Transformer solutions
across the grid
Distribution Transformers / Worldwide Support / Customer-Focused Operations / Reliable Performance / Committed to meeting every transformer need.
Everything is under (quality) control
Generating, distributing and controlling electricity requires proven
expertise, in-depth understanding, worldwide experience and a
commitment to customer responsiveness. That’s what you get
with Prolec GE.
Our products are developed, tested, deployed and continually
improved with a focus on delivering reliable, customer-focused
performance. And a key to that performance is a relentless
commitment to quality.
Our quality systems are based on solid fundamental processes.
Key elements of our Total Quality Model include:
These world-class quality systems ensure reliable, safe, durable,
and environmentally responsible products that meet real customer
needs. Enhancing these sound fundamentals with ongoing
research and development, global best practices, and continuous
process improvement gives you world-class performance in
every product and every procedure.
Our processes and products have been certified as meeting or
exceeding major international quality standards, including:
• ISO 9001 – 2000
• ISO 14001 – Environmental Certifications
• UL
TQM – Total Quality Management
TPS – Toyota Production System
Thanks to our dedication to quality, the entire Prolec GE line
performs precisely as promised. Helping you generate, distribute
and control electricity anywhere on the planet.
KDS – Knowledge Dispersion System
Tell us what you need, and we’ll deliver for you.
Six Sigma Tools
Better quality means better performance
“The one thing you never
get from Prolec GE is
surprises. They do what
they say they’ll do and their
products perform
as promised.”
Single-Phase
Pole-Type Transformers
Optional features & accessories
Prolec GE designs and manufactures a complete line
of single-phase pole-type distribution transformers for
installation on utility overhead systems. These highly
reliable transformers are available in a wide variety of
ratings and accessory combinations.
We utilize state-of-the-art technology in our design and
manufacturing systems, supported by our ISO-9001
certified processes and quality assurance programs, to
provide you with reliable and cost-effective transformer
products matched to your system requirements.
Standard features
• Broad selection of design efficiencies to meet
specific customer applications and new DOE
minimum requirements
• Automatic pressure relief valve
• High-voltage taps with external tank mounted
no load tap changer
• Dual high-voltage ratings (not available with taps)
• Connectors for grounding
• Stencils and labels according to customer requirements
• External tank mounted high-voltage lightning arrester
• Low-voltage circuit breaker with reset (and optional
overload signal light)
• Internal high-voltage expulsion fuse
• Under oil arrester
• External low-voltage surge arrester
• Interlaced secondary windings (through 50 kVA ratings)
• RUS compliant 1 bushing designs with double hanger
bracket configuration (through 50 kVA)
• Stainless steel tank, cover, clamping band
• Extra creep options for high-voltage bushings
• Variety of features available for wildlife protection
• Magnex™
Tests
• All transformers are tested in strict accordance with
the latest revision of applicable ANSI™, IEEE™,
NEMA, and RUS with test reports available by serial
number of the transformer
• Meets or exceeds current RUS, NEMA and ANSI
Standards C57.12.00, ANSI C57.12.20 as applicable
Routine tests are:
• Mild steel tank with welded lifting lugs and hanger
• Leak test
brackets for direct-to-pole mounting
• Polarity and phase relation
• Single piece clamped cover band meets cover
• Resistance
retention requirements of applicable ANSI standards
• No-load losses and excitation current
• Electrostatically applied polyester powder paint
• Load losses and impedance
system for superior corrosion protection
• Applied voltage
• High-voltage porcelain cover-mounted bushings
• Induced voltage
(wall mounted for units with high voltage 4160 or below) • Full wave impulse
• Tank wall mounted porcelain or polymer low-voltage
• Ratio test
bushings
• Tin-plated bronze terminals for connection to copper
or aluminum
• Low-voltage ground provisions
• Tank ground provision
• Insulated cover for wildlife protection
• Laser engraved aluminum nameplate
• Non-PCB insulating oil
• KVA rating on tank wall
• Arrester mounting nuts welded to tank
(single bushing designs)
• One HV bushing with tank ground strap for grounded
wye applications or two HV bushings for wye applications
• Recessed tank bottom
Porcelain
high-voltage bushings
(expulsion fuse internally
mounted in self-protected unit)
High-voltage
lightning arrester*
Oil fill plug
Cover band
Welded hanger brackets
Low-voltage
circuit breaker*
Lifting lugs
Low-voltage bushings
Ground
connector
Copper ground strap
De-energized operation
tap changer
Nameplate
* Accessories for
self-protected units
Popular configurations
Double hanger bracket one highvoltage bushing conventional unit.
