RFID Accessories
R E VO L U T I O N A RY R F I D S YS T E M S F O R S A F E & O P T I M A L H E A LT H C A R E D E LI VERY
bloodcare
pharmacare
labcare
clinicare
Here are a list of IXYS’s main accessories that will further support your efficient and effective use of the IXYS portfolio of RFID Tags and
Readers. IXYS’s powerful RFID technology reduces manual involvement and errors in counting and stock-taking processes and provides
real-time actionable product visibility, workflow automation and inventory monitoring. Resulting in more effective workflows, maximal
inventory control, optimized patient care and lower costs.
IXV - W R I T E 1 0 0
The IXV-WRITE100 is our prefered access card reader and writer (Access 9 CD 2.0 from IDESCO).
It is a new generation MIFARE® DESFire reader designed with user-friendliness and convenience
in mind – but also enhanced with sector read/write ability and unmatched configurability. Access
9 CD 2.0 can power you through user authentication, coding and migration tasks speedily, reliably and securely, whether your site’s population numbers a dozen or a thousand.
IXV - C A R D 1 0 0
The IXV-CARD100 is our standard access card that can be read by all our SmartCabinets,
SmartFridges and SmartFreezers. The access card is written by using the IXV-WRITE100 access card reader and writer.
IXV - P R I N T 1 0 0
The IXV-PRINT100 is a high performance lable printer from CAB. The high-speed processor
ensures fast processing and immediate label output. The unit itself has been built to ensure
a simple and convenient operation coupled with high reliability.
IXV - B A R 1 0 0
The IXV-BAR100 handheld scanner (Symbol LS2208 from Motorola Solutions) is our recommended barcode reader. It provides fast and reliable scanning in an ergonomic, lightweight form. The
wide working range (from near-contact to 43 cm) makes this device ideal for hospital settings.
Multiple on-board interfaces ensure integration with a variety of host systems.
A utomated 24/7 T rack - and -T race
continuously tracking stocks
A lways O n S mart S oftware
ensuring data is always accessible
I nstant V isibility W orldwide
enhancing security and monitoring
RFID Accessories
IXV - W R I T E 1 0 0
Dimensions (H x W x D): 95 x 62 x 24 mm. Material: Plastic - Black. Protection Class: IP67. Chip
Type / Memory: MIFARE® DESFire: UID + Application files, MIFARE® Classic: 4/7 BUID, UID +
Sectors, MIFARE® Ultralight:UID, MIFARE® Plus: UID + Sectors (SLI and SL3) MIFARE® SmartMX:
UID + Sectors ( If Mifare Classic emulation set on). Encryption: AES or Triple DES. LED: Yes. LED
Control: Commands. Buzzer: Yes. Buzzer Control: Commands. USB: Yes. Cable USB 1,5m. Power
Consumption: max 80mA. Voltage: 5 VDC. Operating Frequency: 13,56Mhz. EMC Directive: Meets
CE Requirements. Field Strength: According to EN300330
IXV - C A R D 1 0 0
Dimensions ( H x W x D ): 85 x 54 x 1 mm. Weight: 6 grm. Material: Plastic - White
IXV - P R I N T 1 0 0
Dimensions (H x W x D): 274 x 446 x 242 mm. Weight: 9kg. Print Resolution: 300dpi. Print Speed:
125mm/s. Print Width: 105,5mm. Labels, continuous rolls or fanfolded: Paper, Cardboard, Textile,
Plastics such as PET, PE, PP, PI, PVC, PU Acrylate. Material Thickness: 0,05-0,8 mm. Material
Weight: 60-300 g/m2. Label Width: 4-106 mm. Continuous Material: 10-110 mm linear. Ethernet
10/100 Base T, LPD, RawIPprinting, ftp printing, DHCP, HTTP, FTP, SMTP, SNMP, TIME, Zeroconf,
mDNS, SOAP: Yes. Peripheral connection: Yes. 2 x USB master for external operation panel, keyboard, scanner, service key, USB Flash Drive: Yes. Power Supply: 100-240 V ~ 50/60 Hz, PFC.
Approvals: CE, FCC class A, CB, CCC, UL
IXV - B A R 1 0 0
Dimensions (H x W x D): 152 x 63 x 84 mm. Weight: 146 grm. Voltage: 5 V +/- 10%. Current: 130 mA
typical - 175 mA max. Power Sources: Host Power or External Power Supply. Color: White or Black.
Scanner Type: Bi-Directional. Light Source: 650 nm Visible Laser Diode. Scan Rate: 100 scans per
second typical. Nominal Working Distance: from contact to 17 in./43 cm on 100% U.P.C./EAN. Print
Contrast: 20% minimum reflective difference. Roll (Tilt): +/-30 degrees. Pitch: +/-65 degrees. Skew
(Yaw): +/-60 degrees. Decode Capability: U.P.C./EAN, U.P.C./EAN with Supplementals, UCC/EAN 128,
Code 39, Code 39 Full ASCII, Code 39 TriOptic, Code 128, Code 128 Full ASCII, Codabar, Interleaved
2 of 5, Discrete 2 of 5, Code 93, MSI, Code 11, IATA, RSS variants, Chinese 2 of 5. Interfaces Supported: RS232, Keyboard Wedge, Wand, IBM 468X/9X, USB, Synapse and Undecoded. Electrostatic
Discharge: Conforms to 15 kV air discharge and 8 kV of contact discharge. Electrical Safety: Certified
to UL1950, CSA C22.2 No. 950, EN60950/IEC950 . EMI/RFI: FCC Part 15 Class B, ICES-003 Class B,
European Union EMC Directive, Australian SMA, Taiwan EMC, Japan VCCI/MITI/Dentori. Laser Safety:
CDRH Class II, IEC Class 2
