More advanced aspects
of search
Extensions of A*
Extensions of A*
Iterated deepening A*
Simplified Memory-bounded A*
Iterative-deepening A*
Memory problems with A*
 A* is similar to breadth-first:
Breadthfirst
d=1
d=2
d=3
d=4
Expand by depth-layers
A*
f1
f2
f3
f4
Expands by f-contours
 Here: 2 extensions of A* that improve memory
usage.
4
Iterative deepening A*
Depth-first
in each f- f1
contour
f2
f3
f4
 Perform depth-first
search LIMITED to
some f-bound.
 If goal found: ok.
 Else: increase de fbound and restart.
How to establish the f-bounds?
- initially: f(S)
generate all successors
record the minimal f(succ) > f(S)
Continue with minimal f(succ) instead of f(S)
5
Example:
f-limited, f-bound = 100
f-new = 120
S
f=100
A
f=120
D
f=140
B
f=130
G
f=125
C
f=120
E
f=140
F
f=125
6
Example:
f-limited, f-bound = 120
f-new = 125
S
f=100
A
f=120
D
f=140
B
f=130
G
f=125
C
f=120
E
f=140
F
f=125
7
Example:
f-limited, f-bound = 125
S
f=100
A
f=120
D
f=140
B
f=130
G
f=125
C
f=120
E
f=140
F
f=125
SUCCESS
8
f-limited search:
1. QUEUE <-- path only containing the root;
f-bound <-- <some natural number>;
f-new <-- 
2. WHILE QUEUE is not empty AND goal is not reached
DO remove the first path from the QUEUE;
create new paths (to all children);
reject the new paths with loops;
add the new paths with f(path)  f-bound
to front of QUEUE;
f-new <-- minimum of current f-new and
of the minimum of new f-values which are
larger than f-bound
3. IF goal reached THEN success; ELSE report f-new ;
9
Iterative deepening A*:
1. f-bound <-- f(S)
2. WHILE
DO
goal is not reached
perform f-limited search;
f-bound <-- f-new
10
Properties of IDA*
 Complete and optimal:
 under the same conditions as for A*
 Memory:
Let  be the minimal cost of an arc:
== O( b* (cost(B) /) )
 Speed:
 depends very strongly on the number of f-contours
there are !!
 In the worst case: f(p)  f(q) for every 2 paths:
 1 + 2 + ….+ N = O(N2)
11
Why is this optimal,
even without monotonicity ??
 In absence of Monotonicity:
 we can have search spaces like:
S 100
120
150
C
A
B
D
90
E
60
120
F
140
 If f can decrease,
 how can we be sure that the first goal reached is
the optimal one ???
12
Properties: practical
 If there are only a reduced number of different
contours:
 IDA* is one of the very best optimal search
techniques !
 Example: the 8-puzzle
 But: also for MANY other practical problems
 Else, the gain of the extended f-contour is not
sufficient to compensate recalculating the previous
 In such cases:
 increase f-bound by a fixed number  at each
iteration:
 effects: less re-computations, BUT: optimality is
lost: obtained solution can deviate up to 
13
Simplified Memory-bounded A*
Simplified Memory-bounded A*
 Fairly complex algorithm.
 Optimizes A* to work within reduced memory.
 Key idea:
(15) 13
15
A
S
B
13
C 18
memory of 3 nodes only
 If memory is full and we
need to generate an extra
node (C):
 Remove the highest fvalue leaf from QUEUE
(A).
 Remember the f-value of
the best ‘forgotten’ child
in each parent node (15 in
S).
15
Generate children 1 by 1
13
A
 When expanding a node
(S), only add its children 1
at a time to QUEUE.
S
B
First add A, later B
 we use left-to-right
 Avoids memory overflow
and allows monitoring of
whether we need to delete
another node
16
Too long path: give up
13
S
B

13
 If extending a node would
produce a path longer than
memory: give up on this
path (C).
 Set the f-value of the
node (C) to 
18 C
D
memory of 3 nodes only
(to remember that we
can’t find a path here)
17
Adjust f-values
15 13
15
A
S
B
24
better estimate for f(S)
 If all children M of a node
N have been explored and
for all M:
 f(S...M)  f(S...N)
 then reset:
 f(S…N) = min { f(S…M) |
M child of N}
 A path through N needs
to go through 1 of its
children !
18
SMA*: an example:
10
0+12=12
S
8
8+5=13
10+5=15
A
B
8
16
10
10
20+5=25 C
G1 20+0=20 D 16+2=18
G2 24+0=24
8
10
10
8
30+5=35 E
G3 30+0=30 24+0=24 G4
F 24+5=29
12
12
S
12 13
S
A
15
13 (15)
S
A
15
B
S
13
A
B
15
D 18
13

19
Example: continued
13 (15)
S
B
D
10
8+5=13
10+5=15
A
B
13
8
16
10
10
20+5=25 C
G1 20+0=20 D 16+2=18 G2 24+0=24
8
10
10
8
30+5=35 E
G3 30+0=30 24+0=24 G4
F 24+5=29
15 13 (15)
15 (15)
S
24 ()
D
0+12=12
S
8
B 13
G2
24
15 (24)
S
15
A
B
() 24
G2
24
S
15
B
A
C 25

24
20 15
15 (24)
S
20 A
15
C
()
G1 20
20
SMA*: properties:
 Complete: If available memory allows to store the
shortest path.
 Optimal: If available memory allows to store the
best path.
 Otherwise: returns the best path that fits in
memory.
 Memory: Uses whatever memory available.
 Speed:
If enough memory to store entire tree:
same as A*
21