Single hanger bracket two highvoltage bushings conventional unit.
Single hanger bracket one highvoltage bushing self protected unit.
Standard sizes and voltages
• kVA: 10, 15, 25, 37.5, 50, 75, 100, 167
• HV ratings: 4160GrdY/2400 to 34500GrdY/19920 or 2400 to 19920
(Dual voltages available)
• BIL: 60 kV to 150 kV
• LV ratings: 240/120 and 480/240
Please contact your GE sales representative for kVA
sizes and voltage ratings not listed.
For more information contact your local GE Sales Representative or visit our website at www.prolecge.com
Phone: Toll free 1 800-437-7653 (US & Canada) / +52 (81) 8030-2341 (Mexico) / Fax: +52 (81) 8030-2323 or 2325
1PHPTTR-0111-03
Single-Phase
Pad-Mounted Transformers
• Recessed tank bottom
• Electrostatically applied polyester powder paint system
with urethane top coat for superior corrosion protection
• Removable sill
Optional features & accessories
Prolec GE manufactures a complete line of single-phase
pad-mounted distribution transformers designed to provide
the features, performance and aesthetics needed
for modern underground residential applications.
We utilize state-of-the-art technology in our design and
manufacturing systems, supported by our ISO-9001
certified processes and quality assurance programs.
Standard features
• Meets or exceeds applicable ANSI, NEMA, and RUS
standards, including ANSI C57.12.00, C57.12.28 and
C57.12.38 (enclosure integrity and finishing systems)
• Crowned tank top to prevent water retention
• Removable flip-top hood opens 180° for easy access
with stainless steel hinge pins
• Externally clamped high-voltage bushing wells for
loop feed or radial feed operation
• Externally clamped low-voltage threaded stud
bushings
• Automatic relief device for internal pressures
• Penta-head security bolt with padlock provision
(Hexa-head bolt available)
• NEMA safety labels
• Externally clamped low-voltage bushings
• Tank ground provisions
• Laser engraved aluminum nameplate
• Oil fill/level top plug and bottom drain plug
• Broad selection of design efficiencies to meet
specific customer applications and new DOE
minimum requirements
• High-voltage no load tap changer
• Dual high-voltage ratings (not available with taps)
• Complete stainless steel tank and cabinet or combination
of components with mild steel and stainless steel
• High-voltage, load-break 2 positions or
sectionalizing switch
• Multiple fusing options and combinations, including
internal and external expulsion fuse in series with
isolation link or partial range current limiting fuse
• Low-voltage circuit breaker
• Under oil arrester
• Drain valve with sampling device
• Hold-down cleats
• Connectors for ground pads
• Stencils and labels according to customer needs
• Magnex™
(For optional accessories or features not listed above, please
contact your GE sales representative).
Tests
• All transformers are tested in strict accordance with
the latest revision of applicable ANSI™, IEEE™, NEMA,
and RUS with test reports available by serial number
of the transformer
Routine tests are:
• Polarity and phase relation
• Resistance
• No-load losses and excitation current
• Load losses and impedance
• Applied voltage
• Induced voltage
• Full wave impulse
• Ratio test
• Leak test
Lock mechanism
Flip-top hood
opens 180°
Laser engraved
nameplate
NEMA safety labels
Pressure relief valve
Externally accessible
expulsion fuse with drip cup
Fill plug
Parking stand for
elbow connectors
High-voltage bushing wells
Low-voltage threaded
stud bushings
Removable ground strap
Tank ground provisions
Drain plug
Padlock provision
Removable sill
Mini-Pad (ANSI Type II)
Prolec GE’s Mini-Pad transformers are designed for single-phase residential underground applications where aesthetics
and size are important. They meet all applicable ANSI Standard C57.12.38 Type II requirements for cross-cable
configuration. Transformers feature loop feed two bushing dead-front primary designs. Ratings are 10 kVA through
167 kVA single-phase, 34.5 kV GrdY and below. Standard voltage ratings as well as dual voltages are offered.
