MV/LV Transformers for Distribution Network Solutions Distribution Transformers Up to 36 kV and up to 5 MVA IEC Standards Reliable innovation. Personal solutions. www.ormazabal.com Dielectric liquid immersed transformers Transformers for Distribution Network Solutions up to 36 kV Contens Introduction__________________________ 1 Preface1 Your Electrical Network 2 Your Business and DNS Applications 2 Our Product Map (SSS & DNS) 3 Main features ________________________ 4 Safety4 Reliability6 Efficiency 6 Sustainability 7 Continuous innovation 7 Technical details_______________________ 8 Family8 Applied Standards 8 Constructive structure 8 Design characteristics___________________ 9 Low voltage connection 9 Medium voltage connection 9 Standard equipment 10 Optional equipment 11 Other dielectric liquids Type of transformers_____________________________________ Characteristics 24 kV: D0 CK (AB’) 11 12 12 Characteristics 24 kV: C0 CK (AC’) 14 Characteristics 24 kV: C0 BK (CC’) 16 Characteristics 36 kV: B036 BK3618 The quality of the products designed, manufactured and installed by Ormazabal is backed by the implementation and certification of a quality management system, based on international standard ISO 9001:2008. Our commitment to the environment is reaffirmed with the implementation and certification of an environmental management system as laid down in international standard ISO 14001. In view of the constant evolution in standards and design, the characteristics of the elements contained in this catalogue are subject to change without prior notification. These characteristics, as well as the availability of components, are subject to confirmation by Ormazabal. Dielectric liquid immersed transformers Transformers for Distribution Network Solutions up to 36 kV Introduction Preface The incorporation into Ormazabal in 2001 of the distribution transformer manufacturer Cotradis constituted a strategic milestone for us. Ormazabal is the leading provider of personalized solutions to electrical utilities, to energy end users as well as renewable energy systems applications based on our own technology. The exchange of know-how between our technical teams has significantly reinforced the value added for our customers. We encourage the development of the electrical sector concerning the challenges of the future energy needs. We cooperate with the world's leading local, regional and global companies in the electrical sector with a strong commitment to innovation for personal safety, network reliability, energy efficiency, and sustainability. Growing energy demands, higher quality requirements in energy supply and the priority to reduce the consumption of natural resources require the use of equipment which responds with high levels of reliability, safety and energy efficiency. Focusing on the needs of our customers and mastering new technologies allows us to offer products which comply with these requirements. Our highly qualified and focused team of professionals thrilled by innovation have developed our own products and solutions during our more than a century long consolidated history, always by establishing close relationship with our clients towards achieving mutual long term benefits. Velatia is an international industrial and technological group which operates in the areas of electrical networks, electronics and communication networks as well as in the consulting, security and aviation sectors, where security, efficiency and reliability are valued. Grupo Ormazabal is now called Velatia. We have combined our forces to transform ourselves into a stronger group. Made up of companies with more than a hundred years of experience and committed to innovation to meet the present and future needs of our customers, wherever they may be. The solutions of the companies in Velatia seek to make the world a more connected, more sustainable, smarter, better connected, safer, more humane place. Our specialisation in Medium Voltage is backed by the certification of our transformers in major European electrical companies. We manufacture a wide range of dielectric liquid immersed distribution transformers, compliant with all of the requirements in current international regulations and with a range of powers from 25 kVA to 5000 kVA and insulation levels up to 36 kV. Kalkbukt PV Plant (Republic of South Africa) Furthermore, close collaboration with our customers enables us to develop transformers conforming to their own particular standards and specifications. Athletic Bilbao Stadium (Bilbao, Spain) Public Distribution EDF utility (France) 1 Dielectric liquid immersed transformers Transformers for Distribution Network Solutions up to 36 kV Your Electrical Network "Your dedicated partner for reliable and intelligent electrical network" Your Business and DNS Applications Close relationship with our customers and the profound knowledge of the electrical business are the keys to success that enable us to offer Distribution Network Solutions (DNS) based on high added value products and services adapted to the needs of the electrical utilities, electrical energy end users and renewable energies. 