Operational Amplifier

QUIZ (Op-Amp)
1. Calculate the CMRR (in dB) for the circuit measurements of V d = 1.0mV, VO = 150mV, and VC
= 1.0mV, VO = 50µV.
2. Determine the output voltage of an Op-Amp for input voltages of Vi1 = 200µV and Vi2 =
150µV. The amplifier has a differential gain of Ad = 4000 and the value of CMRR is 200.
3. Calculate the output voltage. (Show the complete solution.)
4. Calculate the output voltage. (Show the complete solution.)
5. Calculate the output voltage. (Show the complete solution.)