Maxi-Pad (ANSI Type I)
Prolec GE’s Maxi-Pad transformers offer the same tamper-resistant features and accessibility as the Mini-Pad
transformer while allowing straight cable configuration with only a small increase in height. The Maxi-Pad is available
in 10 kVA through 167 kVA with the same broad range of voltages and optional accessories as the Mini-Pad.
This product meets ANSI Standard C57.12.38 Type I requirements.
Standard sizes and voltages
• kVA: 10, 15, 25, 37.5, 50, 75, 100, 167
• HV ratings: 4160GrdY/2400 to 34500GrdY/19920 or 2400 to 19920
(Dual voltages available)
• BIL: 60 kV to 150 kV
• LV ratings: 240/120 and 480/240
Please contact your GE sales representative for kVA
sizes and voltage ratings not listed.
Standards and certifications available
For more information contact your local GE Sales Representative or visit our website at www.prolecge.com
Phone: Toll free 1 800-437-7653 (US & Canada) / +52 (81) 8030-2341 (Mexico) / Fax: +52 (81) 8030-2323 or 2325
1PPMTR-1011-03
Three-Phase
Pad-Mounted Transformers
• Designed, manufactured and tested in accordance
with the latest ANSI standards
Optional features & accessories
High-grade materials, combined with sophisticated
engineering design systems, are key elements of a
transformer that will deliver years of highly reliable service.
• Broad selection of design efficiencies to meet specific
customer applications and the new DOE efficiency
requirements
• 50 Hz
• Type II insulating mineral oil
• High-fire point fluid, such as silicone, hydrocarbon or
vegetable fluids
• 55° and 55°/65° C average winding rise
• Copper and aluminum windings available
• Dual high-voltage ratings
• Internal expulsion fuses
• Current limiting fuses
• Internal oil-immersed partial range current-limiting
fuses
• Bayonet fuse holders with and without flapper
• Non-loadbreak and loadbreak dry-well fuseholders
• Internal oil switch (radial or loop)
• Under oil internal arresters
• Low-voltage molded-case circuit breaker
• Seismic Zone III and IV
• Stainless steel tank and cabinet construction
• Special colors
• RUS accepted
• Compliance with Canadian Standards
(CSA)
• Flip-top cabinet
Standard features
Tests
•
•
•
•
•
•
•
•
Each transformer receives all standard commercial tests
in accordance with ANSI C57.12.90 (latest revision), with
test reports available by serial number of the transformer.
Prolec GE offers a complete line of liquid-filled ThreePhase Pad-Mounted distribution transformers that meet
applicable ANSI™/IEEE™ standards.
With high voltages up to 34.5 kV and ratings up to 5,000
kVA (ONAN), Prolec GE compartmental-type Three
Phase Pad-Mounted Commercial Transformers are
designed for outdoor installation on a concrete pad and
provide underground power distribution to commercial,
industrial and institutional loads.
•
•
•
•
•
•
•
•
•
•
60 Hz operation
65° C average winding rise
Radial & loop feed arrangements
Dead and live front type of HV terminals
HV BIL 45 – 150 kV (Dead Front) 200 kV (Live Front)
LV BIL 30 – 60 kV
Three-point latching of low-voltage door
High-voltage door, which can be opened only after
the low-voltage door is opened
Rigid steel partition
Transformer tank welded from cover to base
Permanent nameplate
One-inch NPT pipe cap filling provision
ANSI tank ground pads
One-inch drain valve and sampler
Automatic pressure-relief valve (35 SCFM)
Tap changer with (2) 2.5% full capacity taps above
and below nominal
One 10”x18” (or 14”x25”) hand hole in transformer
tank cover
Painted olive-green color (Munsell 7GY 3.29/1.5)
• Resistance tests of all windings
• Ratio tests on the rated voltage
and all tap connections
• Polarity and phase relation tests
at rated voltage
• No load loss at rated voltage
• Exciting current at rated voltage
• Impedance and load losses
• Applied voltage test
• Induced voltage test
• Full-wave impulse test
• Mechanical leak test
ANSI is a registered trademark of American National
Standards Institute, Incorporated.
