STATIC OF RIGID BODIES
STATIC OF RIGID BODIES
Problem Set #2
Equilibrium Force System
1. Compute for the total reaction at A and B on the truss shown in Fig. 1. Force P is
perpendicular to the inclined member
2. Determine the reaction at A and B of the beam loaded with a concentrated and a
distributed as shown in Fig.2
3. A boom AB is supported in a horizontal position by a hinge A & a cable which runs
from C over a small pulley at D and carries a block with a mass of 250 kg as shown
in Fig. 3. Compute the total reaction at A.
27
Engr. Kim Q. Marañon
STATIC OF RIGID BODIES
4. Compute for the total reaction at A and B on the truss shown in Fig. 4.
5. The beam CD is supported by a roller support at D and C, the roller C rest on top
another beam AB, and it is supported by a hinge at A and a roller at B. Compute for
the total reactions on each supports.
28
Engr. Kim Q. Marañon
