1) Define DFA and NFA , explain the differences between them with an
example.
2) Provide an NFA for the following language
L={w|w contains an even number of 0’s or exactly two 1’s}
3) Construct a NFA accepting ab,ba and use it to find a DFA accepting same
set.
4) draw the transition diagram for the FA M={(A,B,C,D),(0,1),δ,c,(A,C)}
δ(A,0)=,δ(A,1)={A,B,C)
δ(B,0)=B,
δ(B,1)={A,C}
δ(C,0)={B,C},δ(C,1)={B,D}
δ(D,0)={A,B,C,D}
δ(D,1)={A}
5) For the following state transition table, draw state transition diagram
find its equivalent DFA machine for string abbaaab , check whether both
give same result or not.
State
0
1
->q0
{q1}
{q2}
q1
{q1}
{q3}
q2
*q3
{q0 q3}
{q3}
6) Explain the procedure to convert NFA to DFA with any example
7) Explain the procedure to convert NFA with epsilon to NFA without epsilon
with any example.
.