IEEE is a registered trademark of the Institute of Electrical
Electronics Engineers, Inc.
Standard voltages
Standard ratings
Standard Primary
Voltage Ratings
Minimum BIL (kV)
2400
4160
4800
7200
7620
12000
12470
13200
13800
16340
45
60
60
75
75
95
95
95
95
95
Grounded Wye
4160GrdY/2400
12470GrdY/7200
13200GrdY/7620
13800GrdY/7970
22860GrdY/13200
23900GrdY/13800
24940GrdY/14400
34500GrdY/19920
65
95
95
95
125
125
125
150
Standard kVA Ratings
45
225
1000
75
300
1500
500
2000
Delta or Wye 112.5
150
750
2500
Overall typical dimensions for reference
kVA
Height
Width
Depth
Typ Weight
(Lb)
Typ Gal
Oil
75
112.5
150
225
300
500
750
1000
1500
2000
2500
64
64
64
66
67
68
75
78
82
86
87
46
46
47
50
53
62
72
75
82
85
88
65
65
65
67
68
70
72
75
83
89
96
2,512
2,729
2,895
3,499
3,866
4,958
6,590
7,647
9,888
11,891
13,794
136
145
145
164
171
203
272
312
368
433
487
For kVAs not listed, contact factory.
Dimensions and weights are approximate and subject to change
without notice and should not be used for construction purposes.
Standards and certifications available
For more information contact your local GE Sales Representative or visit our website at www.prolecge.com
Phone: Toll free 1 800-437-7653 (US & Canada) / +52 (81) 8030-2341 (Mexico) / Fax: +52 (81) 8030-2323 or 2325
3PPMTR-0914-04
Flip-Top Cabinet
After discussions with numerous customers, Prolec GE
is now offering as an option a flip-top cabinet for commercial
transformers. Please note information below.
Design Overview
• Standard for 3-Phase Pad transformers from 45 kVA
to 2500 kVA
• Opening Angles: 45°, 110° (max)
Advantages
The new cabinet design has a cover that can be flipped
up, with the following benefits:
• Enhanced range of access to front-plate components
• Improved safety for O&M personnel
• Greater visibility, since the open cover allows more
sunlight in the cabinet area
• Shorter product height
Applicable Standards
• IEEE C57-12-00
• IEEE C57-12-28
• IEEE C57-12-34
For more information contact your local GE Sales Representative or visit our website at www.prolecge.com
Phone: Toll free 1 800-437-7653 (US & Canada) / +52 (81) 8030-2341 (Mexico) / +971 4 429 6101 (Middle East) Fax: +52 (81) 8030-2323 or 2325
FTTR-0914-02
Transformer Solutions
for Arc Flash Risks
Prolec GE has developed options for reducing arc flash
risks to personnel responsible for installation, operation
and maintenance routines during transformer operation.
Typically, in renewable applications, transformers are very
close to the generation point, which justifies precautionary
measures against an arc flash event. Our solutions focus
on the safety of personnel by offering several packages
for added protection.
Tamper-proof
pad lockable
enclosures for
externally-accessible
accessories
Typical Operation and Maintenance activities
performed on a transformer for renewable
applications:
• Switching transformers in and out of the collection circuit
• Routinely taking oil samples for dissolved gas analysis
testing
• Monitoring tank pressure and adding gas as needed
• Performing infrared temperature scans of the HV and
LV connections
Available packages
Package
Features
Value point
Basic
Accessories externally accessible with Provides a safe access
padlock provision
for O&M routines.
- Drain valves, liquid level, liquid
temperature and pressure vacuum
gauges, load break switch
Off-load
Molded circuit breakers installed in Minimize risk when
plexiglass barrier in LV compartment de-energizing
transformer from
IR Windows for thermo scanning
generation source.