2 Smart Grid Transmission & Distribution Generation Infrastructures Industrial Tertiary Wind Solar Dispatchable RES Distributors OEM EPC Dielectric liquid immersed transformers Transformers for Distribution Network Solutions up to 36 kV Our Product Map (SSS & DNS) Our Business Lines We believe that excellence does not lie solely in offering effective products and services, but also in the ability to respond to individual requirements and demands. SSS: Substation Solution for primary distribution We provide our clients with personalised projects for efficient energy management via Primary and Secondary Distribution equipment and solutions. DNS: Distribution Network Solutions for secondary distribution Our products for your segment CPG.1 CPG.0 CGM.3 GAE 1250kMAX GAE Protection, automation and control CiBOR AMC A-CiBOR GA Walk-in Compact Concrete enclosure for transformer substations (TS) Underground CGMCOSMOS [IEC - ANSI/IEEE] ORMACONTAINER Prefabricated substations CGMCOSMOS [HN] EA Distribution transformers Conventional oil Concrete prefabricated transformer substations (TS) Underground NVL-CiBOR Walk-in Current® family ekorSYS family Advanced metering, sensing & analytics and communications Protection, automation and control Modular Low voltage board ORGANIC TPC Metallic prefabricated TS CEADS Switching nodes Metallic enclosure for TS Photovoltaic substation Mobile substation 3 Dielectric liquid immersed transformers Transformers for Distribution Network Solutions up to 36 kV Main features Safety Our transformers are subjected to the tests described in the IEC 60076 series of standards. We have our own laboratories for this purpose, equipped with modern, precise measurement devices and systems that are certified and calibrated according to the directives of the ISO 9001 standard, to ensure that our products comply with the most demanding quality standards. Routine test Type test All of the transformers manufactured are subjected to the following routine tests, in accordance with IEC 60076-1: With our customer’s agreement, the following tests are performed in accordance with current international regulations: • Winding resistance measurement. • Temperature-rise test. • Measurement of the voltage ratio and verification of the vector group. • Dielectric type tests: • Measurement of the short-circuit impedance and load losses. • Measurement of no -load losses and current. [kV] • Induced AC voltage test (ACSD) (also known as Short duration induced AC withstand voltage test) Separate source AC withstand voltage test (Applied over-voltage test or Power frequency test) MV LV Highest voltage for the equipment, Um, (Insulation Level). 12 17.5 24 36 1.1 3.6 Rated withstand Voltage of the test (1 minute). [kV] 28 38 50 70 MV 3 LV Highest voltage for the equipment, Um, (Insulation Level). 12 17.5 24 36 1.1 3.6 Rated withstand Voltage for Lightning impulse test (1.2 / 50μs). • Separate source AC withstand voltage test (also known as Applied over-voltage test or Power frequency test) [kV] Lightning impulse (LI) test [kV] • Dielectric routine tests: 4 • Lightning impulse (LI) test. 10 75 95 125 170 20 20 Dielectric liquid immersed transformers Transformers for Distribution Network Solutions up to 36 kV Special test Additional test Special tests specifically requested by the customer: Dielectric Oil Tests • Special dielectric tests. • Partial discharge measurement test. • Winding capacities measurement – earth and between windings. • Zero-sequence (homopolar) impedance measurement (in three-phase transformers). • Ability to withstand Short-circuit test (IEC 60076-5), performed in accredited external and internal laboratories (HPL). • Sound level measurement(IEC 60076-10). • Measurement of no-load current harmonics. The transformer’s operative life is largely related to the quality of the dielectric liquid. We assure the highest quality standards by means of strict qualification and product auditing processes as well as by applying the most advanced technologies in the treatment process. • Density at 20ºC • Viscosity at 40ºC • Water content Tank Tests • EN 50464-4 Endurance test Paint Tests • Film Thickness measurement • Adherence test • Hardness test • Bend test • Impact test • Cupping test • Salt spray test • Breakdown voltage • Dielectric dissipation factor • Interfacial tension • Acidity • Flash point • Measurement of insulation resistance and/or measurement of the dissipation factor (tan delta) of the insulation capacitances. 