Data Sheet M&EG210EN
New: G210 Series
VersalonTM High Pressure Filters
Features
•Flows to 50 L/min (13 US gpm)
• Pressures to 250 bar (3625 psi)
• Port size 1/2”, 5/8” and M22
• Out-to-in filter element flow path
Notes and Specifications
Filter Housing
• Maximum Allowable Working Pressure:
250 bar (3625 psi)
• Temperature Range:
Fluorocarbon Seals:
-29 ºC to 120 ºC (-20 ºF to 250 ºF)
50 ºC (122 ºF) maximum in HWCF
or water glycol fluids
Pressure Drop Information
Housing pressure drop using fluid with 0.9 S.G.
Housing pressure drop is directly proportional
to specific gravity.
Flow (US gpm)
0
• Materials of Construction:
Head: SG Iron
Bowl: Carbon steel
4
6
8
10
12
14
12
0.8
10
0.6
8
6
0.4
4
• Bypass Valve Settings:
4.5 ± 0.5 bard (65 ± 7 psid)
• Indicator Pressure Settings:
3.4 ± 0.4 bard (50 ± 6 psid)
2
ΔP (psid)
• Fluid Compatibility:
Compatible with all petroleum oils, water glycols,
water-oil emulsions and most synthetic hydraulic
and lubrication fluids
G210 Series filter housing
ΔP (bard)
• Rated Fatigue Pressure:
0-240 bar (0-3480 psi) per NFPA T2.06.01R2-2001
CAT C/90/*(1 million cycles), verified by testing at
0-280 bar (0-4060 psi) for 1 million cycles. Contact Pall
for applications with higher pressures at lower cycles
0.2
2
0
10
20
30
40
50
Flow (L/min)
HCG200 Filter Elements – bard/1000 L/min (psid/US gpm)
Length Code
04
KN
9.35
(0.51)
KS
6.41
(0.35)
KD
4.94
(0.27)
KT
3.92
(0.21)
4.90
(0.27)
3.33
(0.18)
2.56
(0.14)
2.04
(0.11)
Filter Element
08
• Filter Element Burst Pressure:
10 bard (145 psid)
Multiply actual flow rate times factor in table above to determine
pressure drop with fluid at 32 cSt (150 SUS), 0.9 S.G. Correct for
other fluids by multiplying new viscosity in cSt/32 (SUS/150) x new
S.G./0.9. Note: factors are per 1000 L/min and per 1 US gpm.
• Filter Element Construction: Inorganic fibers
impregnated and bonded with epoxy resins.
Polyamide endcaps. Corrosion protected carbon steel
core
Sample ∆P calculation
G210 Series 8” length housing with M22 ports using KN grade media.
Operating conditions 50 L/min (13 US gpm) flow rate using a hydraulic
fluid at 45 cSt and specific gravity (s.g.) 1.2.
Total Filter ∆P
= ∆P housing + ∆P element
= (0.55 x 1.2/0.9) bard (housing)
+ ((50 X 4.9/1000) X 45/32 X 1.2/0.9) bard (element)
= 0.73 bard (housing) + 0.46 bard (element)
= 1.19 bard (17.3 psid)
Dimensional Drawings
45 mm
1.77 in
45 mm
1.77 in
Table 1: Housing Port Style Options
Code
Port Style
A
M
C
Straight threads & 0-Ring boss to SAE J1926
Metric threads to BS3643
BSP threads to ISO228
Table 2: Housing Port Sizes Options
46.2 - 44.8 mm
1.82 - 1.76 in
Code
Port Size
Styles Available
08
10
22
Nominally 1/2”
Nominally 5/8”
M22x1.5-6H THD
‘C’
‘A’
‘M’
Table 3: Filter Element Options
A
81 mm
3.19 in
Outlet
58.5 mm
2.30 in
Inlet
30.3 mm
1.19 in
‘H’ Dim.
(Table 6)
60.6 mm
2.39 in
27.5 mm 25 mm
1.08 in 0.98 in
3x mounting holes
12 MIN full thread
for ‘A’ ports
3/8” - 16 UNC-2B
to BS1580 for
C, M & P ports
M10x 1.5-6H to
BS3643
Code
ßx(c) ≥1000 based on ISO 16889
KN
KS
KD
KT
7
12
19
22
Table 4: Length Options
O-ring and anti Ø82 mm
extrusion ring
3.23 in
85 mm
3.35 in
max
Housing Code
Element Code
‘L’ Dim*
R
S
4
8
100.2 mm (3.95 in)
192.9 mm (7.59 in)
* Nominal length
‘L’ Dimenssion
Table 5: Differential Pressure Indicator Options
Code
Indicator
‘H’ Dim.
0
Unmachined indicator port
Machined port with plastic shipping plug
Indicator must be installed prior to operation.
Only available to distributors
Bleed plug and seal in place of indicator
Electrical switch - normally closed, automatic reset
Connection: Deutsch DT042P
Visual indicator, window changes from white to red
on indication. Automatic reset
Electrical switch - normally closed, automatic reset
Connection: AMP junior timer connector
-
1
B
150 mm (5.9 in)
approx. required for
element removal
C
A
Section View A - A
Ø82 mm
2.68 in
D
U
16
74
36
67
Ordering Information
Housing P/N:
HZG210 Table 1 Table 2 Table 3 Table 4 G
Element P/N: HCG200F
Table 5
X160
Table 3 Table 4
Z
Seal P/N: G200SKZ