Monitoring capabilities supported via Mitigate the hazard by
Monitoring accessories with contact switches, remote monitoring.
and SCADA digital communication
signals
Standards and certifications available
Low Voltage
Molded circuit
breaker installed in
a plexiglass barrier
For more information contact your local GE Sales Representative or visit our website at www.prolecge.com
Phone: Toll free 1 800-437-7653 (US & Canada) / +52 (81) 8030-2341 (Mexico) / +971 4 429 6101 (Middle East) Fax: +52 (81) 8030-2323 or 2325
AFTR-0112-01
Prolec GE Step Up Transformers
for Solar Energy Applications
Value Added
Concept
Features
Value point
Step Up
Increased margin for core over
excitation, withstanding high
magnetizing inrush currents
Prevent core saturation or
ferroresonance
Electronic
Protection
Network
Protection
Prolec GE has developed Step Up Transformers designed
specifically for Solar Power Generation applications.
Operational characteristics include thermal design for
higher ambient temperature ranges and core and coils
designed for step up application with an electrostatic
shield for protection against electrical noise coming from
the grid and the inverter. Various efficiency levels are
available to match project financial requirements, including
ultra-efficient amorphous metal cores.
Product scope / Standard features
• 700 kVA and 1000 kVA (See Table 1)
• High Voltage ratings: 12470 V, 24940 V & 34500 V
(See Table 2)
• Low voltage rating: 480Y/277 (See Table 2)
• HV connection: DELTA
• LV connection: Wye
• 60 Hz operation
• 65°C winding temperature rise
• HV tap changer for (2) 5% full capacity tape above and
below rated voltage
• Loop feed dead front HV terminals
• Cooling Class: ONAN
• % Impedance: 5.75% +/- 7.5%
• ANSI 70 Paint Finish
• Altitude of operation up to: 3300 ft
• Bayonet expulsion fuse plus partial range current-limiting
fuses
• Built to all applicable IEEE standards
* Solutions
for
Arc Flash
Electrostatic Shield
Accessories externally
accessible and monitoring
of the transformer
Provide a pathway to
ground for any residual
resonance
Prevent capacitive
coupling between the
grid and capacitive banks
of the inverter
Mitigate the hazard
during the performance
of the O&M routines
* Detailed information in PGE catalog: Transformer solutions for Arc Flash Risks.
Special / Optional features
•
•
•
•
•
•
•
•
•
•
•
•
•
•
From: 500 kVA to 2000 kVA
Other connections available
LV ratings: from 208 V to 600 V
HV BIL: from 95 kV to 200 kV*
LV BIL: from 30 kV to 60 kV
50 Hz operation
55°C winding temperature rise
Bayonet fuse holders with flappers
High fire point fluids, such as silicone, hydrocarbon or
vegetable fluids
Internal oil switch (radial or loop)
Under oil internal arresters
Seismic designs IBC Certified
Stainless steel tank and cabinet construction
Optional colors
* 200 kV BIL on Coil
Standards and certifications available
Table 1
Overall typical dimensions for reference
Table 2
Standard ratings
kVA
A*
Height
B*
Width
C*
Depth
WEIGHT
(lb)
Core
Material
kVA
HV Ratings
BIL
700
1000
700
1000
70
75
75
80
70
90
85
90
80
80
80
80
7,000
9,000
8,000
11,000
Silicon
Steel
Amorphous
Metal
700
1000
12470 DELTA
24940 DELTA
34500 DELTA
95
150
150
LV Ratings
480Y/277
* Dimensions in inches
** Dimensions and weight are approximate and subject to change
without notice and should not be used for construction purposes
*** Other ratings available upon request
For more information contact your local GE Sales Representative or visit our website at www.prolecge.com
Phone: Toll free 1 800-437-7653 (US & Canada) / +52 (81) 8030-2341 (Mexico) / +971 4 429 6101 (Middle East) Fax: +52 (81) 8030-2323 or 2325
SETR-0112-01
Substation
Transformers
Optional features & accessories
Prolec GE offers a complete line of liquidfilled
distribution transformers that meet current applicable
ANSI™ / IEEE™ standards.
