DANGER-HAZARDOUS LABEL

advertisement
FILL COLOR:
BLACK
2.50"
0.25"
!
DANGER
Hazardous Voltage.
Will cause death, serious
injury or substantial
property damage.
1.00"
Turn off power supplying this
equipment before working inside.
!
FILL COLOR: RED (SEE NOTE 2)
INCLUDES EXCLAIMATION POINT
PELIGRO
Voltaje peligroso. Causará la
muerte, lesiones graves o daño
substancial a la propiedad.
Desconecte el suministro de
energía a este equipo antes de
trabajar en su interior.
2.00"
4810260 Rev. A
Not Serviceable by User.
Contact Your Utility
For Service
BLACK BACKGROUND
W/WHITE LETTERS.
NOTES:
DESIGN RESPONSIBILITY LOCATION:
1. MATERIAL: .004 WITHE VINYL WITH PERMANENT ADHESIVE
SEA-ITESA2
2. PRINTING TO BE SILKSCREENED.
PRINTING COLOR: BLACK UNLESS OTHERWISE NOTED.
RED: MUNSELL NOTATION 7.5 R 4.0/14 OR EQUIVALENT UPON APPROVAL.
3. LABELS MUST MEET OR EXCEED THE REQUIREMENTS OF UL 969
FOR OUTDOOR USE.
PRINT DISTRIBUTION
ECN COPIES MUST BE ISSUED TO ALL CHECKED
LOCATIONS FOR APPROVAL PRIOR TO CHANGE
21OCT05
JA
NEW DRAWING
DWN
CHK
1st ARTICLE
ECN NO.
REV
DATE
DESCRIPTION
BY
APVD
JA
CCH
CCH
DATE
DATE
DATE
10/21/05
10/21/05
10/21/05
McPHER
DUR-LEB
CHOICE
SEA-EL
DUR-HOU
IC-ASY
SEA-IT2
SEA-BEL
*
Siemens Energy & Automation, Inc.
TOLERANCES:
.XX ±.12
.XXX
HOLE DIAMETER ±.005
ANGULAR
UNDIMENSIONED 90o ANGLES ±0o30'
A
SEA-DRM
SEA-NOR
-CONFIDENTIAL- PROPERTY OF
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
05-324J2
SEA-TUC
Residential Products Division
DANGER-HAZARDOUS LABEL
SIZE
ISSUE RELEASE NO.
B
SCALE
NONE
DWG. NO.
4810260
DO NOT SCALE DRAWING
SHEET
1 OF 1
REV
A
