TECHNICAL DATA SHEET
SMP
STRAIGHT PLUG PCB
CATCHERS MIT
19S144-40ML5
All dimensions are in mm; tolerances acc. ISO 2768 m-H
Interface
Compatible to
MIL-STD-348
Documents
PCB layout
Tape & reel packaging
B 127
VG23.75000
Material and plating
RF_35/11.05/3.1
Connector parts
Center contact
Outer contact
Dielectric
Material
Brass
Brass
LCP
Rosenberger Hochfrequenztechnik GmbH & Co. KG
P.O.Box 1260
D-84526 Tittmoning
Germany
www.rosenberger.de
Plating
AuroDur®, gold plated
AuroDur®, gold plated
Tel.: +49 8684 18-0
Page
email: info@rosenberger.de
1/2
TECHNICAL DATA SHEET
STRAIGHT PLUG PCB
CATCHERS MIT
SMP
19S144-40ML5
Electrical data
Impedance
Frequency
Return loss
50 
DC to 26.5 GHz
 26 dB, DC to 6 GHz
 21 dB, 6 to 12 GHz
Insertion loss
Insulation resistance
Center contact resistance
Outer contact resistance
Test voltage
Working voltage
Contact Current
 0.1 x
f(GHz) dB,
 5 G
 6.0 m
 2.0 m
500 V rms
335 V rms
 1.2A DC max.
- VSWR in application depends decisive on PCB layout -
Mechanical data
 1000
7N
Mating cycles
Center contact captivation
Engagement force
- catchers mit
Disengagement force
- catchers mit
 9 N max.
 2.2 N min.
Environmental data
Temperature range
Thermal shock
Vibration
Shock
Moisture resistance
Max. soldering temperature
RoHS
-65°C to +155°C
MIL-STD-202, Method 107, Condition B
MIL-STD-202, Method 204, Condition B
MIL-STD-202, Method 213, Condition A
MIL-STD-202, Method 106
IEC 61760-1, +260°C for 10 sec.
compliant
Tooling
N/A
Suitable cables
N/A
Weight
Weight
0.7 g/pce
RF_35/11.05/3.1