With high voltages up to 34.5kV and ratings up to 15 MVA
(ONAN), Prolec GE primary and secondary substation
transformers are used in a wide range of utility, commercial
and industrial applications. High-grade materials, combined
with state of the art technology in our design and
manufacturing systems, are key elements of a transformer
that will deliver years of high reliability service.
Prolec GE Primary and Secondary Substation
Transformers meet all of your industrial applications
for electric distribution.
Standard features
• Insulating mineral oil
• 60 Hertz operation
• Externally operated de-energized tap changer with (2)
2.5% full capacity taps above and below nominal
• 65° C average winding rise
• Side-mounted bushings
• HV and LV flange connections
• Pressure-vacuum gauge
• Top filter press valve provision
• Liquid level gauge
• Liquid temperature gauge
• Pressure test valve
• ANSI grounding pad
• Drain / filter valve with sampling device
• Tank lifting lugs
• Corrosion resistant nameplate
• ANSI 61 paint finish, 5 mils thickness
• ANSI 70 paint finish, 5 mils thickness
• Hydran provision (above 7.5 MVA)
• High-fire point fluid, such as silicone, hydrocarbon or
vegetable fluids. (up to 10 MVA)
• 55° C 55/65° C average winding rise
• Forced air cooling
• Forced air cooling with 2 stages (from 7.5 MVA and up
to 15 MVA)
• Future fan wiring and control
• Removable radiators
• Pressure relief device
• Winding temperature device
• Sudden pressure relay with or without seal in
• Devices with alarm contacts
• Top filter press valve
• HV & LV air terminal compartments
• HV lightning arresters in ATC
• Current transformers
• Neutral grounding resistor
• Special impedances
• Low losses
• Special environment (i.e: classified areas)
• Special / low sound level
• 50 Hertz
• Seismic zone III and IV
• IBC/CBC certified product line up to 5 MVA
• Retrofit to specific dimensions
• Non-standard loading conditions such as harmonic
loading or specified K-factor
• Stainless steel removable radiators
• Galvanized steel removable radiators
• Special paint for marine ambient
• Special paint thickness
• Special colors
• CSA compliance
• Other special features upon request
Tests
Each transformer receives all standard commercial tests
in accordance with ANSI C57.12.90 (latest revision), with
test reports available by serial number of the transformer.
Routine tests include:
• Resistance tests of all windings
• Ratio tests on the rated voltage and all tap connections
• Polarity and phase relation tests at rated voltage
• No load loss at rated voltage
• Exciting current at rated voltage
• Impedance and load losses
• Applied voltage test
• Induced voltage test
• Full wave impulse test
ANSI is a registered trademark of American National
Standards Institute, Incorporated.
IEEE is a registered trademark of the Institute of Electrical
Electronics Engineers, Inc.
Pressure-relief device
Sudden-pressure relay
Lifting lugs
Fill plug
Vacuum
pressure gauge
Filter press
valve gauge
Winding
temperature gauge
Liquid-level gauge
Liquid
temperature gauge
Tap changer
Radiators
Nameplate
Drain valve
Control box
Overall typical dimensions for reference
Standard ratings (ONAN)
Oil Filled; 65˚C Rise; BIL 95 kV
Standard kVA Ratings
kVA
Height
Flange - Flange
Depth
Total Weight (Lb)
750
1000
1500
2000
2500
3000
3750
5000
7500
10000
12000
15000
90
90
95
95
95
100
105
105
120
130
130
130
50
60
60
65
65
70
70
75
80
80
85
130
60
70
75
75
80
90
90
95
110
135
135
155
6,400
7,300
9,500
11,400
13,100
15,800
18,200
22,000
29,000
32,800
38,200
70,000
225
300
500
750
1000
1500
2000
2500
3750
5000
7500
10000
12000
15000
Standard voltages (V)
Standard Primary Voltage Ratings
* 2400
4160
4800
6900
7200
12000
12470
13200
13800
23000
34500
Other
Standard Secondary Voltage Ratings
kVA
750
1000
1500
2000
2500
3000
3750
5000
7500
10000
12000
High Fire Point Fluid; 65˚C; BIL 95 kV
Depth Total Weight (Lb)
Height
Flange - Flange
85
85
85
90
95
100
100
100
110
115
125
55
60
60
65
70
70
75
80
80
90
95
60
75
85
85
90
95
95
105
125
135
135
6,300
7,400
9,500
11,900
13,400
15,700
18,300
22,100
30,400
33,000
35,700
* 208Y
* 240
480
600
2400
4160Y
4800
12000
12470
13200
13800
Other
Standards and certifications available
For kVAs not listed, contact factory. Dimensions and weights are
approximate and subject to change without notice and should not
be used for construction purposes.
