Deltapath v.2.9.3
Configuration Guide
Table of Contents
1. Executive Summary .......................................................................................................... 2
2. Software and Hardware Equipment Requirements for Testing .................................... 3
3. Test Configurations .......................................................................................................... 4
3.1 Lab Configuration ......................................................................................................... 4
4. Test Bed Configuration Files ........................................................................................... 5
4.1 Deltapath basic Configuration for XO lab .................................................................. 5
© Copyright 9/20/2012. XO Communications, LLC. All rights reserved. XO, the XO design logo, and all related
marks are trademarks of XO Communications, LLC. All other trademarks are property of their respective owners.
1
1. Executive Summary
This report provides the test results found to date for the Deltapath IP PBX SIP Trunking evaluation.
The following is a summary addressed the issues and limitation found while performing the test.
“Diversion” header is not supported so that in the Call Forward which is originated from PSTN
and forwarded back to another PSTN number, the 3 rd party can only see the 2nd party calling ID
instead of the 1st party.
Fax is only supported with T.38. Fax with G.711 pass-through is not supported.
Call Transfer with REFER is not supported.
Registration Method
Static registration is utilized between the Deltapath IP phones and the XO call agent.
XO SIP Service Packages Supported
Pkg
Codec
1
G.711
2
DTMF
RFC 2833 / in-band DTMF
G.729a/G.711 RFC 2833 / in-band DTMF
Fax
T.38 (G.711 pass-through NOT
supported)
T.38 (G.711 pass-through NOT
supported)
© Copyright 9/20/2012. XO Communications, LLC. All rights reserved. XO, the XO design logo, and all related
marks are trademarks of XO Communications, LLC. All other trademarks are property of their respective owners.
2
2. Software and Hardware Equipment Requirements for Testing
a. Deltapath
1) Software version : 2.9.3
b. Polycom IP Phones
1) Model no.: 430
© Copyright 9/20/2012. XO Communications, LLC. All rights reserved. XO, the XO design logo, and all related
marks are trademarks of XO Communications, LLC. All other trademarks are property of their respective owners.
3
3. Test Configurations
3.1 Lab Configuration
The following diagram is the configuration used during lab testing.
XO Lab Setup for
Deltapath IPPBx Testing
205.158.163.138
XO Network
IAD FE 0/1
205.158.163.82
255.255.255.248
Dynamic IP via
DHCP
WAN
205.158.163.90
LAN
10.0.0.1
Deltapath
2146355852
2146355851
IP Phone – Dynamic IP via DHCP
IP Phone – Dynamic IP via DHCP
2146355853
Analog
Note: Above lab setup only shows main lab network elements.
© Copyright 9/20/2012. XO Communications, LLC. All rights reserved. XO, the XO design logo, and all related
marks are trademarks of XO Communications, LLC. All other trademarks are property of their respective owners.
4
4. Test Bed Configuration Files
4.1 Deltapath basic Configuration for XO lab
Deltapath main screen -> http://205.158.163.90
Login - administrator
Password - 36789999
© Copyright 9/20/2012. XO Communications, LLC. All rights reserved. XO, the XO design logo, and all related
marks are trademarks of XO Communications, LLC. All other trademarks are property of their respective owners.
5
Network Configuration: Set WAN (IAD) & LAN IP
© Copyright 9/20/2012. XO Communications, LLC. All rights reserved. XO, the XO design logo, and all related
marks are trademarks of XO Communications, LLC. All other trademarks are property of their respective owners.
6
Phone System > Dial Plan
Extension configuration:
© Copyright 9/20/2012. XO Communications, LLC. All rights reserved. XO, the XO design logo, and all related
marks are trademarks of XO Communications, LLC. All other trademarks are property of their respective owners.
7
User configuration:
© Copyright 9/20/2012. XO Communications, LLC. All rights reserved. XO, the XO design logo, and all related
marks are trademarks of XO Communications, LLC. All other trademarks are property of their respective owners.
8
DID Range to Extension Routing :
User Account Settings :
© Copyright 9/20/2012. XO Communications, LLC. All rights reserved. XO, the XO design logo, and all related
marks are trademarks of XO Communications, LLC. All other trademarks are property of their respective owners.
9
Handset configuration:
© Copyright 9/20/2012. XO Communications, LLC. All rights reserved. XO, the XO design logo, and all related
marks are trademarks of XO Communications, LLC. All other trademarks are property of their respective owners.
10
Trunk Group :
© Copyright 9/20/2012. XO Communications, LLC. All rights reserved. XO, the XO design logo, and all related
marks are trademarks of XO Communications, LLC. All other trademarks are property of their respective owners.
11
SIP Peer : Set NBS SIP Port
© Copyright 9/20/2012. XO Communications, LLC. All rights reserved. XO, the XO design logo, and all related
marks are trademarks of XO Communications, LLC. All other trademarks are property of their respective owners.
12
Music On Hold:
Analog Gateway :
© Copyright 9/20/2012. XO Communications, LLC. All rights reserved. XO, the XO design logo, and all related
marks are trademarks of XO Communications, LLC. All other trademarks are property of their respective owners.
13
Voice Mail -
© Copyright 9/20/2012. XO Communications, LLC. All rights reserved. XO, the XO design logo, and all related
marks are trademarks of XO Communications, LLC. All other trademarks are property of their respective owners.
14
Auto Attendant -
© Copyright 9/20/2012. XO Communications, LLC. All rights reserved. XO, the XO design logo, and all related
marks are trademarks of XO Communications, LLC. All other trademarks are property of their respective owners.
15
Call Center :
© Copyright 9/20/2012. XO Communications, LLC. All rights reserved. XO, the XO design logo, and all related
marks are trademarks of XO Communications, LLC. All other trademarks are property of their respective owners.
16
© Copyright 9/20/2012. XO Communications, LLC. All rights reserved. XO, the XO design logo, and all related
marks are trademarks of XO Communications, LLC. All other trademarks are property of their respective owners.
17
© Copyright 9/20/2012. XO Communications, LLC. All rights reserved. XO, the XO design logo, and all related
marks are trademarks of XO Communications, LLC. All other trademarks are property of their respective owners.
18
© Copyright 9/20/2012. XO Communications, LLC. All rights reserved. XO, the XO design logo, and all related
marks are trademarks of XO Communications, LLC. All other trademarks are property of their respective owners.
19
Extension Status :
Software Version :