5 Dielectric liquid immersed transformers Reliability Efficiency The quality and reliability of our products is demonstrated through the testing and certification of our transformers in independent, internationally-renowned laboratories. Dielectric Liquid completely immersed Hermetically-Sealed Transformer Furthermore, the technological development and passion for innovation, which has been fundamentally apparent throughout the history of our company, is reinforced by our High Power Laboratory (HPL) with a capacity up to 2500 MVA. These are our own facilities which enable ongoing tests and which combined with our highly-qualified staff, further certify our technological independence. Together with external organisations and official bodies, we also participate in market quality control campaigns to assure the verification of our products. • Hermetically-sealed tanks: • No expansion tank is needed. • Less dielectric liquid used than in other types of transformer. • No contact between the dielectric liquid and external agents (air, humidity, pollution, etc.) • Prevents deterioration of the dielectric’s characteristics. • Low-level maintenance. • Minimal risk of leakages: • Tank robustness (high quality materials). • Welding processes carried out by qualified staff. • Leak tests performed in all transformers. Minimal Environmental Impact • Respect for the environment: • Use of highly-recyclable materials. • Rationalisation in the use of raw materials. • Optimised transformer dimensions • Optimum consumption of raw materials: • Materials selection. • Maximisation of their characteristics. • Low electrical energy consumption: • Advanced technology in design, manufacturing and testing. • Minimal loss transformers. • Safe, reliable products. • ISO 14001 certification. 6 Transformers for Distribution Network Solutions up to 36 kV Low Noise Level • An optimum design and assembly of the ferromagnetic core enables us to drastically reduce the level of noise generated by the transformer. • There are two components that identify the level of noise produced by a transformer: LwA = LpA + KS Where: • LwA: Acoustic Power (cause) • LpA: Acoustic Pressure (effect) • KS factor (>0) which depends on the size of the transformer. To define a transformer, the use of Acoustic Power LwA is recommended since it is a value which is independent from the environment and is therefore the best magnitude for assessing the acoustic emissivity of a transformer. Dielectric liquid immersed transformers Transformers for Distribution Network Solutions up to 36 kV PCB Free • Our transformers are only manufactured using new components and without any PCBs, in strict compliance with current regulations. Sustainability Continuous innovation Sustainability, understood as the best compromise between satisfying social demands, caring for the environment and financial aspects. Our commitment to innovation places us at the technological forefront of Europe. Social Demands • Safety of people and goods. • Continuity of service. Financial Aspects • Optimum use of raw materials. • Longer equipment life, endurance and robustness. • Equipment adaptable to network evolution. • Equipment durability. Caring for the Environment Electromagnetic Compatibility Our transformers are passive elements in terms of electromagnetic compatibility. In other words, they work satisfactorily without adding electromagnetic noise that is intolerable for equipment in their surroundings and they withstand such interference caused by other devices. The currents that circulate through the conductors connected to the transformers, especially lowvoltage ones, can cause significant electromagnetic fields. The installation designer must make sure that these cables are laid such that the fields are minimised or, if necessary, measures must be adopted to limit their effects. • Reduction in the volume of dielectric liquid. • Minimal dimensions. • Minimal losses in the transformer. • Low risk of oil leakage. • Non-aggressive for the surrounding environment. • Recyclability. Therefore our products meet the most demanding worldwide requirements and are certified by internationally renowned laboratories. Recently we have extended our product range to 5 MVA and also we have developed several new transformers with lower losses. Our quality, environmental and health& safety prevention policies establish our commitment to fostering and being part of an environmentallyresponsible society. Within this framework, our quality management system is internationally recognised through ISO 9001 certification. Furthermore, our strong commitment to the environment is reflected in the implementation of an environmental management system, certified according to the ISO 14001 standard, which monitors the impact of activities on the environment. This policy also aims to promote and establish a culture of excellence and respect for personal health and safety, in accordance with standard OHSAS 18001. Its scope ranges from our team of professionals and partners to the end user. 7 Dielectric liquid immersed transformers Transformers for Distribution Network Solutions up to 36 kV Technical details Family Constructive structure From 25 to 5000 kVA • Insulation Level 24 and 36 kV Active part Tank and dielectric The active part of the transformer is the energy transformation system, composed of the ferromagnetic core, the windings and the medium and low voltage connections. The transformer’s tank and the dielectric liquid provide the necessary insulation and cooling. Dielectric Liquid Immersed Transformers Description These transformers comply with the following characteristics: • Three-phase transformers, 50 Hz for installation indoors or outdoors 2 • Hermetically-sealed 1 • Completely Immersed in mineral oil in accordance with standard IEC 60296. • ONAN cooling. • Colour: RAL 7033 (other colours under request). The data and values shown correspond to the Normal Service Conditions referred to in standard IEC 60076-1. 