METAL POWDER
AlSi10Mg
ENABLING YOUR ADDITIVE REVOLUTION.
When it comes to additive manufacturing with metals, Heraeus
is your trusted partner throughout the process. Combining
decades of experience in metal handling and recycling with our
thorough expertise in additive manufacturing, we are able to
provide you with real peace of mind. Our expertise in processes,
powders and printing gives you with the highest degree of design
freedom for your components.
With high-quality powders, batch consistency and traceability,
and variable particle size distribution, we can meet even very
exacting additive manufacturing demands.
In addition to supplying powders, we are also your partner
for printing components and can offer you the complete
manufacturing service.
Process
Powder
Printing
Material Description
Chemical Composition
AlSi10Mg is an age-hardening cast aluminum alloy with good
hardness, strength and dynamic toughness. It is traditionally used
as a casting alloy. Powder made from AlSi10Mg is commonly used
in additive manufacturing, due to the high corrosion resistance,
low density and high mechanical strength of the final components.
Additive manufacturing components require less thermal postprocessing than cast components. Typical applications are found
in the aerospace and automotive industries.
■■
■■
■■
Good processability
High strength
Good mech. properties for dynamic loads
■■
■■
Structure parts like brackets etc.
Brake caliper
Heat sinks
Available Particle
Distributions
■■ 20-63µm
Customized distributions on
request
acc. EN AC 43000
Al
balance
Si
9.0-11.0
Mg
0.2-0.45
Fe
max. 0.55
Cu
max. 0.05
Mn
max. 0.45
Zn
max. 0.1
Ti
max. 0.15
Ni
max. 0.05
Pb
max. 0.05
Sn
max. 0.05
Physical Properties
Typical Applications
■■
Concentration [wt%]
Element
Powder Quality
■■
■■
■■
■■
Gas atomized particles
Spherical shape
High purity
Excellent flowability
Properties
Value
Density [g/cm3]
2.67
Tensile strength UTS [MPa]
>370
Yield strength [MPa]
>200
Young’s modulus [GPa]
>65
Elongation [%]
<7
Properties as printed and annealed. Values may vary based on machines and build
conditions and are therefore only for reference.
CONTACT
Stable powder quality
Customized alloys
Powder
Spherical powders
High purity
Simulation of printing
processes
Own LBM & EBM
equipment
Printing
Printing of prototypes
Design optimization
Process
Process development
The descriptions and engineering data shown here have been compiled by Heraeus using commonly accepted procedures, in conjunction with modern testing equipment, and have been compiled according to the latest factual knowledge in our possession.
The information was current on the date this document was printed (latest versions can always be supplied upon request). Although the data is considered accurate, we cannot guarantee the accuracy, results obtained from its use, or any patent infringement
resulting from its use (unless this is contractually and explicitly agreed in writing, in advance). The data is supplied on the condition that the user shall conduct tests to determine materials suitability for particular application.
As of September 2019
