AGITATOR SPECIFICATION SHEET IDENTIFICATION Mixing Tank FUNCTION Mix 50% NaOH solution and Water to produce 40% NaOH solution. OPERATION Batch TYPE and SIZING Orientation Vertical Internal Diameter Height Head Type 0.823 m Fluid Name 0.823 m 2:1 Elliptical CONDITIONS Sodium Hydroxide Solution Specific Gravity Density Volume of Tank Operating Temperature N/A 1430 kg/m3 0.437 m3 25 C ĚŠ Operating Pressure 1 atm w=0.055 m J=0.0685 m L=0.069 m Baffle Baffle d=0.27 m E=0.27 m D = 0.823 m h=0.823 m