1. Active part 2. Tank and dielectric WindingsAdvantages • Concentric windings. • Insulation between layers: Cellulose with epoxy resin which compacts the coils, once cured. • Coils are manufactured using the latest techniques and machinery. • Optimised to withstand short circuit forces. Applied Standards • Expertise in coil cooling. • Careful manufacturing of coils and cooling channels. • Improved heat dissipation in the windings. The transformers comply with the following standards: • Use of high-quality cellulosic materials. • Optimum handling and storage to preserve insulation properties. • Guaranteed insulation. For other configurations, please contact our Technical-Commercial Department. •EN 50464 •IEC 60076 Connections and Tap Changer • MV and LV terminals. • Transformer connection to the outside. • Off-circuit Tap changer. • Secondary voltage can be adjusted precisely. Tank and Dielectric Liquid 8 Advantages Advantages • Elastic Corrugated tank with cooling fins. • Increased heat dissipation surface. • Absorption of variations in the volume of the dielectric liquid caused by changes in its temperature. • Mechanical and electrical protection. • Completely filled with dielectric liquid and hermetically sealed tank. • No aging of the dielectric liquid as there is no contact with the air. • Minimal maintenance requirements. • Small size. • No expansion tank or air dehydrating needed • Lighter in weight. • Electromagnetic field shielding. • Immersed in dielectric liquid. • Lower noise level. • Better behaviour in the event of overloads and harmonics. • Surface treatment and paint. • Protection against corrosion, atmospheric agents, insolation and impacts. Dielectric liquid immersed transformers Transformers for Distribution Network Solutions up to 36 kV Design characteristics LV single phase Busbar Bushings (optional) LV connection Flags Metric: from M20 to M55 Metric M12 Low voltage connection LV porcelain bushings for 420 V - B2* Rated Power [kVA] 25 40 50 63 100 160 250 400 500 630 800 1000 1250 1600 2000 2500 [A] 250 250 250 250 250 250 630 630 1000 1000 1600 1600 2000 3150 3150 4000 M12 M12 M12 M12 M12 M12 M20 M20 M30 M30 M42 M42 M42 M48 M48 M55 Brass Brass Brass Brass Brass Brass Brass Brass Brass Brass Brass Brass Copper Copper Copper Copper M12 M12 M12 M12 M12 M12 M20 M20 M30 M30 M42 M42 M42 M48 M48 M55 Rated current Dimension - Metric d1 Material Connections parts – LV Flags Metric e [mm] f0 [mm] Ø [mm] - - - - - - 32 32 32 32 40 40 40 40 40 70 40 40 40 40 40 40 60 60 60 60 100 100 100 120 120 150 14 14 14 14 14 14 14 14 14 14 14 14 14 14 14 18 LV single pole busbar bushings for indoor installation (optional) Rated Power Rated current Material [kVA] 25 40 50 63 100 160 250 400 500 630 800 1000 1250 1600 2000 2500 [A] - - - - - - 630 630 1600 1600 1600 1600 - - - - - - - - - - Al Al Copper Copper Copper Copper - - - - Please contact Ormazabal for ohter secondary voltages and technical values above 2500 kVA. Medium voltage connection Connectors for mv plug-in bushings (not supplied with the transformer) Insulation [kV] 24 36 Type A elbow connector (250 A) Ref. EUROMOLD K-158LR Type B elbow connector (400 A) Ref. EUROMOLD M-400LR Type A straight connector (250 A) Ref. EUROMOLD K-152SR - 9 Dielectric liquid immersed transformers Transformers for Distribution Network Solutions up to 36 kV Standard equipment 1 4 2 9 7 3 2 8 12 10 11 13 6 5 Uninhibited mineral insulating oil IEC 60296 1. Off-circuit regulation tap changer (can only be operated without voltage) IEC 60214 Off circuit voltage tap changer for dual primary voltage transformers (can only be operated without voltage) IEC 60214 2. MV porcelain bushings EN 50180 3. LV porcelain bushings 4. LV connection Flags 5. 2 Earthing terminals in the tank EN 50216-4 6. Draining and sampling device EN 50216-4 7. Filling device EN 50464-1 8. Rating plate EN 50464-1 9. 2 Lifting eyes EN 50464-1 10.4 Latching eyes EN 50464-1 11.4 Pulling eyes EN 50464-1 12.Thermometer pocket EN-50216-4 13.Wheels 10 EN 50386 ≥630 kVA ≥250 kVA EN-50216-4 Dielectric liquid immersed transformers Transformers for Distribution Network Solutions up to 36 kV Optional equipment 6 1 2 4 3 7 7 5 1. MV plug-in bushings EN 50180 2. LV single pole busbar bushings EN 50387 3. Thermometer: measures the temperature of the top layer of the insulation liquid. Available with 2 contacts (alarm and trigger) and upper limit marker. 