CPIT 201: Introduction to Computing
CH4: Operations on Bits
Assignment
((NO hand out))
QUESTION 1 (7 points)
Mark each of the following sentences with True () or False ().
((Showing your work))
a.
b.
c.
d.
e.
f.
g.
NOT (F9)16 = (16)16
(10001010)2 OR (00101011)16 = (10111011)2
[ NOT(AE)16 ] AND (0A)16 (0)16
NOT [(16)16 OR (30)16] = (40)10
[(99)16 AND (33)16] OR [(00)16 AND (FF)16] = (7)16
(71)8 OR (55)8 AND [ (71)8 OR (23)8 ] = (90)8
(00111100)2 XOR [ NOT(11100111)2 ] = (00111100)2
(
(
(
(
(
(
(
QUESTION 2 (5 points)
Construct the mask and choose the appropriate binary logical
operator to execute the following
a. Unset the four leftmost bits of (01100111)2
b. Set the two rightmost bits of (00100001)2
c. Flip the three leftmost and the two rightmost bits of
(01100111)2
d. Set the forth bit (count from right to left) of (01100111 )2
e. Extract the fourth and fifth bits (count from right to left) of
the unsigned integer (44)10
3.Nov.2009
15-AlQeadahl-1430
)
)
)
)
)
)
)
CPIT 201: Introduction to Computing
CH4: Operations on Bits
Assignment
((NO hand out))
QUESTION 3 (4 points)
Using an 8-bits allocation, represent each decimal number in the
mentioned representation. Then, calculate the following
operations (convert the final result to decimal)
a.
b.
c.
d.
(33)10 + (25) 10
(-13) 10 – (6) 10
(13) 10 + (-6) 10
(10) 10 – (20) 10
Two’s Complement
Sign and Magnitude
Sign and Magnitude
Two’s Complement
QUESTION 4 (6 points)
Show the results of the following shift operations
a.
b.
c.
d.
e.
f.
Arithmetic right shift on (01100110) 2 “Evaluate your result”
Circular right shift on (01000111)2
Arithmetic left shift on (10000010) 2 “Evaluate your result”
Logical left shift on (00101111) 2
Arithmetic left shift on (01100110) 2 “Evaluate your result”
Arithmetic right shift on (10010000) 2 “Evaluate your result”
NOTE that :
 the Arithmetic shift operations assume that the bit pattern is
a signed integer in two’s complement format
 the Logical shift operations that the bit pattern is an
unsigned integer
3.Nov.2009
15-AlQeadahl-1430
