Series Circuits http://phet.colorado.edu/sims/circuit­construction­kit/circuit­construction­kit­dc.jnlp 20.0 Ω Bulb 1 50.0 Ω Bulb 2 Resistor Switch 10.0 Ω Battery 20.0 V Measure: Component Current (A) Voltage (V) Power (W) Battery Resistor Bulb 1 Bulb 2 Show Ohm's Law Calculations: Component Current (A) Battery Resistor Bulb 1 Bulb 2 Voltage (V) Power (W) Create a series circuit that includes four resistors (of any kind) and that meets the following requirements: • No two resistors may have the same value • The current everywhere in the circuit must be 0.5 A Draw your circuit below and label the value of each component. ­