4. Protection relay Functions: Internal tank pressure control Dielectric liquid temperature control Oil level control and gas detection EN 50216-3 5. Dielectric liquid collection device 6. Terminal cover box 7. Pole mounting brackets and support for surge arresters (application for pole mounted transformers up to 160 kVA). Other dielectric liquids • ORGANIC transformers: Natural, biodegradable ester for application in electrical transformers. Class K with fire point greater than 300 ºC. • Dielectric liquid silicone according to the IEC 60836 standard, Class K with fire point greater than 300 ºC. • Synthetic biodegradable ester for application in electrical transformers according to the IEC 61099 standard. Class K, with fire point greater than 300 ºC. 11 Dielectric liquid immersed transformers Transformers for Distribution Network Solutions up to 36 kV Type of transformers Characteristics 24 kV: D0 CK (AB’) From 250 up to 5000 kVA • Insulation Level 24 kV Dielectric Liquid Immersed Transformers MV Plug-In Bushings F Filling Device J Draining and Sampling Device H H H J K Thermometer Pocket Filling Device B B MV Regulation Tap Changer A A Electrical characteristics 24 kV: D0 CK (AB’) Rated Power [kVA] Rated Voltage (Ur) J Draining and Sampling Device H H H Thermometer Pocket MV Regulation Tap Changer C D1 Earth connection M12 Wheel Frames (skids) L K M J LV Bushings C D3 D2 Earth connection M12 Wheel Frames (skids) MV Bushings Lifting Eyes MV Bushings L LV Bushings MV Porcelain Bushings F D2 F M F Lifting Eyes 250 400 500 630 800 1000 1250 20 400 / 410 / 415 / 420 (to be defined) Dyn11/ Dyn5 Primary [kV] No-load Secondary [V] Vector Group No-Load Losses - Po [W] Load Losses - Pk [W] Short-Circuit Impedance (%) at 75ºC Sound Power Level LwA [dB] Voltage drop at full load (%) load 100% load 75% Efficiency (%) 1600 2000 2500(*) List D0 530 750 880 1030 1150 1400 1750 2200 2700 3200 List Ck 3250 4600 5500 6500 8400 10500 13500 17000 21000 26500 4 4 4 4 6 6 6 6 6 6 List D0 60 63 64 65 66 68 69 71 73 76 1.37 3.33 98.51 98.15 98.76 98.45 1.22 3.25 98.68 98.36 98.90 98.63 1.16 3.21 98.75 98.44 98.96 98.70 1.11 3.17 98.82 98.53 99.02 98.78 1.19 4.44 98.86 98.58 99.06 98.83 1.22 4.47 98.82 98.53 99.04 98.80 1.25 4.49 98.79 98.50 99.01 98.77 1.24 4.48 98.81 98.52 99.03 98.79 1.22 4.47 98.83 98.54 99.04 98.81 1.23 4.47 98.83 98.54 99.04 98.81 cosƒ=1 cosƒ=0.8 cosƒ=1 cosƒ=0.8 cosƒ=1 cosƒ=0.8 Dimensions [mm] Rated Power [kVA] A (Length) B (Width) C (Height to cover) D1 (Height to MV with porcelain bushings) D3 (Height to MV Plug-In bushings) D2 (Height to LV with Flags) F (Separation between MV bushings) 250 400 500 630 800 1000 1250 1600 2000 2500 1376 1537 1622 1622 1932 1997 2007 1922 1965 2093 930 941 962 962 1161 1200 1200 1224 1277 1487 915 1004 1026 1092 1112 1158 1230 1517 1715 1737 1300 1389 1411 1477 1497 1543 1615 1902 2100 2122 1004 1093 1115 1181 1201 1247 1319 1606 1804 1826 1149 1238 1287 1353 1445 1491 1563 1886 2084 2167 275 275 275 275 275 275 275 275 275 275 H (separation between LV bushings) 150 150 150 150 150 150 150 200 200 200 J (Distance between wheel axis) K (wheel width) Ø (wheel diameter) L (Wheel) 670 670 670 670 670 670 820 820 820 1070 Oil Volume [Litres] Total weight [Kg] 40 40 40 40 40 40 70 70 70 70 125 125 125 125 125 125 200 200 200 200 110 110 110 110 110 110 165 165 165 165 260 330 390 410 510 530 540 1000 1200 1400 1010 1330 1600 1750 2250 2430 2750 3850 4750 5350 (*) Please contact Ormazabal for technical values above 2500 kVA. 12 Dielectric liquid immersed transformers Transformers for Distribution Network Solutions up to 36 kV Characteristics 24 kV: D0 CK (AB’) From 25 up to 160 kVA • Insulation Level 24 kV Dielectric Liquid Immersed Transformers MV Porcelain Bushings F Lifting Eyes F MV Bushings Surge arresters support (Op) LV Bushings D1 80 C D2 140 Latching eyes Wheel Frames (skids) Filling Device K J H H H L L Earth connection M12 Draining and Sampling Device J Thermometer Pocket (optional) B MV Regulation Tap Changer A Electrical characteristics 24 kV: D0 CK (AB’) Rated Power [kVA] Rated Voltage (Ur) 25 40 50 63 100 20 400 / 410 / 415 / 420 (to be defined) Yzn11/Dyn11 List D0 95 125 145 175 260 375 List Ck 700 940 1100 1270 1750 2350 4 4 4 4 4 4 List D0 47 49 50 51 54 57 2.84 3.96 96.92 96.18 97.46 96.84 2.40 3.83 97.41 96.78 97.87 97.35 2.26 3.77 97.57 96.98 98.00 97.52 2.08 3.70 97.76 97.21 98.15 97.70 1.81 3.57 98.03 97.55 98.37 97.97 1.54 3.43 98.33 97.92 98.61 98.26 Primary [kV] No-load Secondary [V] Vector Group No-Load Losses - Po [W] Load Losses - Pk [W] Short-Circuit Impedance (%) at 75ºC Sound Power Level LwA [dB] Voltage drop at full load (%) load 100% load 75% Efficiency (%) cosƒ=1 cosƒ=0.8 cosƒ=1 cosƒ=0.8 cosƒ=1 cosƒ=0.8 160 Dyn/Yzn Dimensions [mm] Rated Power [kVA] A (Length) B (Width) C (Height to cover) D1 (Height to MV with porcelain bushings) D3 (Height to MV Plug-In bushings) D2 (Height to LV with Flags) F (Separation between MV bushings) 25 40 