Crystal oscillator
Product Number (please contact us)
VG-4231CB: X1G002861xxxx00
VOLTAGE -CONTROLLED CRYSTAL OSCILLATOR (VCXO)
OUTPUT : CMOS
VG - 4231CB
 Frequency range :
Supply voltage
:
 Absolute pull range :
 Function
:
 External dimensions:
1 MHz to 81 MHz
3.3 V
-6
±50 × 10
Output enable (OE)
5.0 × 3.2 × 1.2 mm
Actual size
Specifications (characteristics)
Item
Output frequency range
Symbol
Specifications
f0
1.000 MHz to 81.000 MHz
Supply voltage
Storage temperature range
Operating temperature range
Frequency tolerance
Current consumption
Absolute pull range
Input resistance
Frequency change polarity
Symmetry
VCC
T_stg
T_use
f_tol
ICC
APR
Rin
―
SYM
VOH
Output voltage
VOL
Output load condition (CMOS) L_CMOS
VIH
Input voltage
VIL
Rise time / Fall time
tr / tf
Start-up time
t_str
Frequency aging
f_aging
Conditions / Remarks
Please contact us about available
frequencies.
C: 3.3 V ±0.165 V
-40 °C to +85 °C
G: -40 to +85°C, J: -20 to +70°C, K: 0 to +70°C
±50 × 10-6 Max.
10 mA Max.
G : ±50 × 10-6 Min.
10 MΩ Min.
Positive slope
45 % to 55 %
VCC to 0.4 V Min.
0.4 V Max.
15 pF Max.
70 % VCC Min.
30 % VCC Max.
6 ns Max.
10 ms Max.
Storage as single product.
No load condition.
VC=1.65 V±1.5 V
DC level
VC=0.15 to 3.15 V
50 % VCC level
IOH = -0.8 mA
IOL = 3.2 mA
20 % VCC to 80 % Vcc level
Time at minimum supply voltage to be 0 s
+25 °C, VCC=3.3 V, 20 years (f0  60MHz),
+25 °C, VCC=3.3 V, 10 years (60MHz  f0)
This is included in frequency tolerance specification.
* Please keep VC pin open or ground while powering up VCC.
Product Name
(Standard form)
VG-4231 CB 52.000000MHz G G C Z
①
②
③
④⑤⑥⑦
①Model
②Package type ③Frequency ④Operating temperature range
⑤Absolute pull range ⑥Supply voltage (C: 3.3V Typ.) ⑦Function
⑤Absolute pull range
④Operating temperature range
G
J
K
G
-40 to +85°C
-20 to +70°C
0 to +70°C
-6
±50 × 10 Min.
(Unit: mm)
External dimensions
⑦Function
Z
Output enable
(Unit: mm)
Footprint (Recommended)
5.0±0.2
#6
#5
0.89
#4
E
#5
#4
52.000Z
C
GGC714K
#3
2.6
#2
1.2±0.2
#1
#6
1.6
3.2±0.2
C (ex.0.01 µF)
0.64
Pin map
Pin
1
2
3
4
5
6
Connection
Vc
OE
GND
OUT
N.C.
Vcc
1.0
C 0.3
OE pin = "H" or "open": Specified
frequency output.
OE pin = "L": Output is high impedance.
Resist
#1
#2
#3
2.54
To maintain stable operation, provide a 0.01uF to
0.1uF by-pass capacitor at a location as near as
possible to the power source terminal of the crystal
product (between Vcc - GND).