For more information contact your local GE Sales Representative or visit our website at www.prolecge.com
Phone: Toll free 1 800-437-7653 (US & Canada) / +52 (81) 8030-2341 (Mexico) / Fax: +52 (81) 8030-2323 or 2325
SBTR-1011-02
Substation Transformers
up to 69 kV
•
•
•
•
•
•
•
Corrosion resistant nameplate
ANSI 61 paint finish, 5 mils thickness
ANSI 70 paint finish, 5 mils thickness
Hydran Provision
Removable radiators
60 Hertz operation
65° C average winding rise
Optional features & accessories
Prolec GE offers a complete line of liquid-filled distribution
transformers that meet current applicable ANSI™ / IEEE™
standards.
In addition to the already existing Substation Transformers
product line Prolec GE now offers its brand new
transformers, with high voltages from 34.5 kv to 69 kV
and ranging from 5 MVA to 12 MVA (ONAN). These type
of transformers are used in a wide range of utility, and
industrial applications. High-grade materials, combined
with state of the art technology in our design and
manufacturing systems, are key elements of a transformer
that will deliver years of high reliability service.
Prolec GE Substation Transformers meet all of your
industrial applications for electric distribution.
Standard features
• Insulating mineral oil
• Externally operated de-energized tap changer with (2)
2.5% full capacity taps above and below nominal
• High voltage cover-mounted bushings
• Low voltage cover and side-mounted bushings
• Pressure-vacuum gauge
• Top filter press valve provision
• Liquid level gauge
• Liquid temperature gauge
• Winding temperature device
• Pressure relief device
• Pressure test valve
• ANSI grounding pad
• Drain / filter valve with sampling device
• Tank lifting lugs
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Forced air cooling
Future fan wiring and control
Winding temperature device (additional)
Sudden pressure relay with or without seal in
Devices with alarm contacts
Top filter press valve
Low voltage flange connections
Low Voltage air terminal compartments
Current transformers (additional)
Neutral grounding resistor
Special impedances and low losses
Special environment (i.e: classified areas)
Special/Low sound level
50 Hertz
Seismic zone III and IV and IBC
Stainless and galvanized steel removable radiators
Special paint for marine environment
Special colors and paint thickness
CSA compliance
Other special features upon request
55° C, 55/65° C average winding rise
Tests
Each transformer receives all standard commercial tests
in accordance with ANSI C57.12.90 (latest revision), with
test reports available by serial number of the transformer.
Routine tests include:
•
•
•
•
•
•
•
•
•
Resistance tests of all windings
Ratio test on all tap positions
Polarity and phase relation tests at rated voltage
No load loss at rated voltage
Exciting current at rated voltage
Impedance and load losses
Applied voltage test
Induced voltage test
Full wave impulse test
ANSI is a registered trademark of American National Standards Institute,
Incorporated.
IEEE is a registered trademark of the Institute of Electrical Electronics
Engineers, Inc.
High voltage bushings
Current transformers
connection
Pressure relief device
Low voltage bushings
Lifting lugs
Winding temperature
gauge
Liquid temperature
gauge
Fill valve
Control box
Ground connection
Drain valve
Overall dimensions for reference
Weight (Lbs.) Volume (Gallons) and Dimensions (Inches)
kVA
Height
Large
Depth
Oil
Weight
5000
7500
10000
12000
154
158
167
164
180
175
263
263
150
185
157
177
2,400
2,800
3,200
3,200
48,000
60,000
74,000
77,000
Standard Primary
Voltage Ratings, kV
Standard Secondary
Voltage Ratings
46
69
4160 Y / 2400 V
12470 Y / 7200 V
13200 Y / 7620 V
13800 Y / 7960 V
23000 Y / 13280 V
For kVAs not listed, contact factory.
