Status of the Tracker DB System
Tk week april 03
D. Contardo
Developments
Applications
New Developments
BigBrowser :
- Normal correction of bugs
- Introduction of a repair scheme
Data Base :
- Change from Oracle 8i to Oracle 9
- Introduction of final description of hybrids and modules
(still a small correction to be made to the module description
but components can be introduced)
- Introduction of final description of AOH components and tables
- Introduction of full TOB structure ready to be implemented
(to be done for TIB and TEC)
NEW BB RELEASE NEXT WEEK
Applications
- Sensors :
Work on sampling validation scheme in progress
Coherence of data still under check
- Hybrids :
Registration of the components at the factory ready and tested
to be moved to the company and included to FHIT test program
XML calibration files to be finalized
On going discussion on keeping track of APV wafers and including
the DCU number in the data
WEB interface foreseen, common scheme with sensor and gantry
- Gantry :
Implementation ready and tested
Procedure at gantry defined
Specific WEB query interface ready
To be discussed the hybrid test data ?
- Bonding :
Implementation for modules ready
Implementation for hybrids in progress (very similar to modules)
Applications
- Modules :
Final calibration tables implemented
XML calibration files insertion tested for ARC read-out
Situation for LT to be checked
WEB interface foreseen, common scheme with sensor and gantry
- Digital Optohybrids :
Application ready (powerful scheme to automatically collect the
data taken at the production factory)
request of a file loading command line
- Other Optical devices :
Request to implement these components,
needs investigation to be compatible with a link type description
(connectivity)
Conclusion
Central Data Base should be used for modules currently produced
(sensors and hybrids are registered in the Prod DB)
train in test db with registration, assembly and transfer panels
DB tutorial and news at http://cmsdoc.cern.ch/~cmstrkdb