50 63 100 160 888 888 888 926 1006 1205 704 704 704 735 796 848 768 810 810 844 889 847 1153 1195 1195 1229 1274 1232 857 899 899 933 978 936 918 960 960 994 1039 997 275 275 275 275 275 275 80 80 80 80 80 80 J (Distance between wheel axis) K (wheel width) Ø (wheel diameter) L (Wheel) Distance between pole mounting brackets 520 520 520 520 520 520 Oil Volume [Litres] Total weight [Kg] H (separation between LV bushings) 40 40 40 40 40 40 125 125 125 125 125 125 110 110 110 110 110 110 530 530 530 530 530 530 100 105 105 120 155 200 360 400 435 515 610 770 13 Dielectric liquid immersed transformers Transformers for Distribution Network Solutions up to 36 kV Characteristics 24 kV: C0 CK (AC’) From 250 up to 5000 kVA • Insulation Level 24 kV Dielectric Liquid Immersed Transformers MV Plug-In Bushings F L J K Thermometer Pocket Filling Device B B MV Regulation Tap Changer A A Electrical characteristics 24 kV: C0 CK (AC’) Rated Power [kVA] Rated Voltage (Ur) J Draining and Sampling Device H H H Thermometer Pocket MV Regulation Tap Changer C D1 Earth connection M12 Wheel Frames (skids) J Draining and Sampling Device H H H LV Bushings C D3 D2 Filling Device K M J MV Bushings Lifting Eyes MV Bushings Earth connection M12 Wheel Frames (skids) MV Porcelain Bushings F L LV Bushings D2 F M F Lifting Eyes 250 400 500 Primary [kV] No-load Secondary [V] Vector Group No-Load Losses - Po [W] Load Losses - Pk [W] Short-Circuit Impedance (%) at 75ºC Sound Power Level LwA [dB] Voltage drop at full load (%) load 100% load 75% Efficiency (%) 630 800 1000 1250 20 400 / 410 / 415 / 420 (to be defined) Dyn11/ Dyn5 1600 2000 2500(*) List C0 425 610 720 860 930 1100 1350 1700 2100 2500 List Ck 3250 4600 5500 6500 8400 10500 13500 17000 21000 26500 4 4 4 4 6 6 6 6 6 6 List C0 55 58 59 60 61 63 64 66 68 71 1.37 3.33 98.55 98.20 98.81 98.52 1.22 3.25 98.71 98.40 98.95 98.69 1.17 3.22 98.77 98.47 98.99 98.74 1.11 3.17 98.85 98.56 99.05 98.82 1.22 4.47 98.85 98.56 99.07 98.84 1.22 4.47 98.85 98.57 99.07 98.85 1.25 4.49 98.83 98.54 99.06 98.82 1.24 4.48 98.84 98.56 99.07 98.84 1.25 4.48 98.83 98.55 99.06 98.83 1.23 4.47 98.85 98.57 99.08 98.85 cosƒ=1 cosƒ=0.8 cosƒ=1 cosƒ=0.8 cosƒ=1 cosƒ=0.8 Dimensions [mm] Rated Power [kVA] A (Length) B (Width) C (Height to cover) D1 (Height to MV with porcelain bushings) D3 (Height to MV Plug-In bushings) D2 (Height to LV with Flags) F (Separation between MV bushings) 250 400 500 630 800 1000 1250 1600 2000 2500 1376 1537 1622 1622 1932 1997 2007 1922 1965 2157 930 941 962 962 1161 1245 1224 1224 1277 1487 960 1004 1026 1114 1123 1158 1252 1517 1715 1737 1345 1389 1411 1499 1508 1543 1637 1902 2100 2122 1049 1093 1115 1203 1212 1247 1341 1606 1804 1826 1194 1238 1287 1375 1456 1491 1585 1886 2084 2167 275 275 275 275 275 275 275 275 275 275 H (separation between LV bushings) 150 150 150 150 150 150 150 200 200 200 J (Distance between wheel axis) K (wheel width) Ø (wheel diameter) L (Wheel) 670 670 670 670 670 670 820 820 820 1070 Oil Volume [Litres] Total weight [Kg] 40 40 40 40 40 40 70 70 70 70 125 125 125 125 125 125 200 200 200 200 110 110 110 110 110 110 165 165 165 165 270 320 390 395 480 510 550 1020 1230 1390 1090 1355 1640 1835 2310 2510 2905 4020 4850 5525 (*) Please contact Ormazabal for technical values above 2500 kVA. 14 Dielectric liquid immersed transformers Transformers for Distribution Network Solutions up to 36 kV Characteristics 24 kV: C0 CK (AC’) From 25 up to 160 kVA • Insulation Level 24 kV Dielectric Liquid Immersed Transformers MV Porcelain Bushings F Lifting Eyes F MV Bushings Surge arresters support (Op) LV Bushings D1 D2 140 Latching eyes C 80 Wheel Frames (skids) Filling Device K J H H H L L Earth connection M12 Draining and Sampling Device J Thermometer Pocket (optional) B MV Regulation Tap Changer A Electrical characteristics 24 kV: C0 CK (AC’) Rated Power [kVA] Rated Voltage (Ur) 25 40 50 63 100 20 400 / 410 / 415 / 420 (to be defined) Dyn11/ Dyn5 List C0 75 105 125 145 210 300 List Ck 700 940 1100 1270 1750 2350 4 4 4 4 4 4 List C0 45 47 47 48 49 52 2.84 3.96 96.99 96.27 97.56 96.97 2.40 3.83 97.45 96.84 97.93 97.43 2.26 3.77 97.61 97.03 98.06 97.58 2.08 3.70 97.80 97.27 98.21 97.78 1.81 3.57 98.08 97.61 98.43 98.05 1.54 3.43 98.37 97.97 98.67 98.34 Primary [kV] No-load Secondary [V] Vector Group No-Load Losses - Po [W] Load Losses - Pk [W] Short-Circuit Impedance (%) at 75ºC Sound Power Level LwA [dB] Voltage drop at full load (%) load 100% load 75% Efficiency (%) cosƒ=1 cosƒ=0.8 cosƒ=1 cosƒ=0.8 cosƒ=1 cosƒ=0.8 160 Dyn/Yzn Dimensions [mm] Rated Power [kVA] A (Length) B (Width) C (Height to cover) D1 (Height to MV with porcelain bushings) D3 (Height to MV Plug-In bushings) D2 (Height to LV with Flags) F (Separation between MV bushings) 25 40 50 63 100 160 888 888 888 926 1.006 1.205 704 704 704 735 796 848 780 869 828 859 911 847 1165 1254 1213 1244 1296 1232 869 958 917 948 1.000 936 930 1.019 978 1.009 1.061 997 275 275 275 275 275 275 80 80 80 80 80 80 J (Distance between wheel axis) K (wheel width) Ø (wheel diameter) L (Wheel) Distance between pole mounting brackets 520 520 520 520 520 520 Oil Volume [Litres] Total weight [Kg] H (separation between LV bushings) 40 40 40 40 40 40 125 125 125 125 125 125 110 110 110 110 110 110 530 530 530 530 530 530 100 110 100 125 150 190 370 440 445 520 670 790 15 Dielectric liquid immersed transformers Transformers for Distribution Network Solutions up to 36 kV Characteristics 24 kV: C0 BK (CC’) From 250 up to 5000 kVA • Insulation Level 24 kV Dielectric Liquid Immersed Transformers LV Plug-In Bushings F Lifting Eyes Filling Device L M K J J Draining and Sampling Device H H H C Earth connection M12 Wheel Frames (skids) J K J Draining and Sampling Device H H H Thermometer Pocket L Earth connection M12 Wheel Frames (skids) MV Porcelain Bushings LV Plug-In Bushings C D3 D2 LV Plug-In Bushings MV Porcelain Bushings F Thermometer Pocket Filling Device B MV Regulation Tap Changer B MV Regulation Tap Changer A A Electrical characteristics 24 kV: C0 BK (CC’) Rated Power [kVA] Rated Voltage (Ur) 250 400 500 Primary [kV] No-load Secondary [V] Vector Group No-Load Losses - Po [W] Load Losses - Pk [W] Short-Circuit Impedance (%) at 75ºC Sound Power Level LwA [dB] Voltage drop at full load (%) load 100% load 75% Efficiency (%) 630 800 1000 1250 20 400 / 410 / 415 / 420 (to be defined) Dyn11/ Dyn5 1600 2000 2500(*) List D0 425 610 720 860 930 1100 1350 1700 2100 2500 List Bk 2750 3850 4600 5400 7000 9000 11000 14000 18000 22000 4 4 4 4 6 6 6 6 6 6 List C0 55 58 59 60 61 63 64 66 68 71 1.17 3.22 98.75 98.44 98.96 98.70 1.04 3.13 98.90 98.63 99.08 98.86 1.00 3.10 98.95 98.69 99.13 98.91 0.93 3.06 99.02 98.77 99.18 98.98 1.05 4.35 99.02 98.78 99.20 99.00 1.08 4.37 99.00 98.75 99.19 98.98 1.06 4.38 98.98 98.73 99.17 98.97 1.05 4.35 99.03 98.79 99.21 99.01 1.08 4.35 99.03 98.79 99.21 99.02 1.06 4.35 99.03 98.79 99.21 99.02 cosƒ=1 cosƒ=0.8 cosƒ=1 cosƒ=0.8 cosƒ=1 cosƒ=0.8 Dimensions [mm] Rated Power [kVA] A (Length) B (Width) C (Height to cover) D1 (Height to MV with porcelain bushings) D3 (Height to MV Plug-In bushings) D2 (Height to LV with Flags) F (Separation between MV bushings) 250 400 500 630 800 1000 1250 1600 2000 2500 1376 1537 1622 1569 1997 1997 2007 1965 1965 2480 930 941 962 962 1200 1200 1182 1277 1277 1426 915 1004 1092 1169 1158 1158 1373 1671 1715 1836 1300 1389 1477 1554 1543 1543 1758 2056 2100 2221 1004 1093 1181 1258 1247 1247 1462 1760 1804 1925 1149 1238 1353 1430 1491 1491 1706 2040 2084 2266 275 275 275 275 275 275 275 275 275 275 H (separation between LV bushings) 150 150 150 150 150 150 150 200 200 200 J (Distance between wheel axis) K (wheel width) Ø (wheel diameter) L (Wheel) 670 670 670 670 670 670 820 820 820 1070 Oil Volume [Litres] Total weight [Kg] 40 40 40 40 40 40 70 70 70 70 125 125 125 125 125 125 200 200 200 200 110 110 110 110 110 110 165 165 165 165 260 325 390 390 520 500 660 1200 1245 1340 1100 1420 1810 1920 2530 2560 3200 4950 5150 5750 (*) Please contact Ormazabal for technical values above 2500 kVA. 16 D1 MV Porcelain Bushings D2 F M F Lifting Eyes Dielectric liquid immersed transformers Transformers for Distribution Network Solutions up to 36 kV Characteristics 24 kV: C0 BK (CC’) From 25 up to 160 kVA • Insulation Level 24 kV Dielectric Liquid Immersed Transformers MV Porcelain Bushings F Lifting Eyes F MV Bushings Surge arresters support (Op) LV Bushings D1 80 C D2 140 Latching eyes Wheel Frames (skids) Filling Device K J H H H L Earth connection M12 Draining and Sampling Device J Thermometer Pocket (optional) B MV Regulation Tap Changer A Electrical characteristics 24 kV: C0 BK (CC’) Rated Power [kVA] Rated Voltage (Ur) 25 40 50 63 100 20 400 / 410 / 415 / 420 (to be defined) Yzn11 / Yzn5 List C0 75 105 125 145 210 300 List Bk 560 750 875 1050 1475 2000 4 4 4 4 4 4 List C0 45 47 47 48 49 52 2.29 3.79 97.52 96.92 97.96 97.47 1.94 3.63 97.91 97.40 98.27 97.85 1.81 3.57 98.04 97.56 98.38 97.98 1.73 3.53 98.14 97.68 98.47 98.09 1.54 3.43 98.34 97.94 98.63 98.30 1.32 3.31 98.58 98.23 98.83 98.54 Primary [kV] No-load Secondary [V] Vector Group No-Load Losses - Po [W] Load Losses - Pk [W] Short-Circuit Impedance (%) at 75ºC Sound Power Level LwA [dB] Voltage drop at full load (%) load 100% load 75% Efficiency (%) cosƒ=1 cosƒ=0.8 cosƒ=1 cosƒ=0.8 cosƒ=1 cosƒ=0.8 160 Dyn/Yzn Dimensions [mm] Rated Power [kVA] A (Length) B (Width) C (Height to cover) D1 (Height to MV with porcelain bushings) D3 (Height to MV Plug-In bushings) D2 (Height to LV with Flags) F (Separation between MV bushings) 25 40 50 63 100 160 888 888 926 926 1006 1205 704 704 704 704 796 848 780 869 848 899 911 847 1165 1254 1233 1284 1296 1232 869 958 937 988 1000 936 930 1019 998 1049 1061 997 275 275 275 275 275 275 80 80 80 80 80 80 J (Distance between wheel axis) K (wheel width) Ø (wheel diameter) L (Wheel) Distance between pole mounting brackets 520 520 520 520 520 520 Oil Volume [Litres] Total weight [Kg] H (separation between LV bushings) 40 40 40 40 40 40 125 125 125 125 125 