How to get credit for this activity
First, sign-in at the computer and sign-out when the activity is complete. Show your work and results to a PLC tutor so they can check your work and initial the signoff sheet. Be prepared to answer questions about the activity or your results.
Get five 10k Ω resistors, a circuit board and a Digital Multimeter (DMM). a. Measure and record the individual resistance of all 10k Ω resistors using a DMM. b. Draw diagrams showing how you could arrange 3 of these 5 resistors so that their equivalent theoretical resistance is

Three resistors in series

Three resistors in parallel

One resistor in series with two in parallel

One resistor in parallel with two in series c. Using a DMM, measure the equivalent resistance and compare the predicted and measured values using a percent difference. How do they compare? d. Using two additional 10k Ω resistors predict and measure the equivalent resistance
R eq
of the following circuit. How do they compare?
