVRB
BUS03AVRA
BUS03CVRC
BUS03AVRA
e2a
e22a
1.00+8
e2b
e22b
1.00+8
1.00+8
e2c
e22c
1.00+8
e22a
1.00+8
e22b
e22c
1.00+8
T2A
TRANSFORMER
9999
1.0
0.892723.679
1INV02A
2BUSOlABUS02A
0.892723.679
1.0
TRANSFORMER
T2B
9999
0.892723.679
1.0
1INV02B
0.892723.679 1.0
2BUSOlBBUS02B
T2C
TRANSFORMER
9999
1.0
0.892723.679
1INV02C
2BUSOlCBUS02C
0.892723.679 1.0
BLANK RECORD ENDING BRANCHES
BUS02ABUS03A
MEASURING
BUS02BBUS03B
MEASURING
BUS02CBUS03C
MEASURING
INVO2Ae22 a
MEASURING
INV02Be22b
MEASURING
INV02Ce22c
MEASURING
13e2a
e22a
ES2
13e2b
e22b
ES2
13e2c
e22c
ES2
13e22a
CLOSED
e522
13e22b
CLOSED
e522
13e22c
CLOSED
e522
13BUSOlABUS02A
MS 2
13BUSOlBBUS02B
MS 2
13BUSOlCBUS02C
MS2
BLANK RECORD ENDING SWITCHES
60e2a
60e2b
60e2c
0.00
l4VSA
112676.528
60.00
-1.OE-03
9999.
14VSB
112676.528
60.00 -120.00
-1.OE-03
9999.
120.00
l4VSC
112676.528
60.00
-1.OE-03
9999.
l4VRA
112676.528
60.00
-30.00
-1.OE-03
9999.
l4VRB
112676.528
60.00
-150.00
-1.OE-03
9999.
l4VRC
112676.528
60.00
90.00
-1.OE-03
9999.
B b K RECORD ENDING SOURCES
BLANK RECORD ENDING NODE VOLTAGE OUTPUT
BLANK RECORD ENDING PLOT
BEGIN NEW DATA CASE
BLANK RECORD ENDING ALL DATA CASES
KREFERENCES
[11 Transmission Line Dynamic Impedance Compensation System,
L. Gyugyi and C. D. Schauder, US Patent No. 5,198,746.
[2] Static Synchronous Series Compensator: A Solid-state
Approach to the Series Compensation of Transmission Lines, L.
Gyugyi, C. D. Schauder and K. K. Sen, 96 WM 120-6 PWRD,
IEEE PES Winter Meeting, 1996.
Kalyan K. Sen (S' 1983, M' 1988) received
aB.E.E(1982), aM.S.E.E(1983), andaPh.D
(1987) degrees, all in Electrical Engineering,
from Jadavpur University, Calcutta, India,
Tuskegee University, Tuskegee, USA, and
Worcester Polytechnic Institute, Worcester,
USA, respectively. He held a tenure track
assistant professor level position at Prairie
ViewRexas A&M University for 3 years
before joining Westinghouse Electric
Corporation's Science & Technology Center
in Pittsburgh, USA in 1990. He is a member
of the control design team of world's first
UniJed Power Flow Controller. His interests are in Power Converter
Topologies, Electrical Machines, Numerical Computations, and
Microprocessor-based hardware implementations.
Authorized licensed use limited to: Universidad de Sevilla. Downloaded on December 15,2021 at 15:20:59 UTC from IEEE Xplore. Restrictions apply.