Dimensions and weights are approximate and subject to change
without notice and should not be used for construction purposes.
Standard kVA
Ratings
5000
7500
10000
12000
Liquid filled impulse ratings
Nominal System
Standard BIL, kV
Voltage, kV
46
69
250
350
For more information contact your local GE Sales Representative or visit our website at www.prolecge.com
Phone: Toll free 1 800-437-7653 (US & Canada) / +52 (81) 8030-2341 (Mexico) / Fax: +52 (81) 8030-2323 or 2325
SPSTTR-0409-01
The people and philosophy behind the products
At Prolec GE, we’re proud of the dedication, integrity, skill and resourcefulness of our people. We carefully recruit, train, develop
and promote only motivated, customer-focused professionals to power our operations. These outstanding individuals act as a team
to help ensure our customers receive the products, service and support they need to thrive.
Technology development
Research and development is serious business at
Prolec GE. Our Applied Technology Center boasts
more than 80 engineers and specialists developing
multi-generational product plans, design platforms,
and continuous improvement processes. Their expertise
and efforts make our customers’ operations more
reliable, efficient and environmentally sound.
We also draw technology expertise and ideas from
our partners, including GE and its worldwide technology
resources, our suppliers, customers, consultants, and
university centers.
Professionals at every level
Our people are highly qualified professionals driven
by a strong commitment to service, quality and
performance. We emphasize the individual
development of each member of our team through
training and educational programs. We encourage
vand reward employees who understand the value
of building a career, instead of merely holding a job.
Complete range of turnkey services
You can trust Prolec GE with every aspect of your
transformer solution for accountability and continuity
advantages. Your project team coordinates and
orchestrates your entire transformer package,
including:
• Rigging and Mobilizations
• Transportation
• Installation
• Storage Preparation
• Field Services
• Maintenance
• Training
• Condition Assessment
• Spare Parts
Community
Our strong values and behavior standards are part of our
organizational culture. They guide our daily activities and
influence our performance. From a ten-acre, on-site family
activity center to integrated efforts that protect our
environment, we make a concerted effort to improve the
lives of our employees, our neighbors and our planet.
Growing to meet your growing needs
Worldwide energy needs are forecasted to skyrocket as we move through the 21st century.
Prolec GE is uniquely situated to meet those needs.
Our state-of-the-art facility continues to grow with multi-million-dollar expansions and ongoing
equipment upgrades. Our strong supply-chain connections and worldwide resources provide us
with a healthy stream of raw materials, shipping resources and business partners.
So as your energy demands grow, you can continue to count on Prolec GE for the reliable solutions
that power your individual needs.
Headquarters & Service
Sales
Monterrey, N.L., Mexico
Blvd. Carlos Salinas de Gortari
Km. 9.25 Apodaca, N.L.
66600 Mexico
Tel: +52 (81) 8030-2000
+52 (81) 8030-2400
Fax: +52 (81) 8030-2500
USA & Canada
Contact your local GE sales representative
or call 1-800-437-7653 or +52 (81) 8030-2341
24/7
Contact us:
1-800-4377-653
+52 (81) 8030-2360
Mexico City
Paseo de la Reforma No. 222 - 8vo. Piso
Col. Juarez
Delegacion Cuauhtemoc, C.P. 06500
Mexico, D.F.
Tel: +52 (55) 5329-2700
+52 (81) 8030-2400
01-800-377-6532
Fax: +52 (55) 5329-2727
Middle East
General Electric International Operations Co., Inc.
Dubai, United Arab Emirates
Dubai Internet City, PO BOX 11549
Office G01, Building #18
Tel: +971 4 429 6101
Fax: +971 4 429 6133
ADDITIONAL CONTACT INFORMATION:
See your local GE sales representative or visit our website www.prolecge.com
or email sales@prolecge.com or services@prolecge.com
For information about our facilities in India: www.prolecge.in
DTTR-0914-07
Download
