HMC189MS8
v01.0801
GaAs MMIC SMT PASSIVE FREQUENCY
DOUBLER, 2 - 4 GHz INPUT
Typical Applications
Features
The HMC189MS8 is suitable for:
Conversion Loss: 13 dB
• Wireless Local Loop
Fo, 3Fo, 4Fo Isolation: 33 dB
• LMDS, VSAT, and Pt to Pt Radios
Input Drive Level: +10 to +15 dBm
• UNII & HiperLAN
11
• Test Equipment
FREQ. MULTIPLIERS - SMT
Functional Diagram
General Description
The HMC189MS8 is a miniature passive frequency
doubler in a plastic 8-lead MSOP package. The suppression of undesired fundamental and higher order
harmonics is 33 dB typical with respect to input
signal levels. The doubler uses the same diode/
balun technology used in Hittite MMIC mixers. The
doubler is ideal for high volume applications where
frequency doubling of a lower frequency is more
economical than directly generating a higher frequency. The passive Schottky diode doubler technology contributes no measurable additive phase
noise onto the multiplied signal.
Electrical Specifications, TA = +25° C, As a Function of Drive Level
Input = +10 dBm
Parameter
Min.
Frequency Range, Input
Frequency Range, Output
Conversion Loss
11 - 20
Typ.
Input = +13 dBm
Max.
Min.
Typ.
Input = +15 dBm
Max.
Min.
Typ.
Max.
Units
2.5 - 3.5
2.5 - 3.75
2-4
GHz
5-7
5 - 7.5
4-8
GHz
13
17
13
15
13
17
dB
FO Isolation
(with respect to input level)
29
32
30
33
31
34
dB
3FO Isolation
(with respect to input level)
37
43
35
42
33
40
dB
4FO Isolation
(with respect to input level)
32
40
33
40
31
40
dB
For price, delivery, and to place orders, please contact Hittite Microwave Corporation:
20 Alpha Road, Chelmsford, MA 01824 Phone: 978-250-3343 Fax: 978-250-3373
Order On-line at www.hittite.com
HMC189MS8
v01.0801
GaAs MMIC SMT FREQUENCY
DOUBLER, 2 - 4 GHz INPUT
GaAs MMIC
PUMPED
17 - 25
GHz
Conversion
Loss @SUB-HARMONICALLY
+13 dBm Drive Level
Isolation*
@ MIXER
+13 dBm Drive
Level
0
0
-40 C
-10
1Fo
-10
ISOLATION (dB)
-15
-20
+85 C
-20
3Fo
-30
11
4Fo
-40
-25
+25 C
-50
-30
-35
-60
2
3
4
5
6
7
8
9
10
0
2
4
6
OUTPUT FREQUENCY (GHz)
8
10
12
14
16
18
20
18
20
FREQUENCY (GHz)
* With respect to input level
Conversion Loss vs. Drive Level
Isolation* @ +10 dBm Drive Level
0
0
+15 dBm
-10
1Fo
+13 dBm
-10
ISOLATION (dB)
CONVERSION LOSS(dB)
-5
-15
-20
-20
-30
4Fo
-40
-50
-25
+10 dBm
-30
+7 dBm
-60
3Fo
-70
-35
2
3
4
5
6
7
8
9
0
10
2
4
6
8
10
12
14
16
FREQ. MULTIPLIERS - SMT
CONVERSION LOSS (dB)
-5
FREQUENCY (GHz)
FREQUENCY (GHz)
* With respect to input level
Output Return Loss for
Several Input Frequencies
Input Return Loss vs. Drive Level
0
0
OUTPUT RETURN LOSS (dB)
INPUT RETURN LOSS (dB)
Input = 2 GHz
-5
+7 dBm
+10 dBm
-10
-15
-20
+13 dBm
-25
-5
-10
-15
Input = 3 GHz
Input = 4 GHz
-20
-25
1
2
3
FREQUENCY (GHz)
4
5
2
3
4
5
6
7
8
9
10
FREQUENCY (GHz)
For price, delivery, and to place orders, please contact Hittite Microwave Corporation:
20 Alpha Road, Chelmsford, MA 01824 Phone: 978-250-3343 Fax: 978-250-3373
Order On-line at www.hittite.com
11 - 21
v01.0801
HMC189MS8
GaAs MMIC SMT FREQUENCY
DOUBLER, 2.0 - 4.0 GHz INPUT
Absolute Maximum Ratings
FREQ. MULTIPLIERS - SMT
11
Input Drive
+27 dBm
Storage Temperature
-65 to +150 °C
Operating Temperature
-40 to +85 °C
ELECTROSTATIC SENSITIVE DEVICE
OBSERVE HANDLING PRECAUTIONS
Outline Drawing
NOTES:
1. PACKAGE BODY MATERIAL: LOW STRESS INJECTION MOLDED PLASTIC
SILICA AND SILICON IMPREGNATED.
2. LEADFRAME MATERIAL: COPPER ALLOY
3. LEADFRAME PLATING: Sn/Pb SOLDER
4. DIMENSIONS ARE IN INCHES [MILLIMETERS].
5. DIMENSION DOES NOT INCLUDE MOLDFLASH OF 0.15 mm PER SIDE.
6. DIMENSION DOES NOT INCLUDE MOLDFLASH OF 0.25 mm PER SIDE.
7. ALL GROUND LEADS MUST BE SOLDERED TO PCB PF GROUND.
8. CLASSIFIED AS MOISTURE SENSITIVITY LEVEL (MSL) 1.
11 - 22
For price, delivery, and to place orders, please contact Hittite Microwave Corporation:
20 Alpha Road, Chelmsford, MA 01824 Phone: 978-250-3343 Fax: 978-250-3373
Order On-line at www.hittite.com
v01.0801
HMC189MS8
GaAs MMIC SMT FREQUENCY
DOUBLER, 2.0 - 4.0 GHz INPUT
Evaluation PCB
List of Materials
Item
Description
J1, J2
PC Mount SMA Connector
U1
HMC189MS8 Doubler
PCB*
103311 Eval Board
*Circuit Board Material: Rogers 4350
The circuit board used in the final application should be
generated with proper RF circuit design techniques. Signal
lines at the RF port should have 50 ohm impedance and
the package ground leads should be connected directly
to the ground plane similar to that shown above. The
evaluation circuit board shown above is available from
Hittite Microwave Corporation upon request.
