AN ABSTRACT OF THE THESIS OF
Matthew W. Loewen for the degree of Master of Science in Geology presented on June 3,
2011.
Title: Analysis of Semi-Volatile Trace Metals in Basaltic Glass by LA-ICP-MS.
Abstract approved:
Adam J.R. Kent
Semi-volatile trace metals (e.g., Cd, Sn, Pb, Zn, Cu, Mo) have been analyzed by
using laser ablation ICP-MS in a number of silicate glasses (GSE-1G, GSD-1G, NIST
610, NIST 612, BCR-2G, BHVO-2G). Our work investigates and highlights sources of
uncertainty in the analysis of semi-volatile metals using LA-ICP-MS. We identify withincell transport fractionation as a primary source of uncertainty in these analyses. We found
no evidence for significant fractionation of elements on the basis of volatility over typical
45 second ablation intervals. However, systematic fractionation of up to 20% was found
for a number of siderophile and chalcophile trace elements as well as volatile lithophile
elements when comparing analyses from different locations with a simple single-volume
ablation chamber. Some fractionation was also observed for analyses in GSE-1G that
intersected fractures or cracks in the glass, although overall GSE-1G appears to be
homogeneous with respect to semi-volatile element distributions at the ~10 % level.
Calibration using GSE-1G produces more accurate results on basaltic glass compositions
than NIST 610. This work thus confirms the suitability of GSE-1G as a calibration
standard for analysis of semi-volatile metals in mafic composition glasses.
This thesis also reports major and trace element data for glass, olivine, and
olivine-hosted melt inclusions from the 1959 eruption of Kilauea Iki, Hawaii. Major
element compositions of glasses match the results of earlier studies and suggest that
dominant fractionation of olivine + Cr-spinel and secondary mixing between two magma
batches control compositional variations. Melt inclusions trap melts with high sulfur
concentrations (~0.1-0.15 wt.%) suggestive of a melt at or near sulfide saturation, while
matrix glass is highly degassed. Lithophile trace element variations more clearly illustrate
the effects of mixing at a late stage of magmatic development, and require magmas with
two distinct mantle source regions and/or different degrees of partial melt. A number of
non-traditional volatile trace elements were also analyzed including those with a range of
volatility and geochemical affinity. Of these, most (e.g., Sn, Mo, Pb) display typical
incompatible behavior while others appear to be compatible in known phases (primarily
olivine: Zn, Co). Copper concentrations cannot be explained by removal of major
phenocryst phases. Scatter in Cu concentrations could be achieved by either variable
volatile mobility at depth or removal with a Cu-sulfide phase (either fractionated or
residual). Previous studies of rare sulfides present in the 1959 eruption and more
abundant sulfides crystallized in the lava lake suggest high Cu (>40 wt.%) in the sulfides.
In this case even removal of a small amount of sulfide (<<1% by volume) could strongly
deplete the melt of Cu while having little affect on other metals since their presence was
not observed in the sulfides. There is no evidence for loss of volatile or semi-volatile
trace metals during subaerial degassing.