125 110 110 110 110 110 110 530 530 530 530 530 530 100 110 115 125 160 190 380 460 490 548 690 820 17 Dielectric liquid immersed transformers Transformers for Distribution Network Solutions up to 36 kV Characteristics 36 kV: B036 BK36 From 250 up to 5000 kVA • Insulation Level 36 kV Dielectric Liquid Immersed Transformers MV Porcelain Bushings LV Plug-In Bushings F Lifting Eyes F LV Plug-In Bushings F MV Porcelain Bushings F LV Plug-In Bushings MV Porcelain Bushings C D1 D2 C D3 D2 Lifting Eyes H H H Thermometer Pocket H H H Filling Device J Draining and Sampling Device Thermometer Pocket B MV Regulation Tap Changer MV Regulation Tap Changer A A Electrical characteristics 36 kV: B036 BK36 Rated Power [kVA] Rated Voltage (Ur) K J L L J Draining and Sampling Device Earth connection M12 Wheel Frames (skids) B Filling Device K M J Earth connection M12 M J Wheel Frames (skids) 250 400 500 Primary [kV] No-load Secondary [V] Vector Group No-Load Losses - Po [W] Load Losses - Pk [W] Short-Circuit Impedance (%) at 75ºC Sound Power Level LwA [dB] Voltage drop at full load (%) load 100% load 75% Efficiency (%) 630 800 1000 1250 25 400 / 410 / 415 / 420 (to be defined) Dyn11 / Dyn5 1600 2000 2500(*) List B036 List BK36 650 930 1100 1300 1500 1700 2100 2600 3150 3800 3500 4900 5600 6500 8400 10500 13500 17000 21000 26500 4.5 4.5 4.5 4.5 6 6 6 6 6 6 List B036 62 65 66 67 68 68 70 71 73 76 1.49 3.72 98.37 97.97 98.62 98.28 1.32 3.62 98.56 98.21 98.79 98.49 1.21 3.55 98.68 98.35 98.88 98.60 1.13 3.50 98.78 98.48 98.96 98.71 1.22 4.47 98.78 98.48 98.97 98.72 1.22 4.47 98.79 98.50 99.00 98.75 1.25 4.49 98.77 98.46 98.98 98.72 1.24 4.48 98.79 98.49 99.00 98.75 1.22 4.47 98.81 98.51 99.01 98.77 1.23 4.47 98.80 98.51 99.01 98.77 cosƒ=1 cosƒ=0.8 cosƒ=1 cosƒ=0.8 cosƒ=1 cosƒ=0.8 Dimensions [mm] Rated Power [kVA] A (Length) B (Width) C (Height to cover) D1 (Height to MV with porcelain bushings) D3 (Height to MV Plug-In bushings) D2 (Height to LV with Flags) F (Separation between MV bushings) 250 400 500 630 800 1000 1250 1600 2000 2500 1376 1537 1622 1592 1932 1997 2007 1922 1965 2093 930 941 962 962 1161 1200 1200 1224 1277 1487 915 1004 1026 1092 1112 1158 1230 1517 1715 1737 1368 1442 1464 1530 1550 1596 1668 1955 2153 2175 1050 1139 1161 1227 1247 1293 1365 1652 1850 1872 1149 1238 1287 1353 1445 1491 1563 1886 2084 2167 375 375 375 375 375 375 375 375 375 375 H (separation between LV bushings) 150 150 150 150 150 150 150 200 200 200 J (Distance between wheel axis) K (wheel width) Ø (wheel diameter) L (Wheel) 670 670 670 670 670 670 820 820 820 1070 Oil Volume [Litres] Total weight [Kg] 40 40 40 40 40 40 70 70 70 70 125 125 125 125 125 125 200 200 200 200 110 110 110 110 110 110 165 165 165 165 260 340 390 410 500 530 550 1000 1200 1400 1000 1330 1600 1800 2220 2480 2780 3850 4850 5350 (*) Please contact Ormazabal for technical values above 2500 kVA. 18 Dielectric liquid immersed transformers Transformers for Distribution Network Solutions up to 36 kV Characteristics 36 kV: B036 BK36 From 25 up to 160 kVA • Insulation Level 36 kV Dielectric Liquid Immersed Transformers F F MV Porcelain Bushings Surge arresters support (Op) MV Bushings Lifting Eyes LV Bushings D1 80 C D2 140 Latching eyes K Wheel Frames (skids) Draining and Sampling Device J H H H J Thermometer Pocket (optional) B Filling Device L Earth connection M12 MV Regulation Tap Changer A Electrical characteristics 36 kV: C036 BK36 Rated Power [kVA] Rated Voltage (Ur) 25 Primary [kV] No-load Secondary [V] Vector Group No-Load Losses - Po [W] Load Losses - Pk [W] Short-Circuit Impedance (%) at 75ºC Sound Power Level LwA [dB] Voltage drop at full load (%) load 100% load 75% Efficiency (%) 40 50 63 100 20 400 / 410 / 415 / 420 (to be defined) Yzn11 / Yzn5 160 Dyn/Yzn List B036 115 165 190 225 320 460 List Bk36 900 1110 1250 1435 1950 2550 4.5 4.5 4.5 4.5 4.5 4.5 50 51 52 53 56 59 3.64 4.50 96.10 95.17 96.79 96.02 2.84 4.35 96.91 96.17 97.44 96.82 2.57 4.26 97.20 96.53 97.67 97.11 2.35 4.17 97.43 96.81 97.86 97.34 2.03 4.01 97.78 97.24 98.15 97.69 1.68 3.83 98.15 97.70 98.45 98.06 List B036 cosƒ=1 cosƒ=0.8 cosƒ=1 cosƒ=0.8 cosƒ=1 cosƒ=0.8 Dimensions [mm] Rated Power [kVA] A (Length) B (Width) C (Height to cover) D1 (Height to MV with porcelain bushings) D2 (Height to LV with Flags) F (Separation between MV bushings) 25 40 50 63 100 160 888 926 926 926 1006 1205 704 725 725 725 796 848 768 810 810 859 889 847 1221 1263 1263 1312 1342 1300 918 960 960 1009 1039 997 375 375 375 375 375 375 80 80 80 80 80 80 J (Distance between wheel axis) K (wheel width) Ø (wheel diameter) L (Wheel) Distance between pole mounting brackets 520 520 520 520 520 520 Oil Volume [Litres] Total weight [Kg] H (separation between LV bushings) 40 40 40 40 40 40 125 125 125 125 125 125 110 110 110 110 110 110 530 530 530 530 530 530 100 125 130 130 160 200 330 430 475 490 610 760 19 Dielectric liquid immersed transformers Notes 20 Transformers for Distribution Network Solutions up to 36 kV www.ormazabal.com CA-109-EN-1311
