P2002 JF 2012 PRICE LIST
EQUIPMENT
CATORS
ICATOR
G
ed from Stick)
H ON/OFF
P2002-JF STANDARD EQUIPMENT
CS LSA
FLIGHT INSTRUMENTS and INDICATORS
MAGNETIC COMPASS
DYNON PACKAGE SV-D1000 TWO SCREEN
SV-D1000
ADAHRS PRIMARY
SV-D1000
ADAHRS BACK UP
ENGINE MODULE
GPS RECEIVER
BACK UP BATTERY
Airspeed Ind. And Altimeter 2-1/4 Inch back up NON TSO
ROTAX SENSOR
• Amps (Ammeter Shunt or Hall Effect)
• Monitor CHT
• Aircraft bus voltages
• Oil temperature
• OAT
• Oil pressure
• Manifold pressure (ONLY WITH VARIABLE PITCH PROPO)
• Fuel pressure
• RPM
• Fuel quantity (capacitive and resistive measurements)
• Trim Indicator
• Flap position
OTHER INSTRUMENTS / WARNING
GENERATOR WARNING LIGHT
FLIGHT CONTROLS
HYDRAULIC BRAKES
PARKING BRAKE
ELECTRICAL FLAPS
DUAL FLIGHT CONTROLS
STEERABLE NOSE WHEEL
STABILATOR TRIM (Electric actuated from Stick)
ENGINE CONTROLS
_ THROTTLE, TWO
FLIGHT TRIM CONTROLS
_ STABILATOR with INDICATOR
FUEL CONTROL SELECTOR WITH ON/OFF
PANEL SWITCHES:
_ STARTER
_ FUEL PUMP
_ ENGINE LH and RH IGNITION SWITCHES
WITCHES
EPTABLE
ELECTRICAL SYSTEM
12 VOLT 18A AMP. BATTERY
14 VOLT ALTERNATOR 16A AMP.
14 VOLT ALTERNATOR-30A AMP.
SWITCHES
Nav. Lights
_Landing Light
_Strobe Light
CIRCUIT BREAKER PANEL
WITH 100 LITRES
CTRIC
ss, All Seats
NG, All structure
d key
ELAND
place
place
AGE
LER
HP, 4 Cylinders
ction gear
UNT
de fix
ual Control
FUEL SYSTEM
TWO INTEGRAL FUEL TANKS WITH 100 LITRES
TOTAL CAPACITY
AUXILIARY FUEL PUMPS, TWO ELECTRIC
FUEL QUICK DRAIN
INTERIOR
PILOT and COPILOT SEATS
_ Adjustable Fore and Aft
SEAT BELTS & Shoulder Harness, All Seats
WALL TO WALL CARPETING
LUGGAGE COMPARTMENTS
FIRE EXTINGUISHER
RADIO CALL PLATE
SOUNDPROOFING
FIRST AID KIT
EXTERIOR
EPOXY CORROSION PROOFING, All structure
SLIDING CANOPY with lock and key
REAR WINDOW
TIE DOWN RINGS
MAIN WHEELS, 5,00 X 5 MARC INGEGNO
NOSE WHEEL, 5,00 X 5
EXTERIOR LIGHTS
NAV. LIGHTS with strobe
TAXI LIGHT
CABIN CONFORT SYSTEM
WINDSHIELD DEFROSTER
VENTILATOR ADJUSTABLE, 2 place
HEATING SYSTEM
VENTILATOR ADJUSTABLE, 2 place
STANDARD AVIONICS PACKAGE
GARMIN SL 40 COM with Antenna and Inst.
TRANSPONDER SV-XPNDR-262 Mode S (Only for Sky View)
ELT ME406 ARTEX
Two Head Sets
Speakers
Microphone
POWERPLANT AND PROPELLER
ENGINE - ROTAX 912 IS 100 HP, 4 Cylinders
liquid/air cooled, integrated reduction gear
DUAL IGNITION SYSTEM
THROTTLE CONTROL LH/RH
TUBULAR STEEL ENGINE MOUNT
PROPELLER - GT 2 Blade fix
PROPELLER SPINNER
AIR FILTER
OIL FILTER
OIL AND WATER COOLERS
THERMOSTAT VALVE
ENTS
PRODUCT SUPPORT/DOCUMENTS
O YEAR LIMITED WARRANTY
MANUFACTURERS FULL TWO YEAR LIMITED WARRANTY
OK
PILOTS OPERATION HANDBOOK
MAINTENANCE MANUAL
PARTS CATALOG
AIRCRAFT LOG BOOK
ENGINE LOG BOOK
